Symbols and Marks
Symbols and marks are used in this manual to indicate what and where the special service are needed, in
case supplemental information is procedures needed for these symbols and marks, explanations will be
added to the text instead of using the symbols or marks.
Warning
Caution
Engine oil
Grease
Gear oil
Locking sealant
Oil seal
Renew
Brake fluid
Special tools
Correct
Wrong
Indication
Directions
Homepage
Means that serious injury or even death may result if procedures are not
followed.
Means that equipment damages may result if procedures are not followed.
Limits to use SAE 10W-30 API SG class oil. Warranty will not cover the
damage that caused by not apply with the limited engine oil.
(Recommended oil: Bramax G-3
King Mate G-3 is recommended.
King Mate gear oil serials are recommended. (Bramax HYPOID GEAR OIL
# 140)
Apply sealant; medium strength sealant should be used unless otherwise
specified.
Apply with lubricant.
Replace with a new part before installation.
Use recommended brake fluid DOT3 or WELLRUN brake fluid.
Special tools
Meaning correct installation.
Meaning wrong installation.
Indication of components.
Indicates position and operation directions
Components assembly directions each other.
Indicates where the bolt installation direction, --- means that bolt go through
the component (invisibility).
