RECOMMENDED SPARES

PART NUMBER
613-365
652-011
144-04-04
75-347-01
125-21-02
75-210-05
655-014
655-011
655-015
655-016
613-053
76-166
76-167
76-168
98-013
609-022
606-035
76-109
76-213-01
607-042
607-048
608-019
76-082
76-083
76-175-01
76-177-01
76-019-03
78-013
613-351
613-191
75-040
602-085
681-015
Page 26
DESCRIPTION
EMERGENCY STOP SWITCH
SYSTEM SWITCH
JOYSTICK AND LEAD ASSEMBLY
CONTROL PCB ASSEMBLY
DUAL STEPPER DRIVE PCB ASSEMBLY
LCD DISPLAY UNIT (4 x 20) AND LEAD ASSEMBLY
PSU - SWITCH MODE - 5V
(Used on Machines:- Serial Nos. 770001 TO 770180)
PSU - SWITCH MODE - 5V / 24V
(Used on Machines:- Serial Nos. 770181 Onwards)
PSU - SWITCH MODE - 24V
PSU - SWITCH MODE - 48V
FAN 119mm
PAPER JAM SENSOR ASSEMBLY
UPPER SENSOR ASSEMBLY
PAPER GUIDE ASSEMBLY - Bottom Sensor
ANTI-STATIC BRUSH
'O' RING Ø32
KNOB - Roller Tilt
POWER LINK BEARING
BLADE SET - 320 Wide - Standard
TIMING BELT 160XL
TIMING BELT TWIN GRIP - 200 DXL 050
SHOULDER BOLT
PERFORATOR - DRIVE HUB ASSEMBLY
PERFORATOR - DRIVE WHEEL
INPUT ROLLER - Lower
INPUT ROLLER - Upper
OUTPUT SHAFT
PERFORATOR STRIPPER ASSEMBLY
MICRO SWITCH - Guard Circuit
MICRO SWITCH - Home Circuit
STACKER SWITCH ASSEMBLY
BEARING-DRAWN CUP NEEDLE ROLLER Ø10XØ14X10
FUSE - 4.0A - 20mm x 5mm - ANTI-SURGE
HAND FED CREASING
