Introduction; The Morgana Digicreaser - Morgana DigiCreaser Operator's Manual

DigiCreaser
The Morgana Digicreaser is a fully automatic, after feeding, creasing
system designed for use with both conventional litho and digital printers.
The Digicreaser is capable of creasing sheet sizes to a maximum of
630mm x 330mm (24.8" x 13") and weights up to 400gsm.
Up to nine creases can be programmed to a single sheet.
The crease is programmed from the leading edge of the sheet using the
controls on the front panel.
A minimum distance between creases is 0.1mm.
The Digicreaser has up to nine available memory addresses for
programmed creasing operations.
The blade and anvil are mechanically controlled over their entire length
and can be adjusted to accommodate various weights of media.
SYSTEM

INTRODUCTION

DigiCreaser
Page 3
