DigiCreaser

Programming the machine

1. Switch the power 'on' by turning the Emergency stop button clockwise
to release the safety latch. The display is now switched on.
Setting the crease positions
2. Move the selection switch up, one click at a time, until the start up menu is displayed
as shown below.
(i) Move the selection switch to the right to select
(ii) Move the selection switch down to select
(iii) Move the selection switch to the left to select
Decimals.
(iv) The Tens
Rotating the Selection Switch, (clockwise to increase or anti-clockwise to decrease).
(v) Adjust all other digits for the 1st Crease position as described in steps (iii) and (iv),
(I.e. move the selection switch to the left to select the Tens or to the right to select
Decimals and then rotate the Selection Switch to adjust its value.
(vi) Move the selection switch down to select the 2nd Crease. The second crease will
automatically start at 0000.0. Crease positions can be set in increments of 0.1mm.
(vii) Set the 2nd Crease position as described in steps (iii) to (v) above.
Further creases can be set in this way, up to a maximum of nine creases.
Storing the crease positions
3. Once the crease positions are correctly entered, they can be stored as follows.
(i) Move the selection switch up, one click at a time, until the display contains the word
More.
(ii) Move the selection switch to the right, one click at a time, until the display contains
the word Programs
(iii) Move the selection switch down to select Save All Settings.
(iv) Move the selection switch to the right to select
(v) Move the selection switch to the right or to the left to select
(vi) Move the selection switch up to save the program in the selected program number.
(vii) Move the selection switch up to select Ok.
SYSTEM
Tools
2 Creases
or Decimals (whichever has been selected) can then be adjusted by
.
Operating the Digicreaser
Setup
Feed
Zero
Total 20
Program 3
Setup .
Set Creases .
Tens , or to the right to select
Ok .
Program 1 to Program 9
