Summary of Contents for Chrysler pacifica hybrid 2017

Page 1 Pacifica Hybrid 2 0 1 7 O W N E R ’ S M A N U A L...
Page 2 This manual illustrates and describes the operation of VEHICLES SOLD IN CANADA With respect to any Vehicles Sold in Canada, the name FCA features and equipment that are either standard or op- US LLC shall be deemed to be deleted and the name FCA tional on this vehicle.
Page 3 TABLE OF CONTENTS SECTION PAGE INTRODUCTION ..............3 GRAPHICAL TABLE OF CONTENTS .
Page 5 INTRODUCTION CONTENTS INTRODUCTION ......4 WARNINGS AND CAUTIONS ....6 HOW TO USE THIS MANUAL .
Page 6: Introduction 3
4 INTRODUCTION INTRODUCTION HOW TO USE THIS MANUAL Congratulations on selecting your new FCA US LLC ve- Essential Information hicle. Be assured that it represents precision workmanship, Consult the Table of Contents to determine which section distinctive styling, and high quality. contains the information you desire.
Page 7: Introduction
INTRODUCTION...
Page 8 6 INTRODUCTION WARNINGS AND CAUTIONS This Owner’s Manual contains WARNINGS against oper- ating procedures that could result in a collision or bodily injury. It also contains CAUTIONS against procedures that could result in damage to your vehicle. If you do not read this entire Owner’s Manual, you may miss important information.
Page 9 GRAPHICAL TABLE OF CONTENTS CONTENTS FRONT VIEW ......8 INSTRUMENT PANEL .....10 REAR VIEW .
Page 10: Front View
8 GRAPHICAL TABLE OF CONTENTS FRONT VIEW Front View 1 — Hood/Engine Compartment 5 — Charging Port Door 2 — Headlights 6 — Exterior Mirrors 3 — Wheels/Tires 7 — Doors 4 — Windshield 8 — Fuel Door...
Page 11: Rear View
GRAPHICAL TABLE OF CONTENTS 9 REAR VIEW Rear View 1 — Tail Lamps 2 — Rear Windshield Wiper 3 — Liftgate...
Page 12: Instrument Panel
10 GRAPHICAL TABLE OF CONTENTS INSTRUMENT PANEL Instrument Panel 1 — Air Vents 5 — Glove/Storage Compartment 2 — Multifunction Lever 6 — Ignition Start/Stop Button 3 — Instrument Cluster 7 — Steering Wheel 4 — Windshield Wiper Lever 8 — Headlight Switch...
Page 13: Interior
GRAPHICAL TABLE OF CONTENTS 11 INTERIOR Interior Features 1 — Power Window/Door Lock Switches 5 — Door handle 2 — Electronic Gear Selector 6 — Climate Control 3 — Uconnect Radio 7 — Center Console 4 — Switch Panel 8 — Seats...
Page 15: Table Of Contents
GETTING TO KNOW YOUR VEHICLE CONTENTS ▫ To Enter Remote Start Mode ....50 HIGH VOLTAGE BATTERY....17 ▫...
Page 16 14 GETTING TO KNOW YOUR VEHICLE ▫ Manual Lock ......54 HEAD RESTRAINTS ..... .82 ▫...
Page 17 GETTING TO KNOW YOUR VEHICLE 15 ▫ Illuminated Vanity Mirrors — If Equipped ..93 ▫ Courtesy/Interior Lighting ....99 ▫ Instrument Panel Dimmer Control ..100 EXTERIOR LIGHTS .
Page 18 16 GETTING TO KNOW YOUR VEHICLE ▫ Power Sun Shade — If Equipped... .126 ▫ Cargo Area Features .....134 ▫...
Page 19: High Voltage Battery
GETTING TO KNOW YOUR VEHICLE 17 HIGH VOLTAGE BATTERY High Voltage Battery Service Disconnect Your vehicle is equipped with a Lithium-ion high voltage The High Voltage Battery Service Disconnect is located battery that is used to power the electric powertrain under the access panel, in front of the second row passen- systems and the 12 volt vehicle electrical system.
Page 20 18 GETTING TO KNOW YOUR VEHICLE • In extreme temperatures, the High Voltage Battery may General Information need to be conditioned and therefore may require the The vehicle is also equipped with a Battery Management vehicle to be plugged-in. When the vehicle is not System that is designed to: plugged-in, the following message, “Plug In Vehicle for •...
Page 21 GETTING TO KNOW YOUR VEHICLE 19 Battery Conditioning Instrument Cluster Display Message Battery Conditioning Instrument Cluster Display Message • Under cold or hot temperatures, while the vehicle is plugged-in and the ignition is in the OFF position, the vehicle may wake-up to pre-condition the high voltage battery for usage.
Page 22: High Voltage Charging Operation
20 GETTING TO KNOW YOUR VEHICLE HIGH VOLTAGE CHARGING OPERATION AC Level 1 Charging (120V, 15 Amp) Your vehicle is equipped with a 120 Volt AC, SAE J1772 SAE J1772 Charging Inlet Level 1 Electric Vehicle Supply Equipment (EVSE), also Your vehicle uses an industry standard SAE J1772 charge referred to as a charging cordset.
Page 23 GETTING TO KNOW YOUR VEHICLE 21 NOTE: The charging cordset is used for AC Level 1 WARNING! charging only. Shock, fire, property damage, or personal injury may WARNING! occur if the Portable EVSE Cordset is not used prop- erly. There are no serviceable parts contained in the •...
Page 24 22 GETTING TO KNOW YOUR VEHICLE EVSE Charging Cordset The EVSE charging cordset is compliant with SAE J1772, and applicable for use with vehicles fitted with the stan- dard SAE J1772 charge inlets. The EVSE includes: • A Charge Connector •...
Page 25 GETTING TO KNOW YOUR VEHICLE 23 Charging Cordset Operation WARNING! 1. Plug the AC plug of the charging cordset into a 15 A, or Improper connection of the equipment-grounding con- 20 A, 120 VAC, 60 Hz, grounded wall receptacle. Do not ductor could result in a risk of electric shock.
Page 26 24 GETTING TO KNOW YOUR VEHICLE Cordset Indicator Lights Inserting The Charge Connector Into The Vehicle Charge Inlet 1 — AC Power Indicator Light 3 — Charge Active Indicator 4. When the vehicle commences charging, the Charge 2 — Fault Indicator Light Lights Active Indicator Lights will cycle from left to right, and then both turn off.
Page 27 GETTING TO KNOW YOUR VEHICLE 25 NOTE: The vehicle should start charging automatically. If 5. To stop the charging process, disconnect the vehicle side not, please check the following: connector first and then the charging cordset from the wall receptacle. To disengage the vehicle coupler, press •...
Page 28 26 GETTING TO KNOW YOUR VEHICLE Troubleshooting Using The Status Indicator Display Cordset does not attempt to provide charge to the vehicle, the charge connector will need to be removed from the If the vehicle is not charging properly, consult the status vehicle to clear the fault.
Page 29 GETTING TO KNOW YOUR VEHICLE 27 Portable EVSE Cordset Fault Code List Flashing Flashing Fault Fault Indication Recommended Actions Indicator Code 1, 2, 2, 2 AC Power Vehicle Current Draw Check Portable EVSE Cordset and Vehicle at a service location. is Too High 1, 1, 2, 1 AC Power...
Page 30 28 GETTING TO KNOW YOUR VEHICLE Portable EVSE Cordset Fault Code List Flashing Flashing Fault Fault Indication Recommended Actions Indicator Code 1, 1, 1, 2 Fault Portable EVSE Cordset Unplug the Portable EVSE Cordset from the vehicle charge inlet Internal Fault and retry to charge.
Page 31 GETTING TO KNOW YOUR VEHICLE 29 Portable EVSE Cordset Fault Code List Flashing Flashing Fault Fault Indication Recommended Actions Indicator Code 1, 1, 2, 1 Fault & AC EVSE Enclosure Inter- Use caution as the Portable EVSE Cordset housing may be hot. Power nal Temperature is Too It is recommended to move the Portable EVSE Cordset out of...
Page 32: Ac Level 2 Charging (240V, 30 Amp)
30 GETTING TO KNOW YOUR VEHICLE 2. The device must accept any interference received, in- NOTE: During normal operation, the charge connector or cluding interference that may cause undesired operation AC plug may feel warm. If either one feels hot during of the device.
Page 33: Charging Times
GETTING TO KNOW YOUR VEHICLE 31 NOTE: The vehicle should start charging automatically. If Charging Times not, please check the following: The following factors determine the time it takes to charge • Charging Station – Check the indications and instruc- the high voltage battery: tions at the charging station or •...
Page 34: Vehicle Charge Indicators
32 GETTING TO KNOW YOUR VEHICLE Instrument Panel State Of Charge Indicator Type of EVSE Estimated Charge Time In addition to the battery display your vehicle is equipped Level 1 (120V/15A) Approximately 14 hours with a visual state of charge indicator. The state of charge Level 2 (240V/30A) Approximately 2 hours indicator is made up of five lights that are mounted to the...
Page 35: Hybrid Electric Pages
GETTING TO KNOW YOUR VEHICLE 33 vehicle operator when the vehicle in plugged in. Each light Hybrid Electric Pages represents the battery’s current percentage of charge, as Within your Uconnect 8.4/8.4 NAV radio is the “Hybrid shown below in the table. Electric”...
Page 36 34 GETTING TO KNOW YOUR VEHICLE Power Flow The first screen within the “Hybrid Electric” App is the Power Flow screen. The Power Flow screen shows the current power readings for all of the following: • Engine - Shows the amount of power (in kW) the engine is generating to charge the high voltage battery, or providing to the drive wheels.
Page 37 GETTING TO KNOW YOUR VEHICLE 35 Driving History Charging Schedule The second screen with the “Hybrid Electric” App is the The third screen within the “Hybrid Electric” App is the Driving History screen. The Driving History screen shows Charging Schedule screen. From this screen you can set the miles driven in both Full Electric and Hybrid modes for when you want you vehicle to charge.
Page 38: Keys
36 GETTING TO KNOW YOUR VEHICLE vehicle will begin charging immediately, temporarily ig- noring the charge schedule, if plugged in within an hour of turning the vehicle off. To fully deactivate the charge schedule, refer to the charging app. The charging schedule can also be overridden if the vehicle is plugged in, unplugged, and then plugged in a second time.
Page 39 GETTING TO KNOW YOUR VEHICLE 37 NOTE: The emergency key allows for entry into the vehicle should the battery in the vehicle or the key fob go dead. The emergency key is also for locking/unlocking the glove compartment. You can keep the emergency key with you when valet parking.
Page 40 38 GETTING TO KNOW YOUR VEHICLE Five Button Key Fob Six Button Key Fob...
Page 41 GETTING TO KNOW YOUR VEHICLE 39 1st Push Of Key Fob Unlocks Push and release the unlock button on the key fob once to unlock the driver front door and sliding door or twice within five seconds to unlock all doors and liftgate. The hazard lights will flash to acknowledge the unlock signal.
Page 42 40 GETTING TO KNOW YOUR VEHICLE 2nd Push Of Key Fob Unlocks NOTE: If the vehicle is equipped with Passive Entry, refer to “Keyless Enter-N-Go — Passive Entry” in “Getting To Push and release the unlock button on the key fob twice Know Your Vehicle”...
Page 43 GETTING TO KNOW YOUR VEHICLE 41 To remove the emergency key, press the mechanical button Key Fob Battery Replacement on the side of the key fob with your thumb and pull the The recommended replacement battery is one CR2032 emergency key out with your other hand while pushing battery.
Page 44 42 GETTING TO KNOW YOUR VEHICLE Emergency Key Removal Separating The Key Fob Case 2. Insert a coin, a flat blade screw driver, or the tip of your 3. Remove the battery by sliding the battery rearward in its emergency key into the now exposed slot and carefully pocket until the battery lifts up.
Page 45 GETTING TO KNOW YOUR VEHICLE 43 Programming Additional Key Fob Duplication of key fobs may be performed at an authorized dealer. This procedure consists of programming a blank If you do not have a programmed key fob, contact your key fob to the vehicle electronics. A blank key fob is one authorized dealer for details.
Page 46 44 GETTING TO KNOW YOUR VEHICLE This feature also has additional features that are always KeySense Unique Splash Screen enabled when the specific key is in use that cannot be set At start-up the KeySense splash screen should inform the by the vehicle owner.
Page 47: Ignition Switch
GETTING TO KNOW YOUR VEHICLE 45 General Information NOTE: This vehicle is equipped with an automatic shut- down feature. If the vehicle is left in “READY” state The following regulatory statement applies to all Radio (vehicle running) with shifter in “PARK”, for one hour Frequency (RF) devices equipped in this vehicle: after the driver exits, it will automatically turn off the This device complies with Part 15 of the FCC Rules and...
Page 48 46 GETTING TO KNOW YOUR VEHICLE NOTE: The ignition can be placed in the following positions: • Pushing ignition Start/Stop button could just activate the Electric Propulsion System ( Ready will show in • The vehicle is stopped. cluster whenever vehicle is operating in EV (Electric •...
Page 49 GETTING TO KNOW YOUR VEHICLE 47 Reason Vehicle Will Be On • Hybrid battery SOC maintenance in charge sustaining operation • Propulsion power augmentation based on accelerator pedal request (which will cause the engine to come on periodically afterward to maintain the emissions sys- tem) •...
Page 50: Remote Starting System - If Equipped
48 GETTING TO KNOW YOUR VEHICLE shall power down. For further information, refer to Start- WARNING! (Continued) ing Procedures in Starting And Operating for further • Do not leave the key fob in or near the vehicle, or in information, a location accessible to children, and do not leave the ignition of a vehicle equipped with Keyless Enter- REMOTE STARTING SYSTEM —...
Page 51: Remote Start Cancel Message - If Equipped
GETTING TO KNOW YOUR VEHICLE 49 Remote Start Cancel Message — If Equipped How To Use Remote Start The following messages will display in the instrument All of the following conditions must be met before the cluster if the vehicle fails to remote start or exits remote vehicle will remote start: start prematurely: •...
Page 52: To Enter Remote Start Mode
50 GETTING TO KNOW YOUR VEHICLE • For security, power window operation is disabled when WARNING! the vehicle is in the Remote Start mode. • Do not start or run an engine in a closed garage or To Exit Remote Start Mode Without Driving The confined area.
Page 53: Remote Start Comfort Systems - If Equipped
GETTING TO KNOW YOUR VEHICLE 51 Remote Start Comfort Systems — If Equipped 2. This device must accept any interference received, in- cluding interference that may cause undesired opera- When Remote Start is activated, the Climate Control, tion. vented seats (if equipped) are also activated in tempera- tures above 80°...
Page 54: Vehicle Security Alarm - If Equipped
52 GETTING TO KNOW YOUR VEHICLE indicates that someone used an invalid key fob to start the both audible and visible signals. If something triggers the engine. Either of these conditions will result in the engine alarm, the vehicle security alarm will provide the following being shut off after two seconds.
Page 55: To Disarm The System
GETTING TO KNOW YOUR VEHICLE 53 • Cycle the vehicle ignition system out of the OFF posi- 2. Perform one of the following methods to lock the vehicle: tion. • Push lock on the interior power door lock switch with •...
Page 56: Doors
54 GETTING TO KNOW YOUR VEHICLE the vehicle or not. If you remain in the vehicle and open a door, the alarm will sound. If this occurs, disarm the vehicle security alarm. If the vehicle security alarm is armed and the battery becomes disconnected, the vehicle security alarm will remain armed when the battery is reconnected;...
Page 57 GETTING TO KNOW YOUR VEHICLE 55 Manual Door Lock Rocker Switch Manual Rear Door Lock location 1 — Door Handle 2 — Manual Door Lock If the door lock button is locked (no ribbing is visible) when you shut the door, the door will lock. Therefore, make sure the key fob is not inside the vehicle before closing the door.
Page 58: Central Lock/Unlock - If Equipped
56 GETTING TO KNOW YOUR VEHICLE Central Lock/Unlock — If Equipped WARNING! A power door lock switch is on each front door trim panel. • For personal security and safety in the event of a Use this switch to lock or unlock the doors. collision, lock the vehicle doors before you drive as NOTE: The key fob may not be able to be detected by the well as when you park and leave the vehicle.
Page 59: Unlock Doors Automatically On Exit - If Equipped
GETTING TO KNOW YOUR VEHICLE 57 If you push the power door lock switch while the ignition Enter-N-Go. This feature allows you to lock and unlock the is in the ACC or ON/RUN position, and any front door is vehicle’s door(s) without having to push the key fob lock open, the power locks will not operate.
Page 60 58 GETTING TO KNOW YOUR VEHICLE To Unlock From The Driver’s Side: To Unlock From The Passenger Side: With a valid key fob within 5 ft (1.5 m) of the driver’s door With a valid key fob within 5 ft (1.5 m) of the passenger handle, grab the driver’s front door handle to unlock the door handle, grab the front passenger door handle to drivers side doors (driver/sliding door) automatically.
Page 61 GETTING TO KNOW YOUR VEHICLE 59 • A lock request is made by the door panel switch while To Enter The Liftgate the door is open. With a valid key fob within 5 ft (1.5 m) of the liftgate, cycle When any of these situations occur, after all open doors are the handle to open the liftgate and pull the liftgate open shut, the FOBIK-Safe search will be executed.
Page 62 60 GETTING TO KNOW YOUR VEHICLE Push The Door Handle Button To Lock Do NOT Grab The Door Handle When Locking Do NOT grab the door handle, when pushing the door NOTE: handle button. This could unlock the door(s). • After pushing the door handle button, you must wait two seconds before you can lock or unlock the doors, using either Passive Entry door handle.
Page 63: Manual Sliding Side Door
GETTING TO KNOW YOUR VEHICLE 61 Manual Sliding Side Door The sliding door may be opened from the inside or the outside. Pull outward on the exterior handle to open the sliding door. The sliding door inside handle functions by rocking forward and back.
Page 64: Power Sliding Side Door - If Equipped
62 GETTING TO KNOW YOUR VEHICLE • There is a hold-open latch that is activated when the The key fob and the overhead console button will operate sliding door is fully opened. This latch will keep your the door when the door is locked. All other ways require sliding door open on any incline.
Page 65 GETTING TO KNOW YOUR VEHICLE 63 The power OFF LED, in the overhead console, will be lit when the handles are manual. When the LED is lit, pushing the power sliding door power OFF button will return the handles to power operation. NOTE: Tones are sounded and the turn signals are flashed with sliding door movements.
Page 66: Hands-Free Sliding Doors - If Equipped
64 GETTING TO KNOW YOUR VEHICLE Hands-Free Sliding Doors – If Equipped WARNING! Personal injury or cargo damage may occur if caught in the path of the sliding door. Make sure the door path is clear before closing the door. WARNING! Before driving off, check the instrument cluster for a sliding door or door open message or warning indica-...
Page 67: Safe Lock - If Equipped
GETTING TO KNOW YOUR VEHICLE 65 NOTE: Safe Lock — If Equipped • To open the Hands-Free Sliding Doors requires a valid To provide a safer environment for small children riding in Passive Entry key fob within 5 ft (1.5 m) of the door the rear seats, the second row sliding door switches may be handle.
Page 68: Child Locks
66 GETTING TO KNOW YOUR VEHICLE To enable power to the handles and buttons, when the Child Locks overhead console Power OFF LED is lit, push the Sliding To provide a safer environment for small children riding in Doors Power OFF button, located in the front overhead the rear seats, the sliding doors are equipped with a Child console.
Page 69: Seats
GETTING TO KNOW YOUR VEHICLE 67 NOTE: To Disengage The Child Protection Door Lock • After engaging (or disengaging) the Child Protection 1. Open the sliding side door. Door Lock, always test the inside door handle with the 2. Slide the Child Protection Door Lock control outward sliding door closed to make certain the Child Protection (away from the vehicle) to disengage the Child Protec- Door Lock is in the desired position.
Page 70: Manual Adjustment (Front Seats)
68 GETTING TO KNOW YOUR VEHICLE Manual Front Adjuster WARNING! (Continued) Both front seats are adjustable forward or rearward. The these areas are more likely to be seriously injured or manual seat adjustment handle is located under the seat killed. cushion at the front edge of each seat.
Page 71 GETTING TO KNOW YOUR VEHICLE 69 WARNING! • Adjusting a seat while driving may be dangerous. Moving a seat while driving could result in loss of control which could cause a collision and serious injury or death. • Seats should be adjusted before fastening the seat belts and while the vehicle is parked.
Page 72: Manual Adjustment (Rear Seats)
70 GETTING TO KNOW YOUR VEHICLE Manual Adjustment (Rear Seats) WARNING! • Adjusting a seat while the vehicle is moving is dangerous. The sudden movement of the seat could cause you to lose control. The seat belt might not be adjusted properly and you could be injured.
Page 73 GETTING TO KNOW YOUR VEHICLE 71 WARNING! (Continued) WARNING! • Seats should be adjusted before fastening the seat Do not ride with the seatback reclined so that the belts and while the vehicle is parked. Serious injury shoulder belt is no longer resting against your chest. In or death could result from a poorly adjusted seat belt.
Page 74 72 GETTING TO KNOW YOUR VEHICLE NOTE: The seatback may lock into the fold flat position. Use the recline lever to unlock the seatback. Easy Entry Slide Second Row Seating The second row seats can be tilted and slid forward for easy entry into the third row.
Page 75 GETTING TO KNOW YOUR VEHICLE 73 Second Row Removable Seat The Easy Entry Slide second row seating does not stow in the floor, but they are removable for added cargo space. Removing Seat 1. Adjust seat to the full rearward position. 2.
Page 76 74 GETTING TO KNOW YOUR VEHICLE 3. The release strap is located on the front of the seat, near 4. To remove the seat, pull the release strap to release the the floor. rear latches. 5. Tilt the back of the seat to the upward position. Seat Release Strap Tilt Seat Forward...
Page 77 GETTING TO KNOW YOUR VEHICLE 75 6. The seat assembly can now be removed from the vehicle. Grab the front seatback edge located near the head restraint and the grab bar on the rear side of the seat cushion for easy removal. In Floor Seat Detents 2.
Page 78 76 GETTING TO KNOW YOUR VEHICLE Manually Folding Third Row Seats — If Equipped 3. Pull release strap marked “2” and tumble the seat rearward into the storage bin. 1. Lower the center head restraint down to the seatback by pushing the button on the guide and pushing the head restraint down.
Page 79 GETTING TO KNOW YOUR VEHICLE 77 To Unfold Third Row Seats 1. Pull up on the assist strap to lift the seat out of the storage bin and push the seat forward until the anchors latch. Stowed Third Row Seat Assist Straps...
Page 80: Power Adjustment (Front Seats) - If Equipped
78 GETTING TO KNOW YOUR VEHICLE 2. Pulling strap “2” releases the seatback to return to its WARNING! full upright position. • In a collision, you or others in your vehicle could be injured if seats are not properly latched to their floor attachments.
Page 81 GETTING TO KNOW YOUR VEHICLE 79 WARNING! (Continued) • Seats should be adjusted before fastening the seat belts and while the vehicle is parked. Serious injury or death could result from a poorly adjusted seat belt. • Do not ride with the seatback reclined so that the shoulder belt is no longer resting against your chest.
Page 82 80 GETTING TO KNOW YOUR VEHICLE Adjusting The Seat Up Or Down WARNING! (Continued) The height of the seats can be adjusted up or down. Pull • Seats should be adjusted before fastening the seat upward or push downward on the rear of seat switch, the belts and while the vehicle is parked.
Page 83: Front Heated Seats - If Equipped
GETTING TO KNOW YOUR VEHICLE 81 Front Heated Seats — If Equipped NOTE: • Once a heat setting is selected, heat will be felt within The front heated seats control buttons are located within two to five minutes. the climate or controls screen of the touchscreen. •...
Page 84: Ventilated Seats - If Equipped
82 GETTING TO KNOW YOUR VEHICLE NOTE: The vehicle must be running for the ventilated WARNING! (Continued) seats to operate. • Do not place anything on the seat or seatback that Vehicles Equipped With Remote Start insulates against heat, such as a blanket or cushion. This may cause the seat heater to overheat.
Page 85: Head Restraints - Front Seats
GETTING TO KNOW YOUR VEHICLE 83 WARNING! • All occupants, including the driver, should not oper- ate a vehicle or sit in a vehicle’s seat until the head restraints are placed in their proper positions in order to minimize the risk of neck injury in the event of a crash.
Page 86 84 GETTING TO KNOW YOUR VEHICLE rearward, pull forward on the head restraint to furthest forward position and head restraint will reset to furthest rearward position. Forward Adjustment Normal Position...
Page 87: Head Restraints - Second Row
GETTING TO KNOW YOUR VEHICLE 85 WARNING! • A loose head restraint thrown forward in a collision or hard stop could cause serious injury or death to occupants of the vehicle. Always securely stow re- moved head restraints in a location outside the occupant compartment.
Page 88: Head Restraints - Third Row
86 GETTING TO KNOW YOUR VEHICLE WARNING! • A loose head restraint thrown forward in a collision or hard stop could cause serious injury or death to occupants of the vehicle. Always securely stow re- moved head restraints in a location outside the occupant compartment.
Page 89 GETTING TO KNOW YOUR VEHICLE 87 The head restraint in the center position can be raised and lowered for tether routing or height adjustment. Refer to “Occupant Restraint Systems” in “Safety” for further infor- mation. Release Strap NOTE: • The head restraints must be raised manually when occupying the third row.
Page 90: Steering Wheel
88 GETTING TO KNOW YOUR VEHICLE STEERING WHEEL lengthen or shorten the steering column, pull the steering wheel outward or push it inward as desired. To lock the Tilt/Telescoping Steering Column steering column in position, push the lever upward until This feature allows you to tilt the steering column upward fully engaged.
Page 91: Mirrors
GETTING TO KNOW YOUR VEHICLE 89 The heated steering wheel control button is located within WARNING! the Uconnect system. You can gain access to the control • Persons who are unable to feel pain to the skin button through the climate screen or the controls screen. because of advanced age, chronic illness, diabetes, •...
Page 92: Automatic Dimming Mirror - If Equipped
90 GETTING TO KNOW YOUR VEHICLE Headlight glare can be reduced by moving the small NOTE: This feature is disabled when the vehicle is in control under the mirror to the night position (toward the REVERSE. rear of the vehicle). The mirror should be adjusted while set in the day position (toward the windshield).
Page 93: Outside Mirrors
GETTING TO KNOW YOUR VEHICLE 91 Outside Mirrors Driver’s Outside Automatic Dimming Mirror — If Equipped To receive maximum benefit, adjust the outside mirror(s) to center on the adjacent lane of traffic with a slight overlap of The driver’s outside mirror will automatically adjust for the view obtained on the inside mirror.
Page 94: Power Mirrors - If Equipped
92 GETTING TO KNOW YOUR VEHICLE Power Mirrors — If Equipped Power Folding Mirrors — If Equipped The power mirror controls are located on the driver-side The switch for the power folding mirrors is located be- door trim panel. tween the power mirror switches L (left) and R (right). Push the switch once and the mirrors will fold in, pushing the switch a second time will return the mirrors to the normal driving position.
Page 95: Heated Mirrors - If Equipped
GETTING TO KNOW YOUR VEHICLE 93 Resetting The Power Folding Outside Mirrors Illuminated Vanity Mirrors — If Equipped You may need to reset the power folding mirrors if the An illuminated vanity mirror is located on the sun visor. To following occurs: use the mirror, rotate the sun visor down and swing the mirror cover upward.
Page 96: Exterior Lights
94 GETTING TO KNOW YOUR VEHICLE EXTERIOR LIGHTS Rotate the headlight switch clockwise to the second detent for parking light and instrument panel light operation. Headlight Switch Rotate the headlight switch to the third detent for head- The headlight switch is located on the left side of the light, parking light and instrument panel operation.
Page 97: Flash-To-Pass
GETTING TO KNOW YOUR VEHICLE 95 automatically switches from high beams to low beams To Deactivate until the approaching vehicle is out of view. Perform either of the following steps to deactivate the Automatic High Beam system. NOTE: Broken, muddy, or obstructed headlights and tail- lights of vehicles in the field of view will cause headlights 1.
Page 98: Automatic Headlights - If Equipped
96 GETTING TO KNOW YOUR VEHICLE Automatic Headlights — If Equipped Headlight Delay — If Equipped This system automatically turns your headlights on or off This feature provides the safety of headlight illumination based on ambient light levels. To turn the system on, turn for up to 90 seconds after exiting your vehicle.
Page 99: Front Fog Lights - If Equipped
GETTING TO KNOW YOUR VEHICLE 97 Front Fog Lights — If Equipped Multifunction Lever To activate the front fog lights, turn on the parking lights or The multifunction lever is located on the left side of the the low beam headlights and push in the headlight switch steering column.
Page 100: Turn Signals
98 GETTING TO KNOW YOUR VEHICLE Turn Signals Lane Change Assist — If Equipped Move the multifunction lever up or down and the arrows Tap the lever up or down once, without moving beyond on each side of the instrument cluster flash to show proper the detent, and the turn signal (right or left) will flash three operation of the front and rear turn signal lights.
Page 101: Interior Lights
GETTING TO KNOW YOUR VEHICLE 99 INTERIOR LIGHTS To operate the courtesy lights, push either the driver’s or passenger light switch. Courtesy/Interior Lighting NOTE: The courtesy light switches are used to turn the courtesy • Before exiting the vehicle, make sure that the interior lights on/off.
Page 102: Instrument Panel Dimmer Control
100 GETTING TO KNOW YOUR VEHICLE Rear Courtesy/Reading Lights — If Equipped Instrument Panel Dimmer Control Located above the rear passengers are courtesy/reading The instrument panel dimmer control is part of the head- lights. The lights turn on when a front door, a sliding door light switch, and is located on the driver’s side of the or the liftgate is opened.
Page 103: Windshield Wiper And Washers
GETTING TO KNOW YOUR VEHICLE 101 Ambient Light Control — If Equipped Parade Mode (Daytime Brightness Feature) Rotate the ambient dimmer control upward or downward Rotate the instrument panel dimmer control upward to the to increase or decrease the brightness of the ambient light first detent.
Page 104: Intermittent Wiper System
102 GETTING TO KNOW YOUR VEHICLE NOTE: Always remove any buildup of snow that prevents Windshield Wiper Operation the windshield wiper blades from returning to the off Rotate the end of the lever upward, to the first detent past position. If the windshield wiper switch is turned off and the intermittent settings for low-speed wiper operation.
Page 105: Rain Sensing Wipers - If Equipped
GETTING TO KNOW YOUR VEHICLE 103 • The Rain Sensing feature can be turned on and off Rain Sensing Wipers — If Equipped through the Uconnect System. Refer to “Uconnect Set- This feature senses moisture on the windshield and auto- tings”...
Page 106: Rear Wiper And Washer
104 GETTING TO KNOW YOUR VEHICLE • Remote Start Mode Inhibit — On vehicles equipped with Rear Windshield Washer Operation Remote Starting system, Rain Sensing wipers are not op- Pushing the windshield wiper lever forward activates the erational when the vehicle is in the remote start mode. Once rear window washer.
Page 107 GETTING TO KNOW YOUR VEHICLE 105 8.4/8.4 NAV Temperature Controls...
Page 108 106 GETTING TO KNOW YOUR VEHICLE Control Descriptions Icon Description MAX A/C Button Press and release to change the current setting, the indicator illuminates when MAX A/C is on. Performing this function again will cause the MAX A/C operation to switch into manual mode and the MAX A/C indicator will turn off.
Page 109 GETTING TO KNOW YOUR VEHICLE 107 Icon Description AUTO Button Automatically controls the interior cabin temperature by adjusting airflow distribution and amount. Toggling this function will cause the system to switch between manual mode and auto- matic modes. Refer to “Automatic Operation” for more information. Front Defrost Button Press and release to change the current airflow setting to Defrost mode.
Page 110 108 GETTING TO KNOW YOUR VEHICLE Icon Description Driver and Passenger Temperature Up and Down Buttons Provides the driver and passenger with independent temperature control. Push the red button on the faceplate or touchscreen or press and slide the temperature bar towards the red arrow button on the touchscreen for warmer temperature settings.
Page 111 GETTING TO KNOW YOUR VEHICLE 109 Icon Description Modes Control Modes Control Push the button in the center of the knob to change the airflow distribution mode. The airflow distribution mode can be adjusted so air comes from the instrument panel outlets, floor outlets, defrost outlets and demist outlets.
Page 112 110 GETTING TO KNOW YOUR VEHICLE Icon Description Mix Mode Mix Mode Air is directed through the floor, defrost, and side window demister outlets. This setting works best in cold or snowy conditions that require extra heat to the windshield. This setting is good for maintaining comfort while reducing moisture on the windshield.
Page 113 GETTING TO KNOW YOUR VEHICLE 111 NOTE: Recirculation • If fog or mist appears on the windshield or side glass, When outside air contains smoke, odors, or high humidity, select Defrost mode, and increase blower speed if or if rapid cooling is desired, you may wish to recirculate needed.
Page 114: Automatic Temperature Control (Atc) - If Equipped
112 GETTING TO KNOW YOUR VEHICLE Automatic Temperature Control (ATC) — If To provide you with maximum comfort in the automatic mode, during cold start-ups, the blower fan will remain on Equipped low until the engine warms up. The fan will engage Automatic Temperature Control (ATC) immediately if the Defrost mode is selected, or by changing Automatic Operation...
Page 115 GETTING TO KNOW YOUR VEHICLE 113 To change the rear system settings: • Press the REAR CLIMATE button on the touchscreen to change control to rear control mode, Rear display (below) will appear. Control functions now operate rear system. • To return to the Front screen on the Uconnect 8.4 radio, press the Front Climate button on the touchscreen.
Page 116 114 GETTING TO KNOW YOUR VEHICLE Icon Description Front Climate Button Press and release this button to change the display on the Uconnect 8.4 back to the Front Cli- mate Controls. Rear Passenger Temperature Up and Down Buttons Provides the rear passengers with independent temperature control. Push the up arrow button on the touchscreen to increase the temperature.
Page 117 GETTING TO KNOW YOUR VEHICLE 115 Icon Description Rear Passenger Climate Control OFF Button Press and release this button to turn the Rear Climate Controls off. Panel Mode Panel Mode Press this button on the touchscreen to change the air distribution mode to Panel Mode. In Panel Mode, air comes from the outlets in the instrument panel.
Page 118 116 GETTING TO KNOW YOUR VEHICLE Rear Automatic Temperature Control (ATC) — If Equipped The rear ATC system has floor air outlets underneath the passengers’ seats, and overhead outlets at each outboard rear seating position. The system provides heated air through the floor outlets or cool, dehumidified air through the headliner outlets.
Page 119 GETTING TO KNOW YOUR VEHICLE 117 When the system is set up for your comfort level, it is not NOTE: necessary to change the settings. You will experience the • It is not necessary to move the temperature settings. The greatest efficiency by simply allowing the system to func- system automatically adjusts the temperature, mode and tion automatically.
Page 120 118 GETTING TO KNOW YOUR VEHICLE Icon Description Rear Temperature Control • Rear Passenger Temperature Up Button To change the temperature in the rear of the vehicle, push temperature control up button to raise the temperature. The rear temperature settings are displayed in control head.
Page 121: Operating Tips
GETTING TO KNOW YOUR VEHICLE 119 Operating Tips blower setting on high. This will ensure adequate system lubrication to minimize the possibility of compressor dam- NOTE: Refer to the chart at the end of this section for age when the system is started again. suggested control settings for various weather conditions.
Page 122 120 GETTING TO KNOW YOUR VEHICLE Operating Tips Chart...
Page 123: Windows
GETTING TO KNOW YOUR VEHICLE 121 WINDOWS Power Windows You can control either the front or rear windows using controls located on the driver’s door trim panel. The driver may lock out the rear power windows by pushing the bar control just below the power window controls.
Page 124 122 GETTING TO KNOW YOUR VEHICLE Auto Up Feature With Anti-Pinch Protection — If Equipped The front driver and front passenger controls may be equipped with an Auto Up feature. Lift the window control fully upward to the second detent, release, and the window will go up automatically.
Page 125 GETTING TO KNOW YOUR VEHICLE 123 The controls will operate only when the ignition switch is WARNING! in the ON/RUN or ACC position and during power accessory delay. There is no anti-pinch protection when the window is almost closed. To avoid personal injury be sure to clear NOTE: The controls will not operate if the driver has your arms, hands, fingers and all objects from the activated the Power Window Lockout.
Page 126: Tri-Pane Panoramic Sunroof - If Equipped
124 GETTING TO KNOW YOUR VEHICLE Wind Buffeting Wind buffeting can be described as the perception of pressure on the ears or a helicopter-type sound in the ears. Your vehicle may exhibit wind buffeting with the windows down, or the sunroof (if equipped) in certain open or partially open positions.
Page 127: Opening Sunroof
GETTING TO KNOW YOUR VEHICLE 125 NOTE: If the sunshade is in the closed position when the WARNING! (Continued) open switch is pushed, the sunshade will automatically ON/RUN mode. Occupants, particularly unattended cycle to the halfway open position prior to the sunroof children, can become entrapped by the power sun- opening.
Page 128: Closing Sunroof
126 GETTING TO KNOW YOUR VEHICLE Closing Sunroof Power Sun Shade — If Equipped Express Mode Opening Power Shade — Express Mode Push the switch forward and release it within one second Push the shade switch rearward and release it within one and the sunroof will close automatically from any position.
Page 129: Pinch Protect Feature
GETTING TO KNOW YOUR VEHICLE 127 and stop automatically. This is called “Express Close”. Sunroof Maintenance During Express Close operation, any other actuation of the Use only a non-abrasive cleaner and a soft cloth to clean the switch will stop the shade. glass panel.
Page 130 128 GETTING TO KNOW YOUR VEHICLE Hood Release Lever Safety Latch Location 2. Move to the outside of the front of the vehicle. 4. Remove the support rod from the locking tab and insert it into the seat located on the underside of the hood. 3.
Page 131: Closing
GETTING TO KNOW YOUR VEHICLE 129 Closing LIFTGATE 1. Hold up the hood with one hand and with the other Opening hand remove the support rod from its seat and reinsert To Unlock/Enter The Liftgate it into the locking tab. The liftgate may be released in several ways: 2.
Page 132: Closing
130 GETTING TO KNOW YOUR VEHICLE The key fob and the overhead console button will release Closing the liftgate when the liftgate is locked. The outside handle To Close The Liftgate requires the liftgate to be unlocked. If the vehicle is Grasp the liftgate closing handle and initiate lowering the equipped with Passive Entry, pulling the outside handle liftgate.
Page 133: Power Liftgate - If Equipped
GETTING TO KNOW YOUR VEHICLE 131 Power Liftgate — If Equipped The power liftgate may be opened or closed in several ways: • Overhead console liftgate button • Key fob • Outside handle (opens liftgate only) • Button just inside the liftgate on the upper left trim (when liftgate is open) •...
Page 134 132 GETTING TO KNOW YOUR VEHICLE (if equipped) will unlock and open the liftgate, with a valid To Close The Liftgate Passive Entry key fob within 5 ft (1.5 m) of the liftgate The liftgate can also be closed using the Rear Interior handle.
Page 135: Hands-Free Liftgate - If Equipped
GETTING TO KNOW YOUR VEHICLE 133 Hands-Free Liftgate — If Equipped NOTE: To open the Hands-Free Liftgate requires a valid Passive Entry key fob within 5 ft (1.5 m) of the door handle. If a valid Passive Entry key fob is not within 5 ft (1.5 m), the liftgate will not respond to any kicks.
Page 136: Cargo Area Features
134 GETTING TO KNOW YOUR VEHICLE • If the power liftgate encounters multiple obstructions Gas props support the liftgate in the open position. How- within the same cycle, the system will automatically ever, because the gas pressure drops with temperature, it stop.
Page 137: Internal Equipment
GETTING TO KNOW YOUR VEHICLE 135 INTERNAL EQUIPMENT Storage Glove Compartment The glove compartment is located on the passenger side of the instrument panel. To open the glove compartment, pull the release handle. Rear Cargo Area NOTE: With all rear seats stowed or removed, four by eight foot sheets of building material will fit on the vehicle floor with the liftgate closed.
Page 138 136 GETTING TO KNOW YOUR VEHICLE Front Door Storage Instrument Panel Drawer Both interior front door panels have multiple pockets for There is a storage drawer located in the lower center of the storage. instrument panel. It can be released by pushing the access button above it.
Page 139 GETTING TO KNOW YOUR VEHICLE 137 Drawer Released Drawer Fully Open CAUTION! The storage drawer must be closed while driving. If left open during a collision, additional damage may occur to property or the drawer mechanism.
Page 140 138 GETTING TO KNOW YOUR VEHICLE Front Seatback Storage — If Equipped Umbrella Holder The front seatbacks have a storage pocket on some models. An umbrella holder has been conveniently molded into the front door entry scuff moldings. Front Seatback Storage Umbrella Holder...
Page 141: Illuminated Vanity Mirrors - If Equipped
GETTING TO KNOW YOUR VEHICLE 139 Coat Hooks — If Equipped Illuminated Vanity Mirrors — If Equipped Coat hooks are located along the headliner for the second An illuminated vanity mirror is located on the sun visor. To and third row seating positions. The coat hook load limit is use the mirror, rotate the sun visor down and swing the 10 lbs (4.5 kg).
Page 142: Power Outlets
140 GETTING TO KNOW YOUR VEHICLE Power Outlets CAUTION! Your vehicle is equipped with 12 Volt (15 Amp) power Power outlets are designed for accessory plugs only. outlets, and 5 Volt (2.5 Amp) USB power outlets, that can Do not insert any other object in the power outlets as be used to power cellular phones, small electronics and this will damage the outlet and blow the fuse.
Page 143 GETTING TO KNOW YOUR VEHICLE 141 Front USB Charge Only Port Rear Power Outlet In addition to the front power outlets, there is also a power NOTE: The USB outlet in the bottom of the instrument outlet located in the rear cargo area. panel can be switched from “ignition”...
Page 144 142 GETTING TO KNOW YOUR VEHICLE WARNING! (Continued) • Close the lid when not in use and while driving the vehicle. • If this outlet is mishandled, it may cause an electric shock and failure. CAUTION! • Many accessories that can be plugged in draw power from the vehicle’s battery, even when not in use (i.e., cellular phones, etc.).
Page 145: Power Inverter - If Equipped
GETTING TO KNOW YOUR VEHICLE 143 Power Inverter — If Equipped The Power Inverter is designed with built-in overload protection. If the power rating of 150 Watts is exceeded, the There is a 115 Volt, 150 Watt Power Inverter outlet located Power Inverter will automatically shut down.
Page 146: Smoker's Package Kit - If Equipped
144 GETTING TO KNOW YOUR VEHICLE After a few seconds, the lighter automatically returns to its The left rear trim panel cupholder is designed to accom- initial position and is ready to be used. modate a second ash receiver, if desired. Overhead Storage With Sunglass Storage WARNING! At the front of the overhead console, a compartment is...
Page 147: Roof Luggage Rack - If Equipped
GETTING TO KNOW YOUR VEHICLE 145 The door will slowly rotate to the full open position. Roof Rack Full Open Position 1 — Side Rail ROOF LUGGAGE RACK — IF EQUIPPED 2 — Crossbar The crossbars and side rails are designed to carry weight The roof rack does not increase the total load carrying on vehicles equipped with a luggage rack.
Page 148: Deploying The Crossbars
146 GETTING TO KNOW YOUR VEHICLE Deploying The Crossbars 1. To deploy the crossbars, completely loosen the thumb screws at both ends of the crossbar and lift the crossbar from its stowed position in the side rail. Repeat with crossbar on the opposite side. Removing Crossbars CAUTION! Use care when removing and handling the crossbars to...
Page 149 GETTING TO KNOW YOUR VEHICLE 147 Bending Pivot Positioning Crossbars 3. Position the crossbars across the roof making sure the 4. Once the crossbar is in place, tighten both thumb screws letters on the crossbars align with the matching letters completely.
Page 150: Stowing The Crossbars
148 GETTING TO KNOW YOUR VEHICLE Stowing The Crossbars 1. Starting with one crossbar, completely loosen the thumb screws at both ends. Lift the crossbar away from the matching letter to remove it from the deployed position. Repeat with the other crossbar. CAUTION! Use care when removing and handling the crossbars to prevent damage to the vehicle.
Page 151 GETTING TO KNOW YOUR VEHICLE 149 Crossbar Pivot Stowing Crossbars 3. Then, position the crossbar along the correct side rail. 4. The crossbar will nest fully within the side rail. Make sure the letters on the crossbar align with the matching letters on the side rail.
Page 152 150 GETTING TO KNOW YOUR VEHICLE Crossbar To Side Rail Tightening Crossbar 5. Once the driver’s side crossbar is in place, tighten the 6. Repeat the procedure to stow the second crossbar on the thumb screws completely. opposite side.
Page 153 GETTING TO KNOW YOUR VEHICLE 151 WARNING! Cargo must be securely tied down before driving your vehicle. Improperly secured loads can fly off the ve- hicle, particularly at high speeds, resulting in personal injury or property damage. Follow the roof rack cau- tions when carrying cargo on your roof rack.
Page 154 152 GETTING TO KNOW YOUR VEHICLE CAUTION! (Continued) • Load should always be secured to cross bars first, with tie down loops used as additional securing points if needed. Tie loops are intended as supple- mentary tie down points only. Do not use ratcheting mechanisms with the tie loops.
Page 155 GETTING TO KNOW YOUR INSTRUMENT PANEL CONTENTS INSTRUMENT CLUSTER ....154 WARNING/INDICATOR LIGHTS AND MESSAGES ......168 ▫...
Page 156: Instrument Cluster
154 GETTING TO KNOW YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER Instrument Cluster...
Page 157: Instrument Cluster Descriptions
GETTING TO KNOW YOUR INSTRUMENT PANEL 155 • Electric Range: showing values for electric range, Instrument Cluster Descriptions along with a teal gauge shows battery % (state of 1. % Power Gauge charge 0-100%). • Indicates vehicle power. The gauge is a summation of •...
Page 158: Instrument Cluster Display
156 GETTING TO KNOW YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER DISPLAY Instrument Cluster Display Location and Controls Your vehicle is equipped with an Instrument Cluster The Instrument Cluster Display is located in the center of Display, which offers useful information to the driver. With the instrument cluster.
Page 159 GETTING TO KNOW YOUR INSTRUMENT PANEL 157 • Down Arrow Button The system allows the driver to select information by pushing the following buttons mounted on the steering Push and release the down arrow button to scroll wheel: downward through the Main Menu items. •...
Page 160: Oil Life Reset
158 GETTING TO KNOW YOUR INSTRUMENT PANEL Oil Life Reset Keyless Enter-N-Go — Ignition • Your vehicle is equipped with an engine oil change indicator system. The “Oil Change Due” message will display for approximately five seconds after a single chime has sounded, to indicate the next scheduled oil change interval.
Page 161: Fuel And Oil Maintenance Mode
GETTING TO KNOW YOUR INSTRUMENT PANEL 159 4. Hold the OK button to reset the “Oil Life” to 100%. The vehicle will automatically exit the Fuel and Oil Main- tenance Mode when conditions have been satisfied. If the 5. Push the up arrow button to exit the instrument cluster vehicle enters Fuel and Oil Maintenance Mode, due to fuel display menu screen.
Page 162: Instrument Cluster Display Menu Items
160 GETTING TO KNOW YOUR INSTRUMENT PANEL With KeySense in use there will be multiple associated messages shown in the following table: Setting Instrument Cluster Display Message None – With vehicle ignition “KeySense in use. Max vehicle speed set to xx MPH/or km/h” •...
Page 163 GETTING TO KNOW YOUR INSTRUMENT PANEL 161 • If one or more tires have low pressure, “Inflate Tire To The ignition must be in the ON/RUN position • If the conditions are met, holding the OK button will XX” is displayed with the vehicle ICON, and the tire pressure values in each corner of the ICON with the reset the gauge and the numeric display will return to pressure value of the low tire displayed in a different...
Page 164 162 GETTING TO KNOW YOUR INSTRUMENT PANEL Hybrid Info Trip Info Push and release the up or down arrow button until Push and release the up or down arrow button until Trip Hybrid Info is highlighted in the instrument cluster dis- Info is highlighted in the instrument cluster display.
Page 165 GETTING TO KNOW YOUR INSTRUMENT PANEL 163 Hold the OK button to reset feature information. Messages Push and release the up or down arrow button until Audio Messages is highlighted in the instrument cluster display. Push and release the up or down arrow button until Audio This feature shows the number of stored warning mes- is highlighted in the instrument cluster display.
Page 166 164 GETTING TO KNOW YOUR INSTRUMENT PANEL Screen Setup Reconfigu- rable Area Available Options / Feature None Energy Effi- Charge/ Left Side Economy ciency Power Coach (De- fault) Upper None Com- Out- Time Aver- Cur- Trip Trip Bat- Total Elec- Hybrid Left pass...
Page 167 GETTING TO KNOW YOUR INSTRUMENT PANEL 165 Reconfigu- rable Area Available Options / Feature Upper None Com- Out- Time Aver- Cur- Trip Trip Bat- Total Elec- Hybrid Right pass side rent tery Range tric Range Temp (Total (Total Range Dis- Dis- (De- “L/...
Page 168: Battery Saver On/Battery Saver Mode Message - Electrical Load Reduction Actions - If Equipped
166 GETTING TO KNOW YOUR INSTRUMENT PANEL • Defaults are highlighted in BOLD. NOTE: Speed Warning is unavailable while KeySense is in use. • Unique Hybrid Features Highlighted in Italic font . Battery Saver On/Battery Saver Mode Message — • Option that may be setup as Default and Hybrid Fea- Electrical Load Reduction Actions —...
Page 169 GETTING TO KNOW YOUR INSTRUMENT PANEL 167 These messages indicate the vehicle battery has a low state Loss of the battery charge may indicate one or more of the of charge and continues to lose electrical charge at a rate following conditions: that the charging system cannot sustain.
Page 170: Warning/Indicator Lights And Messages
168 GETTING TO KNOW YOUR INSTRUMENT PANEL • The battery was used for an extended period with the • The vehicle should have service performed if the mes- vehicle not running to supply radio, lights, chargers, sage is still present during consecutive trips and the +12V portable appliances like vacuum cleaner’s, game evaluation of the vehicle and driving pattern did not consoles and similar devices.
Page 171: Red Telltale Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL 169 Red Telltale Lights Air Bag Warning Light Red Telltale What It Means Light Air Bag Warning Light This light will turn on for four to eight seconds as a bulb check when the ignition switch is first turned to ON/RUN.
Page 172 170 GETTING TO KNOW YOUR INSTRUMENT PANEL Brake Warning Light Red Telltale What It Means Light Brake Warning Light This light monitors various brake functions, including brake fluid level and parking brake appli- cation. If the brake light turns on it may indicate that the parking brake is applied, that the brake fluid level is low, or that there is a problem with the anti-lock brake system reservoir.
Page 173 GETTING TO KNOW YOUR INSTRUMENT PANEL 171 Operation of the Brake Warning Light can be checked by WARNING! turning the ignition switch from the OFF position to the ON/RUN position. The light should illuminate for ap- Driving a vehicle with the red brake light on is proximately two seconds.
Page 174 172 GETTING TO KNOW YOUR INSTRUMENT PANEL Engine Temperature Warning Light Red Telltale What It Means Light Engine Temperature Warning Light This light warns of an overheated engine condition. If the light turns on while driving, safely pull over and stop the vehicle. If the A/C system is on, turn it off. Also, shift the transmission into PARK and idle the vehicle.
Page 175 GETTING TO KNOW YOUR INSTRUMENT PANEL 173 Electronic Throttle Control (ETC) Warning Light Red Telltale What It Means Light Electronic Throttle Control (ETC) Warning Light This light informs you of a problem with the Electronic Throttle Control (ETC) system. If a prob- lem is detected while the vehicle is running, the light will either stay on or flash depending on the nature of the problem.
Page 176 174 GETTING TO KNOW YOUR INSTRUMENT PANEL Oil Pressure Warning Light Red Telltale What It Means Light Oil Pressure Warning Light This light indicates low engine oil pressure. If the light turns on while driving, stop the vehicle and shut off the engine as soon as possible. A chime will sound when this light turns on. Do not operate the vehicle until the cause is corrected.
Page 177 GETTING TO KNOW YOUR INSTRUMENT PANEL 175 Vehicle Security Warning Light Red Telltale What It Means Light Vehicle Security Warning Light This light will flash at a fast rate for approximately 15 seconds when the vehicle security alarm is arming, and then will flash slowly until the vehicle is disarmed. Door Open Warning Light —...
Page 178 176 GETTING TO KNOW YOUR INSTRUMENT PANEL Hybrid Electric Vehicle System Service Light Red Telltale What It Means Light Hybrid Electric Vehicle System Service light When this telltale illumimates in the cluster it is accompanied by a Service Hybrid Electric Ve- hicle System cluster message.
Page 179: Yellow Telltale Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL 177 Reduced Vehicle Performance Warning Light Red Telltale What It Means Light Reduced Vehicle Performance Warning Light This telltale illuminates when the vehicle is out of gas and only running on High Voltage battery. Simply filling up with some gas could make the telltale go away.
Page 180 178 GETTING TO KNOW YOUR INSTRUMENT PANEL Electronic Stability Control (ESC) Indicator Light — If Equipped Yellow Telltale What It Means Light Electronic Stability Control (ESC) Indicator Light — If Equipped The ESC Indicator illuminates when the system is active. If it remains on or does not light when the ignition is placed in the ON position, this indicates a malfunction.
Page 181 GETTING TO KNOW YOUR INSTRUMENT PANEL 179 Electronic Park Brake Fail Light Yellow Telltale What It Means Light Electronic Park Brake Fail Warning Light This telltale will turn on to indicate the Electronic Park Brake is not functioning properly and that service is required.
Page 182 180 GETTING TO KNOW YOUR INSTRUMENT PANEL LaneSense Failure Indicator Light — If Equipped Yellow Telltale What It Means Light LaneSense Failure Indicator Light This light will turn on when the LaneSense system is not operating and needs service. Please see your authorized dealer.
Page 183 GETTING TO KNOW YOUR INSTRUMENT PANEL 181 Service Adaptive Cruise Control (ACC) System Indicator Light Yellow Telltale What It Means Light Service Adaptive Cruise Control Indicator Light This light will turn on when a ACC is not operating and needs service. Refer to “Adaptive Cruise Control (ACC) —...
Page 184 182 GETTING TO KNOW YOUR INSTRUMENT PANEL Engine Malfunction Warning Light Yellow Telltale What It Means Light Vehicle Check/Malfunction Indicator Light (MIL) The Vehicle Check/Malfunction Indicator Light (MIL) is a part of an Onboard Diagnostic System called OBD II that monitors emissions control systems. The light will illuminate when the igni- tion is in the ON position before vehicle start up.
Page 185 GETTING TO KNOW YOUR INSTRUMENT PANEL 183 Tire Pressure Monitoring System (TPMS) Warning Light Yellow Telltale What It Means Light Tire Pressure Monitoring System (TPMS) Warning Light The warning light switches on and a message is displayed to indicate that the tire pressure is lower than the recommended value and/or that slow pressure loss is occurring.
Page 186 184 GETTING TO KNOW YOUR INSTRUMENT PANEL Please note that the TPMS is not a substitute for proper tire CAUTION! maintenance, and it is the driver’s responsibility to main- tain correct tire pressure, even if under-inflation has not The TPMS has been optimized for the original equip- reached the level to trigger illumination of the TPMS low ment tires and wheels.
Page 187: Green Telltale Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL 185 Green Telltale Lights Turn Signal Warning Lights Green Telltale What It Means Light Turn Signal Indicator Lights The instrument cluster arrow will flash independently for the left or right turn signal as selected, as well as the exterior turn signal lamp(s) (front and rear) as selected when the multifunction le- ver is moved down (left) or up (right).
Page 188 186 GETTING TO KNOW YOUR INSTRUMENT PANEL KeySense Indicator Light — If Equipped Green Telltale What It Means Light KeySense Indicator Light The KeySense indicator is solid green when a KeySense key is detected upon startup of the ve- hicle. The indicator will remain lit for the entire key cycle as a reminder that the KeySense key is in use.
Page 189 GETTING TO KNOW YOUR INSTRUMENT PANEL 187 Adaptive Cruise Control (ACC) Set With No Target Detected Light — If Equipped Green Telltale What It Means Light Adaptive Cruise Control (ACC) Set With No Target Detected Light — If Equipped This light will turn on when the Adaptive Cruise Control speed is SET and there is no target ve- hicle detected.
Page 190 188 GETTING TO KNOW YOUR INSTRUMENT PANEL Electronic Speed Control SET Indicator Light Green Telltale What It Means Light Speed Control SET Light This light will turn on when the speed control speed has been set. Refer to “Speed Control — If Equipped”...
Page 191: Blue Telltale Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL 189 Blue Telltale Lights High Beam Indicator Light Blue Telltale What It Means Light High Beam Indicator Light This indicator shows that the high beam headlights are on. Push the multifunction control lever away from you to switch the headlights to high beam. Pull the lever toward you to switch the headlights back to low beam.
Page 192: Onboard Diagnostic System - Obd Ii
190 GETTING TO KNOW YOUR INSTRUMENT PANEL LaneSense Indicator Light — If Equipped White Telltale What It Means Light LaneSense Indicator Light When the LaneSense system is ON, the LaneSense indicator is solid white when none or only the left or right lane marking has been detected. The indicator will turn green when both lanes are detected and the system will be ready to provide visual warnings in the instrument cluster dis- play if an unintentional lane departure occurs.
Page 193: Onboard Diagnostic System (Obd Ii) Cybersecurity
GETTING TO KNOW YOUR INSTRUMENT PANEL 191 your service technician in making repairs. Although your WARNING! vehicle will usually be drivable and not need towing, see • ONLY an authorized service technician should con- your authorized dealer for service as soon as possible. nect equipment to the OBD II connection port in CAUTION! order to diagnose or service your vehicle.
Page 195 SAFETY CONTENTS ▫ Seat Belt Systems ..... .220 SAFETY FEATURES ..... .194 ▫...
Page 196: Safety Features
194 SAFETY SAFETY FEATURES These are all normal characteristics of ABS. Anti-Lock Brake System (ABS) WARNING! The Anti-Lock Brake System (ABS) provides increased • The ABS contains sophisticated electronic equip- vehicle stability and brake performance under most brak- ment that may be susceptible to interference caused ing conditions.
Page 197: Electronic Brake Control System
SAFETY Electronic Brake Control System WARNING! (Continued) Your vehicle is equipped with an advanced Electronic • The capabilities of an ABS equipped vehicle must Brake Control system (EBC). This system includes Elec- never be exploited in a reckless or dangerous manner tronic Brake Force Distribution (EBD), Anti-Lock Brake that could jeopardize the user’s safety or the safety of System (ABS), Brake Assist System (BAS), Hill Start Assist...
Page 198 196 SAFETY will allow more vehicle torque to be applied to the wheel WARNING! (Continued) that is not spinning. BLD may remain enabled even if TCS conditions. BAS cannot prevent collisions, including and ESC are in a reduced mode. those resulting from excessive speed in turns, driving Brake Assist System (BAS) on very slippery surfaces, or hydroplaning.
Page 199 SAFETY in which the ESC module is detecting vehicle instability. of the vehicle. When ERM determines that the rate of The torque that the steering wheel receives is only meant to change of the steering wheel angle and vehicle’s speed are help the driver realize optimal steering behavior in order to sufficient to potentially cause wheel lift, it then applies the reach/maintain vehicle stability.
Page 200 198 SAFETY for oversteering or understeering of the vehicle by apply- WARNING! ing the brake of the appropriate wheel(s) to assist in • Electronic Stability Control (ESC) cannot prevent the counteracting the oversteer or understeer condition. En- gine power may also be reduced to help the vehicle natural laws of physics from acting on the vehicle, maintain the desired path.
Page 201 SAFETY To enter the “Partial Off” mode, momentarily push the “ESC WARNING! (Continued) Off” switch and the “ESC Off Indicator Light” will illuminate. vehicle modification or poor vehicle maintenance To turn the ESC on again, momentarily push the “ESC Off” that reduces the effectiveness of the ESC system can switch and the “ESC Off Indicator Light”...
Page 202 200 SAFETY ESC Activation/Malfunction Indicator Light and ESC NOTE: OFF Indicator Light • The “ESC Activation/Malfunction Indicator Light” and the “ESC OFF Indicator Light” come on momentarily each time the ignition is turned ON. The “ESC Activation/Malfunction Indicator Light” in the instrument cluster will come on •...
Page 203 SAFETY does not apply the throttle before this time expires, the compensate and hold the vehicle in place until the accel- system will release brake pressure and the vehicle will roll erator pedal is pressed enough to push the vehicle forward. down the hill as normal.
Page 204: Regenerative Braking System (Rbs) - Hybrid
202 SAFETY Rain Brake Support (RBS) The electric power that is generated goes back into the high voltage battery for later use, for example when acceleration Rain Brake Support may improve braking performance in is desired. wet conditions. It will periodically apply a small amount of brake pressure to remove any water buildup on the front The RBS uses conventional hydraulic friction brakes, re- brake rotors.
Page 205 SAFETY The BSM detection zone covers approximately one lane width on both sides of the vehicle 12 ft (3.8 m). The zone length starts at the outside rear view mirror and extends approximately 10 ft (3 m) beyond the rear bumper of the vehicle.
Page 206 204 SAFETY If the blockage message is still present after cycling the ignition and driving in traffic, check again for a blockage. The BSM system notifies the driver of objects in the detection zones by illuminating the BSM warning light located in the outside mirrors in addition to sounding an audible (chime) alert and reducing the radio volume.
Page 207 SAFETY Entering From The Side Entering From The Rear Vehicles that move into your adjacent lanes from either Vehicles that come up from behind your vehicle on either side of the vehicle. side and enter the rear detection zone with a relative speed of less than 30 mph (48 km/h).
Page 208 206 SAFETY Overtaking Traffic If you pass another vehicle slowly with a relative speed less than 15 mph (24 km/h) and the vehicle remains in the blind spot for approximately 1.5 seconds, the warning light will be illuminated. If the difference in speed between the two vehicles is greater than 15 mph (24 km/h), the warning light will not illuminate.
Page 209 SAFETY Stationary Objects Opposing Traffic The BSM system will not alert you of objects that are WARNING! traveling in the opposite direction of the vehicle in adjacent lanes. The Blind Spot Monitoring system is only an aid to help detect objects in the blind spot zones. The BSM system is not designed to detect pedestrians, bicyclists, or animals.
Page 210 208 SAFETY Rear Cross Path (RCP) (5 km/h), to objects moving a maximum of approximately 20 mph (32 km/h), such as in parking lot situations. The Rear Cross Path (RCP) feature is intended to aid the driver when backing out of parking spaces where their NOTE: In a parking lot situation, oncoming vehicles can be vision of oncoming vehicles may be blocked.
Page 211 SAFETY Modes Of Operation NOTE: Whenever an audible alert is requested by the BSM system, the radio is also muted. Three selectable modes of operation are available in the Uconnect System. Refer to “Uconnect Settings” in “Multi- When the system is in RCP, the system shall respond with media”...
Page 212: Forward Collision Warning (Fcw) With Mitigation - If Equipped
210 SAFETY General Information NOTE: FCW monitors the information from the forward looking sensors as well as the Electronic Brake Controller This vehicle has systems that operate on radio frequency (EBC), to calculate the probability of a forward collision. that comply with Part 15 of the Federal Communications When the system determines that a forward collision is Commission (FCC) rules and with Industry Canada Stan- probable, the driver will be provided with audible and...
Page 213 SAFETY • It is unsafe to test the FCW system. To prevent such misuse of the system, after four Active Braking events within a key cycle, the Active Braking portion of FCW will be deactivated until the next key cycle. •...
Page 214 212 SAFETY Changing the FCW status to “off” deactivates the system, vehicle in front using audible/visual warning when the so no warning or active braking will be available in case of latter is at a farther distance than Medium setting. This a possible collision provides the most reaction time to avoid a possible colli- sion.
Page 215: Tire Pressure Monitor System (Tpms)
SAFETY • FCW will be disabled like ACC, with the unavailable Tire Pressure Monitor System (TPMS) screens. The Tire Pressure Monitor System (TPMS) will warn the driver of a low tire pressure based on the vehicle recom- FCW Limited Warning mended cold placard pressure.
Page 216 214 SAFETY off until the tire pressure is at or above the recommended but the “Tire Pressure Monitoring Telltale Light” will still cold placard pressure. Once the low tire pressure warning be on. In this situation, the “Tire Pressure Monitoring (Tire Pressure Monitoring Telltale Light) illuminates, you Telltale Light”...
Page 217 SAFETY • Seasonal temperature changes will affect tire pressure, CAUTION! (Continued) and the TPMS will monitor the actual tire pressure in the • After inspecting or adjusting the tire pressure always tire. reinstall the valve stem cap. This will prevent mois- Premium System —...
Page 218 216 SAFETY Tire Pressure Monitoring Low Pressure Warnings recommended cold placard pressure value as shown in the Inflate to XX message. Once the system receives the updated tire pressures, the system will automatically up- The “Tire Pressure Monitoring Telltale Light” will date if the ignition is in the ON/RUN position, the illuminate in the instrument cluster and a chime pressure values in the graphic display in the instrument...
Page 219 SAFETY will no longer display, and a pressure value will display in 3. After driving the vehicle for up to 20 minutes above place of the dashes. A system fault can occur due to any of 15 mph (24 km/h), the “TPM Telltale Light” will flash the following: on and off for 75 seconds and then remain on solid.
Page 220 218 SAFETY TPMS Deactivation — If Equipped Light will flash on and off for 75 seconds and then turn off. The instrument cluster will display the “SERVICE TPM The TPMS can be deactivated if replacing all four wheel SYSTEM” message and then display pressure values in and tire assemblies (road tires) with wheel and tire assem- place of the dashes.
Page 221: Occupant Restraint Systems
SAFETY OCCUPANT RESTRAINT SYSTEMS seat as far back as possible and use the proper child restraint (refer to “Child Restraints” in this section for Some of the most important safety features in your vehicle further information). are the restraint systems: 3.
Page 222: Seat Belt Systems
220 SAFETY bags will inflate forcefully into the space between occu- vehicle. Seat belts reduce the possibility of ejection and the pants and the door and occupants could be injured. risk of injury caused by striking the inside of the vehicle. Everyone in a motor vehicle should be belted at all times.
Page 223 SAFETY BeltAlert Warning Sequence The outboard front passenger seat BeltAlert is not active when the outboard front passenger seat is unoccupied. The BeltAlert warning sequence is activated when the BeltAlert may be triggered when an animal or other items vehicle is moving above a specified vehicle speed range are placed on the outboard front passenger seat or when and the driver or outboard front seat passenger is unbuck- the seat is folded flat (if equipped).
Page 224 222 SAFETY and reduce your risk of striking the inside of the vehicle or WARNING! (Continued) being thrown out of the vehicle. driver, should always wear their seat belts whether or not an air bag is also provided at their seating WARNING! position to minimize the risk of severe injury or •...
Page 225 SAFETY WARNING! (Continued) WARNING! (Continued) • A twisted seat belt may not protect you properly. In • A shoulder belt placed behind you will not protect a collision, it could even cut into you. Be sure the seat you from injury during a collision. You are more belt is flat against your body, without twists.
Page 226 224 SAFETY Pulling Out The Latch Plate Inserting Latch Plate Into Buckle 3. When the seat belt is long enough to fit, insert the latch 4. Position the lap belt so that it is snug and lies low across plate into the buckle until you hear a “click.” your hips, below your abdomen.
Page 227 SAFETY Lap/Shoulder Belt Untwisting Procedure Use the following procedure to untwist a twisted lap/ shoulder belt. 1. Position the latch plate as close as possible to the anchor point. 2. At about 6 to 12 inches (15 to 30 cm) above the latch plate, grasp and twist the seat belt webbing 180 degrees to create a fold that begins immediately above the latch plate.
Page 228 226 SAFETY NOTE: The adjustable upper shoulder belt anchorage is equipped with an Easy Up feature. This feature allows the shoulder belt anchorage to be adjusted in the upward position without pushing or squeezing the release button. To verify the shoulder belt anchorage is latched, pull downward on the shoulder belt anchorage until it is locked into position.
Page 229 SAFETY Second Row Center (If Equipped) And Third Row Center Seat Belt Operating Instructions The second row center (if equipped) and third row center seat belts feature a seat belt with a mini-latch plate and buckle, which allows the seat belt to detach from the lower anchor when the seat is folded.
Page 230 228 SAFETY Mini-Latch Plate Mini-Latch And Buckle Connected 3. Route the shoulder belt to the inside of the left head 4. When the seat belt is long enough to fit, insert the restraint. mini-latch plate into the mini-buckle until you hear a “click.”...
Page 231 SAFETY Connect Mini-Latch To Buckle 1 — Seat Belt Latch Plate 5. Sit back in seat. Slide the regular latch plate up the 6. When the seat belt is long enough to fit, insert the latch webbing as far as necessary to allow the seat belt to go plate into the buckle until you hear a “click.”...
Page 232 230 SAFETY 8. Position the shoulder belt on your chest so that it is comfortable and not resting on your neck. The retractor will withdraw any slack in the seat belt. 9. To release the seat belt, push the red button on the buckle.
Page 233 SAFETY WARNING! (Continued) WARNING! procedure to detach the mini-latch plate and mini- • ONLY use the Seat Belt Extender if it is physically buckle, untwist the webbing, and reattach the mini- required in order to properly fit the original seat belt latch plate and mini-buckle.
Page 234 232 SAFETY Seat Belts And Pregnant Women Seat Belt Pretensioner The front seat belt system is equipped with pretensioning devices that are designed to remove slack from the seat belt in the event of a collision. These devices may improve the performance of the seat belt by removing slack from the seat belt early in a collision.
Page 235 SAFETY Switchable Automatic Locking Retractors (ALR) webbing out far enough to comfortably wrap around the occupant’s mid-section so as to not activate the ALR. If the The seat belts in the passenger seating positions are ALR is activated, you will hear a clicking sound as the seat equipped with a Switchable Automatic Locking Retractor belt retracts.
Page 236 234 SAFETY How To Engage The Automatic Locking Mode WARNING! (Continued) 1. Buckle the combination lap and shoulder belt. • Do not use the Automatic Locking Mode to restrain occupants who are wearing the seat belt or children 2. Grasp the shoulder portion and pull downward until who are using booster seats.
Page 237: Supplemental Restraint Systems (Srs)
SAFETY WARNING! Do not place the seat belt webbing behind the third row stow clip when using the seat belt to restrain an occupant. The seat belt will not be positioned properly on the occupant and they could be more seriously injured in an accident as a result.
Page 238 236 SAFETY • Instrument Panel The ORC turns on the Air Bag Warning Light in the instrument panel for approximately four to eight seconds • Knee Impact Bolsters for a self-check when the ignition switch is first in the • Driver and Front Passenger Air Bags ON/RUN position.
Page 239 SAFETY NOTE: If the speedometer, tachometer, or any engine Redundant Air Bag Warning Light related gauges are not working, the Occupant Restraint If a fault with the Air Bag Warning Light is Controller (ORC) may also be disabled. In this condition detected, which could affect the Supplemental the air bags may not be ready to inflate for your protection.
Page 240 238 SAFETY Front Air Bags WARNING! This vehicle has front air bags and lap/shoulder belts for • Being too close to the steering wheel or instrument both the driver and front passenger. The front air bags are a panel during front air bag deployment could cause supplement to the seat belt restraint systems.
Page 241 SAFETY The first stage inflator is triggered immediately during an WARNING! (Continued) impact that requires air bag deployment. A low energy any such objects could cause harm if the vehicle is in output is used in less severe collisions. A higher energy a collision severe enough to cause the air bag to output is used for more severe collisions.
Page 242 240 SAFETY On the other hand, depending on the type and location of Occupant Classification System (OCS) — Front impact, front air bags may deploy in crashes with little Passenger Seat vehicle front-end damage but that produce a severe initial The OCS is part of a Federally regulated safety system for deceleration.
Page 243 SAFETY operate as designed, it is important for the front passenger Front Passenger Seat Oc- Front Passenger Air Bag to be seated properly and properly wearing the seat belt. cupant Status Output The OCS will NOT prevent deployment of the Passenger Properly seated adult Full-power deployment Advanced Front Air Bag.
Page 244 242 SAFETY WARNING! (Continued) • Children 12 years or younger should always ride buckled up in a vehicle with a rear seat. The OCS determines the front passenger’s most probable classification. The OCS estimates the seated weight on the front passenger seat and where that weight is located. The OCS communicates the classification status to the ORC.
Page 245 SAFETY • Accessories that may change the seated weight on the The OCS will detect the front passenger’s decreased or increased seated weight, which may result in an adjusted front passenger seat are attached to the front passenger inflation rate of the Passenger Advanced Front Air Bag in a seat.
Page 246 244 SAFETY Not Seated Properly Not Seated Properly...
Page 247 SAFETY WARNING! (Continued) the seatback, sitting upright, facing forward, in the center of the seat, with your feet comfortably on or near the floor. • Do not carry or hold any objects (e.g., backpacks, boxes, etc.) while seated in the front passenger seat. Holding an object may provide an output signal to the OCS that is different than the occupant’s prop- erly seated weight input, which may result in serious...
Page 248 246 SAFETY The passenger seat assembly contains critical OCS compo- be modified or replaced with any part except those nents that may affect the Passenger Advanced Front Air which are approved by FCA US LLC. Bag inflation. In order for the OCS to properly classify the seated weight of a front seat passenger, the OCS compo- WARNING! nents must function as designed.
Page 249 SAFETY WARNING! • Do not drill, cut, or tamper with the knee impact bolsters in any way. • Do not mount any accessories to the knee impact bolsters such as alarm lights, stereos, citizen band radios, etc. Supplemental Driver And Front Passenger Knee Air Bags This vehicle is equipped with a Supplemental Driver Knee Air Bag mounted in the instrument panel below the...
Page 250 248 SAFETY impacts and/or vehicle rollover events, in addition to the WARNING! injury reduction potential provided by the seat belts and body structure. Do not use accessory seat covers or place objects between you and the SABs; the performance could be The SABICs deploy downward, covering the side win- adversely affected and/or objects could be pushed into dows.
Page 251 SAFETY The SABICs and SABs (Side Air Bags) are designed to WARNING! (Continued) activate in certain side impacts and certain rollover events. from the Side Air Bags, occupants must wear their The Occupant Restraint Controller (ORC) determines seat belts properly and sit upright with their backs whether the deployment of the Side Air Bags in a particular against the seats.
Page 252 250 SAFETY Side Impacts The Side Air Bags will not deploy in all rollover events. The rollover sensing system determines if a rollover event may In side impacts, the side impact sensors aid the ORC in be in progress and whether deployment is appropriate. In determining the appropriate response to impact events.
Page 253 SAFETY • Supplemental Knee Air Bags quickly. However, if you haven’t healed significantly within a few days, or if you have any blistering, see your • Front and Side Impact Sensors doctor immediately. • Seat Belt Pretensioners • As the air bags deflate, you may see some smoke-like •...
Page 254 252 SAFETY NOTE: Enhanced Accident Response System Reset Procedure • Air bag covers may not be obvious in the interior trim, but they will open during air bag deployment. After an event occurs requiring activation of the Enhanced Accident Response System, when the system is active, a “ •...
Page 255 SAFETY Event Data Recorder (EDR) WARNING! (Continued) This vehicle is equipped with an event data recorder you. Do not modify the components or wiring, in- (EDR). The main purpose of an EDR is to record, in certain cluding adding any kind of badges or stickers to the crash or near crash-like situations, such as an air bag steering wheel hub trim cover or the upper right side deployment or hitting a road obstacle, data that will assist...
Page 256: Child Restraints
254 SAFETY NOTE: EDR data are recorded by your vehicle only if a children are safer when properly restrained in the rear non-trivial crash situation occurs; no data are recorded by seats rather than in the front. the EDR under normal driving conditions and no personal data (e.g., name, gender, age, and crash location) are WARNING! recorded.
Page 257 SAFETY NOTE: • For additional information, refer to www.safercar.gov/ parents/index.htm or call: 1–888–327–4236 • Canadian residents should refer to Transport Canada’s website additional information: http:// www.tc.gc.ca/eng/motorvehiclesafety/safedrivers- childsafety-index-53.htm Summary Of Recommendations For Restraining Children In Vehicles Recommended Type Of Child Re- Child Size, Height, Weight Or Age straint Infants and Toddlers...
Page 258 256 SAFETY Recommended Type Of Child Re- Child Size, Height, Weight Or Age straint Larger Children Children who have out-grown their Belt Positioning Booster Seat and the forward-facing child restraint, but vehicle seat belt, seated in the rear are too small to properly fit the vehi- seat of the vehicle cle’s seat belt Children Too Large for Child Re-...
Page 259 SAFETY Older Children And Child Restraints WARNING! Children who are two years old or who have outgrown Do not install a rear-facing car seat using a rear support their rear-facing convertible child seat can ride forward- leg in this vehicle. The floor of this vehicle is not facing in the vehicle.
Page 260 258 SAFETY should use the seat belt in a rear seat. Use this simple 5-step WARNING! test to decide whether the child can use the vehicle’s seat • Improper installation can lead to failure of an infant belt alone: or child restraint. It could come loose in a collision. 1.
Page 261 SAFETY WARNING! Never allow a child to put the shoulder belt under an arm or behind their back. In a crash, the shoulder belt will not protect a child properly, which may result in serious injury or death. A child must always wear both the lap and shoulder portions of the seat belt correctly.
Page 262 260 SAFETY Lower Anchors And Tethers For CHildren (LATCH) and Tethers for CHildren. The LATCH system has three Restraint System vehicle anchor points for installing LATCH-equipped child seats. There are two lower anchorages located at the back of the seat cushion where it meets the seatback and one top tether anchorage located behind the seating position.
Page 263 SAFETY LATCH Positions For Installing Child Restraints In This Vehicle 7 Passenger LATCH Positions • Lower Anchorage Symbol (2 Anchorages Per Seating Position) • Top Tether Anchorage Symbol...
Page 264 262 SAFETY Frequently Asked Questions About Installing Child Restraints With LATCH Frequently Asked Questions What is the weight limit (child’s weight + 65 lbs (29.5 kg) Use the LATCH anchorage system until the weight of the child restraint) for using the combined weight of the child and the child LATCH anchorage system to attach the child restraint is 65 lbs (29.5 kg).
Page 265 SAFETY Frequently Asked Questions Can the head restraints be removed? The 2nd row head restraints are removable. The 3rd row center head restraint is remov- able, but the 3rd row outboard head re- straints are not removable. NOTE: If the folding, non-adjustable head restraint inter- feres with the installation of the child restraint, the head restraint may be folded and the child seat installed in front of it.
Page 266 264 SAFETY Locating The LATCH Anchorages The lower anchorages are round bars that are found at the rear of the seat cushion where it meets the seatback, below the anchorage symbols on the seatback. They are just visible when you lean into the rear seat to install the child restraint.
Page 267 SAFETY Center Seat LATCH This vehicle has 4 lower LATCH anchorages in the third row, rear seat. Anchorages A and B are used for the right outboard position behind the front passenger (1). Anchor- ages C and D are used for the center seating position (2). The left outboard position (3) does not have lower anchor- ages.
Page 268 266 SAFETY not use that outboard position. If a child seat in the center 1. Loosen the adjusters on the lower straps and on the position blocks the outboard LATCH anchors or seat belt, tether strap of the child seat so that you can more easily do not install a child seat in that outboard position.
Page 269 SAFETY 6. Test that the child restraint is installed tightly by pulling WARNING! (Continued) back and forth on the child seat at the belt path. It should Follow the child restraint manufacturer’s directions not move more than 1 inch (25.4 mm) in any direction. exactly when installing an infant or child restraint.
Page 270 268 SAFETY The seat belts in the passenger seating positions are Lap/Shoulder Belt Systems For Installing Child equipped with a Switchable Automatic Locking Retractor Restraints In This Vehicle (ALR) that is designed to keep the lap portion of the seat belt tight around the child restraint so that it is not necessary to use a locking clip.
Page 271 SAFETY Frequently Asked Question About Installing Child Restraints With Seat Belts Frequently Asked Questions About Installing Child Restraints With Seat Belts What is the weight limit (child’s weight + Weight limit of the Always use the tether anchor when using the weight of the child restraint) for using the Child Restraint seat belt to install a forward facing child re-...
Page 272 270 SAFETY Installing A Child Restraint With A Switchable WARNING! Automatic Locking Retractor (ALR): Always make sure the head restraint is in its upright Child restraint systems are designed to be secured in vehicle position when the seat is to be used by an occupant seats by lap belts or the lap belt portion of a lap/shoulder belt.
Page 273 SAFETY 4. Pull on the webbing to make the lap portion tight Any seat belt system will loosen with time, so check the against the child seat. belt occasionally, and pull it tight if necessary. 5. To lock the seat belt, pull down on the shoulder part of the Seat Belt Park Stitch —...
Page 274 272 SAFETY If the park stitch interferes with the lock-off features of the Installing Child Restraints Using the Top Tether child restraint, do not use the lock-off feature. Instead, Anchorage switch the seat belt to the locking mode, as described in the steps above or move the car seat to a different seating WARNING! position.
Page 275 SAFETY tether anchorage for that seating position, move the 3. Attach the tether strap hook of the child restraint to the child restraint to another position in the vehicle if one is top tether anchorage as shown in the diagram. available.
Page 276 274 SAFETY 2. If the car seat is in the center, raise the center head WARNING! restraint and route the tether strap around the inboard • An incorrectly anchored tether strap could lead to (left) side of the head restraint support posts, as shown in the diagram.
Page 277: Transporting Pets
SAFETY Transporting Pets Air Bags deploying in the front seat could harm your pet. An unrestrained pet will be thrown about and possibly injured, or injure a passenger during panic braking or in a collision. Pets should be restrained in the rear seat in pet harnesses or pet carriers that are secured by seat belts.
Page 278: Exhaust Gas
276 SAFETY WARNING! (Continued) WARNING! (Continued) • Do not allow people to ride in any area of your • If it is necessary to sit in a parked vehicle with the vehicle that is not equipped with seats and seat belts. vehicle running, adjust your heating or cooling con- •...
Page 279: Safety Checks You Should Make Inside The Vehicle
SAFETY Safety Checks You Should Make Inside The Vehicle Defroster Check operation by selecting the defrost mode and place the Seat Belts blower control on high speed. You should be able to feel the Inspect the seat belt system periodically, checking for cuts, air directed against the windshield.
Page 280 278 SAFETY WARNING! (Continued) WARNING! (Continued) • ONLY use the passenger’s side floor mat on the mat upside down or turn your floor mat over. Lightly pull to confirm mat is secured using the passenger’s side floor area. • ALWAYS make sure objects cannot fall or slide into floor mat fasteners on a regular basis.
Page 281: Periodic Safety Checks You Should Make Outside
SAFETY Periodic Safety Checks You Should Make Outside Door Latches The Vehicle Check for proper closing, latching, and locking. Tires Fluid Leaks Examine tires for excessive tread wear and uneven wear Check area under vehicle after overnight parking for fuel, patterns.
Page 283 STARTING AND OPERATING CONTENTS STARTING PROCEDURES ....284 ACTIVE NOISE CANCELLATION ... .298 ▫ Normal Starting ......284 POWER STEERING .
Page 284 282 STARTING AND OPERATING ▫ To Set A Desired ACC Speed ....305 ▫ ParkSense Display ..... .323 ▫...
Page 285 STARTING AND OPERATING 283 ▫ Parallel Parking Space Assistance REFUELING THE VEHICLE ....375 Operation/Display ..... .347 VEHICLE LOADING .
Page 286: Starting Procedures
284 STARTING AND OPERATING STARTING PROCEDURES Start the engine with the gear selector in the PARK position. Apply the brake before shifting to any driving Before starting your vehicle, adjust your seat, adjust both range. inside and outside mirrors, and fasten your seat belts. Normal Starting WARNING! NOTE: Normal starting of either a cold or a warm engine...
Page 287: Cold Weather Operation
STARTING AND OPERATING 285 ENGINE START/STOP Button Functions — With Driv- After Starting er’s Foot OFF The Brake Pedal (In PARK Or NEUTRAL The vehicle will optimize the energy efficiency and either Position) turn on the engine or operate in electric mode. The ENGINE START/STOP button operates similar to an To Turn Off The Vehicle Using ENGINE ignition switch.
Page 288: Engine Break-In Recommendations
286 STARTING AND OPERATING NOTE: This vehicle is equipped with an automatic shut- While cruising, brief full-throttle acceleration within the down feature. If the vehicle is left in a “READY” state limits of local traffic laws contributes to a good break-in. (vehicle running) with the shifter in “PARK”...
Page 289: Park Brake
STARTING AND OPERATING 287 PARK BRAKE Electric Park Brake (EPB) Your vehicle is equipped with an Electric Park Brake System (EPB) that offers simple operation, and some additional features that make the park brake more conve- nient and useful. The park brake is primarily intended to prevent the vehicle from rolling while parked.
Page 290 288 STARTING AND OPERATING NOTE: The EPB fault lamp will illuminate if the EPB Once the park brake is fully disengaged, the BRAKE switch is held for longer than 180 seconds. The light will warning lamp in the instrument cluster and the LED extinguish upon releasing the switch.
Page 291 STARTING AND OPERATING 289 WARNING! WARNING! (Continued) • Always fully apply the parking brake when leaving • Never use the PARK position as a substitute for the your vehicle, or it may roll and cause damage or parking brake. Always apply the parking brake fully injury.
Page 292 290 STARTING AND OPERATING To disengage the park brake while the vehicle is in motion, open, the vehicle is at a standstill, and there is no attempt release the switch. If the vehicle is brought to a complete to depress the brake pedal or accelerator pedal, the park stop using the park brake, when the vehicle reaches brake will automatically engage to prevent the vehicle approximately 3 mph (4.8 km/h), the park brake will...
Page 293: Automatic Transmission
STARTING AND OPERATING 291 Brake Service Mode has requirements that must be met in AUTOMATIC TRANSMISSION order to be activated: WARNING! • The vehicle must be at a standstill. • Never use the PARK position as a substitute for the •...
Page 294 292 STARTING AND OPERATING WARNING! (Continued) WARNING! (Continued) vehicle could accelerate quickly forward or in re- touch the park brake, brake pedal or the transmis- verse. You could lose control of the vehicle and hit sion gear selector. • Do not leave the key fob in or near the vehicle (or in someone or something.
Page 295: Ignition Park Interlock
STARTING AND OPERATING 293 Ignition Park Interlock Hybrid Transmission Your vehicle is equipped with a Ignition Park Interlock The transmission is controlled using a rotary electronic gear which requires the transmission to be in PARK before the selector located on the center console. The transmission gear ignition can be turned off.
Page 296: Gear Ranges
294 STARTING AND OPERATING Only shift from DRIVE to PARK or REVERSE when the PARK (P) accelerator pedal is released and the vehicle is stopped. Be This range supplements the parking brake by locking the sure to keep your foot on the brake pedal when shifting transmission.
Page 297 STARTING AND OPERATING 295 WARNING! WARNING! (Continued) engine is idling normally (or stopped) and your foot • Never use the PARK position as a substitute for the is firmly pressing the brake pedal. park brake. Always apply the park brake fully when •...
Page 298 296 STARTING AND OPERATING REVERSE (R) WARNING! (Continued) This range is for moving the vehicle backward. Shift into • Do not leave the key fob in or near the vehicle (or in a REVERSE only after the vehicle has come to a complete location accessible to children), and do not leave the stop.
Page 299 STARTING AND OPERATING 297 LOW (L) CAUTION! This range should be used when descending very steep Towing the vehicle, coasting, or driving for any other grades. Using the LOW position will increase the rate of reason with the transmission in NEUTRAL can cause deceleration when the accelerator pedal is released in severe transmission damage.
Page 300: Active Noise Cancellation
298 STARTING AND OPERATING In the event of a momentary problem, the transmission can ACTIVE NOISE CANCELLATION be reset to regain all forward gears by performing the Your vehicle is equipped with an Active Noise Cancellation following steps: System. This system is designed to address exhaust and engine noise.
Page 301: Speed Control - If Equipped
STARTING AND OPERATING 299 SPEED CONTROL — IF EQUIPPED WARNING! When engaged, the Speed Control takes over accelerator Continued operation with reduced assist could pose a operations at speeds greater than 25 mph (40 km/h). safety risk to yourself and others. Service should be The Speed Control buttons are located on the right side of obtained as soon as possible.
Page 302: To Activate
300 STARTING AND OPERATING NOTE: In order to ensure proper operation, the Speed WARNING! Control System has been designed to shut down if multiple Speed Control functions are operated at the same time. If Leaving the Speed Control system on when not in use this occurs, the Speed Control System can be reactivated by is dangerous.
Page 303: To Accelerate For Passing
STARTING AND OPERATING 301 in “Multimedia” for more information. The speed incre- in “Multimedia” for more information. The speed incre- ment shown is dependant on the chosen speed unit of U.S. ment shown is dependant on the chosen speed unit of U.S. (mph) or Metric (km/h): (mph) or Metric (km/h): U.S.
Page 304: To Resume Speed
302 STARTING AND OPERATING To Resume Speed reset your cruise control. ACC utilizes a radar sensor and a forward facing camera designed to detect a vehicle directly To resume a previously set speed, push the RES button and ahead of you. release.
Page 305 STARTING AND OPERATING 303 You can change the mode by using the Cruise Control WARNING! (Continued) buttons. The two control modes function differently. Al- • Does not always fully recognize complex driving ways confirm which mode is selected. conditions, which can result in wrong or missing distance warnings.
Page 306: Adaptive Cruise Control (Acc) Operation
304 STARTING AND OPERATING Adaptive Cruise Control (ACC) Operation NOTE: Any chassis/suspension or tire size modifications to the vehicle will effect the performance of the Adaptive The speed control buttons (located on the right side of the Cruise Control and Forward Collision Warning System. steering wheel) operates the ACC system.
Page 307: To Activate/Deactivate
STARTING AND OPERATING 305 • When the driver door is open at low speed. • When the driver seat belt is unbuckled at low speed. To Activate/Deactivate Push and release the Adaptive Cruise Control (ACC) on/off button. The ACC menu in the instrument cluster displays “ACC Ready.”...
Page 308: To Cancel
306 STARTING AND OPERATING • The gear selector is removed from the DRIVE position. If the system is set when the vehicle speed is below 20 mph (32 km/h), the set speed shall be defaulted to 20 mph • The Electronic Stability Control/Traction Control Sys- (32 km/h).
Page 309: To Vary The Speed Setting
STARTING AND OPERATING 307 NOTE: The driver’s preferred units can be selected through the Uconnect Settings if equipped. Refer to “Uconnect Set- • If your vehicle stays at standstill for longer than two tings” in “Multimedia” for more information. The speed seconds, then the driver will either have to push the RES increment shown is dependant on the chosen speed unit of (resume) button, or apply the accelerator pedal to reen-...
Page 310 308 STARTING AND OPERATING • If the button is continually pushed, the set speed will To Decrease Speed continue to decrease in 10 km/h decrements until the While ACC is set, the set speed can be decreased by button is released. The decrease in set speed is reflected pushing the SET (-) button.
Page 311: Setting The Following Distance In Acc
STARTING AND OPERATING 309 speed. When driving up hill and down hill, the ACC system will cancel if the braking temperature exceeds normal range (overheated). Setting The Following Distance In ACC The specified following distance for ACC can be set by varying the distance setting between four bars (longest), three bars (long), two bars (medium) and one bar (short).
Page 312 310 STARTING AND OPERATING Distance Setting 2 Bars (Medium) Distance Setting 1 Bar (Short) To increase the distance setting, push the Distance Setting — Increase button and release. Each time the button is pushed, the distance setting increases by one bar (longer). To decrease the distance setting, push the Distance Setting —...
Page 313: Overtake Aid
STARTING AND OPERATING 311 Indicator” icon, and the system adjusts vehicle speed automatically to maintain the distance setting, regardless of the set speed. The vehicle will then maintain the set distance until: • The vehicle ahead accelerates to a speed above the set speed.
Page 314: Acc Operation At Stop
312 STARTING AND OPERATING ACC Operation At Stop WARNING! In the event that the ACC system brings your vehicle to a When the ACC system is resumed, the driver must standstill while following a target vehicle, if the target ensure that there are no pedestrians, vehicles or objects vehicle starts moving within two seconds of your vehicle in the path of the vehicle.
Page 315: Display Warnings And Maintenance
STARTING AND OPERATING 313 Push the SET (+) or the SET (-) button (located on the Display Warnings And Maintenance steering wheel) and the following will display in the “Wipe Front Radar Sensor In Front Of Vehicle” instrument cluster display: Warning ACC SET The “ACC/FCW Unavailable Wipe Front Radar Sensor”...
Page 316 314 STARTING AND OPERATING NOTE: If the “ACC/FCW Unavailable Wipe Front Radar When the condition that deactivated the system is no Sensor” warning is active Normal (Fixed Speed) Cruise longer present, the system will return to the “Adaptive Control is still available. For additional information refer to Cruise Control Off”...
Page 317: Precautions While Driving With Acc
STARTING AND OPERATING 315 recover after the vehicle has left these areas. Under rare Precautions While Driving With ACC conditions, when the camera is not tracking any vehicles or In certain driving situations, ACC may have detection objects in its path this warning may temporarily occur. issues.
Page 318 316 STARTING AND OPERATING Turns And Bends Using ACC On Hills When driving on a curve with ACC engaged, the system When driving on hills, ACC may not detect a vehicle in may decrease the vehicle speed and acceleration for stabil- your lane.
Page 319 STARTING AND OPERATING 317 Lane Changing Narrow Vehicles ACC may not detect a vehicle until it is completely in the Some narrow vehicles traveling near the outer edges of the lane in which you are traveling. In the illustration shown, lane or edging into the lane are not detected until they have ACC has not yet detected the vehicle changing lanes and it moved fully into the lane.
Page 320: General Information
318 STARTING AND OPERATING Stationary Objects And Vehicles Operation is subject to the following two conditions: ACC does not react to stationary objects and stationary 1. The device may not cause harmful interference. vehicles. For example, ACC will not react in situations 2.
Page 321 STARTING AND OPERATING 319 To Vary The Speed Setting WARNING! To Increase Speed In the Normal (Fixed Speed) Cruise Control mode, the When the Normal (Fixed Speed) Cruise Control is set, you system will not react to vehicles ahead. In addition, the can increase speed by pushing the SET (+) button.
Page 322 320 STARTING AND OPERATING • If the button is continually pushed, the set speed will Metric Speed (km/h) continue to increase in 10 km/h increments until the • Pushing the SET (-) button once will result in a 1 km/h button is released.
Page 323: Parksense Rear Park Assist - If Equipped
STARTING AND OPERATING 321 To Resume Speed NOTE: • The driver can override the automatic braking function To resume a previously set speed, push the RES button and by pushing the gas pedal, turning ParkSense off via release. Resume can be used at any speed above 20 mph ParkSense switch, or changing the gear while the auto- (32 km/h).
Page 324: Parksense Sensors
322 STARTING AND OPERATING The automatic braking function is intended to assist the display indicating the vehicle speed is too fast. The system driver in avoiding possible collisions with detected ob- will become active again if the vehicle speed is decreased to stacles when backing up in REVERSE gear.
Page 325: Parksense Visual Alert
STARTING AND OPERATING 323 ParkSense Visual Alert and will produce a one-half second tone. As the vehicle moves closer to the obstacle, the display will show the The ParkSense Warning screen will only be displayed if single arc moving closer to the vehicle and the sound tone Sound and Display is selected from the Customer - Pro- will change from slow, to fast, to continuous.
Page 326 324 STARTING AND OPERATING Slow Tone/Solid Arc Slow Tone/Solid Arc...
Page 327 STARTING AND OPERATING 325 Fast Tone/Flashing Arc Fast Tone/Flashing Arc...
Page 328 326 STARTING AND OPERATING The vehicle is close to the obstacle when the warning display shows one flashing arc and sounds a continuous tone. The following chart shows the warning alert opera- tion when the system is detecting an obstacle: Continuous Tone/Flashing Arc...
Page 329 STARTING AND OPERATING 327 WARNING ALERTS Rear Dis- Greater 79-59 inches 59-47 inches 47-39 inches 39-25 inches 25-12 inches Less than tance than (200- (150- (120- (100-65 cm) (65-30 cm) 12 inches (in/cm) 79 inches 150 cm) 120 cm) 100 cm) (30 cm) (200 cm) Arcs —...
Page 330: Enabling And Disabling Parksense
328 STARTING AND OPERATING Enabling And Disabling ParkSense The ParkSense switch LED will be on when ParkSense is disabled or requires service. The ParkSense switch LED ParkSense can be enabled and disabled with the ParkSense will be off when the system is enabled. If the ParkSense switch, located on the switch panel below the Uconnect switch is pushed, and requires service, the ParkSense display.
Page 331: Cleaning The Parksense System
STARTING AND OPERATING 329 show the PARKSENSE UNAVAILABLE WIPE REAR SEN- ParkSense System Usage Precautions SORS or PARKSENSE UNAVAILABLE SERVICE RE- NOTE: QUIRED message for five seconds while the vehicle is in • Ensure that the rear bumper is free of snow, ice, mud, REVERSE.
Page 332 330 STARTING AND OPERATING obstacle behind the fascia/bumper, or it could provide a WARNING! (Continued) false indication that an obstacle is behind the fascia/ • Before using ParkSense, it is strongly recommended bumper. that the ball mount and hitch ball assembly is •...
Page 333: Parksense Front And Rear Park Assist - If Equipped
STARTING AND OPERATING 331 • Automatic brakes will not be available if there is a CAUTION! (Continued) faulted condition detected with the ParkSense Park obstacle is detected. It is recommended that the Assist system or the Braking System Module. driver looks over his/her shoulder when using •...
Page 334: Parksense Sensors
332 STARTING AND OPERATING NOTE: ParkSense Sensors • The driver is always responsible for controlling the The four ParkSense sensors, located in the rear fascia/ vehicle. bumper, monitor the area behind the vehicle that is within the sensors’ field of view. The sensors can detect obstacles •...
Page 335: Parksense Visual Alert
STARTING AND OPERATING 333 ParkSense Visual Alert The ParkSense Warning screen will only be displayed if Sound and Display is selected from the Customer - Pro- grammable Features section of the Uconnect System. Refer to Uconnect Settings” in “Multimedia” for further infor- mation.
Page 336 334 STARTING AND OPERATING and will produce a one-half second tone. As the vehicle moves closer to the obstacle, the display will show the single arc moving closer to the vehicle and the sound tone will change from slow, to fast, to continuous. If an obstacle is detected in the left and/or right rear region, the display will show a single flashing arc in the left and/or right rear region and will produce a fast sound...
Page 337 STARTING AND OPERATING 335 Slow Tone/Solid Arc Fast Tone/Flashing Arc...
Page 338 336 STARTING AND OPERATING Fast Tone/Flashing Arc Continuous Tone/Flashing Arc The vehicle is close to the obstacle when the warning display shows one flashing arc and sounds a continuous tone. The following chart shows the warning alert opera- tion when the system is detecting an obstacle:...
Page 339 STARTING AND OPERATING 337 WARNING ALERTS Rear Dis- Greater 79-59 inches 59-47 inches 47-39 inches 39-25 inches 25-12 inches Less than tance than (200- (150- (120- (100-65 cm) (65-30 cm) 12 inches (inches/cm) 79 inches 150 cm) 120 cm) 100 cm) (30 cm) (200 cm) Arcs —...
Page 340 338 STARTING AND OPERATING Front Park Assist When the vehicle is in DRIVE the ParkSense Warning screen will be displayed when an obstacle is detected. The system will indicate a detected obstacle by showing a single arc in one or more regions based on the obstacle’s distance and location relative to the vehicle.
Page 341 STARTING AND OPERATING 339 No Tone/Flashing Arc Fast Tone/Flashing Arc...
Page 342 340 STARTING AND OPERATING The vehicle is close to the obstacle when the warning display shows one flashing arc and sounds a continuous tone. The following chart shows the warning alert opera- tion when the system is detecting an obstacle: Continuous Tone/Flashing Arc...
Page 343 STARTING AND OPERATING 341 WARNING ALERTS Front Distance Greater than 47-39 inches 39-25 inches 25-12 inches Less than (inches/cm) 47 inches (120-100 cm) (100-65 cm) (65-30 cm) 12 inches (30 cm) (120 cm) Arcs — Left None None None 2nd Flashing 1st Flashing Arcs —...
Page 344: Enabling And Disabling Parksense
342 STARTING AND OPERATING Enabling And Disabling ParkSense The ParkSense switch LED will be ON when ParkSense is disabled or requires service. The ParkSense switch LED ParkSense can be enabled and disabled with the ParkSense will be OFF when the system is enabled. If the ParkSense switch, located on the switch panel below the Uconnect switch is pushed, and requires service, the ParkSense display.
Page 345: Cleaning The Parksense System
STARTING AND OPERATING 343 show a PARKSENSE UNAVAILABLE WIPE REAR SEN- If the PARKSENSE UNAVAILABLE SERVICE RE- SORS , PARKSENSE UNAVAILABLE WIPE FRONT SEN- QUIRED message appears in the instrument cluster dis- SORS or PARKSENSE UNAVAILABLE SERVICE RE- play, see an authorized dealer. QUIRED pop up message for five seconds.
Page 346 344 STARTING AND OPERATING • ParkSense, when on, will reduce the volume of the radio WARNING! when it is sounding a tone. • Drivers must be careful when backing up even when • Clean the ParkSense sensors regularly, taking care not to using ParkSense.
Page 347: Parksense Active Park Assist System - If Equipped
STARTING AND OPERATING 345 ParkSense Active Park Assist system is capable of maneu- CAUTION! vering a vehicle into a parallel or a perpendicular parking • ParkSense is only a parking aid and it is unable to space on either side (i.e., driver side or passenger side). recognize every obstacle, including small obstacles.
Page 348: Enabling And Disabling The Parksense Active Park Assist System
346 STARTING AND OPERATING The system will also continuously perform the dynamic To disable the ParkSense Active Park Assist system, push vehicle calibration to account for differences such as the ParkSense Active Park Assist switch again (LED turns over or under inflated tires and new tires. off).
Page 349: Parallel Parking Space Assistance Operation/Display
STARTING AND OPERATING 347 system will cancel and the instrument cluster display When pushed, the LED on the ParkSense Active Park will instruct the driver to complete the maneuver manu- Assist switch will blink momentarily, and then the LED ally. will turn OFF if any of the above conditions are not present.
Page 350 348 STARTING AND OPERATING • The driver is responsible to ensure that the selected parking space is suitable for the maneuver and free/ clear of anything that may be overhanging or protruding into the parking space (e.g., ladders, tailgates, etc. from surrounding objects/vehicles).
Page 351 STARTING AND OPERATING 349 When an available parking space has been found, and the Once the vehicle is in position, you will be instructed to vehicle is not in position, you will be instructed to move stop the vehicle’s movement and remove your hands from forward to position the vehicle for a parallel parking the steering wheel.
Page 352 350 STARTING AND OPERATING Once the vehicle is at a standstill with your hands removed When the driver places the gear selector into the REVERSE from the steering wheel, you will be instructed to place the position, the system may instruct the driver to wait for gear selector into the REVERSE position.
Page 353 STARTING AND OPERATING 351 • The ParkSense Active Park Assist system will allow a The system will then instruct the driver to check their surroundings and move backward. maximum of six shifts between DRIVE or REVERSE. If the maneuver cannot be completed within six shifts, the system will cancel and the instrument cluster display will instruct the driver to complete the maneuver manu- ally.
Page 354 352 STARTING AND OPERATING When the vehicle has reached the end of its backward Once the vehicle is in a standstill condition, the driver will movement, the system will instruct the driver to check be instructed to place the gear selector into the DRIVE their surroundings and stop the vehicle’s movement.
Page 355 STARTING AND OPERATING 353 When the driver places the gear selector into the DRIVE The system will then instruct the driver to check their position, the system may instruct the driver to wait for surroundings and move forward. steering to complete. Check Surroundings —...
Page 356 354 STARTING AND OPERATING When the vehicle has reached the end of its forward Once the vehicle is in a standstill condition, the driver will movement, the system will instruct the driver to check be instructed to place the gear selector into the REVERSE their surroundings and stop the vehicle’s movement.
Page 357 STARTING AND OPERATING 355 When the driver places the gear selector into the REVERSE The system will then instruct the driver to check their position, the system may instruct the driver to wait for surroundings and move backward. steering to complete. Check Surroundings —...
Page 358: Perpendicular Parking Space Assistance Operation/Display
356 STARTING AND OPERATING Your vehicle is now in the parallel park position. When the switch to change your parking space setting to a perpen- maneuver is complete, the driver will be instructed to dicular maneuver. You may switch back to parallel parking check the vehicle’s parking position.
Page 359 STARTING AND OPERATING 357 NOTE: When an available parking space has been found, and the vehicle is not in position, you will be instructed to move • When searching for a parking space, use the turn signal forward to position the vehicle for a perpendicular parking indicator to select which side of the vehicle you want to sequence.
Page 360 358 STARTING AND OPERATING Once the vehicle is in position, you will be instructed to Once the vehicle is at a standstill with your hands removed stop the vehicle’s movement and remove your hands from from the steering wheel, you will be instructed to place the the steering wheel.
Page 361 STARTING AND OPERATING 359 When the driver places the gear selector into the REVERSE position, the system may instruct the driver to wait for steering to complete. Check Surroundings — Move Backwards NOTE: • It is the driver’s responsibility to use the brake and Check Surroundings —...
Page 362 360 STARTING AND OPERATING • The ParkSense Active Park Assist system will allow a maximum of six shifts between DRIVE or REVERSE. If the maneuver cannot be completed within six shifts, the system will cancel and the instrument cluster display will instruct the driver to complete the maneuver manu- ally.
Page 363 STARTING AND OPERATING 361 Once the vehicle is in a standstill condition, the driver will When the driver places the gear selector into the DRIVE be instructed to place the gear selector into the DRIVE position, the system may instruct the driver to wait for position.
Page 364 362 STARTING AND OPERATING The system will then instruct the driver to check their surroundings and move forward. Check Surroundings — STOP NOTE: It is the driver’s responsibility to use the brake and stop the vehicle. The driver should check their surround- Check Surroundings —...
Page 365 STARTING AND OPERATING 363 Once the vehicle is in a standstill condition, the driver will When the driver places the gear selector into the REVERSE be instructed to place the gear selector into the REVERSE position, the system may instruct the driver to wait for position.
Page 366 364 STARTING AND OPERATING The system will then instruct the driver to check their surroundings and move backward. Active ParkSense Complete — Check Parking Position WARNING! Check Surroundings — Move Backwards Drivers must be careful when performing parallel or Your vehicle is now in the perpendicular park position. perpendicular parking maneuvers even when using When the maneuver is complete, the driver will be in- the ParkSense Active Park Assist system.
Page 367: Lanesense - If Equipped
STARTING AND OPERATING 365 When both lane markings are detected and the driver CAUTION! unintentionally drifts out of the lane (no turn signal • The ParkSense Active Park Assist system is only a applied), the LaneSense system provides a haptic warning in the form of torque applied to the steering wheel to parking aid and it is unable to recognize every prompt the driver to remain within the lane boundaries.
Page 368: Turning Lanesense On Or Off
366 STARTING AND OPERATING Turning LaneSense On Or Off The default status of LaneSense is “off”. The LaneSense button is located on the switch panel below the Uconnect display. Lane Sense On Message To turn the LaneSense system off, push the LaneSense button again (LED turns on).
Page 369: Lanesense Warning Message
STARTING AND OPERATING 367 LaneSense Warning Message marking has been detected and the system is ready to provide visual warnings in the instrument cluster The LaneSense system will indicate the current lane drift display if an unintentional lane departure occurs. condition through the instrument cluster display.
Page 370 368 STARTING AND OPERATING Left Lane Departure — Both Lane Lines Detected solid yellow. At this time torque is applied to the steering wheel in the opposite direction of the lane • When the LaneSense system is ON, the lane lines turn boundary.
Page 371: Changing Lanesense Status
STARTING AND OPERATING 369 this time torque is applied to the steering wheel in the (Early/Medium/Late) that you can configure through the opposite direction of the lane boundary. Uconnect system screen. Refer to “Uconnect Settings” in • For example: If approaching the left side of the lane the “Multimedia”...
Page 372 370 STARTING AND OPERATING NOTE: The ParkView Rear Back Up Camera has program- When the vehicle is shifted out of REVERSE (with camera mable modes of operation that may be selected through the delay turned on), the camera image will continue to be Uconnect System.
Page 373: Surround View Camera System - If Equipped
STARTING AND OPERATING 371 NOTE: If snow, ice, mud, or any foreign substance builds SURROUND VIEW CAMERA SYSTEM — IF up on the camera lens, clean the lens, rinse with water, and EQUIPPED dry with a soft cloth. Do not cover the lens. Your vehicle may be equipped with the Surround View Camera System that allows you to see an on-screen image WARNING!
Page 374 372 STARTING AND OPERATING displayed for up to 10 seconds after shifting out of RE- When enabled, active guide lines are overlaid on the image VERSE unless the vehicle speed exceeds 8 mph (13 km/h), to illustrate the width of the vehicle, including the side the vehicle is shifted into PARK or the ignition is switched view mirrors and its projected backup path based on the to the OFF position.
Page 375 STARTING AND OPERATING 373 Rear View This is the Default view of the system in REVERSE and is always paired with the Top view of the vehicle with optional active guide lines for the projected path when enabled. Rear Cross Path View Pressing the Rear Cross Path soft key will give the driver a wider angle view of the rear camera system.
Page 376 374 STARTING AND OPERATING Front Cross Path View WARNING! Pressing the Front Cross Path soft key Drivers must be careful when backing up even when will give the driver a wider angle view using the Surround View Camera. Always check care- of the front camera system.
Page 377: Refueling The Vehicle
STARTING AND OPERATING 375 REFUELING THE VEHICLE 1. Press the fuel filler door release button (located in the driver’s door). Instrument Cluster Message NOTE: • After pushing the release button you will have 20 minutes to fuel the vehicle, beyond 20 minutes you Fuel Filler Door Release Switch will need to press the release button again.
Page 378 376 STARTING AND OPERATING 3. Open the fuel filler door. 6. Fill the vehicle with fuel, when the fuel nozzle “clicks” or shuts off the fuel tank is full. 7. Wait five seconds before removing the fuel nozzle to allow fuel to drain from nozzle. 8.
Page 379 STARTING AND OPERATING 377 Emergency Fuel Door Release WARNING! 1. Access the storage bin located behind the rear cargo trim • Never have any smoking materials lit in or near the panel. vehicle when the fuel door is open or the tank is 2.
Page 380: Vehicle Loading
378 STARTING AND OPERATING included on this label and indicates the Month, Day and Hour of manufacture. The bar code that appears on the bottom of the label is your VIN. Gross Vehicle Weight Rating (GVWR) The GVWR is the total permissible weight of your vehicle including driver, passengers, vehicle, options and cargo.
Page 381 STARTING AND OPERATING 379 Tire Size The entire vehicle should first be weighed on a commercial scale to insure that the GVWR has not been exceeded. The The tire size on the Vehicle Certification Label represents weight on the front and rear of the vehicle should then be the actual tire size on your vehicle.
Page 382: Trailer Towing
380 STARTING AND OPERATING TRAILER TOWING Trailer towing is not permitted with this vehicle. RECREATIONAL TOWING Towing This Vehicle Behind Another Vehicle Towing Condition Wheel OFF the Ground All Models Flat Tow NONE NOT ALLOWED Dolly Tow Front Rear NOT ALLOWED On Trailer •...
Page 383: Recreational Towing - All Models
STARTING AND OPERATING 381 Recreational Towing — All Models 3. Apply the park brake. DO NOT flat tow this vehicle. Damage to the drivetrain 4. Place the transmission in PARK. will result. 5. Turn the ignition OFF. CAUTION! 6. Properly secure the front wheels to the dolly, following the dolly manufacturer’s instructions.
Page 384: Driving Through Water
382 STARTING AND OPERATING difference in the surface traction under the front (driving) 4. Keep tires properly inflated. wheels. 5. Maintain sufficient distance between your vehicle and the vehicle in front of you to avoid a collision in a WARNING! sudden stop.
Page 385 STARTING AND OPERATING 383 Shallow Standing Water CAUTION! Although your vehicle is capable of driving through shal- • Always check the depth of the standing water before low standing water, consider the following Cautions and driving through it. Never drive through standing Warnings before doing so.
Page 387 IN CASE OF EMERGENCY CONTENTS ▫ Road Tire Installation ....412 HAZARD WARNING FLASHERS ... .386 ASSIST AND 9–1–1 REARVIEW MIRROR —...
Page 388: Hazard Warning Flashers
386 IN CASE OF EMERGENCY HAZARD WARNING FLASHERS ASSIST AND 9–1–1 REARVIEW MIRROR — IF EQUIPPED The Hazard Warning flasher switch is located in the lower center area of the instrument panel. A single ball joint mirror is provided in the vehicle. It is a twist on mirror that has a fixed position at the windshield.
Page 389 IN CASE OF EMERGENCY 387 WARNING! (Continued) and Assist, will NOT work without an operable 1X(voice/data) or 3G(data) network connection. NOTE: • Your vehicle may be transmitting data as authorized by the subscriber. • The 9–1–1 and ASSIST buttons will only function if you are connected to an operable 1X(voice/data) or 3G(data) network.
Page 390 388 IN CASE OF EMERGENCY • Uconnect Access Customer Care – In-vehicle support for 3. Once a connection between the vehicle and a 9-1-1 Uconnect Access. operator is made, the 9-1-1 Call system may transmit the following important vehicle information to a 9-1-1 op- •...
Page 391 IN CASE OF EMERGENCY 389 NOTE: WARNING! (Continued) • Your vehicle may be transmitting data as authorized • Never place anything on or near the vehicle’s oper- by the subscriber. able 1X(voice/data) or 3G(data) network and GPS • Once a connection is made between the vehicle’s 9-1-1 antennas.
Page 392 390 IN CASE OF EMERGENCY WARNING! (Continued) WARNING! • Modifications to any part of the 9-1-1 Call system • Ignoring the Rearview Mirror light could mean you could cause the air bag system to fail when you need will not have 9-1-1 Call services. If the Rearview it.
Page 393 IN CASE OF EMERGENCY 391 • The vehicle battery loses power or becomes discon- NOTE: nected during a vehicle crash. • Your vehicle may be transmitting data as authorized by • 1X(voice/data) or 3G(data) network and/or Global Po- the subscriber. sitioning Satellite signals are unavailable or obstructed.
Page 394: Bulb Replacement
392 IN CASE OF EMERGENCY BULB REPLACEMENT Replacement Bulbs Interior Bulbs Lamps Bulb Number Center & Rear Dome Lamp LED (Serviced At Authorized Dealer) Center & Rear Reading Lamps LED (Serviced At Authorized Dealer) Front Door Courtesy Lamp LED (Serviced At Authorized Dealer) Front Header Reading Lamps –...
Page 395 IN CASE OF EMERGENCY 393 Lamps Bulb Number Dedicated Daytime Running Lamp (If Equipped) LED (Serviced at Authorized Dealer) Front Turn Signal Lamp PWY24WNA (If Halogen Headlamp Equipped) PWY24WSV (If HID Headlamp Equipped) Side Marker Lamp Front Park Lamp PWY24WNA (If Bulb Equipped) LED (Serviced At Authorized Dealer) Front Fog Lamp H11LL...
Page 396: Replacing Exterior Bulbs
394 IN CASE OF EMERGENCY Replacing Exterior Bulbs 3. Firmly grasp the headlamp bulb socket assembly and rotate counterclockwise to remove from the housing. Halogen Headlamps 1. Reach behind the headlamp housing to access the headlamp bulb cap. 2. Firmly grasp the headlamp bulb cap and rotate it counterclockwise to unlock it.
Page 397 IN CASE OF EMERGENCY 395 4. Disconnect the bulb from the electrical connector and 6. Install the headlamp bulb cap in the headlamp housing then connect the replacement bulb. and rotate clockwise to lock it in place. Front Turn Signal Lamp 1.
Page 398 396 IN CASE OF EMERGENCY 4. Install the front turn signal lamp socket assembly into the housing, and rotate the front turn signal lamp socket clockwise to lock it in place. Front And Rear Side Marker Lamps 1. Remove the three fasteners from the inner wheel liner and carefully peel back liner for access.
Page 399 IN CASE OF EMERGENCY 397 Front Fog Lamp — Halogen CAUTION! 1. Remove fasteners from inner wheel liner and carefully Do not touch the new bulb with your fingers. Oil peel back liner for access. contamination will severely shorten bulb life. If the 2.
Page 400: Fuses
398 IN CASE OF EMERGENCY Rear Bodyside Mounted Taillamps FUSES 1. Raise the liftgate. WARNING! 2. Remove two torx head screws on bodyside lamp using • When replacing a blown fuse, always use an appro- a T30 screwdriver. priate replacement fuse with the same amp rating as 3.
Page 401: Fuse Location
IN CASE OF EMERGENCY 399 When a device does not work, you must check the electri- Fuse Location cal circuit inside the fuse for a break/melt. The fuses are grouped into controllers located in the engine Also, please be aware that when using power outlets for compartment.
Page 402 400 IN CASE OF EMERGENCY Cavity Cartridge Fuse Blade Fuse Description – 15 Amp Blue Low Temp Active Pump – 25 Amp Clear Ignition Coil/Fuel Injector – 25 Amp Clear Amplifier / ANC – – Not Used – 15 Amp Blue High Temp Aux Pump &...
Page 403 IN CASE OF EMERGENCY 401 Cavity Cartridge Fuse Blade Fuse Description – – Not Used – – Not used – 20 Amp Yellow RR Wiper F25A – 10 Amp Red Handsfree (Lt & Rt Rear Door Release Module) F25B – Active Grill Shutter 40 Amp Green –...
Page 404 402 IN CASE OF EMERGENCY Cavity Cartridge Fuse Blade Fuse Description – – Not Used 40 Amp Green – CBC Feed #4 (Exterior Lighting / PCM #2) – – Not Used 25 Amp Clear – Rear HVAC Blower Motor 20 Amp Blue –...
Page 405 IN CASE OF EMERGENCY 403 Cavity Cartridge Fuse Blade Fuse Description – – Not Used – – Not Used 40 Amp Green – ESP-ECU And Valves F55A – 15 Amp Blue RF Hub/KIN/ESL - BUX Only F55B – DVD / VRM F56A –...
Page 406 404 IN CASE OF EMERGENCY Cavity Cartridge Fuse Blade Fuse Description – 15 Amp Blue Instrument Panel Cluster (IPC) – 10 Amp Red HALF / PTS / Drivers As- sist System Module (DASM) – – Not Used F69A – 15 Amp Blue BPCM F69B –...
Page 407 IN CASE OF EMERGENCY 405 Cavity Cartridge Fuse Blade Fuse Description F77A – 10 Amp Red Rear Entertainment / Me- dia Hub F77B – Sunroof / Rain Snsr / ECM / Pass WDO Sw En- able / EC Mirror / PIM F78A –...
Page 408 406 IN CASE OF EMERGENCY Cavity Cartridge Fuse Blade Fuse Description – 20 Amp Yellow Rear Heated Seats – 5 Amp Tan EBCM - ECU – 15 Amp Blue Front Ventilated Seats/ Heated Steering Wheel F92A – – Not Used F92B –...
Page 409: Jacking And Tire Changing
IN CASE OF EMERGENCY 407 JACKING AND TIRE CHANGING Preparations For Jacking NOTE: Your vehicle is not equipped with a jack or spare 1. Park the vehicle on a firm, level surface. Avoid ice or tire. This section describes wheel removal and installation. slippery areas.
Page 410: Jacking Instructions
408 IN CASE OF EMERGENCY Jacking Instructions WARNING! Carefully follow these tire changing warnings to help prevent personal injury or damage to your vehicle: • Always park on a firm, level surface as far from the edge of the roadway as possible before raising the vehicle.
Page 411 IN CASE OF EMERGENCY 409 Jack Locations Front Jack Location WARNING! Being under a jacked-up vehicle is dangerous. The vehicle could slip off the jack and fall on you. You could be crushed. Never get any part of your body under a vehicle that is on a jack.
Page 412 410 IN CASE OF EMERGENCY Front Jack Engaged Rear Jacking Location...
Page 413 IN CASE OF EMERGENCY 411 clearance is obtained to remove the desired tire. Mini- mum tire lift provides maximum stability. WARNING! Raising the vehicle higher than necessary can make the vehicle less stable. It could slip off the jack and hurt someone near it.
Page 414: Road Tire Installation
412 IN CASE OF EMERGENCY nut has been tightened twice. Refer to “Torque Specifi- cations” in “Technical Specifications” for proper wheel lug nut torque. If in doubt about the correct tightness, have them checked with a torque wrench by your authorized dealer or at a service station.
Page 415 IN CASE OF EMERGENCY 413 WARNING! To avoid the risk of forcing the vehicle off the jack, do not tighten the wheel nuts fully until the vehicle has been lowered. Failure to follow this warning may result in serious injury. 5.
Page 416: Tire Service Kit - If Equipped
414 IN CASE OF EMERGENCY 2. Install the remaining lug nuts with the cone shaped end 5. After 25 miles (40 km) check the lug nut torque with a of the nut toward the wheel. Lightly tighten the lug torque wrench to ensure that all lug nuts are properly nuts.
Page 417 IN CASE OF EMERGENCY 415 Tire Service Kit Storage Tire Service Kit And Components And Operation The Tire Service Kit is secured with a strap and is stored in the storage bin located behind the rear cargo trim panel. Tire Service Kit Components 1 —...
Page 418 416 IN CASE OF EMERGENCY Using The Mode Select Knob And Hoses Using The Power Button Your Tire Service Kit is equipped with the following Push and release the Power Button once symbols to indicate the air or sealant mode. to turn On the Tire Service Kit.
Page 419 IN CASE OF EMERGENCY 417 • The Sealant Bottle is a one tire application use and needs WARNING! to be replaced after each use. Always replace these • Do not attempt to seal a tire on the side of the vehicle components immediately at your original equipment vehicle dealer.
Page 420 418 IN CASE OF EMERGENCY This will allow the Tire Service Kit Hose to reach the WARNING! (Continued) valve stem and keep the Tire Service Kit flat on the • Take care not to allow the contents of Tire Service Kit ground.
Page 421 IN CASE OF EMERGENCY 419 4. Uncoil the Power Plug and insert the 2. Ensure the Mode Select Knob is to the plug into the vehicle’s 12 Volt power Sealant Mode position. outlet. NOTE: Do not remove foreign objects (e.g., screws or nails) 3.
Page 422 420 IN CASE OF EMERGENCY If the sealant (white fluid) does not flow within 0 – 10 If the sealant (white fluid) does flow through the Sealant seconds through the Sealant Hose: Hose: 1. Push the Power Button to turn Off the Tire Service Kit. 1.
Page 423 IN CASE OF EMERGENCY 421 If the tire does not inflate to at least 26 psi (1.8 Bar) Drive Vehicle: pressure within 15 minutes: Immediately after injecting sealant and • The tire is too badly damaged. Do not attempt to drive inflating the tire, drive the vehicle 5 the vehicle further.
Page 424 422 IN CASE OF EMERGENCY 1. Uncoil the Sealant Hose, and then remove the cap from 5. Uncoil the Hose and screw the fitting the fitting at the end of the hose. at the end of the hose onto the valve stem.
Page 425 IN CASE OF EMERGENCY 423 If the tire pressure is 19 psi (1.3 Bar) or higher: 6. Replace the Sealant Bottle at your authorized dealer as soon as possible. Refer to “Sealant Bottle Replacement”. 1. Push the Power Button to turn on Tire Service Kit and inflate the tire to NOTE: When having the tire serviced, advise the autho- the cold tire inflation pressure found...
Page 426 424 IN CASE OF EMERGENCY 3. Remove the bottle cover. Rotate The Bottle Up 5. Pull the bottle away from the Compressor. Remove The Bottle Cover 4. Rotate the bottle up beyond vertical to release.
Page 427: Jump-Starting
IN CASE OF EMERGENCY 425 JUMP-STARTING The vehicle requires its 12V battery power to turn-on the vehicle’s high voltage battery. The high voltage battery is used to charge the 12V battery, provide electric vehicle operation, and to start the vehicle’s gas engine. If the 12V battery has been discharged, the vehicle can be jump- started using a set of jumper cables and a battery in another vehicle or by using a portable battery booster pack.
Page 428: Preparations For Jump-Start
426 IN CASE OF EMERGENCY Carefully move the vehicle to a level 1 or Level 2 charge WARNING! location. While the vehicle is being moved, the external 12V power must remained connected to the vehicle Do not attempt jump starting if the battery is frozen. It jump posts.
Page 429 IN CASE OF EMERGENCY 427 WARNING! (Continued) • Remove any jewelry such as rings, watches and bracelets that could make an inadvertent electrical contact. • Keep open flames or sparks away from the battery. Batteries contain sulfuric acid that can burn your skin or eyes and generate hydrogen gas which is flammable and explosive.
Page 430: Jump-Starting Procedure
428 IN CASE OF EMERGENCY Jump-Starting Procedure 4. Connect the opposite end of the negative (-) jumper cable to the negative post near the windshield cowl (exposed metal post of the discharged vehicle). WARNING! Failure to follow this jump starting procedure could WARNING! result in personal injury or property damage due to battery explosion.
Page 431: Refueling In Emergency
IN CASE OF EMERGENCY 429 2. Disconnect the opposite end of the negative (-) jumper REFUELING IN EMERGENCY cable from the negative (-) post of the booster battery. The funnel for the Cap-Less Fuel System is located with the spare tire (if equipped) or in the upper storage bin. If your 3.
Page 432: Freeing A Stuck Vehicle
430 IN CASE OF EMERGENCY • You can also turn the temperature control to maximum FREEING A STUCK VEHICLE heat, the mode control to floor and the blower control to If your vehicle becomes stuck in mud, sand or snow, it can high.
Page 433: Towing A Disabled Vehicle
IN CASE OF EMERGENCY 431 WARNING! CAUTION! • When “rocking” a stuck vehicle by shifting between Fast spinning tires can be dangerous. Forces generated by excessive wheel speeds may cause damage, or even DRIVE and REVERSE, do not spin the wheels faster failure, of the axle and tires.
Page 434 432 IN CASE OF EMERGENCY structural members of the vehicle, not to bumpers or CAUTION! associated brackets. State and local laws regarding vehicles under tow must be observed. Towing this vehicle in violation of the above require- ments can cause severe transmission damage. Damage NOTE: from improper towing is not covered under the New •...
Page 435 IN CASE OF EMERGENCY 433 CAUTION! (Continued) • Be applied parallel to the center line of the length of the vehicle. • Not be an abrupt acceleration. If you must use the accessories (wipers, defrosters, etc.) while being towed, the ignition must be in the ON/RUN mode, not the ACC mode.
Page 436: Enhanced Accident Response System (Ears)
434 IN CASE OF EMERGENCY EVENT DATA RECORDER (EDR) CAUTION! (Continued) This vehicle is equipped with an Event Data Recorder • Ensure that the Electric Park Brake is released, and (EDR). The main purpose of an EDR is to record data that remains released, while being towed.
Page 437 SERVICING AND MAINTENANCE CONTENTS ▫ Windshield Wiper Blades ....449 SCHEDULED SERVICING ....437 ▫...
Page 438 436 SERVICING AND MAINTENANCE ▫ Body And Underbody Maintenance ..489 DEPARTMENT OF TRANSPORTATION UNIFORM TIRE QUALITY GRADES ....487 ▫...
Page 439: Scheduled Servicing
SERVICING AND MAINTENANCE 437 SCHEDULED SERVICING referring to “Vehicle Info” in “Instrument Cluster Display” in “Getting To Know Your Instrument Panel”. Your vehicle is equipped with an automatic oil change indicator system. The oil change indicator system will NOTE: Under no circumstances should oil change inter- remind you that it is time to take your vehicle in for vals exceed 10,000 miles (16,000 km), twelve months or 350 scheduled maintenance.
Page 440: Maintenance Plan
438 SERVICING AND MAINTENANCE Maintenance Plan At Every Oil Change Interval As Indicated By Oil Change Indicator System: Required Maintenance Intervals • Change oil and filter Refer to the maintenance schedules on the following page • Rotate the tires. Rotate at the first sign of irregular for the required maintenance intervals.
Page 441 SERVICING AND MAINTENANCE 439 Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Additional Inspections Inspect the CV joints. Inspect front suspension, boot seals, tie rod ends, and replace if necessary. Inspect the brake linings, parking brake function. Inspect front accessory drive belt, tensioner, idler pul- ley, and replace if necessary.
Page 442: Heavy Duty Use Of The Vehicle
440 SERVICING AND MAINTENANCE severe internal damage. If any coolant is needed to be Heavy Duty Use Of The Vehicle added to the system please contact your local authorized Change Engine Oil at 4,000 miles (6,500 km) if the vehicle dealer.
Page 443: Engine Compartment - Hybrid
SERVICING AND MAINTENANCE 441 ENGINE COMPARTMENT — HYBRID 1 — Battery Coolant Reservoir* 6 — Power Distribution Center (Fuses) 2 — Engine Coolant Reservoir 7 — Engine Air Cleaner 3 — Engine Oil Fill 8 — Engine Oil Dipstick 4 — Brake Fluid Reservoir 9 —...
Page 444: Checking Oil Level
442 SERVICING AND MAINTENANCE Checking Oil Level Adding Washer Fluid To assure proper engine lubrication, the engine oil must be maintained at the correct level. Check the oil level at regular intervals, such as every fuel stop. The best time to check the engine oil level is about five minutes after a fully warmed engine is shut OFF.
Page 445: Maintenance-Free Battery
SERVICING AND MAINTENANCE 443 To prevent freeze-up of your windshield washer system in WARNING! (Continued) cold weather, select a solution or mixture that meets or large amounts of water. Refer to “Jump-Starting exceeds the temperature range of your climate. This rating Procedure”...
Page 446: Dealer Service
444 SERVICING AND MAINTENANCE Engine Oil CAUTION! (Continued) Change Engine Oil • If a “fast charger” is used while the battery is in the vehicle, disconnect both vehicle battery cables before The oil change indicator system will remind you that it is connecting the charger to the battery.
Page 447 SERVICING AND MAINTENANCE 445 American Petroleum Institute (API) Engine Oil The engine oil filler cap also shows the recommended Identification Symbol engine oil viscosity for your engine. For information on engine oil filler cap location, refer to the “Engine Compart- ment”...
Page 448: Engine Oil Filter
446 SERVICING AND MAINTENANCE Disposing Of Used Engine Oil And Oil Filters NOTE: Be sure to follow the “Severe Duty Conditions” maintenance interval if applicable. Care should be taken in disposing of used engine oil and oil filters from your vehicle. Used oil and oil filters, WARNING! indiscriminately discarded, can present a problem to the environment.
Page 449: Accessory Drive Belt Inspection
SERVICING AND MAINTENANCE 447 Accessory Drive Belt Inspection WARNING! Keep hands, tools, clothing, and jewelry away from the radiator cooling fan when the hood is raised and disconnect the fan motor lead before working near the radiator cooling fan. The fan may come on without warning, whether the ignition is on or off.
Page 450: Air Conditioner Maintenance
448 SERVICING AND MAINTENANCE • Belt broken (note: identify and correct problem before WARNING! (Continued) new belt is installed) system. Some unapproved refrigerants are flam- • Noise (objectionable squeal, squeak, or rumble is heard mable and can explode, injuring you. Other unap- or felt while drive belt is in operation) proved refrigerants or lubricants can cause the sys- tem to fail, requiring costly repairs.
Page 451: Body Lubrication
SERVICING AND MAINTENANCE 449 a low global-warming potential. The manufacturer recom- Windshield Wiper Blades mends that air conditioning service be performed by Clean the rubber edges of the wiper blades and the authorized dealer using recovery and recycling equipment. windshield periodically with a sponge or soft cloth and a mild nonabrasive cleaner.
Page 452 450 SERVICING AND MAINTENANCE • Hardening Or Cracking • Deformation Or Fatigue If a wiper blade or wiper arm is damaged, replace the affected wiper arm or blade with a new unit. Do not attempt to repair a wiper arm or blade that is damaged. Front Wiper Blade Removal/Installation CAUTION! Do not allow the wiper arm to spring back against the...
Page 453 SERVICING AND MAINTENANCE 451 Wiper Blade With Release Tab In Unlocked Position Wiper Blade Removed From Wiper Arm 1 — Wiper Blade 1 — Wiper Blade 2 — Release Tab 2 — Wiper Arm 3 — Wiper Arm 3 — Release Tab 3.
Page 454 452 SERVICING AND MAINTENANCE Installing The Front Wipers NOTE: The rear wiper arm cannot be fully raised off the glass unless the wiper arm pivot cap is unsnapped first. Attempting 1. Lift the wiper arm off of the glass, until the wiper arm is to fully raise the rear wiper arm without unsnapping the in the full up position.
Page 455 SERVICING AND MAINTENANCE 453 NOTE: Resistance will be accompanied by an audible snap. 4. Still grasping the bottom end of the wiper blade, move the wiper blade upward and away from the wiper arm to disengage. Wiper Blade In Folded Out Position 1 —...
Page 456: Exhaust System
454 SERVICING AND MAINTENANCE Installing The Rear Wiper If you notice a change in the sound of the exhaust system; or if the exhaust fumes can be detected inside the vehicle; 1. Lift the rear wiper arm pivot cap away from the glass to or when the underside or rear of the vehicle is damaged;...
Page 457: Cooling System
SERVICING AND MAINTENANCE 455 In unusual situations involving grossly malfunctioning CAUTION! engine operation, a scorching odor may suggest severe and • The catalytic converter requires the use of unleaded abnormal catalyst overheating. If this occurs, stop the vehicle, turn off the engine and allow it to cool. Service, fuel only.
Page 458 456 SERVICING AND MAINTENANCE This vehicle is equipped with an electric cooling fan WARNING! (Continued) mounted behind the radiator that starts automatically, and • You or others can be badly burned by hot engine may start at any time. Your vehicle may determine the fan coolant (antifreeze) or steam from your radiator.
Page 459 SERVICING AND MAINTENANCE 457 coolant recovery bottle and radiator. Inspect the entire cooling systems. If the coolant level of the battery coolant system for leaks. DO NOT REMOVE THE COOLANT system is low, the wrench warning light will be illuminated PRESSURE CAP WHEN THE COOLING SYSTEM IS HOT.
Page 460 458 SERVICING AND MAINTENANCE Please review these recommendations for using Organic CAUTION! (Continued) Additive Technology (OAT) coolant (antifreeze) that meets • Do not use water alone or alcohol-based engine the requirements of FCA Material Standard MS.90032. coolant (antifreeze) products. Do not use additional When adding coolant (antifreeze): rust inhibitors or antirust products, as they may not •...
Page 461 SERVICING AND MAINTENANCE 459 NOTE: WARNING! • Mixing coolant (antifreeze) types is not recommended • Do not open hot engine cooling system. Never add and can result in cooling system damage. If HOAT and engine coolant (antifreeze) when the engine is over- OAT coolant are mixed in an emergency, have a autho- heated.
Page 462 460 SERVICING AND MAINTENANCE Coolant Level If an examination of your engine compartment shows no evidence of radiator or hose leaks, the vehicle may be The coolant expansion bottle provides a quick visual safely driven. The vapor will soon dissipate. method for determining that the coolant level is adequate.
Page 463: Brake System
SERVICING AND MAINTENANCE 461 • Keep the front of the radiator clean. If your vehicle is to the “Maintenance Plan” in this section for the proper equipped with air conditioning, keep the front of the maintenance intervals. condenser clean. WARNING! •...
Page 464: Automatic Transmission
462 SERVICING AND MAINTENANCE Use only manufacturer’s recommended brake fluid. Refer WARNING! (Continued) to “Fluids And Lubricants” in “Technical Specifications” • Overfilling the brake fluid reservoir can result in for further information. spilling brake fluid on hot engine parts, causing the brake fluid to catch fire.
Page 465 SERVICING AND MAINTENANCE 463 Fluid Level Check CAUTION! The fluid level is preset at the factory and does not require Using a transmission fluid other than the manufactur- adjustment under normal operating conditions. Routine er’s recommended fluid may cause deterioration in fluid level checks are not required;...
Page 466: Raising The Vehicle
464 SERVICING AND MAINTENANCE Routine fluid changes are not required. However, change Tire Markings the fluid if it becomes contaminated (with water, etc.), or if the transmission is disassembled for any reason. RAISING THE VEHICLE In the case where it is necessary to raise the vehicle, go to an authorized dealer or service station.
Page 467 SERVICING AND MAINTENANCE 465 • Temporary spare tires are designed for temporary emer- NOTE: gency use only. Temporary high pressure compact spare • P (Passenger) — Metric tire sizing is based on U.S. tires have the letter “T” or “S” molded into the sidewall design standards.
Page 468 466 SERVICING AND MAINTENANCE Tire Sizing Chart EXAMPLE: Example Size Designation: P215/65R15XL 95H, 215/65R15 96H, LT235/85R16C, T145/80D18 103M, 31x10.5 R15 LT P = Passenger car tire size based on U.S. design standards, or ..blank..= Passenger car tire based on European design standards, or LT = Light truck tire based on U.S.
Page 469 SERVICING AND MAINTENANCE 467 EXAMPLE: H = Speed Symbol – A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under cer- tain operating conditions – The maximum speed corresponding to the speed symbol should only be achieved under specified operating condi- tions (i.e., tire pressure, vehicle loading, road conditions, and posted speed limits) Load Identification: Absence of the following load identification symbols on the sidewall of the tire indicates a Standard Load (SL) tire:...
Page 470 468 SERVICING AND MAINTENANCE Tire Identification Number (TIN) the TIN on the outboard side of black sidewall tires as mounted on the vehicle. If the TIN is not found on the The TIN may be found on one or both sides of the tire; outboard side, then you will find it on the inboard side of however, the date code may only be on one side.
Page 471 SERVICING AND MAINTENANCE 469 Tire Terminology And Definitions Term Definition B-Pillar The vehicle B-Pillar is the structural member of the body located be- hind the front door. Cold Tire Inflation Pressure Cold tire inflation pressure is defined as the tire pressure after the vehicle has not been driven for at least three hours, or driven less than 1 mile (1.6 km) after sitting for a minimum of three hours.
Page 472 470 SERVICING AND MAINTENANCE Tire Loading And Tire Pressure NOTE: The proper cold tire inflation pressure is listed on the driver’s side B-Pillar or the rear edge of the driver’s side door. Example Tire Placard Location (B-Pillar) Example Tire Placard Location (Door)
Page 473 SERVICING AND MAINTENANCE 471 Tire And Loading Information Placard Loading The vehicle maximum load on the tire must not exceed the load carrying capacity of the tire on your vehicle. You will not exceed the tire’s load carrying capacity if you adhere to the loading conditions, tire size, and cold tire inflation pressures specified on the Tire and Loading Information placard in “Vehicle Loading”...
Page 474 472 SERVICING AND MAINTENANCE Steps For Determining Correct Load Limit— this manual to determine how this reduces the available cargo and luggage load capacity of your vehicle. (1) Locate the statement “The combined weight of occupants and cargo should never exceed XXX kg or Metric Example For Load Limit XXX lbs.”...
Page 475 SERVICING AND MAINTENANCE 473 WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the rec- ommended load capacity for your vehicle. Never over- load them.
Page 476: Tires - General Information
474 SERVICING AND MAINTENANCE Tires — General Information WARNING! (Continued) Tire Pressure • Overinflated or underinflated tires can affect vehicle handling and can fail suddenly, resulting in loss of Proper tire inflation pressure is essential to the safe and vehicle control. satisfactory operation of your vehicle.
Page 477 SERVICING AND MAINTENANCE 475 Fuel Economy CAUTION! Underinflated tires will increase tire rolling resistance After inspecting or adjusting the tire pressure, always resulting in higher fuel consumption. reinstall the valve stem cap. This will prevent moisture Tread Wear and dirt from entering the valve stem, which could damage the valve stem.
Page 478 476 SERVICING AND MAINTENANCE pressure should be increased by 3 psi (21 kPa), which Radial Ply Tires equals 1 psi (7 kPa) for every 12°F (7°C) for this outside temperature condition. WARNING! Tire pressure may increase from 2 to 6 psi (13 to 40 kPa) Combining radial ply tires with other types of tires on during operation.
Page 479 SERVICING AND MAINTENANCE 477 Run Flat Tires — If Equipped Tire Spinning Run Flat tires allow you the capability to drive 50 miles When stuck in mud, sand, snow, or ice conditions, do not (80 km) at 50 mph (80 km/h) after a rapid loss of inflation spin your vehicle’s wheels above 30 mph (48 km/h) or for pressure.
Page 480 478 SERVICING AND MAINTENANCE Tread Wear Indicators worn to the tread wear indicators, the tire should be replaced. Refer to “Replacement Tires” in this section for Tread wear indicators are in the original equipment tires to further information. help you in determining when your tires should be re- placed.
Page 481 SERVICING AND MAINTENANCE 479 It is recommended to replace the two front tires or two rear WARNING! (Continued) tires as a pair. Replacing just one tire can seriously affect You could lose control and have a collision resulting in your vehicle’s handling. If you ever replace a wheel, make serious injury or death.
Page 482: Tire Types
480 SERVICING AND MAINTENANCE tire sidewall. Use all season tires only in sets of four; failure WARNING! (Continued) to do so may adversely affect the safety and handling of • Never use a tire with a smaller load index or capacity, your vehicle.
Page 483: Spare Tires - If Equipped
SERVICING AND MAINTENANCE 481 Snow Tires Spare Tires — If Equipped Some areas of the country require the use of snow tires NOTE: For vehicles equipped with Tire Service Kit instead during the Winter. Snow tires can be identified by a of a spare tire, please refer to “Tire Service Kit”...
Page 484 482 SERVICING AND MAINTENANCE Compact Spare Tire — If Equipped WARNING! (Continued) The compact spare is for temporary emergency use only. You more than 50 mph (80 km/h). Temporary use spares can identify if your vehicle is equipped with a compact spare have limited tread life.
Page 485 SERVICING AND MAINTENANCE 483 Do not install a wheel cover or attempt to mount a Limited Use Spare — If Equipped conventional tire on the collapsible spare wheel, since the The limited use spare tire is for temporary emergency use wheel is designed specifically for the collapsible spare tire.
Page 486: Wheel And Wheel Trim Care
484 SERVICING AND MAINTENANCE Wheel And Wheel Trim Care CAUTION! (Continued) All wheels and wheel trim, especially aluminum and covered by the New Vehicle Limited Warranty. Only chrome plated wheels, should be cleaned regularly using car wash soap, Mopar Wheel Cleaner or equivalent is mild (neutral Ph) soap and water to maintain their luster recommended.
Page 487: Tire Chains (Traction Devices)
SERVICING AND MAINTENANCE 485 • Install on front tires only. NOTE: If you intend parking or storing your vehicle for an extended period after cleaning the wheels with wheel • For a 235/65R17 or 235/60R18 tire, use of a snow cleaner, drive your vehicle for a few minutes before doing traction device with a maximum projection of 9 mm so.
Page 488: Tire Rotation Recommendations
486 SERVICING AND MAINTENANCE Refer to the “Scheduled Servicing” for the proper mainte- CAUTION! (Continued) nance intervals. The reasons for any rapid or unusual wear • Do not exceed 30 mph (48 km/h). should be corrected prior to rotation being performed. •...
Page 489: Department Of Transportation Uniform Tire Quality Grades
SERVICING AND MAINTENANCE 487 DEPARTMENT OF TRANSPORTATION UNIFORM on wet pavement, as measured under controlled condi- tions on specified government test surfaces of asphalt TIRE QUALITY GRADES and concrete. A tire marked C may have poor traction The following tire grading categories were established performance.
Page 490: Storing The Vehicle
488 SERVICING AND MAINTENANCE • Clean and protect the painted parts by applying protec- Vehicle Safety Standard No. 109. Grades B and A repre- sent higher levels of performance on the laboratory test tive waxes. wheel, than the minimum required by law. •...
Page 491: Bodywork
SERVICING AND MAINTENANCE 489 NOTE: The hybrid has feature of periodic wake-up that cold weather and other extreme conditions will have an occurs every 21 days. This feature charges the 12V battery adverse effect on paint, metal trim, and underbody protec- from the high voltage battery.
Page 492: Preserving The Bodywork
490 SERVICING AND MAINTENANCE Plastic is not as scratch resistant as glass and therefore CAUTION! different lens cleaning procedures must be followed. • Do not use abrasive or strong cleaning materials such To minimize the possibility of scratching the lenses and as steel wool or scouring powder that will scratch reducing light output, avoid wiping with a dry cloth.
Page 493: Interiors
SERVICING AND MAINTENANCE 491 • If you carry special cargo such as chemicals, fertilizers, If the belts need cleaning, use a mild soap solution or de-icer salt, etc., be sure that such materials are well lukewarm water. Do not remove the belts from the vehicle to wash them.
Page 494: Leather Parts
492 SERVICING AND MAINTENANCE soils can be removed easily with a soft cloth and Mopar CAUTION! (Continued) Total Clean. Care should be taken to avoid soaking your • Damage caused by these type of products may not be leather upholstery with any liquid. Please do not use covered by your New Vehicle Limited Warranty.
Page 495: Glass Surfaces
SERVICING AND MAINTENANCE 493 Glass Surfaces All glass surfaces should be cleaned on a regular basis with Mopar Glass Cleaner, or any commercial household-type glass cleaner. Never use an abrasive type cleaner. Use caution when cleaning the inside rear window equipped with electric defrosters or windows equipped with radio antennas.
Page 497: Technical Specifications
TECHNICAL SPECIFICATIONS CONTENTS ▫ CNG And LP Fuel System Modifications ..499 IDENTIFICATION DATA....496 ▫ Vehicle Identification Number ... . .496 ▫...
Page 498: Identification Data
496 TECHNICAL SPECIFICATIONS IDENTIFICATION DATA WHEEL AND TIRE TORQUE SPECIFICATIONS Proper lug nut/bolt torque is very important to ensure that Vehicle Identification Number the wheel is properly mounted to the vehicle. Any time a The Vehicle Identification Number (VIN) is on the left front wheel has been removed and reinstalled on the vehicle, the corner of the instrument panel and is visible from outside lug nuts/bolts should be torqued using a properly cali-...
Page 499 TECHNICAL SPECIFICATIONS 497 Wheel Mounting Surface Torque Patterns Tighten the lug nuts/bolts in a star pattern until each After 25 miles (40 km) check the lug nut/bolt torque to be nut/bolt has been tightened twice. sure that all the lug nuts/bolts are properly seated against the wheel.
Page 500: Fuel Requirements
498 TECHNICAL SPECIFICATIONS FUEL REQUIREMENTS Reformulated Gasoline Many areas of the country require the use of cleaner burning These engines are designed to meet all gasoline referred to as “Reformulated Gasoline”. Reformu- emissions regulations and provide opti- lated gasoline contains oxygenates and are specifically mum fuel economy and performance blended to reduce vehicle emissions and improve air quality.
Page 501: Gasoline/Oxygenate Blends
TECHNICAL SPECIFICATIONS 499 Indiscriminate use of fuel system cleaning agents should be CNG And LP Fuel System Modifications avoided. Many of these materials intended for gum and Modifications that allow the engine to run on compressed varnish removal may contain active solvents or similar natural gas (CNG) or liquid propane (LP) may result in ingredients.
Page 502: Fuel System Cautions
500 TECHNICAL SPECIFICATIONS Fuel System Cautions NOTE: Intentional tampering with the emissions control system can result in civil penalties being assessed against you. CAUTION! Carbon Monoxide Warnings Follow these guidelines to maintain your vehicle’s performance: • The use of leaded gasoline is prohibited by Federal WARNING! law.
Page 503: Fluid Capacities
TECHNICAL SPECIFICATIONS 501 FLUID CAPACITIES U.S. Metric Fuel (Approximate) 3.6L Engines 16.5 Gallons 62 Liters Engine Oil With Filter 3.6 Liter Engine (SAE 0W-20 , API 5 quarts 4.7 liters Certified) Cooling System* 3.6 Liter Engine Coolant (Mopar 14.5 Quarts 13.7 Liters Antifreeze/Engine Coolant 10 Year/ 150,000 Mile Formula with deionized,...
Page 504: Fluids And Lubricants
502 TECHNICAL SPECIFICATIONS FLUIDS AND LUBRICANTS Engine Component Fluid, Lubricant, or Genuine Part Engine Coolant We recommend you use Mopar Antifreeze/Coolant 10 Year/150,000 Mile Formula OAT (Organic Additive Tech- nology) with deionized, or distilled water for proper cor- rosion protection or equivalent meeting the requirements of FCA Material Standard MS.90032.
Page 505 TECHNICAL SPECIFICATIONS 503 Component Fluid, Lubricant, or Genuine Part Engine Oil Filter We recommend you use a Mopar Engine Oil Filter. Spark Plugs We recommend you use Mopar Spark Plugs. Fuel Selection 87 Octane, 0-15% Ethanol. CAUTION! CAUTION! (Continued) • Do not use water alone or alcohol-based engine •...
Page 506: Chassis
504 TECHNICAL SPECIFICATIONS Chassis Component Fluid, Lubricant, or Genuine Part Automatic Transmission Use only Mopar ZF 8&9 Speed ATF Automatic Transmis- sion Fluid, or equivalent. Failure to use the correct fluid may affect the function or performance of your transmission. Brake Master Cylinder We recommend you use Mopar DOT 3 Brake Fluid, SAE J1703 should be used.
Page 507 MULTIMEDIA CONTENTS ▫ Accessing The System From The Uconnect Theater UCONNECT RADIOS ....507 Rear Screens ......538 PERSONALIZED MENU BAR .
Page 508 506 MULTIMEDIA ▫ Display Settings ......554 ▫ Phone .......569 ▫...
Page 509: Uconnect Radios
MULTIMEDIA UCONNECT RADIOS The new shortcut will now be an active App/shortcut on the main menu bar. For detailed information about your Uconnect radio, refer to your Uconnect Owner’s Manual Supplement. CYBERSECURITY PERSONALIZED MENU BAR Your vehicle may be a connected vehicle and may be equipped with both wired and wireless networks.
Page 510 508 MULTIMEDIA NOTE: WARNING! • FCA US LLC or your dealer may contact you directly • It is not possible to know or to predict all of the regarding software updates. possible outcomes if your vehicle’s systems are • To help further improve vehicle security and minimize breached.
Page 511: Uconnect Settings
MULTIMEDIA UCONNECT SETTINGS Customer Programmable Features — Uconnect 8.4 Settings The Uconnect system uses a combination of buttons on the touchscreen and/or buttons on the faceplate located on the center of the instrument panel that allow you to access and change the customer programmable features.
Page 512 510 MULTIMEDIA NOTE: Arrow button on the right side of the screen will allow you to toggle up or down through the available settings. • Only one touchscreen area may be selected at a time. KeySense • Depending on the vehicles options, feature settings may vary.
Page 513 MULTIMEDIA Setting Name Selectable Options Front ParkSense Volume Medium High Rear ParkSense Volume Medium High Rear ParkSense Braking Assist Blind Spot Alert — If Lights Lights & Chime Equipped NOTE: When the “Blind Spot Alert” feature is selected, it will alert, visibly and/or audibly, to indicate objects are in your blind spot.
Page 514 512 MULTIMEDIA Setting Name Selectable Options SiriusXM Setup Channel Skip Subscription Information NOTE: SiriusXM can be programmed to skip channels. To make your selection, press the “Channel Skip” button on the touchscreen, select the channels you would like to skip. New vehicle purchasers or lessees will receive a free limited time subscription to SiriusXM Satellite Radio with your radio.
Page 515 MULTIMEDIA Setting Name Selectable Options Display Brightness With Headlights ON NOTE: To make changes to the Display Brightness with Headlights ON setting, the headlights must be on and the interior dimmer switch must not be in the party or parade positions. Display Brightness With Headlights OFF NOTE:...
Page 516 514 MULTIMEDIA Setting Name Selectable Options Set Language NOTE: When the “Set Language” feature is selected, you may select one of multiple languages (English / Français / Espa- ñol) for all display nomenclature, including the trip functions and the navigation system (if equipped). Press the “Set Language”...
Page 517 MULTIMEDIA Units After pressing the “Units” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Units Custom NOTE: The “Custom” option allows you to set the “Speed” (MPH, or km/h), “Distance” (mi, or km), “Fuel Consumption” [MPG (US), MPG (UK), L/100 km, or km/L], “Pressure”...
Page 518 516 MULTIMEDIA Clock After pressing the “Clock” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Sync Time With GPS — If Equipped Set Time Hours NOTE: The “Set Time Hours” feature will allow you to adjust the hours. The “Sync time with GPS” button on the touch- screen must be unchecked.
Page 519 MULTIMEDIA Safety & Driving Assistance After pressing the “Safety & Driving Assistance” button on the touchscreen, the following settings will be available: Setting Name Selectable Options ParkView Backup Camera Delay — If Equipped NOTE: The “ParkView Backup Camera Delay” setting determines whether or not the screen will display the rear view image with dynamic grid lines for up to ten seconds after the vehicle is shifted out of REVERSE.
Page 520 518 MULTIMEDIA Setting Name Selectable Options Surround View Camera NOTE: The “Surround View Camera” feature displays a complete 360 degree view of the vehicle’s exterior environment while backing up. Surround View Camera Delay NOTE: The “Surround View Camera Delay” setting determines whether or not the screen will display the 360 degree view image with guidelines for up to ten seconds after the vehicle is shifted out of REVERSE.
Page 521 MULTIMEDIA Setting Name Selectable Options Forward Collision Warn- ing On/Off — If Equipped NOTE: Changing the FCW status to “Off” prevents the system from warning you of a possible collision with the vehicle in front of you. The FCW system state is kept in memory from one ignition cycle to the next. If the system is turned OFF, it will re- main off when the vehicle is restarted.
Page 522 520 MULTIMEDIA Setting Name Selectable Options Rear ParkSense Volume Medium High Front ParkSense Volume Medium High Rear ParkSense Braking Assist — If Equipped NOTE: When the “Rear ParkSense Braking Assist” feature is selected, the park assist system will detect objects located be- hind the vehicle and utilize autonomous braking to stop the vehicle.
Page 523 MULTIMEDIA Setting Name Selectable Options Blind Spot Alert — If Lights Lights and Chime Equipped NOTE: When the “Blind Spot Alert” feature is selected, the Blind Spot Monitor (BSM) system is activated and will show a visual alert in the outside mirrors, or it will show a visual alert in the outside mirrors as well as play an audible alert when the turn signal is on.
Page 524 522 MULTIMEDIA Lights After pressing the “Lights” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Headlight Off Delay 0 sec 30 sec 60 sec 90 sec NOTE: When the “Headlight Off Delay” feature is selected, it allows the adjustment of the amount of time the headlights remain on after the vehicle is shut off.
Page 525 MULTIMEDIA Setting Name Selectable Options Auto Dim High Beams— If Equipped NOTE: When the “Auto Dim High Beams” feature is selected, the high beam headlights will activate/deactivate automati- cally under certain conditions. Daytime Running Lights Flash Lights With Lock Doors & Locks After pressing the “Doors &...
Page 526 524 MULTIMEDIA Setting Name Selectable Options Personal Settings Linked to Key Fob — If Equipped NOTE: The “Personal Seetings Linked to Key Fob” feature provides automatic recall of all settings stored to a memory loca- tion (driver’s seat, exterior mirrors, steering column position and radio station pre-sets) to enhance driver mobility when entering and exiting the vehicle.
Page 527 MULTIMEDIA Setting Name Selectable Options Auto Unlock On Exit NOTE: When the “Auto Unlock On Exit” feature is selected, all doors will unlock when the vehicle is stopped and the trans- mission is in the PARK or NEUTRAL position and the driver’s door is opened. Flash Lights With Lock Sound Horn With Lock 1st Press...
Page 528 526 MULTIMEDIA Auto Comfort Systems — If Equipped After pressing the “Auto-On Comfort” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Auto-On Driver Heated/ Remote Start All Starts Ventilated Seat & Steering Wheel With Vehicle Start —...
Page 529 MULTIMEDIA Vehicle Off Options After pressing the “Engine Off Options” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Vehicle Off Power 0 sec 45 sec 5 min 10 min Delay — If Equipped NOTE: When the “Vehicle Off Power Delay”...
Page 530 528 MULTIMEDIA Audio After pressing the “Audio” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Balance/Fade Speaker Icon NOTE: When in this display you may adjust the “Balance/Fade” of the audio by pressing and dragging the “Speaker Icon” toward any location in the box.
Page 531 MULTIMEDIA Phone/Bluetooth After pressing the “Phone/Bluetooth” button on the touch- screen, the following settings will be available: Setting Name Selectable Options Paired Phones List Of Paired Phones NOTE: This feature shows which phones are paired to the Phone/Bluetooth system. For further information, refer to the Uconnect Owner’s Manual Supplement.
Page 532 530 MULTIMEDIA Setting Name Selectable Options Subscription Info Sirius ID NOTE: New vehicle purchasers or lessees will receive a free limited time subscription to SiriusXM Satellite Radio with your radio. Following the expiration of the free services, it will be necessary to access the information on the Subscription Information screen to re-subscribe.
Page 533 MULTIMEDIA Restore Settings After pressing the “Restore Settings” button on the touch- screen, the following settings will be available: Setting Name Selectable Options Restore Settings Cancel NOTE: When the “Restore Settings” feature is selected it will reset all settings to their default settings. Clear Personal Data After pressing the “Clear Personal Data”...
Page 534: Steering Wheel Audio Controls
532 MULTIMEDIA System Information After pressing the “System Information” button on the touchscreen, the following settings will be available: Setting Name Selectable Options System Information System Software Information Screen NOTE: When this feature is selected, a “System Information” screen will appear, displaying the system software version. STEERING WHEEL AUDIO CONTROLS The remote sound system controls are located on the rear surface of the steering wheel at the three and nine o’clock...
Page 535: Radio Operation
MULTIMEDIA The right-hand control is a rocker-type switch with a AUX/USB/MP3 CONTROL push-button in the center and controls the volume and There are numerous USB ports located throughout the mode of the sound system. Pushing the top of the rocker vehicle.
Page 536 534 MULTIMEDIA There are multiple USB “charge only” ports in this vehicle. • In the center console • On the back of the front row seats in the Uconnect Theater Media hubs • Above the rear cup holders in the third row of seats Rear USB Charging Ports NOTE: The USB “Charge Only”...
Page 537: Uconnect Theater - If Equipped
MULTIMEDIA UCONNECT THEATER — IF EQUIPPED Getting Started Uconnect Theater Overview Your Uconnect Theater is designed to give your family years of enjoyment. There are multiple ways to interact with your Uconnect Theater system. • Play your favorite CDs, DVDs or Blu-ray Discs •...
Page 538: Accessing The System From The Uconnect Radio
536 MULTIMEDIA Accessing The System From The Uconnect Radio You can access your Uconnect Theater system from the radio touchscreen following the steps below: Option 1 1. Press the “Media” button. 2. Press the “Uconnect Theater” button icon. Option 2 1.
Page 539: Uconnect Theater Controls
MULTIMEDIA Uconnect Theater Controls Parents can control certain features of the system with the “Uconnect Theater Controls” screens, right from the Uconnect touchscreen radio. Options are: • Change media sources • Lock one or both screens • Mute an individual screen or both screens •...
Page 540: Accessing The System From The Uconnect Theater Rear Screens
538 MULTIMEDIA Press this button and use the “Listen In” feature to listen to NOTE: audio through cabin speakers. • There will be a touchscreen notification message when pairing is successful. Refer to “Pairing The Remote” on Accessing The System From The Uconnect the full procedure of how to pair the remotes.
Page 541: Pairing The Remote
MULTIMEDIA Pairing The Remote 4. Press the “Remote” button on the Uconnect Theater touchscreen found in the settings menu. 5. Press the “Manage Remote Controls” button and con- firm that there are no remotes already paired to the system. 6. Push the back arrow button on the Remote to go back to the remote menu.
Page 542: Unpairing The Remote
540 MULTIMEDIA Unpairing The Remote Media Sources In events such as updating the Uconnect Theater software, or taking a remote to another vehicle, the remote will need to be unpaired from your Uconnect Theater system. To unpair the remote, follow the procedure below: 1.
Page 543: Uconnect Theater Remote Control
MULTIMEDIA NOTE: Use the “View Screen” function to pull content 3. Home Button — Push to access “Sources”. from one screen to the other in a single press of a button. 4. Arrow Buttons — Push the arrow buttons Doing this however will disable and gray out certain to highlight an item or scroll through menus.
Page 544: Uconnect Theater Home Screen And Controls
542 MULTIMEDIA 12. Screen Indicator — Indicates which screen (1 or 2) is Uconnect Theater Home Screen And Controls being controlled by the remote control when a button is pushed. Replacing The Remote Control Batteries Each remote control requires two AAA batteries for opera- tion.
Page 545 MULTIMEDIA General Settings To change source card order, select “Source Card Reorder”, then press and hold source card on the touchscreen, and drag and drop in desired order. You can also adjust the following below and more. • Brightness • Media port lighting on and off •...
Page 546: Play A Dvd/Blu-Ray Or Usb Media File From Uconnect System
544 MULTIMEDIA Play A DVD/Blu-ray Or USB Media File From 4. For DVD/Blu-ray disc – press Movie Snapshot on radio touchscreen, then press “OK” on following screen. For Uconnect System USB Media Files - Press Music, Movie, or Folders, then 1.
Page 547 MULTIMEDIA Source Controls — Uconnect Radio Media Control Screen NOTE: Control functions apply to individual screen se- lected displayed on touchscreen. 1. Power Press to turn “Selected Screen” On/Off.
Page 548: Blu-Ray Controls - Disc Specific Functions
546 MULTIMEDIA 2. Mute Blu-ray Controls – Disc Specific Functions Mute rear headphones for selected source for the current The four colored buttons (red, green, blue, yellow) are ignition cycle. Pressing mute again will unmute rear head- designed for use with certain Blu-ray disc movie titles to phones.
Page 549: Uconnect Theater Apps
MULTIMEDIA Uconnect Theater Apps Blu-ray Controls – Disc Specific Functions Apps Home Screen 1 — Red Button 4 — Yellow Button 2 — Green Button 5 — 5-Way Control Buttons 3 — Blue Button...
Page 550 548 MULTIMEDIA • Sudoku • Tic Tac Toe NOTE: To exit a game, push “Exit Button” then “Back Arrow,” or “Home Button” on the touchscreen. Are We There Yet? — Uconnect 8.4 NAV Sudoku App Home Screen Select the Apps source card to play pre-loaded games. Pressing the “Help”...
Page 551: Using The Rear Video Usb Port
MULTIMEDIA When a navigation route has been set from the Uconnect Using The Rear Video USB Port radio, the second row passengers can use “Are We There Yet?” for an animated screen showing distance and time remaining on navigation routes as well as the estimated time of arrival with pop-up notifications.
Page 552: Play Video Games
550 MULTIMEDIA Search Screen AUX/HDMI/USB Use the search feature to find your music faster. 1 — AUX Jack (Headphone Output Only) 2 — HDMI Port Play Video Games 3 — USB Port (Charge Only) Connect the video game console to the HDMI 1 or 2 ports, located behind the first row seat.
Page 553: Headphones Operation
MULTIMEDIA Headphones Operation The headphones receive two separate channels of audio using an infrared transmitter from the video screens. If no audio is heard after increasing the volume control, verify that the screen is turned on, the channel is not muted, the headphones are on, and that the headphone channel selector button is on the desired channel.
Page 554 552 MULTIMEDIA Changing The Audio Mode For Headphones Replacing The Headphone Batteries Each set of headphones requires two AAA batteries for 1. Ensure the remote control and the headphones are on operation. the same channel. To replace the batteries: 2. Push the Home button on the remote control. 1.
Page 555: Disc Menu
MULTIMEDIA What Does This Warranty Cover? Except as specified Delphi Automotive reserves the right to replace any dis- below, this warranty covers any Product that in normal use continued Product with a comparable model. THIS WAR- is defective in workmanship or materials. RANTY IS THE SOLE WARRANTY FOR THIS PRODUCT, SETS FORTH YOUR EXCLUSIVE REMEDY REGARDING What Does This Warranty Not Cover? This warranty does...
Page 556: Display Settings
554 MULTIMEDIA used to select specific chapters in a movie, navigate special Listening To Audio With The Screen Closed features, or to play the movie from the menu. To listen to only audio portion of the channel with the screen closed: NOTE: Inserting a disc into the player will “auto play”...
Page 557: Rear Climate Controls
MULTIMEDIA Rear Climate Controls The rear climate controls can also be controlled using the Uconnect Theater system. Refer to “Climate Controls” in “Getting To Know Your Vehicle” for further information. Rear Climate Controls Icon Description ON Button Press and release this button to turn the Rear Climate Controls on. Climate Control OFF Button Press and release this button to turn the Climate Controls off.
Page 558 556 MULTIMEDIA Icon Description Rear Passenger Temperature Up and Down Buttons Provides the rear passengers with independent temperature control. Push the button on the touchscreen to increase the temperature, as it moves towards the red arrow button on the touchscreen for warmer temperature settings.
Page 559: Accessibility - If Equipped
MULTIMEDIA Icon Description Floor Floor Mode Mode Press this button on the touchscreen to change the air distribution mode to Floor Mode. In Floor Mode, air comes from the floor outlets. A slight amount of air is directed through the defrost and side window demister outlets.
Page 560 558 MULTIMEDIA To link your device to the rear Uconnect Theater touch- NOTE: screens: • Some devices will allow you to control your device through the Uconnect Theater rear touchscreens. They 1. Enable your device’s Wi-Fi will react to your selections from the touchscreen and be 2.
Page 561: Bd And Dvd Region Codes
MULTIMEDIA • Open sessions are ignored. Only sessions that are closed Refer to the Wireless Streaming/Mirroring video on Mopa- r’s Youtube Channel for tips and additional information on are playable. the Wireless Streaming/Mirroring function. • For multi-session CDs that contain only multiple CD- Audio sessions, the player will renumber the tracks so BD And DVD Region Codes each track number is unique.
Page 562 560 MULTIMEDIA • If you are creating your own files, the recommended Compressed Audio Files (MP3, WMA and AAC) fixed bit rate for MP3 files is between 32 and 320Kbps The Blu-ray Disc player is capable of playing MP3 and the recommended fixed bit rate for WMA files is (MPEG-1 Audio Layer 3), WMA (Windows Media Audio) between 16 and 192Kbps.
Page 563: Product Agreement
MULTIMEDIA • The licensed software for our company is based on GNU the disc is reached, the Blu-ray Disc player will return to the beginning of the disc and attempt to play the start of LESSER GENERAL PUBLIC LICENSE V2.1 ( LGPL ). the first track.
Page 564 562 MULTIMEDIA boot_loader sh-ipl +g kernel 2.6.16.29 FreeType 2 2.2.1 gcc sh4eb 3.4.5 glibc 2.3.5 1.00 libgcc_s-3.4.5 bash-3.0-31 busybox 1.00 MAKE DEV 1.1.0 module-init-tools 3.1.0 libtermcap 2.0.8 mtd-utils 20050619 initscripts 8.11.1-1 libstdc+ +3.4.5-10 libiconv 1.11 binutils-sh4eb coreutils 6.9 dosfstools 2.10-3 directfb 1.0.0-rc1 kxml 1.21 2.16.91.0.2...
Page 565 MULTIMEDIA NON-COMMERCIAL USE OF A CONSUMER TO (i) EN- message will be displayed and playback or copying will be CODE VIDEO IN COMPLIANCE WITH THE AVC STAN- interrupted. More information about Cinavia technology is DARD ( AVC VIDEO ) AND/OR (ii) DECODE AVC provided at the Cinavia Online Consumer Information VIDEO THAT WAS ENCODED BY A CONSUMER EN- Center at http://www.cinavia.com.
Page 566: General Information
564 MULTIMEDIA General Information the FCC radio frequency (RF) Exposure Guidelines and RSS-102 of the IC radio frequency (RF) Exposure rules. This The operation is subject to the following two conditions: transmitter must not be co-located or operating in conjunc- 1.
Page 567: Radio Operation And Mobile Phones
MULTIMEDIA • Consult the dealer or an experienced radio/TV techni- The internal wireless radio operates within guidelines cian for help. found in radio frequency safety standards and recommen- dations, which reflect the consensus of the scientific com- CAN ICES-3 (B) / NMB-3 (B) munity.
Page 568: Uconnect Voice Recognition Quick
566 MULTIMEDIA NOTE: UCONNECT VOICE RECOGNITION QUICK TIPS • This equipment has been tested and found to comply Introducing Uconnect with the limits for a Class B digital device, pursuant to Start using Uconnect Voice Recognition with these helpful Part 15 of the FCC Rules. These limits are designed to quick tips.
Page 569: Get Started
MULTIMEDIA 4. Each time you give a Voice Command, you must first WARNING! push either the VR or Phone button, wait until after the beep, then say your Voice Command. ALWAYS drive safely with your hands on the wheel. You have full responsibility and assume all risks 5.
Page 570: Basic Voice Commands
568 MULTIMEDIA Basic Voice Commands Radio Use your voice to quickly get to the AM, FM or SiriusXM The basic Voice Commands below can be given at any Satellite Radio stations you would like to hear. (Subscrip- point while using your Uconnect system. tion or included SiriusXM Satellite Radio trial required.) Push the VR button .
Page 571: Media
MULTIMEDIA Media Uconnect offers connections via USB, SD, Bluetooth and auxiliary ports (If Equipped). Voice operation is only available for connected USB and AUX devices. (Remote CD player optional and not available on all vehicles.) Push the VR button . After the beep, say one of the following commands and follow the prompts to switch your media source or choose an artist.
Page 572: Voice Text Reply
570 MULTIMEDIA • Redial (call previous outgoing phone number) Voice Text Reply • Call back (call previous incoming phone number) Uconnect will announce incoming text messages. Push the Phone button and say Listen. (Must have compatible TIP: When providing a Voice Command, push the Phone mobile phone paired to Uconnect system.) button and say “Call,”...
Page 573: Climate
MULTIMEDIA TIP: Your mobile phone must have the full implementation TIP: Voice Text Reply is not compatible with iPhone, but if of the Message Access Profile (MAP) to take advantage of your vehicle is equipped with Siri Eyes Free, you can use this feature.
Page 574: Navigation
• For the 8.4 Uconnect System, say: “Enter state.” steering wheel if equipped. • For the 8.4 NAV Uconnect System, say: “Find address 800 Chrysler Drive Auburn Hills, Michigan.” 2. Then follow the system prompts. TIP: To start a POI search, push the VR button .
Page 575: Uconnect Access
MULTIMEDIA Uconnect Access Vehicle Finder Send ‘N Go WARNING! Stolen Vehicle Assistance ALWAYS obey traffic laws and pay attention to the Remote Vehicle Start** road. Some Uconnect Access services, including 9-1-1 and Assist, will NOT work without an operable Remote Horn and Lights 1X(voice/data) or 3G(data) network connection.
Page 576: Vehicle Health Report/Alert
574 MULTIMEDIA your attention. For further information go to the Mopar Owner Connect website at moparownerconnect.com. Mobile App You’re only a few steps away from using remote com- mands and sending a destination from your phone to your vehicle. Assist Button 2.
Page 577: Voice Texting
MULTIMEDIA • Once on the “Remote” screen, you can begin using You must be registered with Uconnect Access and have a Remote Door Lock/Unlock, Remote Vehicle Start, and compatible MAP – enabled smartphone to use your voice activate your horn and lights remotely, if equipped. to send a personalized text message.
Page 578: Yelp
576 MULTIMEDIA TIP: TIP: Once you perform a search, you can reorganize the results by selecting either the Best Match, Rating or Dis- • Voice Texting is not compatible with iPhone, but if your tance tab on the top of the touchscreen display. vehicle is equipped with Siri Eyes Free, you can use your voice to send a text message.
Page 579: Siri Eyes Free - If Equipped
MULTIMEDIA Push the VR button . After the beep, say one of the natural language to understand what you mean and will following commands: respond back to confirm your requests. The system is designed to keep your eyes on the road and your hands on •...
Page 580: Do Not Disturb
578 MULTIMEDIA Do Not Disturb General Information With Do Not Disturb, you can disable notifications from This device complies with FCC rules Part 15 and Industry incoming calls and texts, allowing you to keep your eyes Canada RSS-210. Operation is subject to the following two on the road and hands on the wheel.
Page 581: Additional Information
MULTIMEDIA Additional Information 4. Do not use solvents such as benzene, thinner, cleaners, or anti-static sprays. © 2016 FCA US LLC. All rights reserved. Mopar and Uconnect are registered trademarks and Mopar Owner 5. Store the disc in its case after playing. Connect is a trademark of FCA US LLC.
Page 583 CUSTOMER ASSISTANCE CONTENTS ▫ Customer Assistance For The Hearing Or Speech SUGGESTIONS FOR OBTAINING SERVICE FOR YOUR VEHICLE ......582 Impaired (TDD/TTY) .
Page 584: Suggestions For Obtaining Service For Your Vehicle
582 CUSTOMER ASSISTANCE SUGGESTIONS FOR OBTAINING SERVICE FOR IF YOU NEED ASSISTANCE YOUR VEHICLE The manufacturer and its authorized dealer are vitally interested in your satisfaction. We want you to be happy Prepare For The Appointment with our products and services. If you are having warranty work done, be sure to have the right papers with you.
Page 585: Fca Us Llc Customer Center
Outside Mexico City: 1-800-505-1300 • Vehicle delivery date and mileage Puerto Rico And U.S. Virgin Islands FCA US LLC Customer Center Customer Service Chrysler International Services LLC P.O. Box 21–8004 P.O. Box 191857 Auburn Hills, MI 48321–8004 San Juan 00919-1857 Phone: (800) 247-9753 Tel.: (787) 782-5757...
Page 586: Customer Assistance For The Hearing Or Speech Impaired (Tdd/Tty)
584 CUSTOMER ASSISTANCE Customer Assistance For The Hearing Or Speech and an Owner Identification Card in the mail within three weeks of the vehicle delivery date. If you have any Impaired (TDD/TTY) questions about the service contract, call the manufactur- To assist customers who have hearing difficulties, the er’s Service Contract National Customer Hotline at 1-800- manufacturer has installed special TDD (Telecommunica-...
Page 587: Warranty Information
CUSTOMER ASSISTANCE 585 REPORTING SAFETY DEFECTS WARNING! In The 50 United States And Washington, D.C. Engine exhaust (internal combustion engines only), If you believe that your vehicle has a defect that could some of its constituents, and certain vehicle compo- cause a crash or cause injury or death, you should nents contain, or emit, chemicals known to the State of immediately inform the National Highway Traffic...
Page 588: In Canada
586 CUSTOMER ASSISTANCE In Canada Diagnostic Procedure Manuals If you believe that your vehicle has a safety defect, you Diagnostic Procedure Manuals are filled with diagrams, should contact the Customer Service Department imme- charts and detailed illustrations. These practical manuals diately.
Page 589 INDEX...
Page 590 588 INDEX Adaptive Cruise Control (ACC) (Cruise Control) ..302 Air Filter ....... .446 Additives, Fuel .
Page 591 INDEX 589 Auxiliary Power Outlet ..... .140 Bulbs, Light ......279, 392, 396 Axle Lubrication .
Page 592 590 INDEX Child Seat Installation ....268, 270 Inspection ......456, 460 How To Stow An Unused ALR Seat Belt .
Page 593 INDEX 591 Driving Compartment Identification ....441 Through Flowing, Rising, Or Shallow Standing Coolant (Antifreeze) ..... .502 Water .
Page 594 592 INDEX Flashers Requirements ......498 Hazard Warning ......386 Specifications .
Page 595 INDEX 593 Hill Start Assist ......200 Key Fob Battery Service (Remote Keyless Entry) ..41 Hood Prop .
Page 596 594 INDEX Daytime Running ......94 Warning (Instrument Cluster Description) ..185 Exterior .
Page 597 INDEX 595 Heated ....... . .93 Viscosity ......445, 501 Outside .
Page 598 596 INDEX Rearward .......79 Disarm The Alarm ......53 Pregnant Women And Seat Belts .
Page 599 INDEX 597 Seat Belt Untwisting Procedure .....225 Adjustable Upper Shoulder Belt Anchorage ..225 Seats .......67, 79, 81 Automatic Locking Retractor (ALR) .
Page 600 598 INDEX Speed Control Tilt Steering Column ......88 Accel/Decel ......301 Tire And Loading Information Placard.
Page 601 INDEX 599 Spinning .......477 Uconnect Access Tread Wear Indicators .....478 Vehicle Health Alert .
Page 602 600 INDEX Washers, Windshield ......442 Washing Vehicle ......490 Water Driving Through .
Page 603 INSTALLATION OF RADIO TRANSMITTING EQUIPMENT Special design considerations are incorporated into this The antenna cable should be as short as practical and vehicle’s electronic system to provide immunity to radio routed away from the vehicle wiring when possible. Use frequency signals. Mobile two-way radios and telephone only fully shielded coaxial cable.
Page 604 STICK WITH THE SPECIALISTS ® 17PHEV-126-AB ©2016 FCA US LLC. All Rights Reserved. Second Edition Chrysler is a registered trademark of FCA US LLC. Printed in the U.S.A.
