DigiCreaser
The Display Unit and the Switches on the Control Panel allow the
operator to read, edit, create and initiate numerous creasing programs
within the memory.
The Control Panel houses the Selection Switch, System Switch, and an
industry standard Emergency Stop switch which will stop all power going
to the machine when activated.
Selection Switch
Allows the operator to scroll through stored addresses and programs, and to set a
crease position.
System switch
When activated the system switch will operate the motors in order to begin the
creasing sequence.
SYSTEM

THE CONTROLS

THE CONTROL PANEL

Features on the Control Panel

Selection Switch
System Switch
Emergency Stop Switch
Page 7
