5.6 Using the wheelchair brake

Putting the wheelchair brake on
If you are in the wheelchair
-
Take the black handle of the brake, picture 17;
-
Push the forward until you hear a click, this confirms that the wheelchair has been put on the brake, picture
18.
If you are next to the wheelchair
-
Go to the side of the wheelchair and face towards the front of the wheelchair;
-
Take the black handle of the brake, picture 17;
-
Push the lever forward until you hear a click, this confirms that the wheelchair has been put on the brake,
picture 18.

5.7 Using the armrest

Flipping the armrest backwards
- Where the front of the armrest meets the frame you will find a black lever. Pull the black lever to the armrest
tube, see picture 19;
- You can now swing the armrest backwards;
- To put the armrest back in place you must reverse the previous steps. Please make sure you hear the click that
confirms that the armrest is back in place.
Picture 17
Picture 19
~ 15 ~
