Step 6

Cable Routing

A. Connect the Weight Stack Cable (#20) to the Top Plate Selector Bar using hardware shown. See FIG. A.
B. Next, route the Weight Stack Cable (#20) up and over the Pulley 3/8 X 4 1/2 (#23-Labeled
the Pulley 3/8 X 4 1/2 (#23-Labeled
C. Connect the Weight Stack Cable (#20) to the Weight Stack Frame using hardware shown. See FIG. B.
D. Secure the looped end of the Short Cable (#18) to the Floating Pulley Bracket (#12) using one Shoulder Bolt 3/8 X 3/4
(#54) and one Nylon Insert Lock Nut 5/16-18 (#41). See FIG. C.
E. Route the Short Cable (#18) down and under the Pulley 3/8 X 4 1/2 (#23-Labeled
F. Next, route the cable under the Weight Stack. Then, route the cable around the Pulleys 3/8" X 3 1/2" (#22-Labeled
) passing the cable between the pulleys and the Cover Plates.
G5
G. Attach the Short Cable (#18) to the Adjustable Cam Plate (#2) and secure it into place using the Socket Head Cap Screw
1/4-20 X 3/4 (#55). See FIG. D.
Item #
18 SHORT CABLE
20 WEIGHT STACK CABLE
28 FINISHED HEX NUT B/O 1/2-13
41 NYLON INSERT LOCK NUT B/O 5/16-18
54 SHOULDER BOLT ALLOY 3/8 X 3/4
9
G2 ) .
Description
Assembly List
Qty. Item #
1 55 SOCKET HEAD CAP SCREW B/O 1/4-20 X 3/4
1 58 SPLIT BOLT Z/P 1/2-13 X 1
1 59 SPLIT HEX TAP BOLT GR-5 B/O 1/2-13 X 3 1/2
1 61 SPLIT LOCK WASHER Z/P 1/2"
