1. General Information
Frame Torque Values
Item
Mounting bolt for steering handle
post
Lock nut for steering stem
Steering top cone race
Front wheel axle nut
Rear wheel axle nut
Front cushion mounting bolt
Rear cushion upper connection bolt
Rear cushion under connection bolt
Rear fork mounting bolt
Brake hose bolt
Brake air-bleeding valve
Front brake disc mounting bolt
Rear brake disc mounting bolt
Brake clipper mounting bolt
Engine hanger link bolt
Engine hanger link nut
Main standard nut
Air cleaner bolts
1-12
To this chapter contents
Q'ty Thread Dia. (mm) Torque Value (Kg-m)
4 8
1 BC1
1 BC1
1 12
1 16
4 10
1 10
1 8
2 10
2 10
1 6
5 8
5 8
2 8
2 12
1 12
1 10
2 6
Remarks
3.0~3.5
1.0~2.0
2.0~3.0
5.0~7.0
11.0~13.0
3.5~4.5
3.5~4.5
2.4~3.0
4.0~5.0
3.0~4.0
0.8~1.0
4.0~4.5
4.0~4.5
2.9~3.5
7.5~9.5 On frame side
7.5~9.5 On engine side
4.0~5.0
1.0~1.4
