DigiBook 300r2
Operator Manual
MyBinding.com
5500 NE Moore Court
Hillsboro, OR 97124
Toll Free: 1-800-944-4573
rel. 03.00
Local: 503-640-5920

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DigiBook 300r2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Morgana DigiBook 300r2

  • Page 1 DigiBook 300r2 Operator Manual MyBinding.com 5500 NE Moore Court Hillsboro, OR 97124 Toll Free: 1-800-944-4573 rel. 03.00 Local: 503-640-5920...
  • Page 2: Table Of Contents

    Operator Manual Digibook 300 Summary INTRODUCTION __________________________________________________ 5 SYMBOLS OF SAFETY _______________________________________________________________ 7 SYMBOLS OF PROHIBITION AND OBLIGATORINESS _______________________________________ 8 THE SAFETY DURING THE USE OF THE MACHINE _________________________________________ 9 1.3.1 general ________________________________________________________________________ 9 1.3.2 SAFETY WARNINGS ______________________________________________________________ 9 SAFETY CLOTHING _______________________________________________________________ 10 INSTALLATION OF ELECTRICAL CABLES AND PIPES ______________________________________ 11 SAFETY EQUIPMENTS IN THE PERFECT BINDER _________________________________________ 11 1.6.1...
  • Page 3: Page Of Job Management

    Operator Manual Digibook 300 TRAINING OF THE OPERATOR ______________________________________ 29 10 POWER ON ____________________________________________________ 30 10.1 ____________________________________________________________________ 31 FUNDAMENTALS 10.2 _____________________________________________________________ 33 ELECTRICAL CONNECTION 10.3 _____________________________________________________________ 33 PNEUMATIC CONNECTION 10.4 __________________________________________________________ 34 DESCRIPTION OF THE GROUPS 10.5 ___________________________________________________________________ 37 CHIPS ASPIRATOR 10.7 .
  • Page 4 Operator Manual Digibook 300 18.1 P _____________________________________ E AGE OF JOB MANAGEMENT RROR OOKMARK NOT DEFINED 19 GLUE RECOVERY PROCEDURE ______________________________________ 64 20 COVER POSITIONING _____________________________________________ 67 PREPARATION OF THE MACHINE TO PRODUCE A BOOK. _____________________ 69 21 CLEANING THE MACHINE _________________________________________ 72 21.1 .
  • Page 5: Introduction

    Operator Manual Digibook 300 1 INTRODUCTION THE READING OF THIS OPERATOR AND MAINTE- NANCE MANUAL IS FUNDAMENTAL FOR THE SAFETY OF THE USER AND FOR THE PROPER USE OF THE EQUIPMENT. We thank you to have bought our product. This machine has been designed specifically for your job and your applications, and provides a high quality production and a wide range of functions.
  • Page 6 Operator Manual Digibook 300 DECLARATION THAT THE MACHINE IS IN SPECIFICATION TO THE EEC DIRECTIVE CONTROLLING THE MACHINES 2006/42/CE, (AND FOLLOWING EEC DIRECTIVES) We declare that the production of: Product: Perfect Binder Model/Type: Digibook 300 Serial Number: MB300-..Year of construction: 2012 Follows the actual releases of the EEC Controlling Directives: EEC Directive 2006/42/CE;...
  • Page 7: Symbols Of Safety

    Operator Manual Digibook 300 SAFETY 1.1 SYMBOLS OF SAFETY In the manual some symbols are used to inform about dangerous situations for people and/or things. The following symbols mean dangerous situations for people and/or things. If you don’t follow carefully the appropriate procedures, damages can occur to people and/or things and in extreme situations also fatal accidents.
  • Page 8: Symbols Of Prohibition And Obligatoriness

    Operator Manual Digibook 300 In case of not warning of the symbols damages, also great, can hap- pen to the machine and to the accessories. 1.2 SYMBOLS OF PROHIBITION AND OBLIGATORINESS  This symbol means a prohibition.  This symbol means an imperative. This symbol means that it is mandatory to read in this manual infor- mation regarding specific topics (for ex.
  • Page 9: The Safety During The Use Of The Machine

    Operator Manual Digibook 300 1.3 THE SAFETY DURING THE USE OF THE MACHINE 1.3.1 GENERAL The manufacturer guarantees that the contents of this manual are in specification with the procedures required by the machine. The manufacturer therefore will be not re- sponsible if the machine will be used in a different way.
  • Page 10: Safety Clothing

    Operator Manual Digibook 300 1.4 SAFETY CLOTHING Clothing to use during the cleaning and /or maintenance operations Eye protection against any spray of PUR glue or high temperature cleaner Respiratory Mask Protective gloves Tight clothing, to avoid that they remain engaged with protruding parts. Long hair must be covered or otherwise collected by using e.
  • Page 11: Installation Of Electrical Cables And Pipes

    Operator Manual Digibook 300 1.5 INSTALLATION OF ELECTRICAL CABLES AND PIPES Cables and pipes must be put inside of special cable channels to avoid the people to stumble and get hurt. 1.6 SAFETY EQUIPMENTS IN THE PERFECT BINDER DANGER! It is forbidden to remove or render ineffective the safety guards for the safety of persons, and to tamper and / or modify, even partially, safety devices installed on the machine.
  • Page 12: Green Button For Start Cycle

    Operator Manual Digibook 300 1.6.2 G FOR START REEN BUTTON CYCLE The green button executes the command to start cycle, it means that the clamp closes and moves to the right, the mill if activated will run the cut, the glue will be applied, and if the press has been ac- tivated will crush the book;...
  • Page 13: Protection Plate Of The Milling Station

    Operator Manual Digibook 300 1.6.4 P ROTECTION PLATE OF THE MILLING STATION An elastic cord exerts constantly on the The plate consists of a mobile plate that, ex- plate (F) a force (see arrows) that covers cept when the book block is moving, covers the mill disc.
  • Page 14: Risks

    Operator Manual Digibook 300 1.7 RISKS There are risks that cannot be completely eliminated by either protective or as designed by the machine. Area of the glue head. Attention – Hot surfaces! Risk of burn. Use protective gloves. Area of glue loading. Attention –...
  • Page 15: Purpose

    Operator Manual Digibook 300 1.8 PURPOSE The machine is used to bind books using the following materials: a) Signatures, or sheet of paper (printed or not) for the block book b) Cardboard as cover of the book Within the limits specified in the data sheet, included in this manual. 1.8.1 USES NOT PROVIDED USES PROHIBITED...
  • Page 16: Technical Sheet Masterbook300

    Operator Manual Digibook 300 2 TECHNICAL SHEET Digibook 300 Machine features: Cycle/Hour 300 mechanical cycles Spine length 100 – 450 mm Workable height of the book 120 – 320 mm Max. Cover size 710x460/240x110 mm Workable thickness of the book 2 –...
  • Page 17 Operator Manual Digibook 300 Mechanical Adjustment Automatic/mechanical height adjustment Mechanical Adjustment Cover back bar adjustment Automatic, driven by the parameters on the Cover loading Hand made by the operator Touch-Screen Dimensions / Weight Length 1850 mm Width 1090 mm Height 1370 mm Weight 500 Kg...
  • Page 18: Electrical

    Operator Manual Digibook 300 2.1.1 E LECTRICAL Electrical power 400 V ±5%, 50 Hz, 3 ph + N + PE Protection fuses on the power network are du- Power of the machine ties of the customer 16 A Distribution cabinet, customer side Differential protection class A 300mA 2.1.2 P NEUMATICS...
  • Page 19: Air Quality Provided To The Perfect Binder

    Operator Manual Digibook 300 Air quality provided to the Perfect Binder CLASS 3, DIN ISO 8573-1 Durst: 5 micron - 5 mg/m3 Water: -20°C - 0,88 g/m3 Oil: 1 mg/m3 The compressed air system upstream of the machine must be equipped with a dryer.
  • Page 20: Accessories

    Operator Manual Digibook 300 3 ACCESSORIES The standard composition includes: – Cleaning Kit – Start- up Kit CLEANING KIT Polizene green spatula (to remove excess glue or cleaner) Steel Wire 0.4" (for cleaning the channels of leakage of the lateral glue) Lamella thickness of 0.4 (for cleaning the slit of leakage of the spine glue) Spare Headless screws for the closure of...
  • Page 21: Transportation

    Operator Manual Digibook 300 4 TRANSPORTATION The Perfect Binder must be handled by a heaver. It can be got on all 4 sides, at the bottom of the frame are provided channels for the insertion of the forks. For the final positioning or small move- ments can be used a trans-pallet.
  • Page 22 Operator Manual Digibook 300 DANGER! For no reason the staff is authorized to pass under a suspended load during transport or in the proximity of. The producer is not respon- sible for what happens during this operation, to be carried out by quali- fied and authorized personnel, with the necessary individual safety pro- tections (Suit, shoes, gloves, helmet, and glasses).
  • Page 23: Storage

    Operator Manual Digibook 300 5 STORAGE The information contained in this section must be observed in case of temporary storage of the machine that may occur in the following situations: Installation of the machine not immediately after its delivery. Uninstalling the machine. Storage awaiting a new location.
  • Page 24: Layout

    Operator Manual Digibook 300 6 LAYOUT 7 POSITIONING AND WORKSPACES Positioning: The Perfect Binder must be positioned so as to have a clear space around of at least 80 cm, and around the work area at least 150 cm. The room where the machine is installed must be properly ventilated with air change. MyBinding.com 5500 NE Moore Court Hillsboro, OR 97124...
  • Page 25 Operator Manual Digibook 300 Workspaces Glue loading area Glue loading area, the operator enter in this area to load the glue in the machine. Access area for the maintenance, for access to the electrical and pneumatic panel. Transit area Used to transit from the work area to the glue loading area. Operator’s work area Operator’s work area during the normal use of the machine.
  • Page 26: Installation

    Operator Manual Digibook 300 8 INSTALLATION 8.1 TECHNICAL STAFF FOR THE INSTALLATION The machine must be installed by people specifically trained and authorized by K.G.S. . 8.2 PHYSICAL CHARACTERISTICS OF THE AREA OF PLACEMENT In addition to the overall dimensions of the machine given in the previous chapter, you must also meet the following conditions: Near the area of placement of the machine should be arranged the sources of electric power and pneumatic following what is written in this manual.
  • Page 27: Light

    Operator Manual Digibook 300 8.5 LIGHT To use and maintain in a safety way the machine a good light is needed. The room light- ing should have a value that should allow normal operations without causing risks to the shadows. 8.6 ENVIRONMENTAL CONDITIONS The values of temperature and humidity should be within the values in the table below.
  • Page 28: Electrical Connection

    Operator Manual Digibook 300 8.7 ELECTRICAL CONNECTION Electrical cable The end of the cable is prepared according to the destination of the Perfect Binder. a) With the European standard plug with protective earth (PE) mounted on a 3 me- ters length cable b) Cable length of 3 meters with sec- tioned end, with the earth conductor (PE) It is the responsibility of the user to ad-...
  • Page 29 Operator Manual Digibook 300 9 TRAINING OF THE OPERATOR DANGER! The operator must be trained about the operations to perform during the occurrence of possible faults, malfunctions or conditions of danger to themselves or others, and anyway he must perform the following procedures: Stop the machine quickly by pressing the emergency button (red button installed aboard of the machine herself);...
  • Page 30 Operator Manual Digibook 300 10 POWER ON 1) Be sure that the machine is correctly fed by air. 2) Turn on the machine turning the general switch. 3) Open the valve on the premelter 4) Close the rear inspection panel. On display you will see: ...
  • Page 31 Operator Manual Digibook 300 10.1 FUNDAMENTALS Pay Attention during the glue loading because of the high temperature, as indicated by the label, and use protective systems such as gloves.  Never open the tank when it The moisture in the air would enter is cold.
  • Page 32 Operator Manual Digibook 300 The depletion of the glue is found in two ways: the lack of glue on the book; issuing at the extrusion zone glue clear glue mixed with air vents and glue bubbles. When you finish the glue and insert a new cartridge you have to wait about 10 min before the new glue melts.
  • Page 33 Operator Manual Digibook 300 10.2 ELECTRICAL CONNECTION Make sure that the cable of the Perfect Binder is connected to electricity network with the specified features. Turn on the main switch located on the left side of the machine, turn right to achieve the position 1= (ON).
  • Page 34 Operator Manual Digibook 300 10.4 DESCRIPTION OF THE GROUPS Position OFF Main switch open. The machine is off. Position ON Main switch closed. The machine is CLAMP MILLING STATION Glue pressure regulator Allows to adjust the amount of glue coming out of the extruder. Approximate values Pressure = 0 lack of glue (don’t use) Pressure = 1.2 - 1.8 (books up to a...
  • Page 35 Operator Manual Digibook 300 Allows to adjust the press force on the book side Pressure = 0 - 2 bar min. force Pressure = 3 bar med. force Pressure = 5 bar max .force Milling height regulator Allows to adjust the milling (in mm) position = 0 only notching position = 0.5 - 1 the best milling and notching situation...
  • Page 36 Operator Manual Digibook 300 On the back Gate access to the tanks. The machine moves only with the door closed. GLUE TANK CLEANER TANK Glue pressure tap -- closed | open Chips aspiring tube MyBinding.com 5500 NE Moore Court Hillsboro, OR 97124 Toll Free: 1-800-944-4573 rev.
  • Page 37 Operator Manual Digibook 300 10.5 CHIPS ASPIRATOR The chips aspirator is located inside the cabinet of the Perfect Binder and is electrically connected to the Perfect Binder herself. When the Perfect Binder is delivered, the chips aspirator is ready, mechanically (aspira- tion tube) and electrically connected, he switches on and off together with the Milling Station.
  • Page 38 Operator Manual Digibook 300 ever efficient. MyBinding.com 5500 NE Moore Court Hillsboro, OR 97124 Toll Free: 1-800-944-4573 Local: 503-640-5920 rev. 3.00...
  • Page 39 Operator Manual Digibook 300 10.7 PUR TANK OPENING AND CLOSING, AND GLUE LOADING. 10.7.1 O PENING OF THE TANK To access the glue tank it is necessary to open the sliding door provided with handle. The opening of this protection put the machine in a state of emergency and reduces the pressure of the glue tank while the Cleaner tank remains at a pressure of 2 Bar.
  • Page 40 Operator Manual Digibook 300 1) Loosen the lock knob. Turn it counter clockwise. Attention! High temperature! Wear protective gloves. 2) Tilt locking knob to its rest po- sition. The cover is so free to open. 3) Lift the lid to its fully open by grasping the lateral knob.
  • Page 41 Operator Manual Digibook 300 10.7.2 PREPARATION AND LOADING OF THE PUR GLUE Take a bottle of glue and verify the integrity of the aluminum color pack, and make sure that the expiration date printed in package over Please read the SAFETY cards of the used glue, and follow all the instructions of the manufacturer.
  • Page 42 Operator Manual Digibook 300 Close the cover. Remove the knob, paying at- tention to high temperature components. Turn the knob clockwise vigorously to tighten the tank. Close the sliding door in the back of the machine, provided with an handle. MyBinding.com 5500 NE Moore Court Hillsboro, OR 97124...
  • Page 43 Operator Manual Digibook 300 10.7.3 C LEANER LOADING Open the sliding door in the back of the machine, provided with an handler. Attention! High temperature! Use protective gloves. Read carefully the SAFETY cards of the used cleaner, and follow all the instructions of the manufacturer. By loosening the knob of the cleaner tank you will notice an air...
  • Page 44 Operator Manual Digibook 300 Tighten the knob un- til the noise of escap- ing air disappears. Close the sliding door in the back of the machine, provided with a handle. MyBinding.com 5500 NE Moore Court Hillsboro, OR 97124 Toll Free: 1-800-944-4573 rev.
  • Page 45 Operator Manual Digibook 300 11 FUNCTIONS OF THE PERFECT BINDER 11.1 START UP PAGE Areas division Area 1 -Selector for the book type -Front glue stop -Rear glue stop -Cover set -Book thickness Optional: Thickness detection for the book. Position a book onto the measurement ta- ble and press the key, the machine will modify the clamp dimension and also the dimensions of the glue station.
  • Page 46 Operator Manual Digibook 300 Area 2 Meters display Selector for permanence time of the book in the clamp. Management page for working JOB. Go to page Speed selector 1-2-3 Alarms It will blinking red in case there are alarms or warnings. Area 3 Clamp set up Glue station set up...
  • Page 47 Operator Manual Digibook 300 Cleaning procedure with CLEANER or GLUE loading Advanced set up Area 4 Groups status bar If red, turned off If yellow, value modified in the advanced set up Status bar. 1 book in the clamp 2 milling station 3 glue station 4 cover MyBinding.com...
  • Page 48 Operator Manual Digibook 300 11.1.1 DISPLAY FOR PRODUCTION METERS Meter of total production Meter showing items produced during the life of the machine. It is not possible to reset it. Meter of partial production Meter showing the items produced by the machine. It is possible to reset it with the Reset key.
  • Page 49 Operator Manual Digibook 300 12 ALARMS PAGE List of Warnings and Messages : Warnings Description Air pressure fault to the machine. Check valve Air pressure fault or current pressure that supplies the line. Auxiliary fault. Verify that the emergency button is not pressed or that the SAFETY Auxiliary fault barriers are not engaged with the machine on cycle or in movement.
  • Page 50 Operator Manual Digibook 300 It requires to start a cycle with a book in the nipping station. If there is no book, verify if the cover is perfectly aligned to the nipping station Book in the nipping station and does not accidentally shroud the sensor for book presence.
  • Page 51 Operator Manual Digibook 300 13 PARAMETERS FOR SINGLE AXES (GROUPS) Standard symbols that you will find in the following pages. Access to manual movement page Axes reset Group movement in the direction indicated by the green arrow. If you push the green arrow, the dimension increases. Group movement in the direction indicated by the red arrow.
  • Page 52 Operator Manual Digibook 300 13.1 PARAMETERS FOR NIPPING STATION/CARRIAGE Offset for carriage position + 5mm Offset for the arrival position of the carriage - 5mm onto the nipping station. This allows to posi- tion the book rightmost (positive value) or more left (negative value) compared to cover.
  • Page 53 Operator Manual Digibook 300 13.2 PARAMETERS FOR THE HEAD OF THE GLUE STATION Management for working parameters of glue station head Temperature control for premelter Current temperature for premelter Temperature control for the glue head Current temperature for glue head Stand by The temperature must be set on the basis of the glue type you are going to use.
  • Page 54 Operator Manual Digibook 300 “Glue station not ready”. When the detected temperatures correspond to the fixed temperatures, the indicators will be green. So the machine will start to move the glue station while it waits for stabilizing the temperatures. At the end of this process the machine will be ready to start. The standby status will decrease the temperatures of 30°...
  • Page 55 Operator Manual Digibook 300 13.3 PARAMETERS FOR NIPPING STATION Management of working parameters for nipping station Nipping station height From 0mm Tune the distance of the spine plate to the to 1.8mm book. MyBinding.com 5500 NE Moore Court Hillsboro, OR 97124 Toll Free: 1-800-944-4573 rev.
  • Page 56 Operator Manual Digibook 300 13.4 CLEANER AND GLUE LOADING See chapter 19 and 21. MyBinding.com 5500 NE Moore Court Hillsboro, OR 97124 Toll Free: 1-800-944-4573 Local: 503-640-5920 rev. 3.00...
  • Page 57 Operator Manual Digibook 300 14 . ACCES TO ADVANCED SET UP PAGES MyBinding.com 5500 NE Moore Court Hillsboro, OR 97124 Toll Free: 1-800-944-4573 Local: 503-640-5920 rev. 3.00...
  • Page 58 Operator Manual Digibook 300 14.1 NIPPING STATION SET UP Nipping station with a standard set up Nipping station with a set up for a sewing book, it widens more when you position the book. MyBinding.com 5500 NE Moore Court Hillsboro, OR 97124 Toll Free: 1-800-944-4573 Local: 503-640-5920 rev.
  • Page 59 Operator Manual Digibook 300 14.2 MILLING STATION SET UP Power vacuum cleaner Release of the engine braking on the nipping station, it only works when the emergency button is pressed. MyBinding.com 5500 NE Moore Court Hillsboro, OR 97124 Toll Free: 1-800-944-4573 rev.
  • Page 60 Operator Manual Digibook 300 14.3 GLUE HEAD SET UP Manual operation for glue station: Glue spillage Doing one push, you move the pins. Hold the key, it spills the glue. With this key it is possible to activate cleaner spillage. Offset compared to the default value.
  • Page 61 Operator Manual Digibook 300 14.4 NIPPING STATION SET UP Nipping station not active Nipping station active Offset compared to the default value. MyBinding.com 5500 NE Moore Court rev. 3.00 Hillsboro, OR 97124 Toll Free: 1-800-944-4573 Local: 503-640-5920...
  • Page 62 Operator Manual Digibook 300 15 MANAGEMENT PAGE FOR WORKING JOB 15.1 MANAGEMENT OF THE JOBS It is possible to save until 100 working JOBS. Using the green and red arrows pick a free page and hold the key “SALVA DATI” to save the set up you have used to manufacture the current product.
  • Page 63 Operator Manual Digibook 300 Using the arrows UP and DOWN pick the page with the desired JOB and hold the key “CARICA DATI”. The machine will update all the positions of the automatic axes. It is necessary to manually operate for manual settings. MyBinding.com 5500 NE Moore Court rev.
  • Page 64: Glue Recovery Procedure

    Operator Manual Digibook 300 16 GLUE RECOVERY PROCEDURE The glue recovery procedure must be performed every time the machine has been switched off by using the procedure “End of job”. If the machine has been switched off by using the procedure “End of job”, it will be im- possible to start again to work without the glue recovery procedure;...
  • Page 65 Operator Manual Digibook 300 Remove the headless screws using the L wrench and take the manometer of the glue at pressure 1 bar Press the button OK Press the button “ANCORA COLLA” until the traces of Blue cleaner disappear. Help the glue to exit from the bin by us- ing the green spatula.
  • Page 66 Operator Manual Digibook 300 Now the machine is ready to work. MyBinding.com 5500 NE Moore Court Hillsboro, OR 97124 Toll Free: 1-800-944-4573 rev. 3.00 Local: 503-640-5920...
  • Page 67: Cover Positioning

    Operator Manual Digibook 300 17 COVER POSITIONING The parameter shows the cov- er position. The value indicates the X di- mension. Position the cover manually as shown by the arrows. MyBinding.com 5500 NE Moore Court Hillsboro, OR 97124 rev. 3.00 Toll Free: 1-800-944-4573 Local: 503-640-5920...
  • Page 68 Operator Manual Digibook 300 The standard calibration requires that the angle between the sides of the cover is 90 ° The standard calibra- tion requires that the angle between sides of the cover is 90 °. If the cover has some problems caused improper trimming, you...
  • Page 69: Preparation Of The Machine To Produce A Book

    Operator Manual Digibook 300 Preparation of the machine to produce a book. CONTROLS TO PERFORM BEFORE STARTING THE JOB Before to use the Perfect Binder perform the following controls: The operator must have read and understood this manual, including the important information concerning the SAFETY. Make sure you have appropriate clothing to work and, if necessary, also safety clothing.
  • Page 70 Operator Manual Digibook 300 Switch on the machine using the main switch. Turn the switch to the position ON. Verify that the pressure in input, dis- played on the input manometer, is correct. MIN 6 BAR Open the valve on the pre-melting unit: The valve with the lever in vertical position indicates that it is open.
  • Page 71 Operator Manual Digibook 300 Insert the parameters of the thick- ness of the book, cover, front and rear glue stops. Select the desired speed Perform a general reset Perform an axis positioning Adjust the pressure of the glue Adjust the pressure of the press Place the cover over the press, plac- ing it at the left fixed reference and the adjustable reference in the bot-...
  • Page 72: Cleaning The Machine

    Operator Manual Digibook 300 18 CLEANING THE MACHINE When the machine work using PUR glue, it is imperative and essential an accurate clean- ing of the glue. The dried glue is no more refundable. Residue of glue during the drying process can cause blockages or a uneven extrusion of the glue.
  • Page 73: Procedure To Clean The Spine Glue Extruder

    Operator Manual Digibook 300 18.1 PROCEDURE TO CLEAN THE SPINE GLUE EXTRUDER. Press the Button “Manual move- ments”. Press the key dedicated to the glue head. Press reset to open the head up to the reset position MyBinding.com 5500 NE Moore Court Hillsboro, OR 97124 rev.
  • Page 74 Operator Manual Digibook 300 Insert the calibrated blade into the slot extrusion to touch bottom move it along the slot to remove or release any pos- sible obstructions. Adjust the value of the glue extrusion pressure to 1bar. Hold the key “FUORIUSCI- TA COLLA”...
  • Page 75: Procedure To Clean The Glue Side Extruders

    Operator Manual Digibook 300 Thoroughly clean blade. When the glue is fully cured the blade will no longer operate. 18.2 PROCEDURE TO CLEAN THE GLUE SIDE EXTRUDERS. Press the Button “Manual move- ments”. Press the key dedicated to the glue head MyBinding.com rev.
  • Page 76 Operator Manual Digibook 300 Press reset to open the head to the reset position. The glue smeared on the side of the book is extruded through 3 small channels located on the plates containing the book. To get a correct extrusion of the side glue you must remove the headless screw and insert in the holes the included wire...
  • Page 77 Operator Manual Digibook 300 To get a correct extrusion of the side glue you must remove the headless screw and insert in the holes the included wire. Pass the thread also in the main conduit until you enter into the below slot.
  • Page 78: End Of Job

    Operator Manual Digibook 300 18.3 “END OF JOB” CLEANING To switch off the machine at the end of the day you must eject the remaining glue inside of the ex- truder. To do it you must activate the au- tomatic procedure that allows executing a safety off.
  • Page 79 Operator Manual Digibook 300 Press “Ancora Cleaner” until from the extruder exits only cleaner. Press OK Screw the headless screws using the same included L wrench (Pay attention to the temperature). Press OK. The machine is now ready to be switched off..
  • Page 80: Details Cleaning

    Operator Manual Digibook 300 18.4 DETAILS CLEANING Press the Button “manual move- ments” Press the head key Press reset to make the head open reset position. MyBinding.com 5500 NE Moore Court Hillsboro, OR 97124 rev. 3.00 Toll Free: 1-800-944-4573 Local: 503-640-5920...
  • Page 81 Operator Manual Digibook 300 Adjust the glue extrusion pressure to 1 bar. Use the included blade to remove all the visible glue traces. MyBinding.com 5500 NE Moore Court rev. 3.00 Hillsboro, OR 97124 Toll Free: 1-800-944-4573 Local: 503-640-5920...
  • Page 82 Operator Manual Digibook 300 If necessary you can use liquid solvents to get a bet- ter cleaning of the surface. During the use of liquid solvents refer to the safety instructions provided the solvent manufacturer. Clean carefully all the used tools, otherwise they be- come unusable later.
  • Page 83: Problems - Solutions

    Operator Manual Digibook 300 19 Problems - Solutions 19.1 CHIPS ASPIRATOR – LESS VACUUM:  Verify that the plexiglass inspection, located on the Milling Station, is free.  Verify that the chips aspirator tank is empty.  Verify that the chips aspirator tube is not full of chips. ...
  • Page 84: Press

    Operator Manual Digibook 300  Verify the head height: if it comes out a little glue lower the head and in- crease the air pressure of the glue group, if it comes out to much glue raise the head and lower the air pressure of the glue. 22.7 PRESS ...
