  • Page 1 T H E C H RYS L ER PACIFICA HYBRID 2017 USER GUIDE...
  • Page 2 IF YOU ARE THE FIRST REGISTERED RETAIL OWNER OF YOUR VEHICLE, YOU MAY OBTAIN A COMPLIMENTARY PRINTED COPY OF THE OWNER’S MANUAL, NAVIGATION/ UCONNECT MANUALS OR WARRANTY BOOKLETS BY CALLING 1 800 247-9753 (U.S.) OR 1 800 387-1143 (CANADA) OR BY CONTACTING YOUR DEALER.
  • Page 3: Table Of Contents

    T A B L E O F C O N T E N T S UCONNECT 8.4/8.4 NAV VOICE INTRODUCTION RECOGNITION QUICK TIPS ..149 WELCOME FROM FCA US LLC ..2 UCONNECT PHONE .
  • Page 4: Introduction

    DVD player capabilities). Additional DVD operational information is located on the back of the DVD sleeve. For complete owner information, refer to your Owner's Manual on www.chrysler.com/en/ owners/manuals. FCA US is committed to protecting our environment and natural resources. By converting from paper to electronic delivery for the majority of the user information for your vehicle, together we greatly reduce the demand for tree-based products and lessen the stress on our environment.
  • Page 5 I N T R O D U C T I O N VEHICLES SOLD IN CANADA With respect to any vehicles sold in Canada, the name FCA US LLC shall be deemed to be deleted and the name FCA Canada Inc. used in substitution (excluding legal lines). WARNING! •...
  • Page 6: Controls At A Glance

    C O N T R O L S A T A G L A N C E DRIVER COCKPIT 1. Power Window/Door Lock Switch Panel 2. Turn Signal/High Beams Lever (behind steering wheel) pg. 90 3. Instrument Cluster pg. 6 4.
  • Page 7 C O N T R O L S A T A G L A N C E 7. Identifying Your Radio pg. 121 8. Radio Hard Controls 9. Climate Controls pg. 105 10. Storage Compartment 11. Speed Controls pg. 93 12.
  • Page 8: Instrument Cluster

    C O N T R O L S A T A G L A N C E INSTRUMENT CLUSTER 1. % Power Gauge 2. Efficiency Gauge NOTE: The gauge will change from green to yellow to orange as it moves in the Accel or Brake direction, depending how quickly the driver is accelerating or braking, respectively.
  • Page 9 4. Range To Empty 5. Fuel Gauge Refer to “Instrument Cluster Descriptions” in “Getting To Know Your Instrument Panel” in your Owner’s Manual at www.chrysler.com/en/owners/manuals/ for additional instrument cluster description information. (See page 193 for more Instrument Cluster Warning Light information.)
  • Page 10: Getting Started

    G E T T I N G S T A R T E D HIGH VOLTAGE BATTERY Your vehicle is equipped with a Lithium-ion high voltage battery that is used to power the electric powertrain systems and the 12 volt vehicle electrical system. The high voltage battery is located under the middle section of the vehicle, below and in front of the second row seating.
  • Page 11: High Voltage Charging Operation

    G E T T I N G S T A R T E D NOTE: • During vehicle start up and shut down a clicking noise may be heard from within the vehicle. When the ignition is in the ON position, the high voltage battery contactors inside the battery are closed to make the stored electricity inside available for vehicle use.
  • Page 12 G E T T I N G S T A R T E D AC Level 1 Charging (120V, 15 Amp) Your vehicle is equipped with a 120 Volt AC, SAE J1772 Level 1 Electric Vehicle Supply Equipment (EVSE), also referred to as a charging cordset. AC Level 1 charging requires a conventional NEMA 5-15 120 Volt AC grounded wall receptacle along with the charging cordset provided with the vehicle.
  • Page 13 G E T T I N G S T A R T E D WARNING! • Read all the instructions before using this product. • Unattended children must not have access to the working Portable EVSE Cordset. • Do not put fingers or objects into the Charge Connector. •...
  • Page 14 G E T T I N G S T A R T E D 2. Check to see if the charging cordset is ready to charge by reviewing the indicator lights. After a brief self-check, where the indicator light will flash, a green AC indicator light and two green “charge active”...
  • Page 15 G E T T I N G S T A R T E D You will hear a “click” when the charge connector is inserted correctly and is coupled with the vehicle’s charge inlet. The vehicle should start charging automatically. If not, please check the instructions at the charging station.
  • Page 16 G E T T I N G S T A R T E D Vehicle Charge Indicators Instrument Cluster High Voltage Battery Display There is a battery display indicator located on the instrument cluster. The battery display will display the current state of charge for the high voltage battery; with the percentage value located to the left of the symbol.
  • Page 17 G E T T I N G S T A R T E D Number Of Indicator Lights Illuminated Percent Of Battery Charge 1st, 2nd, 3rd, and 4th light ON, 5th light blinks 81 – 95% All 5 lights ON 100% Two outer lights are blinking Indicates an error in the charging process.
  • Page 18 G E T T I N G S T A R T E D Power Flow The first screen within the “Hybrid Electric” App is the Power Flow screen. The Power Flow screen shows the current power readings for all of the following: •...
  • Page 19 G E T T I N G S T A R T E D Driving History The second screen with the “Hybrid Electric” App is the Driving History screen. The Driving History screen shows the miles driven in both Full Electric and Hybrid modes for both the previous week and the current week.
  • Page 20 G E T T I N G S T A R T E D Charging Schedule The third screen within the “Hybrid Electric” App is the Charging Schedule screen. From this screen you can set when you want you vehicle to charge. To do so, press the check box next to the setting “Enable Schedule”...
  • Page 21: Vehicle User Guide (U.s. Market Only) - If Equipped

    G E T T I N G S T A R T E D VEHICLE USER GUIDE (U.S. MARKET ONLY ) — IF EQUIPPED Access your Owner’s Information right through your Uconnect 8.4 or 8.4 NAV touchscreen system — If Equipped. Refer to “Identifying Your Radio” in “Electronics” in this guide to determine your radio.
  • Page 22 G E T T I N G S T A R T E D Once you launch your Vehicle User Guide, you will be able to explore your warranty information and radio manual when and where you need them. Your Uconnect radio will display the Vehicle User Guide on your touchscreen radio to assist in better understanding your vehicle.
  • Page 23: Key Fob

    • The default lock setting can be changed within Uconnect Settings so that the system will allow/inhibit the ability to lock the doors when one or more doors/liftgate are open. • For additional information, refer to “Uconnect Settings” in “Multimedia” in the Owner’s Manual on www.chrysler.com/en/owners/manuals for further information.
  • Page 24 The turn signal lights will flash to acknowledge the unlock signal. The illuminated entry system will be activated. NOTE: Refer to “Uconnect Settings” in “Multimedia” in the Owner’s Manual on www.chrysler.com/en/owners/ manuals for further information. Panic Alarm Push the PANIC button once to turn the Panic Alarm on.
  • Page 25 G E T T I N G S T A R T E D The power liftgate may also be opened by pushing the button located on the overhead console. NOTE: • If anything obstructs the power liftgate while it is closing or opening, the liftgate will auto- matically reverse to the closed or open posi- tion, provided it meets sufficient resistance.
  • Page 26 • Entertainment Audio Muted if 1st row Seatbelts are not Fastened • Consistent Seat belt Unfastened Chime • Maximum Radio Volume • Daytime Running Lights Please refer to “Keys” in “Getting To Know Your Vehicle” in your Owner’s Manual on www.chrysler.com/ en/owners/manuals for further information.
  • Page 27: Remote Start - If Equipped

    G E T T I N G S T A R T E D Emergency Key Should the battery in the vehicle or the key fob go dead, there is an emergency key located in the key fob that can be used for locking and unlocking the doors. To remove the emergency key, slide the button at the top of the key fob sideways with your thumb and then pull the key out with your other hand.
  • Page 28: Vehicle Security Alarm

    G E T T I N G S T A R T E D VEHICLE SECURITY ALARM The vehicle security alarm monitors the vehicle doors for unauthorized entry and the ignition for unauthorized operation. While the vehicle security alarm is armed, interior switches for door locks and liftgate release are disabled.
  • Page 29 NOTE: The passive entry system my be programed through Uconnect Setting to meet your needs. Refer to “Uconnect Settings” in “Multimedia” in the Owner’s Manual on www.chrysler.com/en/ owners/manuals for further information. DO NOT grab the door handle when pushing the door handle button. This could unlock the door(s).
  • Page 30: Hands-Free Sliding Door And Liftgate

    The Hands-Free Sliding Doors feature may be turned off through Uconnect Settings. Refer to “Uconnect Settings” in “Multimedia” in the Owner’s Manual on www.chrysler.com/en/owners/manuals for further information. The Hands-Free Sliding Doors feature should be turned off during Jacking, Tire Changing, and Vehicle Service.
  • Page 31 The Hands-Free Liftgate feature may be turned on or off in Uconnect Settings. Refer to “Uconnect Settings” in “Multimedia” in the Owner’s Manual at www.chrysler.com/en/owners/manuals for further information. The Hands-Free Liftgate fea- ture should be turned off during Jacking, Tire Changing, and Vehicle Service.
  • Page 32: Keyless Enter-N-Go - Ignition

    G E T T I N G S T A R T E D Gas props support the liftgate in the open position. However, because the gas pressure drops with temperature, it may be necessary to assist the props when opening the liftgate in cold weather. NOTE: Allow the power system to open the liftgate.
  • Page 33: Occupant Restraint Systems

    G E T T I N G S T A R T E D 3. Push the ENGINE START/STOP button a second time to place the ignition in the RUN mode (instrument cluster will display “ON/RUN”). 4. Push the ENGINE START/STOP button a third time to return the ignition to the OFF mode (instrument cluster will display “OFF”).
  • Page 34: Important Safety Precautions

    G E T T I N G S T A R T E D Important Safety Precautions Please pay close attention to the information in this section. It tells you how to use your restraint system properly, to keep you and your passengers as safe as possible. Here are some simple steps you can take to minimize the risk of harm from a deploying air bag: 1.
  • Page 35 G E T T I N G S T A R T E D Enhanced Seat Belt Use Reminder System (BeltAlert) Driver And Passenger BeltAlert — If Equipped BeltAlert is a feature intended to remind the driver and outboard front seat passenger (if equipped with outboard front passenger seat BeltAlert) to buckle their seat belts.
  • Page 36 G E T T I N G S T A R T E D Lap/Shoulder Belts All seating positions in your vehicle are equipped with lap/shoulder belts. The seat belt webbing retractor will lock only during very sudden stops or collisions. This feature allows the shoulder part of the seat belt to move freely with you under normal conditions.
  • Page 37 G E T T I N G S T A R T E D WARNING! • A seat belt that is worn under your arm is dangerous. Your body could strike the inside surfaces of the vehicle in a collision, increasing head and neck injury. A seat belt worn under the arm can cause internal injuries.
  • Page 38 G E T T I N G S T A R T E D Lap/Shoulder Belt Untwisting Procedure Use the following procedure to untwist a twisted lap/shoulder belt. 1. Position the latch plate as close as possible to the anchor point. 2.
  • Page 39 G E T T I N G S T A R T E D Second Row Center (If Equipped) And Third Row Center Seat Belt Operating Instructions The second row center (if equipped) and third row center seat belts feature a seat belt with a mini-latch plate and buckle, which allows the seat belt to detach from the lower anchor when the seat is folded.
  • Page 40 G E T T I N G S T A R T E D 6. When the seat belt is long enough to fit, insert the latch plate into the buckle until you hear a “click.” 7. Position the lap belt so that it is snug and lies low across your hips, below your abdomen.
  • Page 41 G E T T I N G S T A R T E D WARNING! • ONLY use the Seat Belt Extender if it is physically required in order to properly fit the original seat belt system. DO NOT USE the Seat Belt Extender if, when worn, the distance between the front edge of the Seat Belt Extender buckle and the center of the occupant’s body is LESS than 6 inches.
  • Page 42 G E T T I N G S T A R T E D Switchable Automatic Locking Retractors (ALR) The seat belts in the passenger seating positions are equipped with a Switchable Automatic Locking Retractor (ALR) which is used to secure a child restraint system. For additional informa- tion, refer to “Installing Child Restraints Using The Vehicle Seat Belt”...
  • Page 43 G E T T I N G S T A R T E D How To Disengage The Automatic Locking Mode Unbuckle the combination lap/shoulder belt and allow it to retract completely to disengage the Automatic Locking Mode and activate the vehicle sensitive (emergency) locking mode. WARNING! •...
  • Page 44 G E T T I N G S T A R T E D Third Row Stow Clip — If Equipped Your vehicle may be equipped with a stow clip on the lower trim behind the third row. This clip is used to hold the seat belt out of the path of the power folding third row seat.
  • Page 45 G E T T I N G S T A R T E D • Supplemental Side Air Bags • Supplemental Knee Air Bags • Front and Side Impact Sensors • Seat Belt Pretensioners • Seat Track Position Sensors • Seat Belt Buckle Switch •...
  • Page 46 G E T T I N G S T A R T E D Redundant Air Bag Warning Light If a fault with the Air Bag Warning Light is detected, which could affect the Supplemental Restraint System (SRS), the Redundant Air Bag Warning Light will illuminate on the instrument panel.
  • Page 47 G E T T I N G S T A R T E D WARNING! • Being too close to the steering wheel or instrument panel during front air bag deployment could cause serious injury, including death. Air bags need room to inflate. Sit back, comfortably extending your arms to reach the steering wheel or instrument panel.
  • Page 48 G E T T I N G S T A R T E D Front Air Bag Operation Front Air Bags are designed to provide additional protection by supplementing the seat belts. Front air bags are not expected to reduce the risk of injury in rear, side, or rollover collisions. The front air bags will not deploy in all frontal collisions, including some that may produce substantial vehicle damage —...
  • Page 49 G E T T I N G S T A R T E D • The front passenger seat is occupied by a rear-facing child restraint; or • The front passenger is not properly seated or his or her weight is taken off of the seat for a period of time.
  • Page 50 G E T T I N G S T A R T E D Lighter Weight Passengers (Including Small Adults) When a lighter weight passenger, including a small adult, occupies the front passenger seat, the OCS may reduce the inflation rate of the Passenger Advanced Front Air Bag. This does not mean that the OCS is working improperly.
  • Page 51 G E T T I N G S T A R T E D Not Seated Properly Not Seated Properly WARNING! • If a child restraint system, child, small teenager or adult in the front passenger seat is seated improperly, the occupant may provide an output signal to the OCS that is different from the occupant’s properly seated weight input.
  • Page 52 G E T T I N G S T A R T E D The following requirements must be strictly followed: • Do not modify the front passenger seat assembly or components in any way. • Do not use prior or future model year seat covers or cushions not designated by FCA US LLC for the specific model being repaired.
  • Page 53 G E T T I N G S T A R T E D Supplemental Side Air Bags Your vehicle is equipped with two types of side air bags: 1. Supplemental Seat-Mounted Side Air Bags (SABs): Located in the outboard side of the front seats.
  • Page 54 G E T T I N G S T A R T E D WARNING! Do not stack luggage or other cargo up high enough to block the deployment of the • SABICs. The trim covering above the side windows where the SABIC and its deployment path are located should remain free from any obstructions.
  • Page 55 G E T T I N G S T A R T E D Side Impacts In side impacts, the side impact sensors aid the ORC in determining the appropriate response to impact events. The system is calibrated to deploy the Side Air Bags on the impact side of the vehicle during impacts that require Side Air Bag occupant protection.
  • Page 56 G E T T I N G S T A R T E D If A Deployment Occurs The front air bags are designed to deflate immediately after deployment. NOTE: Front and/or side air bags will not deploy in all collisions. This does not mean something is wrong with the air bag system.
  • Page 57 G E T T I N G S T A R T E D Enhanced Accident Response System In the event of an impact, if the communication network remains intact, and the power remains intact, depending on the nature of the event, the ORC will determine whether to have the Enhanced Accident Response System perform the following functions: •...
  • Page 58: Child Restraints

    G E T T I N G S T A R T E D Event Data Recorder (EDR) This vehicle is equipped with an event data recorder (EDR). The main purpose of an EDR is to record, in certain crash or near crash-like situations, such as an air bag deployment or hitting a road obstacle, data that will assist in understanding how a vehicle’s systems performed.
  • Page 59 G E T T I N G S T A R T E D There are different sizes and types of restraints for children from newborn size to the child almost large enough for an adult safety belt. Always check the child seat Owner’s Manual to make sure you have the correct seat for your child.
  • Page 60 G E T T I N G S T A R T E D weight limit in the rear-facing direction than infant carriers do, so they can be used rear-facing by children who have outgrown their infant carrier but are still less than at least two years old. Children should remain rear-facing until they reach the highest weight or height allowed by their convertible child seat.
  • Page 61 G E T T I N G S T A R T E D All children whose weight or height is above the forward-facing limit for the child seat should use a belt-positioning booster seat until the vehicle’s seat belts fit properly. If the child cannot sit with knees bent over the vehicle’s seat cushion while the child’s back is against the seatback, they should use a belt-positioning booster seat.
  • Page 62 G E T T I N G S T A R T E D Recommendations For Attaching Child Restraints Restraint Combined Use Any Attachment Method Shown With An “X” Below Type Weight of the LATCH – Seat Belt LATCH – Seat Belt + Child + Child Lower An-...
  • Page 63 G E T T I N G S T A R T E D LATCH Positions For Installing Child Restraints In This Vehicle LATCH Positions — Lower Anchorage Symbol (2 Anchorages Per Seating Position) — Top Tether Anchorage Symbol Frequently Asked Questions About Installing Child Restraints With LATCH Frequently Asked Questions Use the LATCH anchorage system until the combined...
  • Page 64 G E T T I N G S T A R T E D Frequently Asked Questions The child seat may touch the back of the front passenger Can the rear-facing child seat if the child restraint manu- restraint touch the back of the facturer also allows contact.
  • Page 65 G E T T I N G S T A R T E D Locating The LATCH Anchorages The lower anchorages are round bars that are found at the rear of the seat cushion where it meets the seatback, below the anchorage symbols on the seatback. They are just visible when you lean into the rear seat to install the child restraint.
  • Page 66 G E T T I N G S T A R T E D Locating The Upper Tether Anchorages There are tether strap anchorages located behind all second row seating positions. The third row has a tether anchor on the 40% seat for the right outboard position and in the center of the 60% seat for either the center or left outboard seating position.
  • Page 67 G E T T I N G S T A R T E D WARNING! • Use anchorages C and D to install a LATCH-compatible child restraint in the center seating position (2). Do not install a LATCH-compatible child restraint using anchorages B and C. This is not a LATCH-compatible position in your vehicle.
  • Page 68 G E T T I N G S T A R T E D How To Stow An Unused Switchable-ALR (ALR) Seat Belt When using the LATCH attaching system to install a child restraint, stow all ALR seat belts that are not being used by other occupants or being used to secure child restraints.
  • Page 69 G E T T I N G S T A R T E D Lap/Shoulder Belt Systems For Installing Child Restraints In This Vehicle Automatic Locking Retractor (ALR) Locations ALR = Switchable Automatic Locking Retractor — Top Tether Anchorage Symbol Frequently Asked Question About Installing Child Restraints With Seat Belts Frequently Asked Questions About Installing Child Restraints With Seat Belts What is the weight limit (child’s...
  • Page 70 G E T T I N G S T A R T E D NOTE: If the folding, non-adjustable head restraint interferes with the installation of the child restraint, the head restraint may be folded and the child seat installed in front of it. WARNING! Always make sure the head restraint is in its upright position when the seat is to be used by an occupant who is not in a child restraint.
  • Page 71 G E T T I N G S T A R T E D 2. Pull enough of the seat belt webbing from the retractor to pass it through the belt path of the child restraint. Do not twist the belt webbing in the belt path. 3.
  • Page 72 G E T T I N G S T A R T E D If the park stitch interferes with the lock-off features of the child restraint, do not use the lock-off feature. Instead, switch the seat belt to the locking mode, as described in the steps above or move the car seat to a different seating position.
  • Page 73 G E T T I N G S T A R T E D 1. Look behind the seating position where you plan to install the child restraint to find the tether anchorage. You may need to move the seat forward to provide better access to the tether anchorage.
  • Page 74 G E T T I N G S T A R T E D Third Row Tether Attachment The tether anchorage found on the back of the 60% seat in the third row may be used by either the left outboard or the center seating position. Only tether one child restraint to the tether anchorage at a time.
  • Page 75: Head Restraints

    G E T T I N G S T A R T E D HEAD RESTRAINTS Head restraints are designed to reduce the risk of injury by restricting head movement in the event of a rear impact. Head restraints should be adjusted so that the top of the head restraint is located above the top of your ear.
  • Page 76 G E T T I N G S T A R T E D NOTE: To remove the head restraint, raise it as far as it can go. Then, push the release button and the adjustment button at the base of each post while pulling the head restraint up. Seatback angle may need to be adjusted to fully remove the head restraint.
  • Page 77 The head restraint in the center position can be raised and lowered for tether routing or height adjustment. Refer to “Occupant Restraint Systems” in “Safety” in your Owner’s Manual on www.chrysler.com/en/owners/manuals for further information. Release Strap NOTE: To remove the center head restraint, raise it as far as it can go. Then, push the release button and the adjustment button at the base of each post while pulling the head restraint up.
  • Page 78: Front Seats

    G E T T I N G S T A R T E D FRONT SEATS Manual Adjustment (Front Seats) WARNING! • Adjusting a seat while the vehicle is moving is dangerous. The sudden movement of the seat could cause you to lose control. The seat belt might not be adjusted properly and you could be injured.
  • Page 79 G E T T I N G S T A R T E D Manual Reclining Seats — If Equipped For models equipped with manual seats, the recline lever is located on the outboard side of the seat. To recline, lean forward slightly, lift the lever and push back to the desired position and re- lease the lever.
  • Page 80 G E T T I N G S T A R T E D Power Adjustment (Front Seats) — If Equipped Some models may be equipped with eight-way power seats for the driver and front passenger. The power seat switches are located on the outboard side of the seat.
  • Page 81 G E T T I N G S T A R T E D Adjusting The Seat Forward Or Rearward The seat can be adjusted both forward and rearward. Push the seat switch forward or rearward, and the seat will move in the direction of the switch. Release the switch when the desired position has been reached.
  • Page 82: Rear Seats

    G E T T I N G S T A R T E D REAR SEATS Manual Adjustment Precautions WARNING! • Adjusting a seat while the vehicle is moving is dangerous. The sudden movement of the seat could cause you to lose control. The seat belt might not be adjusted properly and you could be injured.
  • Page 83 G E T T I N G S T A R T E D Manual Recline To recline, lean forward slightly, lift the lever, then push back to the desired position and release the lever. Lean forward and lift the lever to return the seatback to its normal position.
  • Page 84 G E T T I N G S T A R T E D Easy Entry Slide Second Row Seating The second row seats can be tilted and slid forward for easy entry into the third row. 1. Located in the seatback of the second row seat is a lever that provides easier access to the third row by tilting the seat forward.
  • Page 85 G E T T I N G S T A R T E D Reinstalling Seat 1. To reinstall the seat, align the seats front attachments into the detent positions on the floor. 2. Tilt seat rearward to lock the seat back into its original position. NOTE: Push downward to ensure the rear latches are in the locked position.
  • Page 86: Heated/Ventilated Seats

    This feature can be programmed through the Uconnect system. Refer to “Uconnect Settings” in “Multimedia” in the Owner's Manual on www.chrysler.com/en/owners/manuals. WARNING! • Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, exhaustion or other physical condition must exercise care when using the seat heater.
  • Page 87: Steering Wheel

    On models that are equipped with remote start, the ventilated seats can be programed to come on during a remote start. This feature can be programmed through the Uconnect system. Refer to “Uconnect Settings” in “Multimedia” in the Owner's Manual on www.chrysler.com/en/owners/manuals for further information. STEERING WHEEL Tilt/Telescoping Steering Column This feature allows you to tilt the steering column upward or downward.
  • Page 88 On models that are equipped with remote start, the heated steering wheel can be programmed to come on during a remote start through the Uconnect system. Refer to “Uconnect Settings” in “Multimedia” in the Owner’s Manual on www.chrysler.com/en/owners/manuals for further information.
  • Page 89: Operating Your Vehicle

    O P E R A T I N G Y O U R V E H I C L E ENGINE BREAK-IN RECOMMENDATIONS A long break-in period is not required for the engine and drivetrain (transmission and axle) in your vehicle.
  • Page 90: Headlight Switch

    To Activate 1. Select “Automatic High Beams — ON” through the Uconnect system. Refer to "Uconnect Settings” in “Multimedia” in your Owner’s Manual on www.chrysler.com/en/owners/manuals for further information. 2. Rotate the headlight switch clockwise to the AUTO position.
  • Page 91 Perform either of the following steps to deactivate the Automatic High Beam system. 1. Select “Automatic High Beams — OFF” through the Uconnect System. Refer to “Uconnect Settings” in “Multimedia” in your Owner’s Manual on www.chrysler.com/en/owners/manuals for further information. 2. Pull the multifunction lever toward you to switch the headlights from the high beam to the low beam position.
  • Page 92: Multifunction Lever

    O P E R A T I N G Y O U R V E H I C L E MULTIFUNCTION LEVER The multifunction lever is located on the left side of the steering column. The multifunction lever controls the turn signals, headlight high/ low beams, and flash-to-pass functions.
  • Page 93: Windshield Wiper And Washers

    O P E R A T I N G Y O U R V E H I C L E WINDSHIELD WIPER AND WASHERS The wipers and washers are operated by a switch within the wiper lever. Rotate the end of the wiper lever to select the desired wiper speed.
  • Page 94 • Use of Rain-X or products containing wax or silicone may reduce rain sensor performance. • The Rain Sensing feature can be turned on and off through the Uconnect System. Refer to “Uconnect Settings” in “Multimedia” in the Owner’s Manual on www.chrysler.com/en/ owners/manuals for further information.
  • Page 95: Speed Control

    O P E R A T I N G Y O U R V E H I C L E Rear Wiper And Washer Rear Windshield Wiper Operation Rotate the windshield wiper lever center ring upwards to operate one of two modes for the rear window wiper: •...
  • Page 96 O P E R A T I N G Y O U R V E H I C L E WARNING! Speed Control can be dangerous where the system cannot maintain a constant speed. Your vehicle could go too fast for the conditions, and you could lose control and have an accident. Do not use Speed Control in heavy traffic or on roads that are winding, icy, snow-covered or slippery.
  • Page 97 O P E R A T I N G Y O U R V E H I C L E Metric Speed (km/h) • Pushing the SET (+) button once will result in a 1 km/h increase in set speed. Each subsequent tap of the button results in an increase of 1 km/h.
  • Page 98: Adaptive Cruise Control (Acc)

    The driver's preferred units can be selected through the instrument panel settings if equipped. Refer to “Uconnect Settings” in “Multimedia” in your Owner’s Manual on www.chrysler.com/en/owners/ manuals for more information. The speed increment shown is dependant on the speed of U.S.
  • Page 99 The driver's preferred units can be selected through the instrument panel settings if equipped. Refer to “Uconnect Settings” in “Multimedia” in your Owner’s Manual on www.chrysler.com/en/owners/ manuals for more information. The speed increment shown is dependant on the speed of U.S.
  • Page 100 (ACC) on/off button which turns the ACC and the Normal (Fixed Speed) Cruise Control off. • Pushing the Normal (Fixed Speed) Cruise Control on/off button will result in turning on (changing to) the Normal (Fixed Speed) Cruise Control mode. Refer to your Owner's Manual on www.chrysler.com/en/owners/manuals for further information.
  • Page 101 • Normal (Fixed Speed) Cruise Control mode for cruising at a constant preset speed. For additional information, refer to “Normal (Fixed Speed) Cruise Control Mode” section in the Owner’s Manual on www.chrysler.com/en/owners/manuals. Normal (Fixed Speed) Cruise Control mode will not react to preceding vehicles. Always be aware of the mode selected.
  • Page 102: Forward Collision Warning (Fcw)

    O P E R A T I N G Y O U R V E H I C L E FORWARD COLLISION WARNING (FCW ) The Forward Collision Warning (FCW) system provides the driver with audible warnings and visual warnings within the instrument cluster display, to warn the driver when it detects a potential frontal collision.
  • Page 103: Automatic Transmission

    Active braking can be turned “off” in the Uconnect controls settings. Refer to the Owner's Manual on www.chrysler.com/en/owners/manuals for further details. WARNING! Forward Collision Warning (FCW) is not intended to avoid a collision on its own, nor can FCW detect every type of potential collision.
  • Page 104 O P E R A T I N G Y O U R V E H I C L E WARNING! • Unintended movement of a vehicle could injure those in or near the vehicle. As with all vehicles, you should never exit a vehicle while the engine is running or the propulsion system is active. Before exiting a vehicle, always apply the park brake, shift the transmission into PARK, turn the ignition OFF, and remove the key fob.
  • Page 105: Park Brake

    • The EPB fault lamp will illuminate if the EPB switch is held for longer than 20 seconds in either the released or applied position. The light will extinguish upon releasing the switch. • Refer to “Parking Brake” in “Starting And Operating” located in your Owner’s Manual on www.chrysler.com/en/owners/manuals for further details.
  • Page 106 O P E R A T I N G Y O U R V E H I C L E WARNING! • Never use the PARK position as a substitute for the parking brake. Always apply the parking brake fully when exiting the vehicle to guard against vehicle movement and possible injury or damage.
  • Page 107: Automatic Temperature Controls (Atc)

    O P E R A T I N G Y O U R V E H I C L E AUTOMATIC TEMPERATURE CONTROLS (ATC ) Uconnect 8.4 Touchscreen Automatic Climate Controls 1 — MAX A/C Button 9 — Passenger Temperature Control Down 2 —...
  • Page 108 O P E R A T I N G Y O U R V E H I C L E Automatic Climate Controls 1 — A/C Button Button 2 — Driver Temperature Control Up Button 8 — FRONT Defroster Button 3 —...
  • Page 109: Parksense Front And Rear Park Assist

    Uconnect System screen). As the vehicle moves closer to the object, the chime rate will change from single 1/2 second tone (for rear only), to slow (for rear only), to fast, to continuous. Refer to your Owner's Manual on www.chrysler.com/en/owners/manuals for further details.
  • Page 110 O P E R A T I N G Y O U R V E H I C L E ParkSense Rear Park Assist — If Equipped The ParkSense Rear Park Assist system provides visual and audible indications of the distance between the rear fascia and a detected obstacle when backing up, e.g.
  • Page 111: Parkview Rear Back Up Camera - If Equipped

    ParkSense Active Park Assist Switch Location space setting. You may switch back to parallel parking if you desire. Refer to your Owner's Manual on www.chrysler.com/en/owners/manuals for further details. Cleaning The ParkSense Sensors If “PARKSENSE UNAVAILABLE WIPE REAR SENSORS" or "PARKSENSE UNAVAILABLE WIPE FRONT SENSORS”...
  • Page 112: Surround View Camera System - If Equipped

    O P E R A T I N G Y O U R V E H I C L E When the vehicle is shifted out of REVERSE (with camera delay turned on), the camera image will continue to be displayed for up to 10 seconds after shifting out of REVERSE unless the vehicle speed exceeds 8 mph (13 km/h), the vehicle is shifted into PARK or the ignition is switched to the OFF position.
  • Page 113 The Surround View Camera System has programmable settings that may be selected through the Uconnect System. Refer to “Uconnect Settings” in “Multimedia” in the Owner’s Manual on www.chrysler.com/en/owners/manuals for further information. When the vehicle is shifted into REVERSE, the rear camera view & top view is the default view of the system.
  • Page 114 O P E R A T I N G Y O U R V E H I C L E Front View The Front view will show you what is immediately in front of the vehicle with guide lines for the projected path when enabled.
  • Page 115: Blind Spot Monitoring

    RCP is on and the vehicle is in REVERSE, the driver is alerted using both the visual and audible alarms, including reducing the radio volume. Refer to “Safety Features” in “Safety” in the Owner's Manual on www.chrysler.com/en/owners/ manuals for more information.
  • Page 116: Tri-Pane Panoramic Sunroof - If Equipped

    O P E R A T I N G Y O U R V E H I C L E TRI-PANE PANORAMIC SUNROOF — IF EQUIPPED The Tri-Pane Panoramic Sunroof switch is lo- cated to the left between the sun visors on the overhead console.
  • Page 117 O P E R A T I N G Y O U R V E H I C L E Opening Sunroof Express Mode Push the switch rearward and release it within one second. The sunroof will open automatically from any position and stop at the full open position. This is called “Express Open.” During Express Open operation, any other actuation of the sunroof switch will stop the sunroof.
  • Page 118 O P E R A T I N G Y O U R V E H I C L E Wind Buffeting Wind buffeting can be described as the perception of pressure on the ears or a helicopter-type sound in the ears. Your vehicle may exhibit wind buffeting with the windows down, or the sunroof (if equipped) in certain open or partially open positions.
  • Page 119: Wind Buffeting

    OFF/LOCK position. Opening either front door will cancel this feature. NOTE: Ignition Off time is programmable through the Uconnect System. Refer to “Uconnect Settings” in “Multimedia” in your Owner’s Manual on www.chrysler.com/en/owners/manuals for further information. WIND BUFFETING Wind buffeting can be described as a helicopter-type percussion sound.
  • Page 120: Electronics

    E L E C T R O N I C S YOUR VEHICLE'S SOUND SYSTEM 1. Uconnect Phone Button pg. 165 2. Uconnect Voice Command Button pg. 149 3. Phone Hang Up Button 4. Steering Wheel Audio Controls (Left – Behind Steering Wheel) pg. 184 5.
  • Page 121 E L E C T R O N I C S 9. Browse/Tuner Control Knob 10. Back Button 11. USB Port pg. 185 12. Audio/AUX Jack pg. 185 13. Media Hub USB Port pg. 185 14. Front Power Outlet pg. 188 15.
  • Page 122: Cybersecurity

    For further information, refer to “Privacy Practices - If Equipped with Uconnect 8.4 Radio” in your Uconnect Owner’s Manual Supplement and “Onboard Diagnostic System (OBD II) Cybersecurity” in “Getting To Know Your Instrument Panel” in your Owner’s Manual on www.chrysler.com/en/owners/manuals.
  • Page 123: Identifying Your Radio

    E L E C T R O N I C S IDENTIFYING YOUR RADIO Uconnect 8.4 • 8.4” Touchscreen • HD Button will not be visible on right side of screen when viewing AM or FM • SiriusXM Travel Link feature not listed within Apps (US Market Only) Uconnect 8.4 NAV •...
  • Page 124 E L E C T R O N I C S Uconnect Access enhances your ownership and driving experience by connecting your vehicle to an operable 1X(voice/data) or 3G(data) network. When connected to an operable 1X (voice/ data) or 3G (data) network, you can: •...
  • Page 125 E L E C T R O N I C S Uconnect Access Subscription • After the trial period, you can subscribe by pushing the ASSIST button on the rear-view mirror and speaking with a Uconnect Access Care agent or by visiting the owner site Mopar.com. If you need assistance, U.S.
  • Page 126 E L E C T R O N I C S Download The Uconnect Access App You’re only a few steps away from using remote commands and sending a destination from your phone to your vehicle. To use the Uconnect Access Mobile App: •...
  • Page 127 E L E C T R O N I C S Charge Status The “Charge Status” section of the “Info” page indicates whether the vehicle is currently charging, displays the amount of time it will take until the vehicle is 100% charged, and allows you to access and change the charging schedule currently set for the vehicle.
  • Page 128 E L E C T R O N I C S Trip Information The “Trip Information” section of the “Info” page displays the information for both Trip A and Trip B, set within the vehicle. Select either Trip A or Trip B and the following information will be displayed: •...
  • Page 129 E L E C T R O N I C S Vehicle Finder The Vehicle Finder feature of the Uconnect Access Mobile App allows you to find the location of your vehicle when you have lost it. You can also sound the alarm and flash the lights to make finding your vehicle even easier.
  • Page 130 E L E C T R O N I C S Send ‘N Go The Send ‘n Go feature of the Uconnect Access Mobile App allows you to search for a destination on your mobile device and then send the route to your vehicle’s native navigation system. To send a navigation route to your vehicle: 1.
  • Page 131 E L E C T R O N I C S Renewing Subscriptions And Purchasing 3G Wi-Fi Hotspot (Uconnect 8.4/8.4 NAV, U.S. 48 Contiguous States, Alaska And Hawaii) Subscriptions, and 3G Wi-Fi Hotspot, can be purchased from the Uconnect Store within your vehicle, and online at your Owner Site.
  • Page 132 E L E C T R O N I C S App Manager Press the “App Manager” button to access the following categories: Favorite Apps — This is the default screen when you first press the “App Manager” button on the touchscreen, and is a good place to put the apps you use most frequently.
  • Page 133 E L E C T R O N I C S WARNING! • The 9-1-1 Call system is embedded into the vehicle’s electrical system. Do not add aftermarket electrical equipment to the vehicle’s electrical system. This may prevent your vehicle from sending a signal to initiate an emergency call. To avoid interference that can cause the 9-1-1 Call system to fail, never add aftermarket equipment (e.g., two-way mobile radio, CB radio, data recorder, etc.) to your vehicle’s electrical system or modify the antennas on your vehicle.
  • Page 134 E L E C T R O N I C S 3. Roadside Assistance (If Equipped) — If your vehicle is equipped with this feature and has an operable 1X (voice/data) or 3G (data) network connection, you may be able to connect with Roadside Assistance by pushing the "ASSIST"...
  • Page 135 E L E C T R O N I C S WARNING! NEVER use the 3G Wi-Fi Hotspot when you are driving the vehicle. As the driver, you should only use the 3G Wi-Fi Hotspot when the vehicle is parked in a safe location. Failure to do so may result in an accident involving serious injury or death.
  • Page 136 E L E C T R O N I C S Remote Door Lock/Unlock — This feature provides the ability to lock or unlock the door on your vehicle, without the keys and from virtually any distance. You can send a request to your vehicle in one of three ways: 1.
  • Page 137 E L E C T R O N I C S To Send A Text Message: 1. Push the Uconnect Phone Button on the steering wheel. 2. Wait for the beep. 3. Say “Text.” 4. Uconnect will prompt you “Say the phone number, or full name and phone type of the contact you want to send a message to.”...
  • Page 138: Uconnect 8.4/8.4 Nav

    E L E C T R O N I C S UCONNECT 8.4/8.4 NAV Uconnect 8.4/8.4 NAV At A Glance Uconnect 8.4 NAV Radio Screen WARNING! ALWAYS drive safely with your hands on the wheel. You have full responsibility and assume all risks related to the use of the Uconnect features and applications in this vehicle.
  • Page 139 E L E C T R O N I C S Setting The Time • Model 8.4 NAV synchronizes time automatically via GPS, so it should not require any time adjustment. If you do need to set the time manually, follow the instructions below for Model 8.4. •...
  • Page 140 E L E C T R O N I C S Personalized Menu Bar The Uconnect features and services in the main menu bar are easily changed for your conve- nience. Simply follow these steps: Uconnect 8.4/8.4 NAV Main Menu 1.
  • Page 141 E L E C T R O N I C S Radio Uconnect 8.4 NAV Radio 1 — Radio Station Presets 6 — Seek Up 2 — Toggle Between Presets 7 — Direct Tune To A Radio Station 3 — View Small Navigation Map 8 —...
  • Page 142 E L E C T R O N I C S Seek Up/Seek Down • Press the Seek up or down arrow buttons on the touchscreen for less than two seconds to seek through radio stations. • Press and hold either arrow button on the touchscreen for more than two seconds to bypass stations without stopping.
  • Page 143 E L E C T R O N I C S • Press and hold either arrow button on the touchscreen for more than two seconds to bypass channels without stopping. The radio will stop at the next listenable channel once the arrow button on the touchscreen is released.
  • Page 144 E L E C T R O N I C S Browse Sub-Menu Description Sub-Menu Favorites Lets you manage artists and songs in the Favorites list and configure Alert Settings to let you know when favorite songs or artists are playing on other channels. Also, view a list of channels airing any of your Favorites.
  • Page 145 E L E C T R O N I C S Seek Up/Down Buttons • Press to seek through Disc tracks. • Hold either button to bypass tracks without stopping. Browse • Press the “Browse” button on the touchscreen to scroll through and select a desired track on the Disc.
  • Page 146 E L E C T R O N I C S Bluetooth Streaming Audio • If equipped with Uconnect Voice Command, your Bluetooth-equipped device may also be able to stream music to your vehicle's sound system. Your connected device must be Bluetooth-compatible and paired with your system (see Uconnect Phone for pairing instruc- tions).
  • Page 147 E L E C T R O N I C S Navigation • The information in the section below is only applicable if you have the 8.4 NAV system or the Navigation has been activated on your 8.4 system. • If you have a Uconnect 8.4 system your radio is “Navigation-Ready,” and can be equipped with Navigation at an extra cost.
  • Page 148 • Just push the Uconnect Voice Command button on the steering wheel, wait for the beep and say something like, "Find Address 800 Chrysler Drive Auburn Hills MI." NOTE: Destination entry is not available while your vehicle is in motion. However, you can use Voice Commands to enter an address while moving.
  • Page 149 E L E C T R O N I C S Go Home • A Home location must be saved in the system. From the Main Navigation menu, press the “Where To?” button on the touchscreen, then press the “Go Home” button on the touchscreen. Uconnect 8.4 NAV Map 1 —...
  • Page 150 E L E C T R O N I C S Taking A Detour • To take a detour you must be navigating a route. • Press the “Detour” button on the touchscreen. NOTE: If the route you are currently taking is the only reasonable option, the device may not calculate a detour.
  • Page 151: Uconnect 8.4/8.4 Nav Voice Recognition Quick Tips

    E L E C T R O N I C S To access SiriusXM Travel Link, press “Apps” button on the touchscreen, then press the “SiriusXM Travel Link” button on the touchscreen. NOTE: SiriusXM Travel Link requires a subscription, sold separately after the five year trial subscription included with your vehicle purchase.
  • Page 152 E L E C T R O N I C S Get Started All you need to control your Uconnect system with your voice are the buttons on your steering wheel. 1. Visit UconnectPhone.com to check mobile device and feature compatibility and to find phone pairing instructions.
  • Page 153 E L E C T R O N I C S Basic Voice Commands The basic Voice Commands below can be given at any point while using your Uconnect system. Push the VR button . After the beep, say… • Cancel to stop a current voice session •...
  • Page 154 E L E C T R O N I C S Radio Use your voice to quickly get to the AM, FM or SiriusXM Satellite Radio stations you would like to hear. (Subscription or included SiriusXM Satellite Radio trial required.) Push the VR button .
  • Page 155 E L E C T R O N I C S Media Uconnect offers connections via USB, SD, and Bluetooth. Voice operation is only available for connected USB and Bluetooth devices. (Remote CD player optional and not available on all vehicles.) Push the VR button .
  • Page 156 E L E C T R O N I C S Phone Making and answering hands-free phone calls is easy with Uconnect. When the Phonebook button is illuminated for the Uconnect 5.0 and 8.4/8.4 NAV radios, your system is ready. Visit UconnectPhone.com for mobile phone compatibility and pairing instructions.
  • Page 157 E L E C T R O N I C S Voice Text Reply Uconnect will announce incoming text messages. Push the Phone button and say Listen. (Must have compatible mobile phone paired to Uconnect system.) 1. Once an incoming text message is read to you, push the Phone button and say .
  • Page 158 E L E C T R O N I C S Climate Too hot? Too cold? Adjust vehicle temperatures hands-free and keep everyone comfortable while you keep moving ahead. (If vehicle is equipped with climate control.) Push the VR button .
  • Page 159 1. To enter a destination, push the VR button . After the beep, say: • For the 8.4 Uconnect System, say: “Enter state.” • For the 8.4 NAV Uconnect System, say: “Find address 800 Chrysler Drive Auburn Hills, Michigan.” 2. Then follow the system prompts.
  • Page 160 E L E C T R O N I C S Voice Texting 1. To send a message, push the Phone button . After the beep, say the following command: “Send message to John Smith.” 2. Listen to the prompt. After the beep, dictate the message you would like to send. Wait for Uconnect to process your message.
  • Page 161 E L E C T R O N I C S Yelp Once registered with Uconnect Access, you can use your voice to search for the most popular places or things around you. Please refer to the procedure below to launch a Yelp search: 1.
  • Page 162 E L E C T R O N I C S SiriusXM Travel Link Need to find a gas station, view local movie listings, check a sports score or the 5 - day weather forecast? SiriusXM Travel Link is a suite of services that brings a wealth of information right to your Uconnect 8.4 NAV system.
  • Page 163 E L E C T R O N I C S Siri Eyes Free — If Equipped Siri lets you use your voice to send text messages, select media, place phone calls and much more. Siri uses your natural language to understand what you mean and will respond back to confirm your requests.
  • Page 164 E L E C T R O N I C S Getting Started Ensure Siri is enabled on your iPhone. Enable Siri 1 — Select Settings On Your iPhone 3 — Select Siri 2 — Select General 4 — Enable Siri 1.
  • Page 165 E L E C T R O N I C S 2. Push and Hold, then release the Uconnect Voice Recognition (VR) button on the steering wheel. After you hear the familiar Siri "double beep," say a command. NOTE: A push and release of the button will start normal embedded VR functions.
  • Page 166 E L E C T R O N I C S Additional Information © 2016 FCA US LLC. All rights reserved. Mopar and Uconnect are registered trademarks and Mopar Owner Connect is a trademark of FCA US LLC. Android is a trademark of Google Inc. SiriusXM and all related marks and logos are trademarks of SiriusXM Radio Inc.
  • Page 167: Uconnect Phone

    E L E C T R O N I C S UCONNECT PHONE Uconnect Phone (Bluetooth Hands Free Calling) Uconnect 8.4/8.4 NAV Phone Menu 1 — Favorite Contacts 12 — Browse Phone Book Entries 2 — Mobile Phone Battery Life (Contains 9-1-1) 3 —...
  • Page 168 Uconnect Phone features. Refer to the “Uconnect Voice Recognition Quick Tips” in “Multimedia” in your vehicle's Owner's Manual on www.chrysler.com/en/owners/manuals for further details. NOTE: • The Uconnect Phone requires a mobile phone equipped with the Bluetooth Hands-Free Profile, Version 1.0 or higher.
  • Page 169 E L E C T R O N I C S Pair Your iPhone: To search for available devices on your Bluetooth enabled iPhone: 1. Press the Settings button. 2. Select Bluetooth. • Ensure the Bluetooth feature is enabled. Once enabled, the mobile phone will be- gin to search for Bluetooth connections.
  • Page 170 E L E C T R O N I C S Pair Your Android Device: To search for available devices on your Bluetooth enabled Android Device: 1. Push the Menu button. 2. Select Settings. 3. Select Connections. 4. Turn Bluetooth setting to “On.” •...
  • Page 171 E L E C T R O N I C S You are now ready to make hands-free calls. Press the Uconnect “Phone” button on your steering wheel to begin. NOTE: Refer to UconnectPhone.com website for additional information on mobile phone pairing and for a list of compatible phones.
  • Page 172 E L E C T R O N I C S Changing The Volume • Start a dialogue by pushing the Phone button , then say a command for example - "Help". • Use the radio VOLUME/MUTE rotary knob to adjust the volume to a comfortable level while the Uconnect system is speaking.
  • Page 173 E L E C T R O N I C S To enable incoming text messaging: iPhone 1. Press the settings button on the mobile phone. 2. Select Bluetooth. • Ensure Bluetooth is enabled, and the mobile phone is paired to the Uconnect system. 3.
  • Page 174 E L E C T R O N I C S Voice Text Reply (Not Compatible With iPhone) NOTE: Voice texting reply and voice texting features require a compatible mobile device enabled with Bluetooth Message Access Profile (MAP). iPhone, and some other smartphones, may not entirely support Bluetooth MAP.
  • Page 175 E L E C T R O N I C S Helpful Tips And Common Questions To Improve Bluetooth Performance With Your Uconnect System Mobile Phone won’t reconnect to system after pairing: • Set mobile phone to auto-connect or trusted device in mobile phone Bluetooth settings (Blackberry devices).
  • Page 176: Uconnect Theater - If Equipped

    E L E C T R O N I C S UCONNECT THEATER — IF EQUIPPED Uconnect Theater Overview Your Uconnect Theater is designed to give your family years of enjoyment. There are multiple ways to interact with your Uconnect Theater system. •...
  • Page 177 E L E C T R O N I C S 8. Test to see if the remote is paired to the intended screen by checking the screen indicator light on the remote, and/or running your finger on the gesture pad to see if the cursor responds. NOTE: •...
  • Page 178 E L E C T R O N I C S 10. Back Button — Push to exit out of menus or return to previous screen. 11. Power Button — Turns the screen and wireless headphone transmitter for the selected Channel on or off.
  • Page 179 E L E C T R O N I C S 4. For DVD/Blu-ray disc – press Movie Snapshot on radio touchscreen, then press “OK” on following screen. For USB Media Files - Press Music, Movie, or Folders, then select media title from list(s).
  • Page 180 E L E C T R O N I C S Uconnect Theater Apps Select the Apps source card to play pre-loaded games. Pressing the “Help” button teaches us- ers how to play each game. Pick from games: • Back Seat Bingo •...
  • Page 181 E L E C T R O N I C S Using The Rear Video USB Port Plug in a jump drive, iPhone, iPod or mass storage device and play your favorite music or movies. NOTE: To view USB media on the rear theater screens, insert a USB jump drive into the port next to the DVD/Blu-ray disc player.
  • Page 182 E L E C T R O N I C S Headphones Operation The headphones receive two separate channels of audio using an infrared transmitter from the video screens. If no audio is heard after increasing the volume control, verify that the screen is turned on, the channel is not muted, the headphones are on, and that the headphone channel selector button is on the desired channel.
  • Page 183 E L E C T R O N I C S Changing The Audio Mode For Headphones 1. Ensure the remote control and the headphones are on the same channel. 2. Push the Home button on the remote control. 3. When the Home menu appears on the touchscreen, use the arrow buttons on the remote control to navigate to the available modes and push the OK button to select the new mode or use the Gesture Pad at the top of the remote control.
  • Page 184 E L E C T R O N I C S What Does This Warranty Not Cover? This warranty does not cover any damage or defect that results from misuse, abuse or modification of the Product other than by Delphi Automotive. Foam earpieces, which will wear over time through normal use, are specifically not covered (replacement foam is available for a nominal charge).
  • Page 185 Accessibility is a feature of the DVD/Blu-ray/USB Video system that announces a function prior to performing the action. For further information refer to “Uconnect Settings” in “Multimedia” in your Owner’s Manual on www.chrysler.com/en/owners/manuals Wireless Streaming/Mirroring — If Equipped Your Uconnect Theater System may be equipped with Wireless Streaming/Mirroring function- ality that allows you to project your smartphone or tablet onto your rear Uconnect Theater touchscreens.
  • Page 186: Steering Wheel Audio Controls

    E L E C T R O N I C S Settings Below is a list of the settings available for the Wireless Streaming/Mirroring feature of your Uconnect Theater system: • Wireless: ON/OFF – Turn on and off the wireless feature of the Uconnect Theater system. •...
  • Page 187: Aux/Usb/Mp3 Control

    E L E C T R O N I C S AUX/USB/MP3 CONTROL There are numerous USB ports located throughout the vehicle. This feature allows an external USB device to be plugged into the USB port. For further information, refer to the Uconnect Owner’s Manual Supplement. There are multiple USB “charge only”...
  • Page 188: Instrument Cluster Display

    E L E C T R O N I C S INSTRUMENT CLUSTER DISPLAY Instrument Cluster Display And Controls The vehicle’s instrument cluster is equipped with an instrument cluster display, which offers useful information to the driver. With the ignition in the STOP/OFF position, opening/closing of a door will activate the instrument cluster display for viewing, and display the total miles or kilometers in the odometer.
  • Page 189: Programmable Features

    The different sections of the instrument cluster display can each be programmed separately to display some of the options above. For further information, refer to “Instrument Cluster Display” in “Getting To Know Your Instrument Panel” in the Owner’s Manual at www.chrysler.com/en/owners/manuals/. Uconnect Customer Programmable Features The Uconnect system allows you to access Customer Programmable feature settings such as KeySense, Display, Units, Voice, Clock, Safety &...
  • Page 190: Power Inverter - If Equipped

    E L E C T R O N I C S POWER INVERTER — IF EQUIPPED There is a 115 Volt, 150 Watt Power Inverter outlet located on the right side of the vehicle, before the third row of seats to convert DC current to AC current. The Power Inverter can power cellular phones, electronics and other low power devices requiring up to 150 Watts.
  • Page 191 E L E C T R O N I C S CAUTION! Power outlets are designed for accessory plugs only. Do not insert any other object in the power outlets as this will damage the outlet and blow the fuse. Improper use of the power outlet can cause damage not covered by your New Vehicle Limited Warranty.
  • Page 192 E L E C T R O N I C S The rear power outlet is located in the right rear cargo area. NOTE: The USB outlet in the bottom of the instru- ment panel can be switched from “ignition” only to constant “battery”...
  • Page 193: Utility

    U T I L I T Y TRAILER TOWING Trailer towing is not permitted with this vehicle. RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) Towing This Vehicle Behind Another Vehicle Towing Condition Wheel OFF the Ground All Models Flat Tow NONE NOT ALLOWED Front Dolly Tow Rear...
  • Page 194 U T I L I T Y Recreational Towing — All Models DO NOT flat tow this vehicle. Damage to the drivetrain will result. CAUTION! • DO NOT flat tow this vehicle. Damage to the drivetrain will result. If this vehicle requires towing, make sure the drive wheels are OFF the ground.
  • Page 195: What To Do In Emergencies

    W H A T T O D O I N E M E R G E N C I E S ROADSIDE ASSISTANCE Dial toll-free 1-800-521-2779 for U.S. Residents or 1-800-363-4869 for Canadian Residents. • Provide your name, vehicle identification number, license plate number, and your location, including the telephone number from which you are calling.
  • Page 196 W H A T T O D O I N E M E R G E N C I E S – Low Fuel Warning Light This warning light indicates when the fuel level reaches approximately 1.5 gal (5.8 L). This light will turn on and a single chime will sound.
  • Page 197 W H A T T O D O I N E M E R G E N C I E S – Brake Warning Light This light monitors various brake functions, including brake fluid level and parking brake appli- cation. If the brake light turns on, it may indicate that the parking brake is applied, that the brake fluid level is low, or that there is a problem with the brake system master cylinder reservoir.
  • Page 198 W H A T T O D O I N E M E R G E N C I E S If the light remains lit with the engine running, your vehicle will usually be drivable. However, see an authorized dealer immediately. If the light is flashing when the engine is running, immediate service is required, and you may experience reduced performance, an elevated/rough idle or engine stall, and your vehicle may require towing.
  • Page 199 W H A T T O D O I N E M E R G E N C I E S IF THE LIGHT STARTS FLASHING INDICATING A LOW TIRE PRESSURE, ADJUST THE AIR PRESSURE IN THE LOW TIRE TO THE AIR PRESSURE SHOWN ON THE VEHICLE PLACARD OR TIRE INFLATION PRESSURE LABEL LOCATED ON THE DRIVER'S DOOR.
  • Page 200 W H A T T O D O I N E M E R G E N C I E S Instrument Cluster Indicator Lights – Turn Signal Indicator The arrows will flash with the exterior turn signals when the turn signal lever is operated. A tone will chime, and a message will appear if either turn signal is left on for more than 1 mile (1.6 km).
  • Page 201 W H A T T O D O I N E M E R G E N C I E S – KeySense Indicator Light This indicator will illuminate when a KeySense key fob is detected upon startup of the vehicle. While the KeySense key is in use, the vehicle will respond to customized vehicle settings and mandatory settings which were specified when the KeySense key was activated and given a PIN.
  • Page 202 W H A T T O D O I N E M E R G E N C I E S – Speed Control ON Indicator This indicator will illuminate when the speed control has been activated to the “ON” position. –...
  • Page 203 W H A T T O D O I N E M E R G E N C I E S Oil Life Reset • Your vehicle is equipped with an engine oil change indicator system. The “Oil Change Due” message will display for approximately five seconds after a single chime has sounded, to indicate the next scheduled oil change interval.
  • Page 204: If Your Engine Overheats

    W H A T T O D O I N E M E R G E N C I E S IF YOUR ENGINE OVERHEATS In any of the following situations, you can reduce the potential for overheating by taking the appropriate action.
  • Page 205: Tire Service Kit - If Equipped

    W H A T T O D O I N E M E R G E N C I E S TIRE SERVICE KIT — IF EQUIPPED Your vehicle is equipped with a Tire Service Kit. Small punctures up to 1/4 inch (6 mm) in the tire tread can be sealed with Tire Service Kit.
  • Page 206 W H A T T O D O I N E M E R G E N C I E S Using The Mode Select Knob And Hoses Your Tire Service Kit is equipped with the following symbols to indicate the air or sealant mode. Selecting Air Mode Push in the Mode Select Knob and turn to this position for air pump operation only.
  • Page 207 W H A T T O D O I N E M E R G E N C I E S WARNING! • Do not attempt to seal a tire on the side of the vehicle closest to traffic. Pull far enough off the road to avoid the danger of being hit when using the Tire Service Kit.
  • Page 208 W H A T T O D O I N E M E R G E N C I E S Setting Up To Use Tire Service Kit: 1. Uncoil the Sealant Hose and then remove the cap from the fitting at the end of the hose. 2.
  • Page 209 W H A T T O D O I N E M E R G E N C I E S If the tire inflates to the recommended pressure or is at least 26 psi (1.8 Bar) pressure within 15 minutes: NOTE: If the tire becomes over-inflated, push the Deflation Button to reduce the tire pressure to the recommended inflation pressure before continuing.
  • Page 210 W H A T T O D O I N E M E R G E N C I E S If the tire pressure is 19 psi (1.3 Bar) or higher: 1. Push the Power Button to turn on Tire Service Kit and inflate the tire to the cold tire inflation pressure found on the tire and loading information label located in the driver-side door opening.
  • Page 211: Jump-Starting

    W H A T T O D O I N E M E R G E N C I E S JUMP-STARTING The vehicle requires its 12V battery power to "turn-on" the vehicle's high voltage battery. The high voltage battery is used to charge the 12V battery, provide electric vehicle operation, and to start the vehicle's gas engine.
  • Page 212 W H A T T O D O I N E M E R G E N C I E S CAUTION! Do not use a portable battery booster pack or any other booster source with a system voltage greater than 12 Volts or damage to the battery, starter motor, alternator or electrical system may occur.
  • Page 213 W H A T T O D O I N E M E R G E N C I E S Jump-Starting Procedure WARNING! Failure to follow this jump-starting procedure could result in personal injury or property damage due to battery explosion. CAUTION! Failure to follow these procedures could result in damage to the charging system of the booster vehicle or the discharged vehicle.
  • Page 214: Towing A Disabled Vehicle

    W H A T T O D O I N E M E R G E N C I E S If frequent jump-starting is required to start your vehicle, you should have the battery and charging system inspected at your authorized dealer. CAUTION! Accessories plugged into the vehicle power outlets draw power from the vehicle’s battery, even when not in use (i.e., cellular devices, etc.).
  • Page 215 W H A T T O D O I N E M E R G E N C I E S Vehicle Recovery Tow Points Your vehicle is equipped with Vehicle Recovery Points that can be used to recover a disabled vehicle, located on the underbody of the vehicle.
  • Page 216: Freeing A Stuck Vehicle

    Off" mode, before rocking the vehicle. Refer to “Electronic Brake Control System” in “Safety” in the Owner’s Manual on www.chrysler.com/en/owners/manuals for further information. Once the vehicle has been freed, push the "ESC Off" switch again to restore "ESC On" mode.
  • Page 217: Enhanced Accident Response System (Ears)

    W H A T T O D O I N E M E R G E N C I E S ENHANCED ACCIDENT RESPONSE SYSTEM (EARS) This vehicle is equipped with an Enhanced Accident Response System. Please refer to “Occupant Restraint Systems” in “Getting Started” for further information on the Enhanced Accident Response System (EARS) function.
  • Page 218: Maintaining Your Vehicle

    M A I N T A I N I N G Y O U R V E H I C L E HOOD Opening The hood release lever (to open the primary latch) and safety latch (to open the secondary latch) must be released to open the hood.
  • Page 219 M A I N T A I N I N G Y O U R V E H I C L E Closing 1. Hold up the hood with one hand and with the other hand remove the support rod from its seat and reinsert it into the locking tab.
  • Page 220: Engine Compartment - Hybrid

    M A I N T A I N I N G Y O U R V E H I C L E ENGINE COMPARTMENT — HYBRID 1. Battery Coolant Reservoir* 2. Engine Coolant Reservoir 3. Engine Oil Fill 4. Engine Oil Dipstick 5.
  • Page 221 M A I N T A I N I N G Y O U R V E H I C L E 6. Washer Fluid Reservoir 7. Brake Fluid Reservoir 8. Remote Jump Start Positive Terminal 9. Low Voltage Power Distribution Center (Fuses) 10.
  • Page 222: Fluid Capacities

    M A I N T A I N I N G Y O U R V E H I C L E Adding Washer Fluid The fluid reservoir is located in the front of the engine compartment. Be sure to check the fluid level in the reservoir at regular intervals.
  • Page 223: Fluids And Lubricants

    M A I N T A I N I N G Y O U R V E H I C L E FLUIDS AND LUBRICANTS Engine Component Fluid, Lubricant, or Genuine Part Engine Coolant We recommend you use Mopar Antifreeze/Coolant 10 Year/150,000 Mile Formula OAT (Organic Additive Technology) with deionized, or distilled water for proper corrosion protection or equivalent meeting the require-...
  • Page 224: Maintenance Procedures

    For information on the maintenance procedures for your vehicle, please refer to “Dealer Services” in “Maintaining And Caring For Your Vehicle” in your Owner’s Manual on www.chrysler.com/en/owners/manuals or in an applicable supplement for further details. MAINTENANCE SCHEDULE Your vehicle is equipped with an automatic oil change indicator system. The oil change indicator system will remind you that it is time to take your vehicle in for scheduled maintenance.
  • Page 225 M A I N T A I N I N G Y O U R V E H I C L E Your authorized dealer will reset the oil change indicator message after completing the scheduled oil change. If a scheduled oil change is performed by someone other than your authorized dealer, the message can be reset by referring to “Vehicle Info”...
  • Page 226 M A I N T A I N I N G Y O U R V E H I C L E...
  • Page 227 M A I N T A I N I N G Y O U R V E H I C L E...
  • Page 228 M A I N T A I N I N G Y O U R V E H I C L E...
  • Page 229: Fuses

    M A I N T A I N I N G Y O U R V E H I C L E FUSES WARNING! • When replacing a blown fuse, always use an appropriate replacement fuse with the same amp rating as the original fuse. Never replace a fuse with another fuse of higher amp rating. Never replace a blown fuse with metal wires or any other material.
  • Page 230 M A I N T A I N I N G Y O U R V E H I C L E Cavity Cartridge Fuse Blade Fuse Description – – Not Used 40 Amp Green – CBC Feed #4 (Exterior Lights #1) –...
  • Page 231 M A I N T A I N I N G Y O U R V E H I C L E Cavity Cartridge Fuse Blade Fuse Description 30 Amp Pink – Front Wiper – – Not Used – – Not Used 40 Amp Green –...
  • Page 232 M A I N T A I N I N G Y O U R V E H I C L E Cavity Cartridge Fuse Blade Fuse Description ICS / Frt & Rr HVAC / F79A – EPB Sw / SCCM 10 Amp Red F79B –...
  • Page 233: Refueling The Vehicle

    M A I N T A I N I N G Y O U R V E H I C L E REFUELING THE VEHICLE 1. Press the fuel filler door release button (located in the driver’s door). Fuel Filler Door Release Switch 2.
  • Page 234 M A I N T A I N I N G Y O U R V E H I C L E 3. Open the fuel filler door. NOTE: In certain cold conditions, ice may prevent the fuel door from opening. If this occurs, lightly push on the fuel door to break the ice buildup and re-release the fuel door using the inside release button.
  • Page 235 M A I N T A I N I N G Y O U R V E H I C L E Emergency Fuel Door Release 1. Access the storage bin located behind the rear cargo trim panel. 2. Remove access cover in the upper right corner. Access Cover Location 3.
  • Page 236: Tire Safety Information

    M A I N T A I N I N G Y O U R V E H I C L E TIRE SAFETY INFORMATION Tire Markings NOTE: • P (Passenger) — Metric tire sizing is based on U.S. design standards. P-Metric tires have the letter “P”...
  • Page 237 M A I N T A I N I N G Y O U R V E H I C L E Tire Sizing Chart EXAMPLE: Example Size Designation: P215/65R15XL 95H, 215/65R15 96H, LT235/85R16C, T145/ 80D18 103M, 31x10.5 R15 LT P = Passenger car tire size based on U.S.
  • Page 238 M A I N T A I N I N G Y O U R V E H I C L E Tire Identification Number (TIN) The TIN may be found on one or both sides of the tire; however, the date code may only be on one side.
  • Page 239 M A I N T A I N I N G Y O U R V E H I C L E Tire Loading And Tire Pressure Tire And Loading Information Placard Location NOTE: The proper cold tire inflation pressure is listed on the driver’s side B-Pillar or the rear edge of the driver's side door.
  • Page 240 M A I N T A I N I N G Y O U R V E H I C L E WARNING! • Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recommended load capacity for your vehicle.
  • Page 241 M A I N T A I N I N G Y O U R V E H I C L E Steps For Determining Correct Load Limit— (1) Locate the statement “The combined weight of occupants and cargo should never exceed XXX kg or XXX lbs.”...
  • Page 242 M A I N T A I N I N G Y O U R V E H I C L E Metric Example For Load Limit For example, if “XXX” amount equals 635 kg, and there will be five 68 kg passengers in your vehicle, the amount of available cargo and luggage load capacity is 295 kg (635-340 (5x68) = 295 kg) as shown in step 4.
  • Page 243: Tires - General Information

    M A I N T A I N I N G Y O U R V E H I C L E TIRES — GENERAL INFORMATION Tire Pressure Proper tire inflation pressure is essential to the safe and satisfactory operation of your vehicle. Four primary areas are affected by improper tire pressure: •...
  • Page 244 M A I N T A I N I N G Y O U R V E H I C L E Tire Inflation Pressures The proper cold tire inflation pressure is listed on the driver's side B-Pillar or rear edge of the driver's side door.
  • Page 245 M A I N T A I N I N G Y O U R V E H I C L E Radial Ply Tires WARNING! Combining radial ply tires with other types of tires on your vehicle will cause your vehicle to handle poorly.
  • Page 246 M A I N T A I N I N G Y O U R V E H I C L E Snow Tires Some areas of the country require the use of snow tires during the Winter. Snow tires can be identified by a “mountain/snowflake”...
  • Page 247 M A I N T A I N I N G Y O U R V E H I C L E Compact Spare Tire — If Equipped The compact spare is for temporary emergency use only. You can identify if your vehicle is equipped with a compact spare by looking at the spare tire description on the Tire and Loading Information Placard located on the driver’s side door opening or on the sidewall of the tire.
  • Page 248 M A I N T A I N I N G Y O U R V E H I C L E Full Size Spare — If Equipped The full size spare is for temporary emergency use only. This tire may look like the originally equipped tire on the front or rear axle of your vehicle, but it is not.
  • Page 249 M A I N T A I N I N G Y O U R V E H I C L E Life Of Tire The service life of a tire is dependent upon varying factors including, but not limited to: •...
  • Page 250 M A I N T A I N I N G Y O U R V E H I C L E WARNING! • Do not use a tire, wheel size or rating other than that specified for your vehicle. Some combinations of unapproved tires and wheels may change suspension dimensions and performance characteristics, resulting in changes to steering, handling, and braking of your vehicle.
  • Page 251: Department Of Transportation Uniform Tire Quality Grades

    M A I N T A I N I N G Y O U R V E H I C L E When cleaning extremely dirty wheels including excessive brake dust, care must be taken in the selection of tire and wheel cleaning chemicals and equipment to prevent damage to the wheels. Mopar Wheel Treatment, Mopar Chrome Cleaner, or their equivalent is recommended or select a non-abrasive, non-acidic cleaner for aluminum or chrome wheels.
  • Page 252 M A I N T A I N I N G Y O U R V E H I C L E Treadwear The Treadwear grade is a comparative rating, based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and one-half times as well on the government course as a tire graded 100.
  • Page 253: Bulb Replacement

    M A I N T A I N I N G Y O U R V E H I C L E BULB REPLACEMENT Replacement Bulbs Interior Bulbs Lamps Bulb Number Center & Rear Dome Lamp LED (Serviced At Authorized Dealer) Center &...
  • Page 254: Consumer Assistance

    Visa, Master Card, American Express and Discover orders are accepted. NOTE: • The Owner's Manual and User Guide electronic files are also available on the Chrysler, Jeep®, Ram Truck, Dodge and SRT websites. • Click on the “For Owners” tab, select “Owner/Service Manuals”, then select your desired...
  • Page 255: Reporting Safety Defects In The United States

    C O N S U M E R A S S I S T A N C E REPORTING SAFETY DEFECTS IN THE UNITED STATES If you believe that your vehicle has a defect that could cause a crash or cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying FCA US LLC.
  • Page 256: Mopar® Accessories

    • For the full line of Authentic Chrysler Accessories by Mopar visit your local dealership or online at mopar.com for U.S. residents and mopar.ca for Canadian residents.
  • Page 257: Faq's

    F A Q ’ S FREQUENTLY ASKED QUESTIONS GETTING STARTED • How do I install my LATCH Equipped Child Seat? pg. 65 • How do my heated seats operate? pg. 84 ELECTRONICS How do I use my Uconnect Theater? • Uconnect Theater (play DVD’s) pg. 174 Which radio is in my vehicle? •...
  • Page 258: Index

    I N D E X Access Automatic Headlights ...88 Uconnect ...121, 123, 130 Automatic Temperature Control Accessories ....254 (ATC) .
  • Page 259 I N D E X Child Seat Installation ..67, 68 Pressure Cap ... . .222 How To Stow An Unused ALR Selection Of Coolant Seat Belt .
  • Page 260 I N D E X Oil ... . .220, 221, 222 Voice Text Reply ... .172 Oil Filler Cap ... . .222 Hands-Free Sliding Door And Liftgate .
  • Page 261 I N D E X Bulb Replacement ..251 Overheating, Engine ...202 Fog ....198 High Beam Indicator .
  • Page 262 I N D E X Reporting Safety Defects ..253 SIRIUS Travel Link ... .148 Restraint, Head ....73 SmartBeams .
  • Page 263 I N D E X Load Capacity ..237, 238 In Vehicle Features ..130 Quality Grading ...249 Purchase Apps .
  • Page 264 This guide has been prepared to help you get quickly acquainted with your new Chrysler brand vehicle and to provide a convenient reference source for common questions. However, it is not a substitute for your Owner’s Manual. For complete operational instructions, maintenance procedures and important safety messages, please consult your Owner’s Manual, Navigation/...
  • Page 265 ©2017 FCA US LLC. All Rights Reserved. Chrysler is a registered trademark of FCA US LLC. 1 7 P H E V- 9 2 6 - A A • PA C I F I C A H Y B R I D...

Table of Contents
