Ringing time – time for which is ringing. When is setup more numbers as
same as progressive ringing then after this time ringing is ended on
first phone number (IP adress in P2P) and starts ringing on second.
It is time until which subscriber must pick up. When is not next
number to call then email is sent either to email adress mentioned in
phone book or to default email (E-mail setting).Setting range is 5 to
300sec (6min.) caution: it might happen that ringing time will not be
limited but it is limited by time parametres of SIP protocol and it is
usually 2-5min (according SIP device setting).
message to SD card during this time and simultaneously send email.
Maximal call duration – when call is picked up timer for call duration limit is
activated. When you insert empty, then there is no limit. The 10sec
before call end you hear tone after which you can dial character for
call prolongation and by this prolong the call about same time period.
Call prolongation character – options are * or # and usage is descriped in
„Maximal call duration"
Number of ringing cycles – this option enable repeating of call (or
progressive call) . In phone book is for example filled first and second
phone number and not create group. When come condition for first
number:
Then second number is dialled. When the same conditions come true
and ringing cycles are setup 2 the whole cycle is repeated one more
time.
The same button pressed one more time – when you press again the same
button then you setup door entry behaviour. Options are:
Maximal number inserting time – this time concern buttons (keypad) and it is
deciding for correct code inserting. When space between button
press is longer than this time the cod eis not correctly evaluated .
Situation:
This time simultaneously prolong dial time at buttons which are initial
numbers of codes.
Maximal DTMF inserting time – this time concerns incoming calls from
telephones and it is deciding for correct code inserting . The principle
is the same as previous parametr but it concerns codes from telefone.
Keypad mode – models TK only – memory number dial means that you
press 1-3 digit code on keypad which determined position in phone
book (1-999). The door entry process the call same way as you
- ringing time is out
- phone number is busy
- subscriber is not reachable / registrated in network
- call is hang up
- call is repeated
- nothing happen
- code keylock provides correct code evaluation
- number dial from keypad –dial end resolution
IP BOLD
- installation and operating instructions
You can record
