Step 4 Handles and Leg Pad Pivot Brackets Assembly
A
Attach the Handles (#6, #7) to the Main Frame (#11) using hardware shown.
B
Insert the Leg Pad Pivot Brackets (#10) into the receptacles of the Pivot Legs (#8, 16). Next, secure the Leg Pad
Brackets (#10) using the two Retaining Snap Rings (#49). If possible, use special snap ring pliers for this job. If tool is
not available, carefully work each Retaining Snap Ring (#49) into the grooves of the Leg Pad Pivot Brackets (#10) then
push up alternately with a screw driver working the Retaining Snap Ring into the groove.
C
Attach the Leg Pads (#9) to the Leg Pad Pivot Brackets (#10) using hardware shown.
Item #
6 HANDLE (LT)
7 HANDLE (RT)
9 LEG PAD
10 LEG PAD PIVOT BRACKET
26 BUTTON HEAD SOC CAP SCREW B/O 3/8-16 X 1 1/4
30 FLAT WASHER SAE B/O 3/8"
5
Description
Assembly List
Qty. Item #
1 32 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1 3/4
1 34 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 3 1/4
2 40 NYLON INSERT LOCK NUT B/O 3/8-16
2 49 RETAINING SNAP RING EXT. PLAIN .925 X 1 X .042
3 50 RUBBER BUMPER W/WASHER 3/8 X 1 1/2
7
Description
Inner Outer Thigh Station
Qty.
1
2
2
2
1
