- Page 1 WS-843A User Manual Version 1.2 12.1” TFT Display Workstation February 3, 2004...
-
Page 2: Copyright Notice
Trademarks WS-843A is a registered trademark of ICP Electronics Inc. IBM PC is a registered trademark of International Business Machines Corporation. Intel is a registered trademark of Intel Corporation. Other product names mentioned herein are used for identification purposes only and may be trademarks and/or registered trademarks of their respective companies. -
Page 3: Table Of Contents
Table of Contents CHAPTER 1 PRODUCT INFORMATION ..........3 ..............3 ENERAL NFORMATION ..............4 RODUCT PECIFICATIONS ...................5 IMENSIONS CD-ROM 3.5" FDD..........6 RONT CCESSIBLE ..........8 EALED EMBRANE CCESSIBLE EYPAD CHAPTER 2 SYSTEM SETUP ..............9 ..........9 ARDS AND LAMPS NSTALLATION ............... 10 RIVES INSTALLATION ............. -
Page 4: Chapter 1 Product Information
This system unit consists of a CPU board, a power supply, a passive backplane and a touch-pad for minimum size. LCD Display The WS-843A series workstations are equipped with a color 800 x 600 resolution 12.1” TFT LCD display. Versatile Passive Backplane WS-843A workstation is compatible with BP-10S, BP-10SD, IP-10S, PX-10S or PCI-10S, PCI-10S2 and IP-10S2 backplane. -
Page 5: Product Specifications
Operating Temperature: 0 ~ 50 ℃ Relative Humidity: 10 -95%, @40°C non-condensing Dimensions: 483 x 310 x 271.7 mm Color: white (Pantone 413C) and black LCD Display Model WS-843A Display Type 12.1" TFT color Resolution 800 X 600 LCD Display Colors... -
Page 6: Dimensions
Dimensions The following diagram indicates the dimensions of WS-843A: Front Panel: 483 mm (W) x 310mm (H) x 12mm (D) Cabinet: 433 mm (W) x 291mm (H) x 259.7mm (D) 417.80 D6.5x8.5 465.00 433.00 < > " 483.00 271.70... -
Page 7: Front Accessible Cd-Rom And 3.5" Fdd
Front Accessible CD-ROM and 3.5" FDD WS-843A workstation is equipped with one 5.25” CD-ROM, one 3.5" FDD and one 3.5” HDD. The CD-ROM and FDD are accessible by loosening the two captive fasteners of lockable door as shown in the following diagram. A power switch and a USB port are also reachable through opening this front lockable door. - Page 8 Display Module:...
-
Page 9: Sealed-Membrane Accessible Keypad
Sealed-Membrane Accessible Keypad The sealed-membrane keypad has 59 data keys, including 10 function keys to allow users to enter data directly. A built-in controller will merge the signals from the membrane keypad into one signal that acts as a standard IBM PC/AT keyboard. -
Page 10: Chapter 2 System Setup
Chapter 2 System Setup The following sections of this chapter show how to install the components and do the maintenance. Cards and Card Clamps Installation Before installing the cards, the back cover should be removed first by releasing screws as shown in the diagram below. Then, users can slowly slide the card in and carefully press it into the appropriate slot of backplane. -
Page 11: Disk Drives Installation
Disk Drives installation WS-843A provides one 5.25" CD-ROM, one 3.5" FDD and one 3.5" HDD. The diagram below shows how to install the disk drives. Before placing the CD-ROM into the workstation, the CD-ROM should be mounted into the CD-ROM bracket first. -
Page 12: Power Supply Installation
Power Supply Installation Power supply is located at the rear of workstation as shown in the following diagram. Please fasten it with screws. PX-10S ACE-832A POWER SUPPLY Brown Black Blue White WHITE Brown BLACK Blue Black BLUE White BROWN... -
Page 13: Cooling Fan Installation And Filter Replacing
Cooling Fan Installation and Filter Replacing WS-843A is equipped with a 12cm cooling fan attached to a removable fan filter on the side of workstation. The following diagram shows how to install the fan. Please note that the filter should be removed and cleaned at least once a month to achieve optimum performance. -
Page 14: Rack Mounting
Rack Mounting WS-843A can be mounted into a 19” rack. The following diagram shows you how to mount WS-843A into a 19” rack. -
Page 15: Panel Mounting
Panel Mounting WS-843A not only can be mounted into the 19” Rack but also can be mounted within a panel as shown in the illustration below. Please make sure that the dimensions of the case fits panel aperture so that your screw holes match with the mounting bolts on the flange of WS-843A. -
Page 16: Chapter 3 Maintenance
Warning: Do not use wet filter to sift out the dirt. Disk Drives WS-843A provides one 5.25" CD-ROM, one 3.5" FDD and one 3.5" HDD. Please refer to the diagram of section 2.2 to uninstall them. -
Page 17: Appendix Aexploded Diagram
Appendix A Exploded Diagram WS-843A Parts List: ITEM DESCRIPTION QUANTITY REMARK DM-121 Module HINGE-R HINGE-L 59 Membrane Keypad Door Cover Front Panel Bracket Rear Panel Touch-Pad Module Rear Chassis Bracket USB Port Power Switch(I/O) Filter Bracket Fan Bracket Filter Set... -
Page 18: Appendix Bkeypad
Appendix B Keypad A. Block Diagram CON1 Membrane 2 Membrane 1 A203 CON2 Keyboard 2 Keyboard 1 B. Jumper Setting CON1 Pin1 Pin2 Pin3 Pin4 Pin5 +5V in DATA CLOCK CON2 Pin1 Pin2 Pin3 Pin4 Pin5 +5V in DATA CLOCK CON3 Pin1 Pin2... - Page 19 Pin1 Pin2 Pin3 Pin4 Pin5 BTN0 BTN1 BTN2 BTN3 BTN4 Pin6 Pin7 Pin8 BTN5 BTN6 BTN7 Pin1 Pin2 Pin3 Pin4 Pin5 LINE0 LINE1 LINE2 LINE3 LINE4 Pin6 Pin7 Pin8 Pin9 Pin10 LINE5 LINE6 LINE7 POWER GOOD +5V in LED- out Pin11 Pin12 Pin13...
-
Page 20: Appendix Ctouch Panel Controller
Appendix C Touch Panel Controller Please refer to the following diagram for graphic illustration of how connection of touch panel controller is done. Touch screen... -
Page 21: Appendix Dtouch Pad
Appendix D Touch Pad TP-101 Touch Pad is compatible with the PS/2 mouse. Users have to connect the external PS/2 mouse cable as the below figure shown. Touch Pad, a pointing device for computers, detects the position of a finger over a touch-sensitive area. To move the cursor, users have to lightly slide a finger over the smooth sensor area. -
Page 22: Appendix Euser Mode Osd Item Description
Appendix E User Mode OSD Item Description Auto-Adjustment This item will automatically adjust the H/V position, frequency, phase, and black level. Auto Phase This item will automatically adjust the sampling. Brightness It is used to adjust the brightness of screen. This function will adjust the offset value of ADC. - Page 23 DOS/GFX It is used to chose VGA input signal that are text mode or graphic mode. ( It is only selectable on resolution of 720/640x400 or 720/640x350 . ) 400 and 350 standard IBM mode have the same Hsync. and Vsync. value , AV-9261 MPU can not differentiate them automatically , user need to adjust them by manual to match proper VGA mode .
- Page 24 Revert It is used to reload original parameters from the factory’s OSD data area of the system EEPROM 24c16 device to re-initialize AV-9261 system device. When user adjust OSD data too much and can not see better quality than before , user can select this item and MPU will reload default BIOS setting and re-initialize the system.
