TuffStuff Apollo Standard Assembly Instructions Manual
Hide thumbs
Also See for Apollo Standard:
- Assembly instructions manual (8 pages) ,
- Assembly instructions manual (12 pages) ,
- Assembly instructions manual (12 pages)
Related Manuals for TuffStuff Apollo Standard
Summary of Contents for TuffStuff Apollo Standard
- Page 1 A S S E M B L Y I N S T R U C T I O N S Revision Date 08-23-05 Apollo Modular Gym System Single Column Station Standard Deluxe A m e r i c a ’ s P r e m i e r E x e r c i s e E q u i p m e n t Single Column Station Rev0...
- Page 2 Every Tuffstuff product has been built to precise quality standards and has been carefully packaged to ensure that damage ool Requirements will not occur during shipment. The TuffStuff Warranty and signature 1. One 7/8” combination wrench indicating final inspection has been conducted by our line foreman, 2.
- Page 3 Assembly Instructions FIG. 3 Next, insert the assembled Low Row Stabilizer (#63) into FIG. 4 Locate the Adjustable Pulley Bracket (#45) and attach one the receptacle of the Bottom Upright Connector (#69). Pulley 3 1/2 Rd. (#128-Labeled E6) using one Hex Head Cap Screw 3/8-16 X 1 3/4 (#101), two Flat Washers SAE 3/8”...
- Page 4 FIG. 7 Attach two Pulleys 4 1/2 Rd (#78-Labeled E4, E8) and two FIG. 8 Attach the Single Column Upright (#61) to the Bottom Up- Cable Retainer Brackets (#26) to the Top Upright Connector (#59) right Connector (#69) using two Hex Head Cap Screws 3/8-16 X 3/4 using one Hex Head Cap Screw 3/8-16 X 4 3/4 (#110), two Flat (#97), two Split Lock Washers 3/8”...
- Page 5 Assembly Instructions FIG. 11 Attach two Pulleys 4 1/2 Rd (#78-Labeled E3, E9) and two Ca- FIG. 12 Route the Single Column Cable (#62) between the Pulleys ble Retainer Brackets (#26) to the Single Column Upright (#61) using 3 1/2 Rd. (#128-Labeled E1, E2), and then route up through the tube of two Hex Head Cap Screws 3/8-16 X 3 1/2 (#106), four Flat Washers SAE the Double Pulley Bracket (#66).
- Page 6 FIG. 15 Continue routing the Cable (#62) down and under the Pulley FIG. 16 Attach Snap Links (#167) to both ends of the Cable (#62) 4 1/2” Rd. (#78-Labeled E9), then up and over the Pulley 3 1/2” Rd. using two Shoulder Bolts 3/8 X 3/4 (#166), and Nylon Insert Lock Nuts (#128-Labeled E10).
- Page 7 CHART Single Column Station (Deluxe) BOLD FONT = SUB-ASSEMBLY PARTS REGULAR FONT = HARDWARE Parts List ITEM NO. DESCRIPTION PART NO. QTY. ITEM NO. DESCRIPTION PART NO. QTY. INSERT TUBE 1 X 16 UP0053 NYLON BALL 1 3/4 X 1/4 BNH0047 CABLE RETAINER BRACKET(L-SHAPED) UP0014...
- Page 8 (3) months, and all other parts not mentioned elsewhere in this warranty will expire one (1) year from the date of delivery to the original purchaser. The obligation of TuffStuff under this warranty is limited to repairing or re- placing warranted defective parts, as TuffStuff may elect, at TuffStuff’s facility in Pomona, California, without charge to purchaser for either parts or labor.
