6. Engine Removal
Remove the fuel tube of carburetor.
Loosen the air filter pipe strainer, and
separate the pipe.
Remove the carburetor holding nuts. (Nut X
2)
Remove the carburetor.
Loosen the rear wheel axle nut, and the
sleeve nut. Then loosen the adjusting nut and
push the rear wheel forward.
Remove the L crankcase chain cover.
Remove the driving sprocket holding bolts.
(Bolt X 2). Turn slightly and take out the
stopping plate, then remove the driving
sprocket and chain.
Remove the spark plug cap and the cable.
6-4
To this chapter contents
Fuel tube
Air filter pipe strainer
Rear wheel axle nut
Stopper plate
IG coil cable
Holding nut×2
Sleeve nut
Adjusting nut
Bolt×2
