Introduction
Thank you for buying a Mitsubishi i-MiEV powered by MiEV
(Mitsubishi innovative Electric Vehicle) technology.
We are confident you will enjoy your vehicle. It has been engi-
neered for optimum performance, durability and comfort. By
thoroughly reading this Owner's Manual, you will gain an
understanding of the many features that are included in the i-
MiEV. The Owner's Manual contains descriptions and illustra-
tions that will assist in the operation and maintenance of your
vehicle.
A Certified i-MiEV Dealer will be happy to assist you with any
further questions you may have regarding the operation of your
vehicle.
Please note that this manual applies to all i-MiEV models and
explains all features including options. Some features
explained in this manual may not be installed on your vehicle.
Please leave this Owner's Manual in the vehicle at the time of
resale. The next owner will appreciate having access to the
information contained here.
This manual includes instructions for standard and optional
equipment available at the time of printing. Mitsubishi Motors
Corporation reserves the right to make changes in design and
specifications and to make additions or improvements in its
product without assuming any obligation to install these on
previously manufactured products.
Throughout this manual the words WARNING and CAUTION
appear.
N09200100934
These are reminders to be especially careful. Failure to follow the
instructions could result in personal injury or damage to your
vehicle.
WARNING
!
Indicates a strong possibility of severe personal injury or
death if instructions are not followed.
CAUTION
!
Points out hazards or unsafe practices that could cause minor
personal injury or damage to your vehicle.
You will see another important symbol:
NOTE Gives helpful information.
WARNING
!
Certain fluids contained in vehicles and certain
products of component wear contain or emit chemi-
cals known to the State of California to cause cancer
and birth defects or other reproductive harm.
©2011 Mitsubishi Motors Corporation
Printed in Japan

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the i-MiEV 2011 and is the answer not in the manual?

Questions and answers

Related Manuals for Mitsubishi i-MiEV 2011

Summary of Contents for Mitsubishi i-MiEV 2011

  • Page 1 N09200100934 These are reminders to be especially careful. Failure to follow the Thank you for buying a Mitsubishi i-MiEV powered by MiEV (Mitsubishi innovative Electric Vehicle) technology. instructions could result in personal injury or damage to your We are confident you will enjoy your vehicle. It has been engi- vehicle.

  • Page 2: Table Of Contents

    Table of contents Overview Quick index General information/ Charging Seat and restraint systems Features and controls Driving safety Comfort controls For emergencies Vehicle care and maintenance Customer assistance/ Reporting Safety Defects Specifications...
  • Page 3 Overview Instruments and controls (Driver’s area) N00100201459 Wiper and washer switch P.3-84 Instrument cluster P.3-58 Rear window wiper and washer switch Combination headlights and dimmer switch P.3-76 P.3-87 Turn signal lever P.3-82 Front fog light switch (if so equipped) P.3-83 Electric motor switch P.3-30 Electric remote-controlled outside mirror switch P.3-28...
  • Page 4 Hazard warning flasher Supplemental restraint system (SRS) - switch P.3-83 airbag (for front passenger’s seat) P.2-35 Audio (if so equipped) P.5-18 Mitsubishi Multi-Communication System (if so equipped) Side vents P.5-2 Refer to the separate “Mitsubishi Multi-Communication System owner’s manual” Cup holder P.3-130 Glove compartment P.3-...
  • Page 5 Overview Interior N00100301229 Sun visors P.3-122 Dome light (rear) P.3-127 Vanity mirror P.3-122 Card holder P.3-122 Assist grip P.3-131 Seat belts P.2-13 Dome light (front)/Reading lights P.3-125 Supplemental restraint system (SRS) - curtain airbags P.2-52 Head restraints P.2-10 Inside rearview mirror P.3-26 Window lock switch P.3-24 Power door...
  • Page 6 Overview Under the hood/Electric motor unit room N00100800025 Under the hood Electric motor unit room Coolant reservoir Windshield washer fluid reservoir P.7-7 P.7-11 On board charger/DC-DC converter 12V starter battery P.7-2 P.7-13 Brake electric vacuum pump P.3-73 Hot water heater reservoir P.7-7 Inverter P.1-42 Brake fluid reservoir...
  • Page 7 Overview Outside (Front) N00100601336 Outside rearview mirrors P.3-28 Power window P.3-22 Windshield wipers P.3-84 Hood P.7-4 Quick charging lid (if so equipped) P.1-33 Main drive lithium-ion battery P.7-2 Front side-marker lights Front fog lights (if so equipped) P.3-83, 7-36, P.3-76, 7-36, 7-38 7-40 Daytime running lights (if so equipped) Front turn signal lights P.3-82, 7-36, 7-40...
  • Page 8 Overview Outside (Rear) N00100601307 Back-up light P.7-36, 7-42 Antenna P.5-40 Tail and stop lights P.3-76, 7-36, 7-42 High-mounted stop light P.7-36, 7-45 Rear turn signal lights P.3-82, 7-36, 7-42 Rear window wiper P.3-87 Liftgate P.3-16 Keyless entry system P.3-7 License plate lights Locking and unlocking P.3-76, 7-36, 7-47 P.3-12...
  • Page 10 Quick index If this warning light comes on or flashes while you’re driving... N00200701110 NOTE These warning lights will come on for a few seconds for a bulb check when the electric motor switch is first turned to “ON”. Warning light Do this Ref.
  • Page 11 Quick index Warning light Do this Ref. page When this light comes on, the anti-lock braking system is not func- tioning and only the ordinary braking system is functioning. Park your vehicle in a safe place and stop the electric motor unit. P.3-42, Test the system as described on page 3-43.
  • Page 12 Quick index Warning light Do this Ref. page Have the transmission checked at a certified i-MiEV dealer as soon as P.3-34 possible. Selector lever position indicator in the instru- ment cluster flashes slowly Park your vehicle in a safe place and turn off the electric motor unit. Restart the electric motor unit and check to see if the indicator comes on again.
  • Page 13 Quick index If this problem occurs... N00200900841 Problem Do this Ref. Page Cannot turn the key. From “LOCK” to “ACC”. Turn the key while turning the steering wheel in either direction. From “ACC” to “LOCK”. P.3-30, Check the position of the selector lever. The key cannot be removed unless the selector lever is set to the “P”...
  • Page 14 Quick index Problem Do this Ref. Page The electric motor unit does not start. The lights do not come on. P.6-2, The lights are dim. Have the 12V starter battery checked. Recharge or replace as needed. The horn does not honk. 7-13 The horn sound is weak.
  • Page 15 Quick index Problem Do this Ref. page The brakes are not functioning properly after driving through Dry out the brakes by driving slowly while lightly pressing the brake pedal. P.4-8 water. A tire is punctured. 1. Park the vehicle in a safe place where the surface is flat and level. P.6-7 2.

  • Page 16: General Information/ Charging

    Familiarizing yourself with i-MiEV ...1- Modifications to and racing of your vehicle ..1- Mitsubishi Motors genuine parts ....1- California Perchlorate Materials Requirements. . .1- Cautions and actions to deal with intense heat .

  • Page 17: Familiarizing Yourself With I-Miev

    General information/Charging Familiarizing yourself with i-MiEV The main drive lithium-ion battery provides power to the electric motor that propels the vehicle and charges the N01200100013 12V starter battery. i-MiEV is a pure electric vehicle. Some of the vehicle systems Through a process called regenerative braking, the main operate differently from and have different characteristics than drive lithium-ion battery is automatically charged, while ordinary vehicles equipped with an internal combustion...
  • Page 18 General information/Charging Regenerative braking WARNING N01205600013 It is equivalent to engine braking of a gasoline or diesel pow- Keep the brake pedal depressed until you are ready to drive. When the vehicle is in the “D” (DRIVE), ered vehicle. When you take your foot off the accelerator pedal “ECO”...
  • Page 19 General information/Charging Main drive lithium-ion battery CAUTION N01200300015 Do not store your vehicle at ambient temperatures above 131 °F (55 °C) for over 24 hours, or below WARNING -13 °F (-25 °C) for over 7 days. The temperatures The main drive lithium-ion battery is a sealed high may damage the main drive lithium-ion battery.

  • Page 20: Cruising Range

    General information/Charging Cruising range Mitsubishi Motors estimates that after 5 years, the capac- ity of the main drive lithium-ion battery provided with N01200400016 The distance you can drive the vehicle (cruising range) your vehicle will be approximately 80% of the original depends on a number of factors including available charge, capacity.
  • Page 21 General information/Charging Range-Driving conditions N01205900016 Shorten Lengthen driving driving range range Range Reducing Condition Range Extending High acceleration, speed Driving style Low acceleration, speed Heater off Heater on Heater usage (or use seat heater) A/C on A/C usage A/C off Highway City/Highway City...

  • Page 22: Modifications To And Racing Of Your Vehicle

    Modifications to and racing of your vehicle Installation of accessories N01200600018 N01200500017 This vehicle should not be modified with non-Mitsubishi CAUTION Motors genuine parts. Mitsubishi Motors designs and manufac- tures high quality vehicles with an emphasis on safety and Before any electrical or electronic accessories are durability.
  • Page 23 MiEV dealer before installation of any accessory which may the attachment or installation of non-Mitsubishi Motors genu- involve modification of the electrical systems. ine parts will affect the driving safety of your Mitsubishi-vehi- cle. CAUTION Please consult a certified i-MiEV dealer concerning any such accessory fitment or modification.

  • Page 24: Mitsubishi Motors Genuine Parts

    Each Mitsubishi vehicle has a Special handling may apply. For additional information, see selection of Mitsubishi Motors authorized accessories to www.dtsc.ca.gov/hazardouswaste/perchlorate.

  • Page 25: Cautions And Actions To Deal With Intense Heat

    General information/Charging Cautions and actions to deal with intense heat N01201000019 When the vehicle is driven in a high ambient temperature, its air-conditioner performance can be insufficient. Also, using the air conditioner will reduce the vehicle’s cruising range. When the ambient temperature is approximately 104 °F (40 °C) or higher, the phenomena described below may occur. Please take the described actions.
  • Page 26 General information/Charging Approx. ambi- Phenomena Corrective action ent temperature Approx.113 °F Startup and driving • During quick charging (if so equipped), repeated high- • Stop the vehicle in a safe (45 °C) or higher speed driving, or repeated uphill driving, the power down place for a while, avoid quick warning light* comes on and the motor output is restricted charging (if so equipped), and...

  • Page 27: Cautions And Actions To Deal With Intense Cold

    General information/Charging Cautions and actions to deal with intense cold N01201100010 When the vehicle is driven in a low ambient temperatures, its heater performance can be insufficient. Also, using the heater can reduce the vehicle’s cruising range. When the ambient temperature is approximately 5 °F (-15 °C) or lower, the phenomena described below may occur. Please take the corrective actions described below.
  • Page 28 General information/Charging Approx. ambi- ent tempera- Phenomena Corrective action ture Approx.-13 °F Startup and • Motor output is restricted, and the power down warning • Keep driving if you can drive at the (-25 °C) or driving same speed as surrounding vehicles. light* may come on.
  • Page 29 General information/Charging NOTE : Refer to “Power down warning light” on page 3-75. Illumination of the power down warning light does not indicate a mal- function. : Refer to “Ready indicator” on page 3-72. 1-14...

  • Page 30: Charging

    General information/Charging Charging N01201200011 Your vehicle is equipped with a charge port and a charging cable (EV charging cable) for charging with a AC 110-120V or a AC 220-240V outlet. Additionally your vehicle may be equipped with another charge port for quick charging capable for CHAdeMO quick charger.
  • Page 31 General information/Charging Charging time Refer- Category Charge port Charge connector Charging Source with fully dis- ence charged battery Level 2 Regular charging 220-240V P.1-20, 1- (Primary Home About 6 hours EVSE* Dock- Available sepa- rately) Home or public charging passenger side of vehicle device Quick charging (charging method...
  • Page 32 General information/Charging Charging time will vary depending on battery condition, air temperature and condition of power source (such as specification of the quick charger). A vehicle equipped with a quick charge port is compatible with most CHAdeMO (Japanese industry standard) connectors on charg- ing stations.

  • Page 33: Precautions During Charging The Main Drive Lithium-Ion Battery

    General information/Charging Precautions during Charging the Main WARNING Drive Lithium-ion Battery Individuals using an electro-medical apparatus such as implantable pacemakers and implantable cardio- N01202600012 vascular-defibrillators should check with the manu- WARNING facturer of the apparatus to confirm the effect of the electromagnetic waves from charging.
  • Page 34 General information/Charging • Fully charge the vehicle by regular charging every 2 CAUTION weeks. • Do not repeat charging when the main drive lithium-ion To prevent damage to the charging equipment: battery is at or near the full charge. • Do not close the charge port lid without closing the cap.

  • Page 35: Regular Charging (Charging Method With Rated Ac 120 V Outlet)

    General information/Charging Regular charging (charging method with WARNING rated AC 120 V outlet) Make sure that the plug is inserted all the way into the outlet before use. N01203100014 Carefully read instructions regarding “Precautions during While it is normal for the plug and charging cable to charging the main drive lithium-ion battery”...
  • Page 36 General information/Charging Charging from rated AC 120 V outlet 5. Press the tab (C) to open the inner lid (D). N01203200015 1. Fully apply the parking brake and place the selector lever to the “P” (PARK) position. 2. Stop the electric devices such as lamps and turn the elec- tric motor switch to the “LOCK”...
  • Page 37 General information/Charging CAUTION WARNING To help keeping foreign material out of the charge Make sure that the plug is inserted all the way into port, do not leave the inner lid open without con- the outlet before use. necting the charge connector. To reduce the risk of electric shock or fire due to electric leak, always use an outlet protected by a ground-fault circuit interrupter, rated for 15A or...
  • Page 38 General information/Charging 7. Open the cap (F) on the regular charge connector (G) and 8. Connect the regular charge connector until a click is heard make sure that there is no foreign matter such as dust at without pressing the button (H). the end of the regular charge connector and the regular charge port.
  • Page 39 General information/Charging 9. Make sure that the charging indicator on the instrument CAUTION cluster is illuminated. Do not clasp the top of regular charge connector. It could cause injury to from the protrusion on the lid. If the charging indicator is not illuminated, charging will not start.
  • Page 40 General information/Charging NOTE 10. Charging is complete when the charging indicator turns When the regular charge connector is connected to the off. Pull out the regular charge connector while pressing charge port, the charging indicator is blinking. When the button (J). charging is started, the charging indicator is illuminated.
  • Page 41 General information/Charging Main drive lithium-ion battery warming system 11. Close the inner lid and close the regular charging lid. (if so equipped) NOTE N01202500011 Make sure that the inner lid is completely closed before You cannot charge the main drive lithium-ion battery when the closing the regular charging lid.
  • Page 42 General information/Charging The energy level gauge (A) in the instrument cluster and charg- NOTE ing indicator (B) illuminate while the main drive lithium-ion The main drive lithium-ion battery warming system does battery warming system is operating. not operate when the main drive lithium-ion battery tem- perature is -22 °F (-30 °C) or lower.

  • Page 43: Ev Charging Cable

    General information/Charging EV charging cable N01202800014 Your vehicle is equipped with an EV charging cable that consists of a cable (A), control box (B), plug (C) and regular charge con- nector (D). Ready (green), Charge (orange) and Fault (red) indicators are on the control box and they will illuminate/blink in response to the following conditions: : Illuminates : Blinking...
  • Page 44 General information/Charging READY CHARGE FAULT Status and action to be taken (Green) (Orange) (Red) While the main drive lithium-ion battery is being charged When the ground cable is disconnected Check the grounding of the outlet being used. If the outlet is properly grounded, contact a certified i-MiEV dealer.
  • Page 45 General information/Charging NOTE WARNING All indicators are illuminated momentarily for confirming Improper use of the EV charging cable can result in operation when the charging cable plug is inserted into an a fire, property damage, and serious injury or death. outlet.
  • Page 46 General information/Charging Handling and storing the control box FCC Notice: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to N01202900015 part 15 of the FCC Rules. These limits are designed to provide CAUTION reasonable protection against harmful interference in a residen- tial installation.

  • Page 47: Regular Charging (Using 240V Electric Vehicle Supply Equipment)

    General information/Charging Cleaning the EV charging cable Regular charging (using 240V Electric Vehicle Supply Equipment) N01203000013 1. Gently wipe outside surface of the EV charging cable with N01216100018 gauze or a similar soft cloth soaked with a mild soap and You can charge your vehicle through the regular charging port water solution.

  • Page 48: Quick Charging (Charging Method With Quick Charger) (If So Equipped)

    General information/Charging Quick charging (charging method with WARNING quick charger) (if so equipped) As the quick charge connector is heavier in compar- ison to the regular charge connector, allowing it to N01203300016 Your vehicle may be equipped with the quick charging port. drop could cause damage to the vehicle or charge The quick charge port is compatible with most CHAdeMO* connector or personal injury.
  • Page 49 General information/Charging 3. Pull the quick charging lid opener (A) at the bottom left of 5. Press the tab (C) to open the inner lid (D). the driver’s seat to open the quick charging lid (B) at the left rear side of the vehicle. WARNING Do not touch the metal terminal of the quick charge port (E) and the quick charge connector.
  • Page 50 General information/Charging 6. Insert the quick charge connector completely into the CAUTION quick charge port to begin charging. Be sure to insert the quick charge connector straight For connecting and disconnecting, follow the instruction into the quick charge port all the way to the base. manual for each quick charger.
  • Page 51 General information/Charging NOTE 7. Make sure that the charging indicator on the instrument When the quick charging plug is connected to the charg- cluster is illuminated. ing connection, the charging indicator will blink. Once charging has started, the charging indicator will illumi- nate.
  • Page 52 General information/Charging Since the main drive lithium-ion battery cooling system 9. Close the inner lid and close the quick charging lid. uses cool air from the air conditioning system, the air con- ditioning will automatically be operated. WARNING After quick charging, you may find dehumidified water After charging, be sure to close the inner lid and the from the air conditioning system under the vehicle.

  • Page 53: Charging Troubleshooting Guide

    General information/Charging Charging troubleshooting guide N01202300019 Symptom Possible cause Possible solution Charging cannot be The electric motor switch is in Before charging, place the electric motor switch in the “LOCK” position. started. the ON position. The main drive lithium-ion bat- Charging cannot be performed if the main drive lithium-ion battery is tery is already fully charged.
  • Page 54 General information/Charging Symptom Possible cause Possible solution Regular charging is There is no power coming from There may have been a electrical power failure, or the breaker may have discontinued. the outlet. failed.Charging will resume when the power source is reset. The EV charging cable has been Check that the EV charging cable has not been disconnected.
  • Page 55 General information/Charging Symptom Possible cause Possible solution Quick charge is dis- Charging is stopped by the quick Charging will stop depending on the timer function setting of the quick continued. charge timer. charge device.If you need to charge the main drive lithium-ion battery more, start the charging procedure again.

  • Page 56: High-Voltage Components

    General information/Charging High-Voltage components High voltage components and wiring cables are located as shown in the figure below. N01205700014 WARNING The EV (Electric Vehicle) system uses high voltage up to DC 330 volt. The system can be hot during and after starting and when the vehicle is shut off.
  • Page 57 General information/Charging In case of a collision WARNING N01205800015 If a fire occurs in this vehicle, leave the vehicle as In case of a collision, follow the instructions described below soon as possible. Only use a type ABC, BC or C fire to avoid severe burns and electrical shock that may result in extinguisher that is meant for use on electrical fires.

  • Page 58: Miev Remote System (If So Equipped)

    General information/Charging MiEV Remote System NOTE (if so equipped) The emergency shut-off system will be activated and the N01203400017 high-voltage system will automatically turn off under the The MiEV Remote System has the following three functions. following conditions: Charging Timer •...
  • Page 59 General information/Charging WARNING CAUTION Individuals who use implantable pacemakers or Never disassemble or modify the MiEV Remote. No implantable cardiovascular-defibrillators should user serviceable parts are inside except batteries. keep away from the external and internal transmit- Disassembling or modifying the MiEV Remote or ters.
  • Page 60 General information/Charging Melody and buzzer from the MiEV Remote can be turned on or off. Refer to “To turn on/off melody and buzzer” on page 1- The transmitter signal will reach further when the antenna of the MiEV Remote is fully extended and held upright. The onboard antenna is printed on the right side delta glass of the vehicle.
  • Page 61 General information/Charging MiEV Remote • When the MiEV Remote is on, the MiEV Remote can be turned off by pressing the switch for 3 seconds or N01203500018 more. 2. MODE switch The display of the MiEV Remote is changed in order of “ON timer”, “OFF timer”...
  • Page 62 General information/Charging 3_ When communicating with the vehicle, the MiEV Remote display blinks if a communication error occurs or the MiEV Remote is not functioning properly. If the buzzer sounds while this indicator blinks, a problem has been detected. Refer to “Actions to be taken when the MiEV Remote sys- tem does not operate correctly”...
  • Page 63 General information/Charging Charging Timer CAUTION N01203700010 The Charging Timer can be set as follows. Never leave the MiEV Remote in place where it will ON timer: Time from the present to when charging will be subject to high temperatures, such as in direct sunlight, or subject to extreme low temperatures.
  • Page 64 General information/Charging Example of Charging Timer N01205000017 1. Setting of ON Timer = 2h, OFF Timer = 8h 2. When Charging timers are set up, initially 4h for ON-Timer and 8h for OFF-Timer are displayed. Charging Waiting 9:00 11:00 7:00 7:00 11:00 7:00...
  • Page 65 General information/Charging To turn the MiEV Remote ON/OFF To set the ON timer N01205100018 N01205200019 1. Extend the antenna (A) and press the power/communica- 1. Start the regular charging. Refer to “Regular charging tion switch (B) for 1 second or more to turn the MiEV (charging method with rated AC 120 V outlet)”...
  • Page 66 General information/Charging NOTE 4. If you need to change the remaining time for the ON The remaining time for the last charging is displayed with timer, press the UP switch (C) or the DOWN switch (D) to blinking as follows. change the remaining time.
  • Page 67 General information/Charging NOTE 5. Press the power/communication switch (B) for less than 1 The energy level gauge in the instrument panel on the second to send the setting data to the vehicle. vehicle will illuminate and the charging indicator will The MiEV Remote will sound melodies on transmission blink approximately 30 seconds after the vehicle has and reception.
  • Page 68 General information/Charging Turning the electric motor switch to the “ON” position or To start the charging immediately after the ON timer the “ACC” position will cancel the Charging Timer. has been set If the MODE switch is pressed while changing the ON N01206000014 timer setting, the change will be canceled.
  • Page 69 General information/Charging To set OFF Timer 5. Turn off the MiEV Remote. Refer to “To turn the MiEV Remote ON/OFF” on page 1-50. N01205300010 The OFF timer can be set during the regular charging or after setting the ON timer. 1.
  • Page 70 General information/Charging 3. Press the UP switch (C) or the DOWN switch (D) once. 5. Press the power/communication switch (B) for less than 1 The time set last time for the OFF timer will be displayed second to send the setting data to the vehicle. and blink.
  • Page 71 General information/Charging NOTE symbol on the MiEV Remote illuminates while The energy level gauge in the instrument panel will illu- the Main Drive Lithium-ion Battery is charging. minate and the charging indicator will blink approxi- The Charging Timer will be cancelled if the electric motor mately 30 seconds after the vehicle has received the switch is turned to the “ON”...
  • Page 72 General information/Charging Display of MiEV Remote during communicating with To cancel Charging Timer vehicle N01203900012 There are two methods to cancel Charging Timer. N01203800011 By using the MiEV Remote It communicates with the vehicle when the power of the MiEV By operating the electric motor switch on the vehicle Remote is turned on with pressing the power supply/communi- cation switch (B) for 1 second or more and if the power sup-...
  • Page 73 General information/Charging 2. Press the manual charging switch (H), then press the B. By operating the electric motor switch on the vehicle power/communication switch (B) for less than 1 sec- Turn the electric motor switch to the “ACC” or “ON” ond.
  • Page 74 General information/Charging Remote Climate Control NOTE The Remote Climate Control works regardless the posi- N01204200012 tion of the air conditioning switch or dial on the vehicle. WARNING While the Remote Climate Control is activated, the air conditioning switch or dial on the vehicle will not affect The Remote Climate Control, even when set, cannot operation of the cooler, heater or defroster.
  • Page 75 General information/Charging To operate the Remote Climate Control 3. Press the MODE switch (E) to change the mode to Remote Climate Control (3). N01204300013 The following conditions must be met to operate the Remote Climate Control. Selector lever: P (PARK) position. Electric motor switch: LOCK position.
  • Page 76 General information/Charging The modes will be changed in the order from 1 to 4 by 4. Select a desired mode by pressing UP switch (C) or pushing the UP switch. DOWN switch (D). 1_ COOL: Pre-Cooling Mode 2_ HEAT: Pre-Heating Mode : Pre-Defroster Mode 4_ A/C OFF: Remote Climate Control OFF 1-61...
  • Page 77 General information/Charging 5. Press the power/communication switch (B) for less than 1 A. By using the MiEV Remote, after pressing the manual second to send the setting to the vehicle. The MiEV charging switch (H), press the power/communication Remote will sound melodies on transmission and recep- switch (B) for less than 1 second.
  • Page 78 General information/Charging Main Drive Lithium-ion Battery Level Indicator To turn on/off melody and buzzer N01204100011 N01204500015 The remaining energy in the Main Drive Lithium-ion Battery 1. Turn on the MiEV Remote. Refer to “To turn the MiEV can be checked using the MiEV Remote. Remote ON/OFF”...
  • Page 79 General information/Charging General information The remening energy is shown by the number of segments displayed. N01205400011 Your MiEV Remote System operates on a radio frequency sub- ject to Federal Communications Commission (FCC) Rules : 3 segments: Full or near full (For vehicles sold in U.S.A.) and Industry Canada Rules (For : 2 segments: Moderate vehicles sold in Canada).
  • Page 80 General information/Charging Replacement of batteries for the MiEV Remote 2. Battery cover (B) lifts when the slide portion (A) is moved to the arrow direction. N01204600016 CAUTION MiEV Remote is a precision electronic device with a built-in signal transmitter. Do not disassemble or touch an internal parts.
  • Page 81 General information/Charging 3. By moving the battery cover (B) in the arrow direction, 5. Install two new coin type CR2032 batteries (D) with the tabs (C) on the battery cover will come out and the battery “+” side up. cover can be removed. Coin type batteries CR2032 6.
  • Page 82 General information/Charging Actions to be taken when the MiEV Remote system does not operate correctly N01204900019 Take the following actions when the system does not operate correctly. If the system still does not operate correctly after the action(s) have been taken, a system component may not be working properly. Please consult with a certified i-MiEV dealer to check Phenomena Cause Remedy...
  • Page 83 General information/Charging Phenomena Cause Remedy The following Blinks after about 1 Electrical noise source is present in Move away from the noise source. symbol blinks second. the vicinity of the MiEV Remote. when the power (e.g. personal computer) supply/communi- Electrical noise source is present cation switch on between the vehicle and the MiEV the MiEV Remote...
  • Page 84 General information/Charging Phenomena Cause Remedy Charging Timer is After the power/com- Regular charge connector is not inserted Lock the regular charge connector securely. not possible. munication switch is or not locked completely. pressed, the following A household electrical outlet, which the Turn on the household electrical outlet which the symbol blinks in sev- EV charging cable (regular charger) is...
  • Page 85 General information/Charging Phenomena Cause Remedy Timed charging is The system is charged Backup charging for the Main Drive This is not a malfunction.Charging will be termi- impossible. although the ON timer Lithium-ion Battery Warming System nated when the system has been charged enough is being set.
  • Page 86 General information/Charging Phenomena Cause Remedy Timed charging is It is not fully charged. If the charging unit is equipped with the Preset the Charging Timer while the charging impossible. timer function, the power supply to the unit with timer function is powered on. unit has been cut off.
  • Page 87 General information/Charging Phenomena Cause Remedy The Remote Cli- After the power/com- Any of the door or liftgate is open. Close all the doors and liftgate. mate Control can- munication switch is The selector lever is at the position other Place the selector lever to P (PARK) position. not be activated.
  • Page 88 General information/Charging Phenomena Cause Remedy The Remote Cli- The heated seat is not The heated seat switch is turned off. Turn on the heated seat switch. mate Control can- powered on. not be activated. The heated seat The heated seat switch is turned on. Turn off the heated seat switch.

  • Page 90: Seat And Restraint Systems

    Seat and restraint systems Seats ........2- Seats and restraint systems.

  • Page 91: Seats

    Seat and restraint systems Seats N00408400466 1 - Front seats 2 - Rear seats To adjust the seat forward or backward → P.2-5 To adjust the seatback → P.2-8 To adjust the seatback → P.2-5 Folding the seatbacks forward → P.2-9 To adjust the seat height (Driver’s side only) →...

  • Page 92: Seats And Restraint Systems

    Seat and restraint systems Seats and restraint systems Front seats N00401600209 N00401800386 Your vehicle has seat belts and other features that help protect Position the driver’s seat as far back as possible while main- you and your passengers in an accident. taining a position that still enables you to fully apply the ped- Seat belts are the most important safety device.
  • Page 93 Seat and restraint systems WARNING CAUTION Do not attempt to adjust the seat while driving. This Make sure that the seat is adjusted by an adult. If it can cause loss of vehicle control and result in an is adjusted by a child, an unexpected accident might accident.
  • Page 94 Seat and restraint systems To adjust the seat forward or backward To adjust the seatback N00401900303 N00402000356 Pull the seat adjusting lever up and slide the seat forward or To adjust the seatback, lean forward slightly, gently pull the backward to the desired position. Release the adjusting lever to seatback lock lever up, then lean backward to a comfortable lock the seat in place.
  • Page 95 Seat and restraint systems To adjust the seat height (Driver’s side only) WARNING N00402100230 Operate the lever repeatedly to raise or lower the seat. To reduce the risk of serious injury or death in the event of an accident or sudden stop, all seatbacks should be kept in the upright position while the vehi- cle is in motion.
  • Page 96 Seat and restraint systems Heated seat (Driver’s side only) CAUTION N00435600323 The heated seat can be operated when the electric motor switch Switch off the seat heater when not in use. is in the “ON” position. Do not place heavy objects on the seat or stick pins, needles, or other pointed objects into the seat.

  • Page 97: Rear Seats

    Seat and restraint systems Rear seats To adjust the seatback N00402800022 N00402500218 To adjust the seatback, lean forward slightly, gently pull the CAUTION seatback lock lever, then lean backward to a comfortable posi- tion and release the lever. The seatback will lock in place. Child restraint lower anchorages (A) are provided between the seat cushion and the seatback.
  • Page 98 Seat and restraint systems Folding the seatbacks forward WARNING N00402900182 The rear seatbacks can be folded forward to provide additional Do not allow anyone to ride in the center of rear seat luggage compartment space. or in the luggage compartment vehicle is in motion. Pull the lever, and fold the rear seatbacks forward.

  • Page 99: Head Restraints

    Seat and restraint systems Head restraints WARNING N00404300571 Padded head restraints for the seats can reduce the risk of a In order to minimize the risk of a neck injury due to a rear impact, the head restraint must be adjusted to whiplash injury if your vehicle is hit from the rear.
  • Page 100 Seat and restraint systems Adjustment of the head restraint height To remove To reduce the risk of injury in an accident, adjust the head Press the lock knob (A) in the direction shown by the arrows. restraint height so that the center of the restraint is at your eye Then pull the head restraint up and out of the seatback.
  • Page 101 Seat and restraint systems CAUTION CAUTION Check that the lock knob (A) is extended out as The shape and size of the head restraint differs shown in the illustration. Then pull the head according to the seat. Always use the correct head restraint up to make sure that it is locked in place restraint provided for the seat and do not install the and will not come out of the seatback.

  • Page 102: Seat Belts

    Seat and restraint systems Seat belts WARNING N00406000471 To reduce the risk to a front seat passenger of seri- Seat belts are installed in your vehicle to help reduce the risk of ous injury or death from a deploying airbag, make injury to the driver and passenger in the event of an accident.
  • Page 103 Seat and restraint systems Seat belt instructions 1. Occupants should always sit back in their seats with their backs against the upright seatback. To reduce the risk of N00406200457 All seats are equipped with a seat belt which uses one com- serious injury or death during deployment of the airbag, bined lap-and-shoulder belt with an emergency locking retrac- adjust the driver’s seat as far back as possible while main-...
  • Page 104 Seat and restraint systems 2. Grasp the latch plate and slide it up the webbing so that it WARNING easily pulls across your body. To reduce the risk of serious injury or death in the event of an accident or sudden stop, all seatbacks should be kept in the upright position while the vehi- cle is in motion.
  • Page 105 Seat and restraint systems 3. Pull the seat belt out slowly while holding the latch plate. 4. The lap part of the belt must always be worn low and snug Push the latch plate into the buckle until you hear a across the hips.
  • Page 106 Seat and restraint systems Driver’s seat belt reminder/warning light NOTE With the exception of the seat belt for the driver, the seat N00418400371 belts in all other seating positions are equipped with an A tone and warning light are used to remind the driver to fasten Automatic Locking Retractor (ALR) function.
  • Page 107 Seat and restraint systems Front passenger seat belt warning light belt while driving, the warning will operate in the same way. When the seat belt is fastened, the warnings will stop. N00418300224 The front passenger seat belt warning light is located in the WARNING instrument panel.
  • Page 108 Seat and restraint systems Adjustable seat belt shoulder anchor (front seats) WARNING N00406300328 Do not install any accessory or sticker that makes The seat belt anchor height can be adjusted. To move the the light difficult to see. anchor, pull the lock knob (A) and slide the anchor to the desired position.
  • Page 109 Seat and restraint systems Seat belt extender WARNING N00406700087 When your seat belt, even fully extended, is not long enough, a Always adjust the shoulder belt anchor so that the seat belt extender must be obtained. The extender may be used shoulder belt is positioned across the center of your for either of the front seats.

  • Page 110: Seat Belt Use During Pregnancy

    Seat and restraint systems Seat belt use during pregnancy Seat belt pre-tensioner and force limiter systems N00406800121 Seat belts work for everyone, including pregnant women. Like N00417700654 all occupants, pregnant women are more likely to be seriously The driver’s and front passenger’s seats each have a seat belt injured or killed in an accident if they do not wear seat belts.
  • Page 111 Seat and restraint systems The seat belt pre-tensioner system includes the following com- When the seat belt pre-tensioners activate, some smoke is ponents: released and a loud noise will be heard. The smoke is not harm- ful, but care should be taken not to intentionally inhale it, as it may cause some temporary irritation to people with respiratory problems.

  • Page 112: Child Restraint Systems

    Seat and restraint systems Force limiter system Child restraint systems N00408900113 N00407100697 In the event of an accident, the seat belt force limiter system When transporting infants or small children in your vehicle, an will help reduce the force applied to the driver and front seat appropriate child restraint system must always be used.
  • Page 113 Seat and restraint systems Guidelines for child restraint system selection WARNING Any child who is too large to use a child restraint All children should be properly restrained in a restraint device system should ride in the rear seat and wear the lap that offers the maximum protection for their size and age.
  • Page 114 Seat and restraint systems WARNING WARNING Never hold an infant or child in your arms or on Your vehicle is also equipped with a front passenger your lap when riding in this vehicle, even when you airbag. are wearing your seat belt. Never place any part of Never put REAR-FACING CHILD RESTRAINT the seat belt you are wearing around an infant or SYSTEMS or INFANT RESTRAINT SYSTEMS in...
  • Page 115 Seat and restraint systems WARNING WARNING FRONT-FACING CHILD RESTRAINT SYS- It is important to use an approved rear-facing infant TEMS should be used in the rear seat whenever pos- restraint until the infant is one year old (unless the sible. If they must be used in the front passenger infant outgrows the seat sooner).
  • Page 116 Seat and restraint systems Installing a child restraint system using the NOTE Before purchasing a child restraint system, try installing it LATCH (Lower Anchors and Tethers for chil- in the rear seat to make sure there is a good fit. Because of dren) system the location of the seat belt buckles and the shape of the N00418800144...
  • Page 117 Seat and restraint systems Tether anchor locations Examples of child restraint systems compatible with the LATCH system N00418900187 Your vehicle has 2 attachment points on the floor of the lug- N00419000185 gage compartment. These are for securing a child restraint sys- tem tether strap to each of the 2 rear seating positions in your vehicle.
  • Page 118 Seat and restraint systems Using the LATCH system N00419100229 1. In order to securely fasten the tether strap, remove the head restraint from the location where you wish to install the child restraint system. 2. Open the gap a little between the seat cushion (A) and the seatback (B) with your hand to locate the lower anchor- ages (C).
  • Page 119 Seat and restraint systems NOTE 4. Open the cover (E) for the tether anchor by pulling it back In order to secure a child restraint system compatible with with your hand as illustrated below (4). the LATCH system, use the lower anchor points in the 5.
  • Page 120 Seat and restraint systems Installing a child restraint system using the seat Installation belt (with emergency/automatic locking mecha- 1. Place the child restraint system in the rear seating posi- tion. nism) 2. Route the seat belt through the child restraint system N00407300442 With the exception of the driver, the seat belt in all other seat- according to the instructions provided by the child...
  • Page 121 Seat and restraint systems 3. To activate the ALR child restraint installation function, 5. After confirming that the belt is locked, grab the shoulder slowly pull the shoulder part of the belt all the way out of part of the belt near the buckle and pull up to remove any the retractor until it stops.
  • Page 122 Seat and restraint systems 6. Open the cover from the tether anchor installation point 9. Before putting your child in the restraint, push and pull by pulling it back with your hand as illustrated below (6). the restraint in all directions to be sure it is firmly secured. Do this before each use.

  • Page 123: Maintenance And Inspection Of Seat Belts

    Seat and restraint systems Children who have outgrown child restraint sys- Maintenance and inspection of seat belts tems N00407000351 The seat belt webbing may be cleaned with mild soap or deter- N00407600591 Children who have outgrown a child restraint system should be gent solution.

  • Page 124: Supplemental Restraint System (Srs) - Airbag

    Seat and restraint systems Supplemental Restraint System (SRS) - The SRS airbags are NOT a substitute for use of the seat belts. For maximum protection in all types of accidents, seat belts airbag must ALWAYS be worn by everyone who drives or rides in N00407700693 this vehicle (with infants and small children in an appropriate This vehicle is equipped with a Supplemental Restraint System...
  • Page 125 Seat and restraint systems WARNING WARNING IT IS VERY IMPORTANT TO BE PROPERLY Airbags inflate very quickly and with great force. SEATED. Do not sit on the edge of the seat or lean your head • A driver or front passenger sitting too close to the or chest close to the steering wheel or the instrument steering wheel or instrument panel during airbag panel.
  • Page 126 Seat and restraint systems WARNING WARNING Infants and small children should never ride unre- NEVER put REAR-FACING CHILD RESTRAINT strained, or lean against the instrument panel. They SYSTEMS or INFANT RESTRAINT SYSTEMS in should never ride held in your arms or on your lap. the front passenger seat.
  • Page 127 Seat and restraint systems WARNING WARNING FRONT-FACING CHILD RESTRAINT SYS- Older children should be seated in the rear seat with TEMS should be used in the rear seat whenever pos- their seat belt properly worn, and with an appropri- sible. If they must be used in the front passenger ate booster seat (including a booster cushion) if seat, move the seat to the most rearward position needed.
  • Page 128 Seat and restraint systems How the Supplemental Restraint System works N00407800489 The SRS includes the following components: 9- Side airbag modules 10- Curtain airbag modules 11- Side impact sensors 1- Driver’s airbag The airbag control unit monitors the readiness of the electronic 2- SRS warning light parts of the system whenever the electric motor switch is in the 3- Passenger’s airbag off indicator...

  • Page 129: Event Data Recording

    Seat and restraint systems Event Data Recording When the impact sensors detect a sufficient front or side impact to deploy the airbag(s), the appropriate airbag(s) will be N00418600201 Your vehicle is equipped with an “EDR” - Event Data deployed. Recorder which is capable of collecting and storing data in the When airbags deploy, some smoke is released accompanied by event of an airbag deployment.
  • Page 130 Seat and restraint systems Driver’s seat position sensor Passenger’s seat occupant classification sensor system N00417900210 The driver’s seat position sensor is attached to the seat rail and N00418000348 provides the airbag control unit with information on the seat’s The passenger’s seat occupant classification sensor system is fore-aft position.
  • Page 131 Seat and restraint systems WARNING WARNING To ensure that the passenger’s seat occupant classifi- If the vehicle is involved in a severe impact, have the cation sensor system can correctly sense the weight SRS sensors inspected by a certified i-MiEV dealer being applied to the seat, observe the following as soon as possible.
  • Page 132 Seat and restraint systems Passenger’s airbag off indicator WARNING N00418100310 The passenger’s airbag off indicator is located in the instru- If any of the following conditions occur, you should ment panel. immediately have the airbag system in your vehicle inspected by a certified i-MiEV dealer as soon as possible: •...
  • Page 133 Seat and restraint systems SRS warning light WARNING N00408300566 There is a Supplemental Restraint System (SRS) warning light If any of the following conditions occur, the SRS on the instrument panel. The system checks itself each time the and/or seat belt pre-tensioners are not working electric motor switch is turned on.
  • Page 134 Seat and restraint systems Driver’s and passenger’s front airbag system N00407900321 The driver’s airbag is located under the padded cover in the middle of the steering wheel. The front passenger’s airbag is contained in the instrument panel above the glove compart- ment.
  • Page 135 Seat and restraint systems Deployment of front airbags N00408000589 The front airbags ARE DESIGNED TO DEPLOY when… Head-on collision with a solid wall at speeds of Moderate to severe frontal impact within the approx. 15 mph (25 km/h) or higher shaded area between the arrows The front airbags are designed to deploy when the vehicle suf- old level may also be higher if the vehicle hits something that...
  • Page 136 Seat and restraint systems The front airbags MAY NOT DEPLOY when … Collision with a utility pole, tree or other narrow objects In certain types of front collisions, the front airbags may not deploy, even if the deformation of the body seems to be large, because the vehicle’s body structure is designed to absorb the impact and deform in order to help protect the occupants.
  • Page 137 Seat and restraint systems The front airbags ARE NOT DESIGNED TO DEPLOY Rear end collision to your vehicle when … The front airbags are not designed to deploy in situations where they cannot provide protection to the occupants. Some typical situations are shown in the illustrations. Because the front airbags do not protect the occupants in all types of collisions, be sure to always wear your seat belts prop- erly.
  • Page 138 Seat and restraint systems The front airbags MAY DEPLOY when … Collision with an elevated median/island or curb The front airbags may deploy if the underside of the vehicle suffers a moderate to severe impact (undercarriage impact). Some typical situations are shown in the illustrations. Because the front airbags may deploy in certain types of unex- pected impacts, as shown in the illustrations, and these unex- pected impacts can move you out of position, it is important to...

  • Page 139: Glove Compartment

    Seat and restraint systems WARNING WARNING Do not attach anything to the steering wheel’s pad- Do not attach accessories to, or put them in front of, ded cover, such as trim material, badges, etc. These the windshield. They could restrict the airbag infla- could strike and injure an occupant if the airbag tion, or strike and injure an occupant, when the inflates.
  • Page 140 Seat and restraint systems Side airbag system A label is attached to the seatbacks in vehicles with side airbags. N00408100418 The side airbags (A) are contained in the driver and front pas- senger seatbacks. The side airbag is designed to inflate only on the side of the vehicle that is impacted, even with no passenger in the front seat.

  • Page 141: Curtain Airbag System

    Seat and restraint systems Curtain airbag system WARNING N00419200204 The curtain airbags are contained in the front pillars and roof The side airbag and curtain airbag can cause serious side rail. The curtain airbag is designed to inflate only on the injury or death to anyone too close to the airbag side of the vehicle that is impacted, even with no passenger in when it deploys.
  • Page 142 Seat and restraint systems WARNING WARNING In order to reduce the risk of injury from a deploy- Do not attach a microphone (A) or any other object ing side airbag, do not allow any rear seat passen- around the part where the curtain airbag (B) gers to hold onto the back of either front seat.
  • Page 143 Seat and restraint systems Deployment of side airbag and curtain airbag WARNING N00408200480 Never install a rear-facing child restraint system in The side airbag and curtain airbag ARE DESIGNED the front passenger seat. Rear-facing child restraint TO DEPLOY when … systems MUST ONLY be used in the rear seat.
  • Page 144 Seat and restraint systems The side airbag and curtain airbag MAY NOT DEPLOY when … In certain types of side collisions, the side airbag and curtain airbag may not deploy, even if the deformation of the body seems to be large, because the vehicle’s body structure is designed to absorb the impact and to deform in order to help protect the occupants.
  • Page 145 Seat and restraint systems Side impact in an area away from the passenger compartment Oblique side impact Motorcycle or other similar small vehicle collision with the Vehicle rolls onto its side or roof side of vehicle Collision with a utility pole, tree or other narrow object 2-56...
  • Page 146 Seat and restraint systems SRS servicing The side airbag and curtain airbag ARE NOT DESIGNED TO DEPLOY when … N00408500715 The side airbag and curtain airbag are not designed to deploy in WARNING situations where they cannot provide protection to the occu- pants.
  • Page 147 [For vehicles sold in Canada] equipped with the SRS and refer that owner to the applica- To contact Mitsubishi Motor Sales of Canada, Inc. ble sections in this owner’s manual. call 1-888-576-4878 or write to: If you decide to junk or scrap your vehicle, we urge you to Mitsubishi Motor Sales of Canada, Inc.

  • Page 148: Warning Labels

    Seat and restraint systems Warning labels N00408600367 Occupant restraint warning labels for the SRS are located in the vehicle as shown in the illustration. * - Located in the passenger’s side as well. 2-59...

  • Page 150: Features And Controls

    Features and controls Break-in recommendations ....3- Active stability control (ASC)....3- 46 Keys .

  • Page 151: Break-In Recommendations

    Features and controls Break-in recommendations Keys N00508700343 N00508800618 Advanced automobile manufacturing techniques permit you to Two keys are provided. operate your new vehicle without requiring a long break-in The keys fit all locks. Keep one in a safe place as a spare key. period of low-speed driving.

  • Page 152: Electronic Immobilizer (Anti-Theft Starting System)

    Features and controls Electronic immobilizer (Anti-theft starting NOTE The key number (A) is stamped on the key number plate system) as shown in the illustration. N00509100777 Make a record of the key number and store the key and The electronic immobilizer is designed to significantly reduce key number plate in separate places, so that you can order the possibility of vehicle theft.
  • Page 153 Features and controls NOTE In the following cases, the vehicle may not be able to rec- ognize the registered ID code from the key. This means the electric motor unit will not start even when the registered key is turned to the “START” position. •...

  • Page 154: Additional Keys

    Features and controls Additional keys NOTE Electronic immobilizer is not compatible with commer- To add a key, you need to register the ID code to the vehicle. cially available remote starting systems. Use of commer- Registering the ID code can be done by a certified i-MiEV cially available remote starting systems may result in dealer.
  • Page 155 Features and controls NOTE 4. When the immobilizer indicator starts blinking, turn the It is not possible to register a key if: second valid key to the “LOCK” position and remove it. • the immobilizer indicator goes off during the procedure Within 30 seconds after doing so, insert a blank immobi- •...

  • Page 156: Keyless Entry System

    Features and controls General information Keyless entry system N00562300084 N00509000907 Your electronic immobilizer operates on a radio frequency sub- Press the remote control transmitter buttons to lock or unlock ject to Federal Communications Commission (FCC) Rules the doors and to open the liftgate. (For vehicles sold in U.S.A.) and Industry Canada Rules (For It can also help you signal for attention by setting off the panic vehicles sold in Canada).
  • Page 157 Features and controls To lock Horn deactivation/reactivation The horn answerback function can be set to the following three Press the LOCK button (1) to lock all the doors and the liftgate. conditions. If the dome light switch is in the door position, the dome light Each time the horn answerback function is set, a chime will will blink once.
  • Page 158 Features and controls Setting of door unlock function Replacement remote control transmitters N00543600105 N00543800077 The door and liftgate unlock function can be set so that all Only remote control transmitters programmed with the vehi- doors and liftgate unlock when the UNLOCK button (2) is cle’s electronics can lock or unlock all doors.
  • Page 159 This device must accept any interference received, includ- Be sure to perform the procedure with the Mitsubishi ing interference that may cause undesired operation. mark facing up. If the Mitsubishi mark is not facing up when you open the remote control transmitter case, the CAUTION buttons may come out.
  • Page 160 Features and controls 3. Remove the remote control transmitter from the remote 5. Install a new battery with the + side (A) down. control transmitter case. Then, open the remote control transmitter using the method described in step 1. + side - side Coin type battery CR1620 6.

  • Page 161: Door Locks

    Features and controls Door locks To lock or unlock the door with the key Turn the key toward the front of the vehicle to lock the door. N00509200534 After checking that the door is locked, turn the key back to the WARNING center and remove it.
  • Page 162 Features and controls To lock or unlock the door from the inside To lock the door without using the key Move the lock knob to the lock position to lock the door. 1. Move the inside lock knob to the locked position. All doors should be kept locked while driving.

  • Page 163: Power Door Locks

    Features and controls Power door locks To lock and unlock by the power door lock switch N00509300607 NOTE When locking or unlocking with the key on the driver’s door, only the driver’s door will lock or unlock. Repeated continuous operation between lock and unlock could activate the power door locking systems built-in protection circuit and prevent the system’s from operat- ing.

  • Page 164: Child Safety Locks For Rear Door

    Features and controls To unlock the doors and liftgate Child safety locks for rear door N00563400095 N00509400288 You can select the functions to unlock the doors and liftgate either using the electric motor switch position or using the selec- tor lever position. These functions are not activated when the vehicle is shipped from the factory.

  • Page 165: Liftgate

    Features and controls Liftgate WARNING N00510100230 Always keep the doors tightly closed and locked WARNING when driving. An unlocked door may be acciden- tally opened by a passenger, especially by a child When opening and closing the liftgate, make sure who could fall out.
  • Page 166 Features and controls NOTE CAUTION If you do not open the liftgate immediately after pulling Before starting the vehicle, be sure to confirm that the handle, the liftgate can not be lifted. If this happens, the liftgate is locked. If the liftgate opens while driv- pull the handle again and lift the liftgate.

  • Page 167: Theft-Alarm System

    Features and controls Theft-alarm system N00510200244 The theft-alarm system is designed to provide protection from unauthorized entry into the vehicle. This system is operated in three stages: the first is the “armed” stage, the second is the “alarm” stage, and third is the “disarmed” stage. If triggered, the system provides both audible and visual alarm signals.
  • Page 168 Features and controls Armed stage At this time, the theft-alarm indicator (A) in the meter cluster flashes for confirmation. Park the vehicle and stop the electric motor unit. Arm the sys- tem as described below. 1. Remove the key from the electric motor switch. 2.
  • Page 169 Features and controls Type of alarm NOTE The system will be disarmed if, while the theft-alarm indi- When the alarm is activated: cator is illuminated, all doors and the liftgate are unlocked 1. The headlights blink on and off for 3 minutes. by using the keyless entry system.
  • Page 170 Features and controls Alarm deactivation NOTE If the UNLOCK button on the remote control transmitter The alarm can be deactivated in the following ways. By using the keyless entry system to lock or unlock the is operated when all doors and the liftgate are closed and no door is opened within approximately 30 seconds, re- doors and liftgate.

  • Page 171: Power Window Control

    Features and controls Power window control WARNING N00510800396 Before operating the power windows, make sure that nothing can be trapped (head, hands, fingers, etc.) in the window. Never leave the vehicle without carrying the key. Never leave children or unreliable adults unat- tended inside the vehicle.
  • Page 172 Features and controls Sub switch N00548800115 1- Driver’s door window switch 2- Front passenger door window switch 3- Left rear door window switch 1- Close 4- Right rear door window switch 2- Open 5- Lock switch Each sub-switch can be used for it’s own passenger door win- dow, unless the driver’s window lock switch is activated.
  • Page 173 Features and controls Power window timer function Lock switch N00548900145 N00549000156 The power windows can be run up or down when the electric When this switch is in the lock mode, the passenger door motor switch is in the “ON” position. switches cannot be used to open or close the door windows, The door windows can be opened or closed for a 30-second and the main switch will open or close only the driver’s door...

  • Page 174: Parking Brake

    Features and controls Parking brake To release N00511400386 To park the vehicle, first bring it to a complete stop, fully engage the parking brake, and set the selector lever to “P” (PARK) position. To apply 1- Pull the lever up slightly. 2- Press and hold the button at the end of the hand grip.

  • Page 175: Inside Rearview Mirror

    Features and controls Inside rearview mirror To adjust the vertical mirror position It is possible to move the mirror up and down to adjust its posi- N00511600287 Adjust the inside rearview mirror only after making any seat tion. adjustments so as to have a clear view to the rear of the vehicle. WARNING Do not attempt to adjust the inside rearview mirror while driving.
  • Page 176 Features and controls To adjust the mirror position To reduce the glare It is possible to move the mirror up/down and left/right to The day/night knob (A) at the bottom of the mirror can be used adjust its position. to adjust the mirror to reduce the glare from the headlights of vehicles behind you during night driving.

  • Page 177: Outside Rearview Mirrors

    Features and controls Outside rearview mirrors To adjust the mirror position The outside rearview mirrors can be adjusted when the electric N00512200222 Adjust the outside rearview mirrors only after making any seat motor switch is in the “ON” or “ACC” position. adjustments so you have a clear view to the rear of the vehicle.
  • Page 178 Features and controls To fold the mirror Heated mirror (if so equipped) The outside mirror can be folded in toward the side window to N00549300205 When the rear window defogger switch is pressed, the outside prevent damage when parking in tight locations. rearview mirrors are defogged or defrosted.

  • Page 179: Electric Motor Switch

    Features and controls Electric motor switch START The electric motor unit operates. After the electric motor unit N00571500011 has started, release the key and it will automatically return to the “ON” position. NOTE Your vehicle is equipped with an electronic immobilizer. To start the electric motor unit, the ID code which the transponder inside the key sends must match the one registered to the immobilizer computer.
  • Page 180 Features and controls Key reminder buzzer N00571700013 If the driver’s door is opened while the electric motor switch is in the “LOCK” or “ACC” position, a tone will sound. CAUTION Do not remove the key from the electric motor switch while driving. The steering wheel will lock, causing loss of control.

  • Page 181: Steering Wheel Lock

    Features and controls Steering wheel lock NOTE If the front wheels are turned, the anti-theft lock may N00512500209 sometimes make it difficult to turn the key from “LOCK” position to “ACC” position. Firmly turn the steering wheel to the left or to the right as you turn the key. To lock Remove the key at the “LOCK”...

  • Page 182: Starting The Electric Motor Unit

    Features and controls Starting the electric motor unit Transmission N00571800014 N00513200203 Selector lever operation CAUTION N00513800371 Never attempt to start the electric motor unit by pushing or pulling the vehicle. 1. Make sure all occupants are properly seated with seat belts fastened.
  • Page 183 Features and controls Selector lever position indicator WARNING N00513900431 When the electric motor switch is turned to the “ON” position, Always depress the brake pedal when shifting the the current position of the selector lever is indicated on the selector lever into another position from the “P” instrument cluster.
  • Page 184 Features and controls Selector lever positions When the selector lever position indicator flashes while you are driving, there could be a malfunction in the transmission. N00514200369 “P” PARK This position locks the transmission to prevent the vehicle from moving. The electric motor unit can be started from the “PARK”...
  • Page 185 Features and controls “N” NEUTRAL “ECO” ECO MODE Use this position only when the vehicle is stationary for an Use this position when you desire to limit power consumption extended length of time while driving, such as in a traffic jam. and/or when moderate regenerative braking is required.
  • Page 186 Features and controls Operation of the transmission CAUTION N00514500359 Never hold the vehicle stationary on a hill with the CAUTION accelerator. Always apply the parking brake and/or service brake. Before selecting a position with the electric motor unit running and the vehicle stationary, fully depress the brake pedal to prevent the vehicle from Parking creeping.

  • Page 187: Acoustic Vehicle Alerting System (Avas)

    Features and controls Acoustic vehicle alerting system (AVAS) Under normal conditions, the indicator light in the instrument cluster illuminates when the electric motor switch is turned to N00571900028 the “ON” position and goes off a few seconds later. Always While driving at low speeds, such as in parking lots, the acous- confirm the indicator light goes off before driving.

  • Page 188: Service Brake

    Features and controls Service brake Power brakes N00517600410 N00517500305 Your vehicle is equipped with power brakes for more braking Brake pedal force with reduced brake pedal effort. Overuse of the brake can cause poor brake response and pre- Your brakes are designed to operate at full capacity, even if the mature wear of the brake pads.

  • Page 189: Brake Assist System

    Features and controls Brake assist system Brake pad wear alarm N00532500162 N00567300063 The disc brakes have an alarm that makes a metallic squeal The brake assist system is a device assisting drivers who can- when the brake pads have worn down enough to need service. not depress the brake pedal firmly such as in emergency stop If you hear this sound, have the brake pads replaced at a certi- situations and provides greater braking force.

  • Page 190: Anti-Lock Braking System

    Features and controls Anti-lock braking system NOTE Once the brake assist system is operational, it maintains N00517900325 great braking force even if the brake pedal is lightly The anti-lock braking system helps prevent the wheels from released. locking up when braking. This helps you keep control of your To stop its operation, completely remove your foot from vehicle and its direction.
  • Page 191 Features and controls Anti-lock braking system warning light An operation noise may be emitted from under the hood in the following situations. The sound is associated with N00531600661 This light comes on in the event of a malfunction in the anti- checking the operations of the anti-lock braking system.
  • Page 192 Features and controls If the warning light illuminates while driving After driving on snow or icy roads, remove any snow and ice which may have been left around the wheels. On vehi- N00531700590 cles that have an anti-lock braking system, be careful not If only the ABS warning light illuminate to damage the wheel speed sensors (A) or the cables Avoid hard braking and high-speed driving.

  • Page 193: Electric Power Steering System (Eps)

    Features and controls Electric power steering system (EPS) Rear N00568400045 The electric power steering system (EPS) operates while the electric motor unit is running. The EPS uses an electric motor to assist the turning of the steering wheel. The EPS has mechanical steering capability in case the power assist is lost.
  • Page 194 Features and controls If you turn the steering wheel while the vehicle is station- If the warning light appears while driving ary with the headlights on, the headlights may become N00574500012 1. Stop the vehicle in a safe place, put the selector lever to dim.

  • Page 195: Active Stability Control (Asc)

    Features and controls Active stability control (ASC) NOTE An operation noise may be emitted from under the hood in N00559100163 The active stability control (ASC) takes overall control of the the following situations. The sound is associated with checking the operations of the ASC. At this time, you may anti-lock braking system, traction control function and skid feel a shock from the brake pedal if you depress it.
  • Page 196 Features and controls Skid control function ASC OFF switch N00546800049 N00559400238 The skid control function is designed to help the driver main- The ASC is automatically activated when the electric motor tain control of the vehicle on slippery roads or during rapid switch is turned to the “ON”...
  • Page 197 Features and controls ASC indicator, ASC OFF indicator NOTE Using the ASC OFF switch turns off both the skid control N00546900053 The indicators should illuminate when the electric motor function and the traction control function. switch is turned to the “ON” position, and should turn off after When moving out of mud, sand or fresh snow, pressing a few seconds.

  • Page 198: Tire Pressure Monitoring System

    Features and controls Tire pressure monitoring system CAUTION N00530200426 If an abnormal condition occurs in the system while The tire pressure monitoring system uses tire inflation pressure sensors (A) on the wheels to monitor the tire inflation pres- driving, the indicators will illuminate.
  • Page 199 Features and controls Tire pressure monitoring system warning light NOTE The tire pressure monitoring system is not a substitute for N00554800136 When the electric motor switch is turned to the “ON” position, regularly checking tire inflation pressures. this light normally illuminates and goes off a few seconds later. Be sure to check the tire inflation pressures as described in If one or more of the vehicle tires is significantly under- “Tires”...
  • Page 200 Features and controls CAUTION If a malfunction is detected in the tire pressure mon- itoring system, the tire pressure monitoring system warning light will blink for approximately 1 minute and then remain continuously illuminated. The warning light will issue further warnings each time the electric motor unit is restarted as long as the malfunction exists.
  • Page 201 Features and controls If the warning light illuminates while driving Under-inflation also reduces alternative fuel efficiency and tire tread life, and may affect the vehicle’s handling and stopping N00532800484 ability. 1. If the low tire pressure monitoring system warning light Please note that the TPMS is not a substitute for proper tire illuminates, avoid hard braking, sharp steering maneuvers maintenance, and it is the driver’s responsibility to maintain...
  • Page 202 Driving with an under-inflated tire adversely affects The tire inflation pressure sensors’ battery is exhausted. vehicle performance and can result in an accident. Wheels other than Mitsubishi Motors genuine wheels are being used. CAUTION Wheels that are not fitted with tire inflation pressure sen- sors are being used.
  • Page 203 Features and controls Whenever the tires and wheels are replaced with General information new ones N00533000207 Your tire pressure monitoring system operates on a radio fre- N00532900182 quency subject to Federal Communications Commission If you use new wheels with new tire inflation pressure sensors, (FCC) Rules (For vehicles sold in U.S.A.) and Industry Canada their ID codes must be programmed into the tire pressure mon- Rules (For vehicles sold in Canada).

  • Page 204: Rear-View Camera (If So Equipped)

    When the selector lever is in the “R” (REVERSE) position with the electric motor switch is in the “ON” position, the rear- view image will be displayed on the screen of the Mitsubishi Multi Communication System. When the selector lever is shifted out of the “R” position, the rear-view image will turn off.
  • Page 205 Features and controls Reference lines on the screen CAUTION Reference lines and upper surface of the rear bumper (A) are The rear-view camera uses a wide-angle lens. As a displayed on the screen. result, images and distances shown on the screen are Red line (B) indicates approximately 20 inches (50 cm) not exact.
  • Page 206 Features and controls CAUTION Case 1 The reference lines for distance and vehicle width are intended to indicate the distance to a flat object such as a level, flat road surface. They may not indi- cate correct distance depending on the shape of an obstacle.

  • Page 207: Instrument Cluster

    It is possible to change the display language of the screen. For details, please refer to the separate owner’s manual for “Mitsubishi Multi-Communication System”. Under certain circumstances, it may become difficult to see an image on the screen, even when the system is func- tioning correctly.
  • Page 208 Features and controls Speedometer Changing the display unit N00572000013 N00519100246 It is possible to select the speedometer’s display unit. When the electric motor switch is in the “ON” position, the speedometer indicates the vehicle’s speed in miles per hour 1. Press the reset button (A) to display the odometer (B). (mph) or kilometers per hour (km/h).
  • Page 209 Features and controls Energy usage indicator The display unit for the cruising range will change to match the selected speedometer’s display unit. N00572100014 The consumption power of the electric motor unit, the air con- ditioning, and charged power of electric energy generated from Speedometer Cruising range the regenerative brake are indicated.
  • Page 210 Features and controls Odometer/Trip odometer/Dash lights brightness indicator/Service reminder/Cruising range indi- cator/Outside temperature display N00519500439 With the electric motor switch in the “ON” position, odometer, trip odometer, dash lights brightness indicator, service reminder, cruising range indicator, and outside temperature are displayed.
  • Page 211 Features and controls NOTE The cruising range indicator and outside temperature dis- play are indicated when the electric motor switch is in the “ON” position. If there is no operation for about 10 seconds when the meter illumination control or service reminder is shown, the display returns to the odometer.
  • Page 212 Features and controls Trip odometer Service reminder N00572400020 N00572500021 The trip odometer shows the distance traveled since the last The service reminder shows the driving distance or number of time it was reset. months remaining until the next recommended periodic main- tenance inspection is required.
  • Page 213 Features and controls Driving distance Number of months 1. The display shows the driving distance or number of 3. After your vehicle is inspected at a certified i-MiEV months remaining until the next periodic inspection. dealer, it displays the time and miles (km) until the next periodic inspection.
  • Page 214 Features and controls Resetting the service reminder 1. Push the reset button (D) to view the driving distance or With the electric motor switch in the “LOCK” position or the number of months remaining until the next periodic “ACC” position, it is possible to reset the spanner mark (A) inspection.
  • Page 215 Features and controls Dash lights brightness indicator NOTE You can adjust to 4 different levels for when the parking N00572600019 Each time you press the dash lights illumination button (B), the lights or headlights are illuminated and 4 for when they brightness of the instruments changes.

  • Page 216: Outside Temperature Display

    Features and controls Outside temperature display Cruising range indicator N00572700023 N00573000010 This displays the approximate cruising range (how many more This value (A) shows the outside temperature of the vehicle. miles or kilometres you can drive). When the cruising range becomes short, the indication changes to “---”.
  • Page 217 Features and controls If the outside temperature drops below approximately 37 °F Change of the outside temperature unit (3 °C), the alarm sounds and the outside air temperature warn- N00573100011 When the electric motor switch is in the “ACC” or “ON” posi- ing indicator (B) flash for approximately 10 seconds to show tion, pressing the selector button (A) for more than 2 seconds there is a danger the road might be icy.
  • Page 218 Features and controls Energy level gauge Low energy warning indicator N00572900025 N00572800024 The energy level gauge indicates the remaining power in the main drive lithium-ion battery during charging or when the electric motor switch is in the “ON” position. When the electric motor switch is in the “ON” position and the remaining bar of the energy level gauge shows 2 bars or less, the warning indicator (A) and the charging bars (B) flash as follows:...
  • Page 219 Features and controls NOTE If the energy level gauge shows 0 bars during use of the air conditioning, the cooling or heating may stop opera- tion and the mode is changed to fan only. If the energy level gauge shows 0 bars, the power down warning light is illuminated to control the output.

  • Page 220: Indicator And Warning Light Package

    Features and controls Indicator and warning light package N00519800836 14- Electric power steering system warning light → P.3-45 1- Low energy warning indicator → P.3-69 15- Electric motor unit warning light → P.3-75 2- Selector lever position indicator → P.3-34 16- Brake warning light →...

  • Page 221: Indicators

    Features and controls Indicators Charging indicator N00573300013 N00519900127 This indicator flashes when the regular charging cable or quick charging cable is connected. Turn signal indicators/Hazard warning lights After that, the light switches to being illuminated when charg- ing starts and goes out when charging is completed. N00520000232 The arrows will flash in time with the corresponding exterior Regenerative brake system indicator...

  • Page 222: Warning Lights

    Features and controls Warning lights CAUTION N00520300147 If any of the following situations occur, stop the vehicle in a safe location, avoiding any sudden brake Brake warning light (brake warning buzzer) application, and contact a certified i-MiEV dealer. N00520400500 • The brake warning light does not illuminate when This light comes on when the electric motor switch is turned to the parking brake is applied or does not turn off the “ON”...
  • Page 223 Features and controls 12V starter battery charging system warning Door-ajar warning light and buzzer light N00520900316 This light comes on when any door or liftgate is open or not N00573500028 completely closed. This light will illuminate when there is a problem with the When the vehicle is moving at more than 5 mph (8 km/h) and charging system for the 12V starter battery.
  • Page 224 Features and controls Electric motor unit warning light If the warning light illuminates when the outside air tempera- ture is very low, move the vehicle to a warmer location. N00573600029 This warning light will illuminate when there is a problem with If the warning light illuminates after the vehicle has been a high voltage component.

  • Page 225: Combination Headlights And Dimmer Switch

    Features and controls Combination headlights and dimmer switch Type 1 N00522500710 Rotate the switch to operate the lights. Headlights NOTE Do not leave the headlights and other lights on for a long period of time while the ready indicator is not illuminated. A run down 12V starter battery could result.
  • Page 226 Features and controls Vehicles equipped with daytime running lights Type 2 [When the ready indicator is illuminated, and the parking brake Rotate the switch to operate the lights. is released] The daytime running lights will be illuminated: OFF The daytime running lights illuminated The daytime running lights illuminated Parking, tail, front and rear side-marker lights, license plate and instrument panel lights on...
  • Page 227 Features and controls Vehicles equipped with daytime running lights [When the ready indicator is not illuminated, or when the ready [When the ready indicator is illuminated, and the parking brake indicator is illuminated but the parking brake is not released] is released] The electric motor unit starts when the lights are off.
  • Page 228 Features and controls Light auto-cutout function (headlights and other NOTE The sensitivity of the automatic on/off control can be lights) adjusted. N00532600554 For further information, please contact a certified i-MiEV If the key is turned to “LOCK” or “ACC” position or dealer.
  • Page 229 Features and controls Headlight reminder buzzer When you want to keep the lights on: If the combination headlights and dimmer switch is turned to N00549800213 If the driver’s door is opened with the key removed from the the “ ” or “ ”...

  • Page 230: Headlight Flasher

    Features and controls Dimmer (high/low beam change) Headlight flasher N00549900155 N00550000198 To change the headlights from high beam to low beam and vice You can flash the high beams by pulling the lever gently versa, pull the turn signal lever to fully toward you (1). Switch toward you (2).

  • Page 231: Turn Signal Lever

    Features and controls Turn signal lever NOTE A light in the instrument panel flashes to show when the N00522600506 When changing lanes, or to making a gradual turn, hold the front and rear turn signal lights are working properly. If this light flashes faster than usual, check for a burned lever in the “lane change”...

  • Page 232: Hazard Warning Flasher Switch

    Features and controls Hazard warning flasher switch Front fog light switch (if so equipped) N00522700305 N00522800410 The front fog lights illuminate only when the headlights are on low beam. Turning the knob in the direction of the “ON” position turns on the front fog lights as well as the indicator in the instrument cluster.

  • Page 233: Wiper And Washer Switch

    Features and controls Wiper and washer switch If the combination headlights and dimmer switch is rotated to the “OFF” or “ ” position while the front fog N00523000640 lights are illuminated, they will automatically turn off. CAUTION They can be turned back on again by rotating the combi- nation headlights and dimmer switch back to “...
  • Page 234 Features and controls To adjust intermittent intervals With the lever in the “INT” (speed sensitive intermittent opera- tion) position, the intermittent intervals can be adjusted by turning the knob (A). MIST- Misting function The wipers will operate once. OFF- Off INT- Intermittent (Speed sensitive) LO- Slow 1- Fast...

  • Page 235: Windshield Washer

    Features and controls Windshield washer Misting function The wipers will operate once if the wiper lever is raised to the N00504600272 To turn on the windshield washer, pull the lever toward you “MIST” position and released. This operation is useful when it with the electric motor switch in either the “ON”...
  • Page 236 Features and controls Rear window wiper and washer NOTE To ensure a clear rearward view, the wiper performs sev- N00523200394 The rear window wiper and washer can be operated when the eral continuous operations when the reverse gear is electric motor switch in either the “ON” or “ACC” position. engaged and the switch is in the “INT”...
  • Page 237 Features and controls Precautions to observe when using wipers and Replace the wiper blades when they are worn. Use the proper size replacement blades. If you have questions, ask washers a certified i-MiEV dealer. N00523500241 CAUTION If the washer is used in cold weather, the washer fluid sprayed onto the glass might freeze, blocking your view.

  • Page 238: Electric Rear Window Defogger Switch

    Features and controls Electric rear window defogger switch CAUTION N00523700399 The electric rear window defogger can be used when the ready The rear window defogger is not designed to melt snow. Remove any snow manually before using the indicator is illuminated. rear window defogger.

  • Page 239: Horn Switch

    Link System End User License Agreement N00563800015 You have acquired a device that includes software licensed by Mitsubishi Motors Corporation from JOHNSON CONTROLS Inc (the automotive experience business unit), and their subse- quent 3rd party suppliers. For a complete list of these 3rd party products and their end user license agreements, please go to the following website.
  • Page 240 Features and controls ® Bluetooth 2.0 interface WARNING (if so equipped) N00563900087 ® Although the Bluetooth 2.0 interface allows you to ® The Bluetooth 2.0 interface allows for making/receiving make hands-free calls, if you choose to use the cellu- ® hands-free calls in the vehicle using a Bluetooth compatible lar phone while driving, you must not allow yourself...
  • Page 241 Features and controls Steering control switch ® Some Bluetooth devices are not compatible with the ® N00564000056 Bluetooth 2.0 interface. Steering control switch → P.3-92 Voice recognition function → P.3-94 Useful voice commands → P.3-95 Speaker enrollment function → P.3-97 ®...
  • Page 242 Features and controls Volume up button HANG-UP button Press this button to increase the volume. Press this button when an incoming call is received to refuse the call. Volume down button Press this button during a call to end the current call. Press this button to decrease the volume.
  • Page 243 Features and controls Voice recognition function Selecting the language 1. Press the SPEECH button. N00564100031 ® The Bluetooth 2.0 interface is equipped with a voice recogni- 2. Say “Setup.” tion function. 3. Say “Language.” Simply say voice commands and you can perform various 4.
  • Page 244 Features and controls Useful voice commands Confirmation function setting N00564500019 N00564200016 ® The Bluetooth 2.0 interface is equipped with a confirmation Help function function. N00564300017 With the confirmation function activated, you are given more ® The Bluetooth 2.0 interface is equipped with a help function. opportunities than normal to confirm a command when making If you say “Help”...
  • Page 245 Features and controls Setting the passcode Entering the passcode Use the following procedure to turn on the security function by If a passcode has been set and the security function is enabled, setting a passcode. the voice guide will say “Hands-free system is locked. State the passcode to continue”...
  • Page 246 Features and controls Speaker enrollment function 4. The voice guide will say “This operation must be per- formed in a quiet environment while the vehicle is N00564700011 ® stopped. See the owner’s manual for the list of required The Bluetooth 2.0 interface can use the speaker enrollment training phrases.

  • Page 247: Bluetooth Device

    Please go to following website for a lot of compatible Say “Retrain” to start the speaker enrollment process and devices. recreate a new voice model. (Refer to “Speaker www.mitsubishifuse.com enrollment” on page 3-97.） Or contact Mitsubishi hands-free customer support at (888)702-4100. 3-98...
  • Page 248 Features and controls To pair 6. The voice guide will say “Please say a 4-digit pairing ® ® code.” Say a 4-digit number. To pair a Bluetooth device with the Bluetooth 2.0 interface, When the confirmation function is on, the system will follow the steps below.
  • Page 249 Features and controls Selecting a device 7. The voice guide will say “Start pairing procedure on the device. See the device manual for instructions.” Enter in N00565100012 ® If multiple paired Bluetooth devices are available in the vehi- ® the Bluetooth device the 4-digit number you have cle, the cellular phone or music player most recently connected registered in Step 6.
  • Page 250 Features and controls ® 5. The selected music player will be connected to the 5. The selected phone will be connected to the Bluetooth ® 2.0 interface. The voice guide will say “<device tag> Bluetooth 2.0 interface. selected” and then the system will return to the main The voice guide will say “<device tag>...
  • Page 251 Features and controls NOTE 7. The voice guide will say “Deleted,” and then the system If you press and release the SPEECH button and say will end the device deletion process. “Continue” or “Previous” while the list is being read, the NOTE system will advance or rewind the list.
  • Page 252 Features and controls Operating a music player connected via 5. The voice guide will say “Please say,” and read out the ® ® numbers of the Bluetooth devices and device tags of cor- Bluetooth ® responding devices in order, starting with the Bluetooth N00565400028 ®...
  • Page 253 Features and controls To make a call The maximum supported telephone number length is as follows: N00565600033 You can make a call in the following 3 ways using the • International telephone number: + and telephone num- ® bers (to 18 digits). Bluetooth 2.0 interface: •...
  • Page 254 Features and controls 4. If there is only 1 match, the system will proceed to Step 5. 5. If only 1 telephone number is registered under the name If there are 2 or more matches, the voice guide will say you just said, the voice guide will proceed to Step 6.
  • Page 255 Features and controls Receiving calls 6. The voice guide will say “Calling <name> <location>” and then the system will dial the telephone number. N00565800022 If an incoming phone call is received while the electric motor NOTE switch is in the “ACC” or “ON” position, the audio system will When the confirmation function is on, the system will be automatically turned on and switched to the incoming call, check if the name and location of the receiver are correct.
  • Page 256 Features and controls Phonebook function Mute function N00565900010 N00566000018 At any time during a call, you can mute the vehicle micro- ® The Bluetooth 2.0 interface has 2 types of unique phonebooks phone. that are different from the phonebook stored in the cellular Pressing the SPEECH button and then saying “Mute”...
  • Page 257 Features and controls To register a telephone number in the vehicle phonebook 5. When the name has been registered, the voice guide will You can register a telephone number in the vehicle phonebook say “home, work, mobile, or other?” Say the location for in the following 2 ways: Reading out a telephone number, and which you want to register a telephone number.
  • Page 258 Features and controls To select and transfer one phonebook entry from the 7. The voice guide will repeat the telephone number you phonebook of the cellular phone have just read, and then register the number. You can select 1 phonebook entry from the phonebook of the When the telephone number has been registered, the voice cellular phone and register it in the vehicle phonebook.
  • Page 259 Features and controls 4. The voice guide will say “Would you like to import a sin- 7. When the reception is complete, the voice guide will say gle entry or all contacts?” Say “Single entry.” “<Number of telephone numbers that had been registered in the import source>...
  • Page 260 Features and controls To change the content registered in the vehicle phonebook 6. The voice guide will say “Number, please.” Say the tele- You can change or delete a name or telephone number phone number you want to register. registered in the vehicle phonebook. NOTE You can also listen to the list of names registered in the vehicle If the telephone number is already registered in the...
  • Page 261 Features and controls [Editing a name] [Listening to the list of registered names] 1. Press the SPEECH button. 1. Press the SPEECH button. 2. Say “Phonebook.” 2. Say “Phonebook.” 3. The voice guide will say “Select one of the following: 3.
  • Page 262 Features and controls [Deleting a telephone number] 6. The system will ask if you really want to delete the 1. Press the SPEECH button. selected telephone number(s) to go ahead with the dele- tion, answer “Yes.” 2. Say “Phonebook.” Answer “No,” the system will cancel deleting the tele- 3.
  • Page 263 Features and controls Erasing the phonebook Mobile phonebook You can delete all registered information from the vehicle N00566200023 All entries in the phonebook stored in the cellular phone can be phonebook. transferred in a batch and registered in the mobile phonebook. 1.
  • Page 264 Features and controls To import a devices phonebook 5. The voice guide will say “Importing the contact list from Follow the steps below to transfer to the mobile phonebook the the mobile phonebook. This may take several minutes to phonebook stored in the cellular phone. complete.
  • Page 265 Features and controls General information Enrollment commands N00566300040 N00566400038 MODEL: MMC FCC ID: CB2MDGMY10 IC: 279B- MDGMY10 ® Your Bluetooth 2.0 interface operates on a radio frequency subject to Federal Communications Commission (FCC) Rules (For vehicles sold in U.S.A.) and Industry Canada Rules (For vehicles sold in Canada).

  • Page 266: Usb Input Terminal (If So Equipped)

    Features and controls USB input terminal How to connect a USB memory device (if so equipped) N00566800087 N00566700028 You can connect your USB memory device or iPod* to play 1. Park your vehicle in a safe place and turn the electric music files stored in the USB memory device or iPod.
  • Page 267 Features and controls 3. Connect a commercially available USB connector cable 4. Connect the USB connector cable (C) to the USB input (C) to the USB memory device (B). terminal (D). WARNING Place the USB memory device and the USB connec- tor cable so as not to interfere with driving.
  • Page 268 Features and controls How to connect an iPod 3. Connect the Dock connector (C) to the iPod (B). N00566900075 1. Park your vehicle in a safe place and turn the electric motor switch to the “LOCK” position. 2. Open the USB input terminal cover (A) in the floor con- sole.

  • Page 269: Specifications

    Features and controls Types of connectable devices and supported file 4. Connect the Dock connector (C) to the USB input termi- nal (D). specifications N00567000031 Device types N00567100074 Devices of the following types can be connected. Model name Condition Storage capacity of 256 Mbytes USB memory device or more iPod touch*...
  • Page 270 Features and controls File specifications NOTE Depending on the type of the USB memory device or N00567200017 other device connected, the connected device may not You can play music files of the following specifications that function properly or the available functions may be lim- are saved in a USB memory device or other device supporting ited.

  • Page 271: Sun Visors

    Features and controls Sun visors Vanity mirror A vanity mirror is fitted to the back of the sun visor. N00524600340 Fold the sun visor downward (1) to reduce front glare while driving. To reduce side glare, turn the visor to the side (2). 3-122...

  • Page 272: 12 V Power Outlet

    Features and controls Card holder 12 V power outlet Cards can be slipped into the front (A) of the lid of the vanity N00525000602 mirror. CAUTION Be sure to use a “plug-in” type accessory operating at 12 V and 120 W or less. Be aware that using electronic equipment with the ready indicator off may run the 12 V starter battery down.

  • Page 273: Interior Lights

    Features and controls Interior lights The accessory can be operated when the electric motor switch is in the “ON” or “ACC” position. N00525300559 To use a “plug-in” type accessory, open the cover, then insert the plug in the socket. 1- Dome light (Rear) → P.3-127 2- Dome light (Front)/Reading lights →...
  • Page 274 Features and controls Dome light (Front)/Reading lights (if so equipped) 1- (DOOR) N00525800219 The dome light comes on when any door or the liftgate is opened. It goes off approximately 30 seconds after Dome light (Front) the door or liftgate is closed (delayed off function). The dome light can be turned on by sliding the dome light However, the light goes off immediately if: switch.
  • Page 275 Features and controls Reading lights NOTE When the key is removed while the doors and liftgate N00553800096 Regardless of the dome light switch position, when you press are closed, the dome light will illuminate for about 30 the lens, the light on the side that is pressed illuminates; when seconds before going off.
  • Page 276 Features and controls Dome light (Rear) 1- (ON) N00525400446 The dome light comes on. The rear dome light can be turned on by sliding the dome light 2- ( ) switch. The dome light comes on when any door or the liftgate is opened.

  • Page 277: Storage Spaces

    Features and controls Storage spaces NOTE When the key is removed while the doors and liftgate N00526400502 are closed, the dome light will illuminate for about 30 CAUTION seconds before going off. The time until the light goes off (delayed off) can be Never leave lighters, carbonated drink cans, or spec- adjusted.
  • Page 278 Features and controls Glove compartment Card holder N00571400010 N00551500259 To open the glove compartment, pull the lever (A). There is a card holder on the inside of the glove compartment. WARNING An open glove compartment door can cause a seri- ous injury or death to the front passenger in an acci- dent, even if the passenger is wearing his/her seat belt.

  • Page 279: Cup Holder

    Features and controls Cup holder Do not put your hand on the cup holder while getting in or out of the vehicle. The cup holder could break. N00527300364 Never place anything other than cup or drink can in the For the front seat cup holder.

  • Page 280: Assist Grip

    Features and controls Assist grip N00559000058 These grips are to support the body by hand while seated in the vehicle. CAUTION Do not use the assist grips when getting into or out of the vehicle. The assist grips could detach and cause an accident. 3-131...

  • Page 282: Driving Safety

    Driving safety Economical driving ......4- Driving, alcohol and drugs....4- Floor mat .

  • Page 283: Economical Driving

    Driving safety Economical driving Air conditioning Too much cooling/heating can affect the cruising range, so N00628500029 For economical driving, there are some technical requirements maintain an appropriate temperature to extend the cruising that have to be met. In order to achieve longer life of the vehi- range.

  • Page 284: Driving, Alcohol And Drugs

    Similarly, prescription and nonprescription drugs affect your floor mat from moving forward and possibly interfering with alertness, perception and reaction time. Consult with your doc- the operation of the pedals, Mitsubishi genuine floor mats are tor or pharmacist before driving while under the influence of recommended.
  • Page 285 Never install a second mat over or under an existing floor mat. Do not use a floor mat designed for another model vehicle even if it is a Mitsubishi genuine floor mat. Before driving, be sure to check the following: • Periodically check that the floor mat is properly secured with the retaining clips.

  • Page 286: Vehicle Preparation Before Driving

    Driving safety Vehicle preparation before driving N00629000698 For a safer and more enjoyable trip, always observe the follow- ing: Seat belts and seats Before starting the vehicle, make certain that you and all passengers are seated and wearing their seat belts properly (with children in the rear seat, in appropriate restraints), and that all the doors and the rear hatch are locked.

  • Page 287: Safe Driving Techniques

    Driving safety Tires Safe driving techniques Check all the tires for heavy tread wear or uneven wear pat- N00629200124 Even this vehicle’s safety equipment, and your safest driving, terns. Look for stones, nails, glass, or other objects stuck in the cannot guarantee that you can avoid an accident or injury.

  • Page 288: Driving During Cold Weather

    Driving safety Driving during cold weather Check the antifreeze. If there is not enough coolant because of a leak, add high- N00629400403 quality ethylene glycol antifreeze and water. Use Dia Check the 12V starter battery, including terminals and Queen Super Long Life Coolant Premium or an equiva- cables.

  • Page 289: Braking

    Driving safety Braking Parking N00629500518 N00629600317 All the parts of the brake system are critical to safety. Have the Parking on a hill vehicle serviced by a certified i-MiEV dealer at regular inter- When parking on a hill, set the parking brake, and turn the vals according to the “WARRANTY AND MAINTENANCE front wheels toward the curb on a downhill, or away from the MANUAL”.

  • Page 290: Loading Information

    Driving safety Parking with the electric motor unit running Loading information Never leave the electric motor unit running while you take a N00629900411 It is very important to know how much weight your vehicle can short sleep/rest. carry. This weight is called the vehicle capacity weight and WARNING includes the weight of all occupants, cargo and non-factory- installed options.
  • Page 291 Driving safety Tire and loading information placard Curb weight: the weight of a motor vehicle with standard equipment including the maximum capacity of oil, and N00630100370 The tire and loading information placard is located on the coolant. driver’s door sill. Accessory weight: the combined weight (in excess of those standard items which may be replaced) of automatic transmission, power steering, power brakes, power win-...
  • Page 292 Driving safety Steps for Determining Correct Load Limit This placard shows the maximum number of occupants permit- ted to ride in your vehicle as well as “the combined weight of N00630200081 Locate the statement “The combined weight of occu- occupants and cargo” (C), which is called the vehicle capacity pants and cargo should never exceed XXX kg or weight.
  • Page 293 Driving safety NOTE The following table shows examples on how to calculate total cargo/load capacity of your vehicle with varying seating config- urations and number and size of occupants. This table is for illustration purposes only and may not be accurate for the seating and load capacity of your vehicle.

  • Page 294: Cargo Loads

    Driving safety Cargo loads WARNING N00629700510 To reduce the risk of serious injury or death, the Cargo load precautions combined weights of the driver, passengers and To determine the cargo load capacity for your vehicle, subtract cargo and must never exceed the vehicle capacity the weight of all vehicle occupants from the vehicle capacity weight.

  • Page 295: Trailer Towing

    Driving safety Trailer towing Dinghy towing N00629800188 N00630700015 Dinghy towing is towing the vehicle with all four wheels on the ground. WARNING Do not use this vehicle for trailer towing. It may not CAUTION be possible to maintain control or adequate braking. Your vehicle is not designed to be dinghy towed behind a motor home.

  • Page 296: Comfort Controls

    Comfort controls Vents........5- Air conditioning ......5- Important air conditioning operating tips .

  • Page 297: Vents

    Comfort controls Vents Air flow and direction adjustments N00730200314 N00729900265 Center vents Adjust the direction of the air flow by moving the knob (A) and vent. 1- Center vents 2- Side vents NOTE Do not place beverages on top of the instrument panel. If 1- Left-right adjustment they splash into the air conditioning vents, they could 2- Up-down adjustment...
  • Page 298 Comfort controls Changing the mode selection Side vents When the dimple (A) is pressed, the vent opens. N00736400581 To change the position and amount of air flowing from the To close the vent, press the dimple (B) on the opposite side. vents, turn the mode selection dial.
  • Page 299 Comfort controls Foot/Face position Foot position Air flows to the upper part of the passenger compartment, and Air flows mainly to the leg area. flows to the leg area. NOTE With the mode selection dial between the “ ” and “ ”...
  • Page 300 Comfort controls Foot/Defroster position Defroster position Air flows to the leg area, the windshield and the door windows. Air flows mainly to the windshield and the door windows. NOTE With the mode selection dial between the “ ” and “ ”...

  • Page 301: Air Conditioning

    Comfort controls Air conditioning Control panel N00730500290 N00730300328 The air conditioning can only be used when the ready indicator is illuminated. NOTE If the energy level gauge is at 0 bars or the power down warning light illuminates, the vehicle interior may not be cooled/heated even though the dial or switch is operated.
  • Page 302 Comfort controls Blower speed selection dial NOTE There is an interior air temperature sensor (G) in the illus- N00736500191 When the electric motor switch is in the “ON” position, select trated position. the blower speed by turning the blower speed selection dial. Never place anything over the sensor, since doing so will Turning the dial clockwise will increase the blower speed;...
  • Page 303 Comfort controls Temperature control dial When the temperature control dial is set to “C” position, the air selection will be automatically set to the N00736600235 Use this dial to adjust the temperature of the air flow from the recirculation position and the air conditioning will oper- vents.
  • Page 304 Comfort controls “AUTO” position Air selection switch The vents change to the following positions according to the N00736800400 Normally, use the outside air position to keep the windshield position of the temperature control dial. and side windows clear and to quickly remove fog or frost Refer to “Temperature control dial”...
  • Page 305 Comfort controls If high cooling performance is desired, or, if the outside air is Air conditioning switch dusty or contaminated in some way, use the recirculation posi- N00731000465 Push the switch, and the air conditioning compressor will turn tion. Switch to the outside air position every now and then to on.
  • Page 306 Comfort controls MAX switch When the temperature control dial is set between “C” and middle ( ) position N00766500015 When the blower speed selection dial is not OFF and the MAX The air conditioning automatically operates and the cooling switch is pressed, the indicator light (A) illuminates and cool- capability is at maximum.
  • Page 307 Comfort controls Operating the air conditioning system NOTE When the blower speed selection dial is set to the N00731100251 “AUTO” position, the air flow is adjusted automatically Heating according to the temperature of the interior and the posi- 1. Set the mode selection dial to the “ ”...
  • Page 308 Comfort controls Quick heating Cooling 1. Set the mode selection dial to the “ ” position. N00731200337 2. Set the air selection switch (A) to the outside position. For ordinary cooling 3. Turn the temperature control dial clockwise or counter- clockwise to between middle ( ) position and “H”...
  • Page 309 Comfort controls For quick cooling NOTE If the outside air is dusty or contaminated in some way, set the air selection switch (A) to the recirculation position. Let in some outside air from time to time for good ventila- tion. To cool the leg areas, set the mode selection dial to the “...
  • Page 310 Comfort controls Defrosting or defogging (windshield, door windows) For ordinary defrosting Use this setting to keep the windshield and door windows clear N00731400557 of mist, and to keep the leg area heated (when driving in rain or CAUTION snow). For safety, make sure you have a clear view through all the windows.
  • Page 311 Comfort controls For quick defrosting NOTE When the mode selection dial is set to the “ ” position, the air conditioning compressor runs automatically. Out- side air introduction will also be selected automatically. When defrosting, do not set the temperature control dial to the maximum cool position.

  • Page 312: Important Air Conditioning Operating Tips

    Comfort controls Important air conditioning operating tips CAUTION N00733700323 The air conditioning system in your vehicle must be 1. Park the vehicle in the shade whenever possible. Parking charged with the refrigerant HFC-134a and the in the hot sun makes the vehicle interior extremely hot lubricant POE MA68EV.

  • Page 313: Air Purifier

    Comfort controls Air purifier AM/FM electronically tuned radio with CD player N00733800177 (if so equipped) The air conditioning system is equipped with an air filter to N00734301062 reduce pollen and dust entering the cabin. The audio system can only be used when the electric motor The air filter’s ability to collect pollen and dust will be reduced switch is in the “ON”...
  • Page 314 Comfort controls Volume and tone control panel To adjust the volume N00711900716 N00712000408 Turn the VOLUME knob clockwise to increase the volume; counterclockwise to decrease the volume. The status will be displayed in the display. 1- VOLUME (Volume control) knob 2- SEEK (Audio adjust) button 3- Display NOTE...
  • Page 315 Comfort controls To adjust the tone SEEK button operation Adjust Adjust N00712100669 Mode Level 1. Press the button repeatedly to select the tone, balance and SCV (Speed Compensated Volume) function control BASS Stronger Weaker to change. The order is: BASS → TREBLE → FADER → -6 to 6 BALANCE →...
  • Page 316 Comfort controls Radio control panel and display NOTE In a four-speaker vehicle, keep the FADER setting in the N00734900902 middle position. Since no rear speakers are connected, adjusting the FADER setting toward the “R” side will result in a loss of sound output. SCV (Speed Compensated Volume) function Speed Compensated Volume function is a feature that automat- ically adjusts the VOLUME, BASS and TREBLE settings in...
  • Page 317 Comfort controls To listen to the radio To store a frequency in the memory, follow these steps: 1. Press the SEEK button to tune to the frequency you wish N00735000913 1. Press the POWER button until it beeps to turn the audio to keep in the memory.
  • Page 318 Comfort controls CD control panel and display 15- DISP (Title display) button 16- MENU button N00735300743 17- SCAN button 18- SEEK (Up-seek) button/ (Return) button 19- SEEK (Down-seek) button/ (Select) button 1- Disc loading slot 2- Eject button 3- CD (CD mode changeover) button 4- TRACK (Fast-forward/Track up) button 5- TRACK...
  • Page 319 Comfort controls To listen to a CD To listen to a music CD N00735501074 To set a disc 1. Press the POWER button until it beeps to turn the audio system ON and OFF. The system turns on in the last mode used.
  • Page 320 Comfort controls To listen to an MP3 CD NOTE While listening to a disc on which CD-DA (CD-Digital This CD player allows you to play MP3 (MPEG Audio Layer- 3) files recorded on CD-ROMs, CD-Rs (recordable CDs), and Audio) and MP3 files have both been recorded, you can switch between reading of the CD-DA, reading of the CD-RWs (rewritable CDs) in ISO9660 Level 1/Level 2, Joliet, MP3 files, and the external audio input mode by pressing...
  • Page 321 Comfort controls Folder selection order/MP3 file playback order (Example) To fast forward/reverse the disc To fast forward or fast reverse the disc, press the TRACK button or the TRACK button. Root folder (Root directory) Fast forward You can fast-forward the disc by pressing the TRACK but- ton.
  • Page 322 Comfort controls To find a file (MP3 CDs only) To select the playing mode Operate the following buttons or the SELECT knob to select N00771500013 1. Press the MENU button until beeps. desired file. 2. Press the SEEK button repeatedly to select the When this mode is activated by pressing the button, the mode.
  • Page 323 Comfort controls To play tracks in repeat To play tracks in random order N00771600014 N00771800016 Repeat an all track (normal playback) Random playback for a disc (music CDs only) Select the ALL REPEAT mode. Refer to “To select the playing Select the RANDOM mode.
  • Page 324 Comfort controls To find the start of each track on a disc for playback CD text and MP3 title display N00771900017 N00752100166 Press the SCAN button. “SCAN” will appear on the display This audio system can display CD text and MP3 titles includ- and the CD player will play back the first 10 seconds of each ing ID3 tag information.

  • Page 325: To Play Ipod/Usb Memory Device Tracks Via Voice Operation (Vehicles With Bluetooth Interface)

    Comfort controls To play iPod/USB memory device tracks via ID3 tag information The audio system can display ID3 tag information for files that ® voice operation (vehicles with Bluetooth have been recorded with ID3 tag information. 2.0 interface) 1. Press the DISP button for 2 seconds or longer to switch to the ID3 tag information.
  • Page 326 Comfort controls To search by artist name 5. If there are two or more matches, the voice guide will say “More than one match was found, would you like to play N00772200017 1. Say “Play” on the main menu. <artist name>?” If you say “Yes,” the system proceeds to step 6.
  • Page 327 Comfort controls To search by album title 6. After the voice guide says “Playing <album title>,” the system creates a playlist index for the album title. N00772300018 1. Say “Play” on the main menu. NOTE NOTE If the confirmation function is active, the voice guide con- ®...
  • Page 328 Comfort controls To search by genre 3. After the voice guide says “What Playlist would you like to play?,” say the playlist name. N00772500010 1. Say “Play” on the main menu. 4. If there is only one match, the system proceeds to step 6. 5.

  • Page 329: Steering Wheel Audio Remote Control Switch (If So Equipped)

    Comfort controls Steering wheel audio remote control switch 6. After the voice guide says “Playing <genre>,” the system creates an index for the genre. (if so equipped) N00714800471 NOTE The remote control switch is located on the left side of the If the confirmation function is active, the voice guide con- steering wheel.

  • Page 330: Volume Control

    Comfort controls To turn on the power To listen to a CD Press the power switch to turn on the power. When the power is Press the mode selector button and select CD mode. turned on, the last mode used before turning off is displayed. To fast forward/reverse the disc (music CDs only) To turn off the power, press and hold down the power switch To fast forward or fast reverse the disc, press the fast-forward...
  • Page 331 Comfort controls To listen to a USB memory device To select a desired track You can select your desired track by using the track up button Press the mode selector button and select USB mode. or the track down button. To select a desired file NOTE File up button...

  • Page 332: Error Codes

    Comfort controls Error codes N00736100777 If an error code appears in the display, take action in accordance with the table below. Error display Problem Item Repair NO DISC No disc inserted Disc is not in CD player. Insert disc. Disc is not loaded correctly, or condensation Insert disc with label facing up.

  • Page 333: Handling Of Compact Discs

    Comfort controls Handling of compact discs N00734100340 Use only the type of compact discs that have the mark shown in the illustration below. (Playback of CD-R or CD-RW discs may cause problems.) The use of special shaped, damaged compact discs (like cracked discs) or low-quality compact discs (like warped discs or burrs on the discs) such as those shown will dam- age the CD player.
  • Page 334 Comfort controls In the following circumstances, moisture can form on Do not put additional labels or stickers on compact discs. compact discs and inside the audio system, preventing Also, do not use any compact disc on which a label or normal operation.

  • Page 335: Antenna

    Comfort controls Notes on CD-Rs/RWs Antenna N00751900112 N00734200471 You may have trouble playing back some CD-R/RW discs To remove recorded on CD recorders (CD-R/RW drives), either due Turn the pole (A) counterclockwise. to their recording characteristics or dirt, fingerprints, scratches, etc. on the disc surface. To install CD-R/RW discs are less resistant to high temperatures and Screw the pole (A) clockwise into the base (B) until it is...

  • Page 336: Clock (If So Equipped)

    Comfort controls Clock 3. When the “hours” digit is adjusted, press the clock button (if so equipped) to flash the “minutes” digit. N00755000124 The time is displayed when the electric motor switch is in the Press the SEEK button to adjust the “minutes” digit. “ON”...

  • Page 337: General Information About Your Radio

    Comfort controls General information about your radio Signal transmission FM signals do not follow the earth surface nor are they N00733900439 Your vehicle’s radio receives both AM and FM stations. reflected by the upper atmosphere. For this reason, FM broad- The quality of your reception is affected by distance, obstacles, casts cannot be received over long distances.
  • Page 338 Comfort controls Reflection Cross modulation The reason why one can hear FM but not AM in parking If one listens to a weak station and is in the vicinity of another garages, under bridges etc., is that FM signals, unlike AM sig- strong station, both stations might be received simultaneously.
  • Page 339 Comfort controls Causes of disturbances FM reception is affected by the electrical systems of vehicles in the vicinity, especially those without an electronic noise sup- pression device. The disturbance is even greater if the station is weak or poorly tuned. FM reception is not as sensitive to electrical disturbances as AM.

  • Page 340: For Emergencies

    For emergencies If the vehicle breaks down ....6- Jump-starting ......6- Tire repair kit .

  • Page 341: If The Vehicle Breaks Down

    For emergencies If the vehicle breaks down Jump-starting N00836300220 N00836400739 If your vehicle breaks down on the road, move to the shoulder If the electric motor unit cannot be energized because the 12V and turn on the hazard warning flashers. If there is no shoulder, starter battery is weak or dead, you can start it with the battery or the shoulder is not safe, drive in the right lane slowly, with from another vehicle using jumper cables.
  • Page 342 For emergencies 2. Position the vehicles close enough together so that the 6. Remove the battery cover, and then make sure your 12V jumper cables can reach, but be sure the vehicles are not starter battery electrolyte is at the proper level. (Refer to touching each other.
  • Page 343 For emergencies 8. Connect one end of the other jumper cable to the nega- WARNING tive (-) terminal of the booster battery (B), and then con- Make sure that the jumper cables and your clothing nect the other end to the designated ground location of are clear of the cooling fans and drive belts.
  • Page 344 For emergencies 10. Check if the ready indicator illuminates. 13. When the charging indicator on the instrument cluster is illuminated, stop the engine of the other vehicle and dis- [When the ready indicator illuminates] connect the jumper cables in the reverse order. Stop the engine of the other vehicle, and disconnect the cables in the reverse order and keep the electric motor switch in the ON position to charge the 12V starter battery...
  • Page 345 For emergencies Charging the 12V starter battery by using an 16. Turn the electric motor switch to the “START” position, make sure that the ready indicator on the instrument clus- external battery charger ter is illuminated. If the ready indicator does not illuminate, perform the pro- WARNING cedure again starting from step 5.

  • Page 346: Tire Repair Kit

    The vehicle must promptly be inspected and repaired by a certified i-MiEV dealer after using the tire repair kit. Use only the Mitsubishi genuine tire repair kit. Seal- ant in other repair kits may not sufficiently seal the tire puncture.
  • Page 347 For emergencies Tire repair kit storage 6- Valve insert (spare) 7- Valve remover N00837700016 The tire repair kit is stowed under the rear seat cushion. 8- Speed restriction sticker 9- Instruction manual for tire repair To remove N00837800017 1. Pull forward the seat stoppers (A) under the rear seat cushion (B).
  • Page 348 For emergencies To store 3. Remove the screws (A), and remove the cover (B). N00837900018 1. Return the tire repair kit to its original place. Attach the cover and fasten the screws. 2. Insert two wire tabs at the rear edge of the seat cushion under the seat back.
  • Page 349 For emergencies How to use the tire repair kit N00800200026 WARNING Never use the tire repair kit under in any of the situ- ations listed below. The tire cannot be repaired by the tire repair kit. If any of these situations occurs, please contact a certified i-MiEV dealer.
  • Page 350 For emergencies 6. Shake the tire sealant bottle well. CAUTION If the vehicle body is contaminated by the tire seal- ant, wipe the tire sealant off immediately with a wet cloth. Immediately wash clothes contaminated with tire sealant. NOTE Do not pull out an object, such as a nail or screw, that pen- etrates the punctured tire.
  • Page 351 For emergencies 7. Take the cap (C) off the tire sealant bottle (D). Do not 8. Take the valve cap (G) off the tire valve (H), then press remove the seal (E). Screw the filler hose (F) onto the bot- the valve remover (I) onto the valve as illustrated.
  • Page 352 For emergencies 9. Remove the valve insert (J) by turning it counterclockwise 10. Remove the plug (K) from the free end of the hose (L). using the valve remover (I). Put the removed valve insert Press the hose onto the valve (H). in a clean place so it does not get dirty.
  • Page 353 For emergencies 11. Holding the sealant bottle upside-down, squeeze it again 12. After injecting the sealant, pull the hose off the valve, and again to inject all of the sealant into the tire. remove any residual sealant from the valve, rim and/or tire.
  • Page 354 For emergencies 13. Pull out the compressor hose (M) from the side of the tire 14. Place the compressor (N) with its air pressure gauge (O) compressor, and then securely attach the hose to the tire on top. valve (H). Pull out the compressor’s power cord (P), insert the plug on the cord into the 12 V power outlet (Q), and then turn the electric motor switch to the “ACC”...
  • Page 355 For emergencies 15. Check and adjust the tire pressure with reference to the air WARNING pressure gauge on the compressor. If you overinflate the Do not place your hand or fingers between the tire tire, release air by loosening the hose’s end fitting. (Refer and wheel while inflating the tire.
  • Page 356 For emergencies 16. Turn OFF the compressor switch, then pull the power cord 17. Affix the speed restriction sticker (R) to the three-dia- plug out of the 12 V power outlet. mond mark on the steering wheel. Then immediately drive with great care to a certified i-MiEV dealer and have NOTE tire repair/replacement performed.
  • Page 357 For emergencies 18. When you have inflated the tire to the specified pressure, 19. After driving for 10 minutes or 3 miles (5 km), park the stow the compressor, bottle, and other items in the vehicle vehicle in safe place. Remove the air compressor from the and make sure that the seat cushion is properly secured.

  • Page 358: Towing

    For emergencies Towing 20. After driving for 10 minutes or 3 miles (5 km) again, check the tire pressure using the air pressure gauge on the N00837000859 compressor. (Refer to “Tire inflation pressures” on page If your vehicle needs to be towed 7-21.) If the tire pressure has apparently not dropped, the If you need to tow your vehicle, contact a certified i-MiEV emergency repair procedure is complete.
  • Page 359 For emergencies WARNING CAUTION Never tow the vehicle with rear wheels (drive Never tow the vehicle using a sling type truck. wheels) on the ground. This may cause damage to Doing so will damage the bumper and/or body. the electric motors. Also this may cause a fire, if wir- ing in the electric motor unit room becomes dam- aged.
  • Page 360 For emergencies If a wheel gets stuck in a ditch, do not try to tow the vehicle. Place the selector lever in the “N” (NEUTRAL) position. Turn Please contact a certified i-MiEV dealer or a commercial tow the electric motor switch to the “ACC” position and secure the truck service for assistance.

  • Page 361: Operation Under Adverse Driving Conditions

    For emergencies Operation under adverse driving conditions On wet roads N00837200747 CAUTION If your vehicle becomes stuck in sand, mud or snow Do not drive on a flooded road. If you drive on a flooded road, not only the electric motor unit stops If your vehicle becomes stuck in snow, sand, or mud, it can but also a failure like electric leakage or short circuit often be moved by a rocking motion.
  • Page 362 For emergencies On snowy or icy roads On a bumpy or rutted road When driving on a road covered with snow or ice, use Drive as slow as possible when driving on bumpy or rut- snow tires. Tire chains cannot be used on your vehicle. ted roads or over potholes etc.

  • Page 364: Vehicle Care And Maintenance

    Vehicle care and maintenance Service precautions ......7- Hood........7- View under the hood and electric motor unit room .

  • Page 365: Service Precautions

    Vehicle care and maintenance Service precautions High voltage components and wiring cables are located as shown in the figure below. N00937300361 Taking regular care of your vehicle helps preserve its value and appearance as long as possible. This vehicle is an electric vehicle and is equipped with many high-voltage components.
  • Page 366 Ask a certified i-MiEV dealer if you have questions. Have you purchased the Mitsubishi Motors Diamond Care Pro- tection Plan? The Plan supplements your new vehicle warran- ties. See a certified i-MiEV dealer for details.

  • Page 367: Hood

    Vehicle care and maintenance Hood Release the safety lever (A) and lift the hood. N00937500549 To open Use the hood release lever (located under the instrument panel near the passenger’s door) to unlock the hood. Pull the lever toward you to release the hood latch. NOTE To prevent damage to the hood and wipers, make sure the wipers are at resting position when you open the hood.
  • Page 368 Vehicle care and maintenance To close Support the hood by inserting the support prop (B) into its slot on the underside of the hood arm. Make sure the hood is securely locked by softly lifting the cen- tre of the hood. CAUTION Slowly lower the hood about 12 inches (30 cm), then let it drop Always insert the support prop into the hole spe-...

  • Page 369: View Under The Hood And Electric Motor Unit Room

    Vehicle care and maintenance View under the hood and electric motor unit NOTE If this does not close the hood properly, drop it again from room a slightly higher position. N00937600696 Do not push down strongly on the hood. Depending on how strongly or where you push down, you could create a Under the hood dent in the hood.

  • Page 370: Coolant/Hot Water Heater Fluid

    Vehicle care and maintenance Coolant/Hot water heater fluid Electric motor unit room N00937800539 To check the coolant level WARNING Before checking the coolant level, make sure the electric motor switch is in the “Lock” position to avoid the risk of an electrical shock that can result in serious injury or death.
  • Page 371 Vehicle care and maintenance 2. Peel off the Velcro fastener (A) to remove the luggage 3. Turn the 4 screws on the front and rear of the electric room floor carpet (B). motor unit room lid (C) counterclockwise to loosen and remove them, and then remove the electric motor unit room lid (C).
  • Page 372 Vehicle care and maintenance Hot water heater fluid 4. Check the coolant level in the reservoir (D). While the motor is cold, the coolant level must always be The reservoir (A) is located under the hood. The coolant level in this reservoir should be kept between the between the “F (FULL)”...
  • Page 373 Take your vehicle to a certified i- the room under the hood damage. Only use a Genuine MiEV dealer for testing. Mitsubishi Parts reservoir cap, or an approved equivalent. CAUTION WARNING Do not use alcohol or methanol antifreeze or any Wait for the electric motor to cool down before coolants that contain them.

  • Page 374: Washer Fluid

    Vehicle care and maintenance Points to remember Washer fluid N00955700019 N00938600303 Do not overfill the reservoir. The windshield washer fluid reservoir is under the hood. Your vehicle uses a special reservoir cap that stays sealed Check the washer fluid level at regular intervals and add and keeps the pressure in the reservoir below the allow- washer fluid to reservoir if necessary.

  • Page 375: Brake Fluid

    Vehicle care and maintenance Brake fluid Fluid type Use the recommended brake fluid conforming to DOT 3 or N00938700261 DOT 4. The reservoir cap must be tightly sealed to keep dirt To check the fluid level and water out. The brake fluid level must be between the “MAX” and “MIN” marks on the reservoir.

  • Page 376: 12V Starter Battery

    Vehicle care and maintenance 12V starter battery To install 1. Install the 12V starter battery upper cover (B) onto the N00939100914 The condition of the 12V starter battery is very important to 12V starter battery, and then push the plastic nut (A) in the keep the vehicle’s electrical system working properly.
  • Page 377 Vehicle care and maintenance CAUTION Be sure to install the 12V starter battery upper cover. Otherwise, the battery electrolyte may spill and cause a malfunction. When installing the 12V starter battery upper cover and plastic nut do not touch the cooling fan or other moving parts under the hood.
  • Page 378 Vehicle care and maintenance During cold weather WARNING N00901600057 Electrolyte (battery acid) is made of corrosive The 12V starter battery is weaker in cold temperatures. This diluted sulfuric acid. If it spills on nearby parts, it has to do with its chemical and physical properties and is why a can crack, stain, or discolor them.
  • Page 379 Vehicle care and maintenance Disconnection and connection Loosen the nut (B), and then disconnect the 12V starter battery cable from the positive (+) terminal. N00901700058 To disconnect the 12V starter battery cable, stop the electric motor. Disconnect the negative (-) terminal first, then the posi- tive (+) terminal.
  • Page 380 Vehicle care and maintenance NOTE WARNING Before cleaning the 12V starter battery, tighten all the Open doors and windows in any closed space where filler port caps to keep dirt and moisture out. you may be charging or working with the 12V Check each 12V starter battery terminal for corrosion.

  • Page 381: Tires

    Vehicle care and maintenance Tires Intended outboard sidewall: • The sidewall that contains a whitewall, bears white let- N00939200540 tering or bears manufacturer, brand, and/or model name WARNING molding that is higher or deeper than the same molding on the other sidewall of the tire, Driving with tires that are worn, damaged or improperly inflated is dangerous.

  • Page 382: Tire Markings

    Vehicle care and maintenance Cord: the strands forming the plies in the tire. Size Designation Rim: a metal support for a tire or a tire and tube assembly upon which the tire beads are seated. EXAMPLE:P215/65R15 Rim diameter: nominal diameter of the bead seat. Passenger car tire size based on U.S.A.
  • Page 383 Vehicle care and maintenance Service Description Maximum Pressure Maximum Pressure indicates the maximum permissible cold tire inflation pressure for this tire. EXAMPLE: 95H Load index Tire Identification Number (TIN) A numerical code associated with the maxi- The TIN may be found on one or both sides of the tire but mum load a tire can carry.

  • Page 384: Tire Inflation Pressures

    Vehicle care and maintenance Tire inflation pressures Treadwear, Traction and Temperature Grades N00939300860 Treadwear Proper tire inflation pressure is essential for the safe and satis- The treadwear grade is a comparative rating based on the wear factory operation of your vehicle. The wrong tire pressure will rate of the tire when tested under controlled conditions on a cause problems in three major areas: specified government test course.
  • Page 385 Vehicle care and maintenance The recommended inflation pressures should be used for the After filling your tires to the correct pressure, check them tires listed below. for damage and air leaks. Be sure to reinstall the caps on the valve stems. Tire size Front Rear...

  • Page 386: Tread Wear Indicators

    Consult a certified i-MiEV dealer before using wheels that you have. Only Mitsubishi Motors genuine wheels should be used, because your vehicle is equipped with a tire pressure monitoring system.

  • Page 387: Tire Rotation

    If flange nuts are used on your vehicle, change to tapered nuts when using snow tires with steel wheels. Only Mitsubishi Motors genuine wheels should be used, because your vehicle is equipped with a tire pressure monitoring system. Use of another type of wheel risks air leaks and sensor damage, as it will not be possible to install the tire pressure sensor properly.

  • Page 388: Brake Pedal Free Play

    Vehicle care and maintenance Brake pedal free play Parking brake lever stroke N00940300310 N00940400236 To check the brake pedal free play (A), turn off the electric Check the parking brake lever travel occasionally. To check motor unit and press the brake pedal several times with your this, pull the lever up slowly and count the number of clicks of foot.

  • Page 389: Wiper Blades

    Vehicle care and maintenance Wiper blades When removing snow and frost, be careful not to damage the washer nozzle which are attached to the wiper arm. N00940700200 Check the wiper blades occasionally. Clean them regularly to remove deposits of salt and road film. Use a sponge or cloth and a mild detergent or non-abrasive cleaner to clean the blades and glass areas.

  • Page 390: General Maintenance

    N00941500289 The next pages list the maintenance service recommended by N00941800077 Mitsubishi Motors Corporation. In addition to the general Check the following parts for damage and grease leaks: maintenance that needs to be performed at the times listed, Ball joint boots of the front suspension and steering link- there are other parts which do not usually need regular mainte- nance.

  • Page 391: For Cold And Snowy Weather

    Vehicle care and maintenance For cold and snowy weather Fusible links N00942600131 N00942700321 The fusible links will melt to prevent a fire if a large current Ventilation slots attempts to flow through certain electrical systems. The ventilation slots in front of the windshield should be In case of a melted fusible link, see a certified i-MiEV dealer brushed clear after a heavy snowfall so that the operation of the for inspection and replacement.

  • Page 392: Fuses

    Vehicle care and maintenance Fuses Passenger compartment The fuse block in the passenger compartment is located in front N00942800885 of the driver’s seat at the position shown in the illustration. Press the tab (A) and remove the fuse cover (B). Fuse block location N00901000107 To prevent damage to the electrical system from short-circuit-...
  • Page 393 Vehicle care and maintenance Fuse load capacities Under the hood Under the hood, the fuse block is located as shown in the illus- N00954800215 This fuse list shows the names of the electrical systems and tration. their fuse capacities. Press the tab (A) and remove the cover. Always replace a blown fuse with one of the same capacity as the original.
  • Page 394 Vehicle care and maintenance Symbol Electrical system Capacity Symbol Electrical system Capacity Heated door outside rearview Tail light (left) 7.5 A 7.5 A mirrors Cigarette lighter/ 15 A Windshield wiper 20 A 12 V power outlet Back-up lights 7.5 A —...
  • Page 395 Vehicle care and maintenance Under the hood fuse location table Symbol Electrical system Capacity Water pump 15 A (Electric motor unit) Charge 10 A Hazard warning flasher 10 A Horn 10 A Daytime running lights 10 A Main drive lithium-ion bat- 15 A tery fan motor Water pump...

  • Page 396: Fuse Replacement

    Vehicle care and maintenance Fuse replacement Identification of fuse N00901100078 N00954900115 1. Before replacing a fuse, always turn off the electrical item Capacity Color connected to the fuse and turn the electric motor switch to the “LOCK” position. 7.5 A Brown 2.
  • Page 397 Vehicle care and maintenance 3. Clamp it on the fuse you wish to remove, and pull the fuse 4. Use the fuse location diagrams and their corresponding straight out from the fuse block. tables, to check the fuse that is related to the problem. If the fuse is not blown, something else must be causing the problem.

  • Page 398: Replacement Of Light Bulbs

    Vehicle care and maintenance Replacement of light bulbs CAUTION N00942900336 Never use a fuse with a capacity greater than the one Before replacing a bulb, be sure the light is off. Do not touch listed or any substitute, such as wire, foil etc. This the glass part of the new bulb with your bare fingers;...
  • Page 399 Vehicle care and maintenance Bulb capacity ANSI Trade N00943000099 Description Wattage No. or Bulb The bulb should only be replaced with a new bulb with the type same rating and type. The type and rating are listed on the base 4- Daytime running light of the bulb.
  • Page 400 Vehicle care and maintenance Inside Rear N00950400604 ANSI Trade Description Wattage No. or Bulb type Description Wattage 8- High-mounted stop 1- Dome light (Rear) light 2- Dome light (Front)/Read- ing lights 9- Tail and stop light — — 10- Rear turn signal light 21 W WY21W Adjustment of headlight aim...
  • Page 401 Vehicle care and maintenance Front side-marker lights 2. Remove the socket and bulb assembly together by turning it counterclockwise. N00915500161 1. Insert a flat blade screwdriver into the end of the light nearer the rear of the body and pry gently to remove the light.
  • Page 402 Vehicle care and maintenance 3. Pull the bulb out of the socket. 4. To install the bulb, perform the removal steps in reverse. NOTE When installing the light assembly, push in the end facing the front of the vehicle first. *: Front of the vehicle 7-39...
  • Page 403 Vehicle care and maintenance Front turn signal lights/Front fog lights (if so 3. Turn the socket counterclockwise to remove it. equipped)/Daytime running lights (if so equipped) N00943400312 1. To create enough work space, turn the steering wheel all the way in the same direction to the side you wish to replace.
  • Page 404 Vehicle care and maintenance 4. Remove the bulb as follows. 5. To install the bulb, perform the removal steps in reverse. [Front turn signal light] CAUTION Pull the bulb out of the socket. [Front fog light and daytime running light] Handle halogen light bulb with care.

  • Page 405: Rear Combination Lights

    Vehicle care and maintenance Rear combination lights 3. Move the light unit toward the rear of the vehicle and remove the pins (B) of the light unit from the vehicle. N00943700487 1. Open the liftgate. (Refer to “Liftgate” on page 3-16.) 2.
  • Page 406 Vehicle care and maintenance 4. Turn the socket counterclockwise to remove it. 5. Pull the bulb out of the socket. 6. To install the bulb, perform the removal steps in reverse. C- Tail and stop light (LED) - cannot be replaced D- Rear turn signal light E- Back up light NOTE...
  • Page 407 Vehicle care and maintenance Rear side-marker lights 2. Turn the socket (C) counterclockwise to remove it. N00935400108 1. Remove the clips (A), then lift the cover (B). 3. Pull the bulb out of the socket. 7-44...
  • Page 408 Vehicle care and maintenance High-mounted stop light 4. To install the bulb, perform the removal steps in reverse. N00943900115 1. Remove the mounting screws (A) and remove the light unit. 7-45...
  • Page 409 Vehicle care and maintenance 2. While holding down the tab (B), pull out the connector. 3. Remove the screws (C) and then remove the bulb holder (D). 7-46...

  • Page 410: License Plate Lights

    Vehicle care and maintenance License plate lights 4. Pull the bulb out of the socket. N00944000399 1. When removing the light unit (A), push it toward the left side of the vehicle body. 5. To install the bulb, perform the removal steps in reverse. 7-47...
  • Page 411 Vehicle care and maintenance 2. Use a flat blade screwdriver into the tab (B) and pry gen- 3. Pull the bulb out of the socket. tly to remove the lens. 7-48...

  • Page 412: Vehicle Care Precautions

    Vehicle care and maintenance Vehicle care precautions 4. To install the bulb, perform the removal steps in reverse. N00945100195 NOTE In order to maintain the value of your vehicle, perform regular When installing the light, insert tab (C) first then align and maintenance using the proper materials and procedures.

  • Page 413: Cleaning The Inside Of Your Vehicle

    Vehicle care and maintenance Cleaning the inside of your vehicle These can all be dangerous, and they all can damage your vehi- cle. N00945200079 After washing the inside of your vehicle with any cleaner, wipe it dry in a shady, well ventilated area. CAUTION Do not use organic substances (solvents, benzine, kerosene, alcohol, gasoline, etc.) or alkaline or acidic...
  • Page 414 Vehicle care and maintenance NOTE 2. To rinse, dip the cloth in fresh water, wring it out well, and Do not use cleaners, conditioners, and protectants contain- wipe off all the soap. ing silicones or wax. 3. To preserve and protect, use a leather protecting agent on Such products, when applied to the instrument panels or the genuine leather surface.

  • Page 415: Cleaning The Outside Of Your Vehicle

    Vehicle care and maintenance Cleaning the outside of your vehicle WARNING N00945700061 To protect your vehicle’s finish, wash it often and thoroughly. Do not wash the vehicle while charging the main drive lithium-ion battery. If desired, you may wax your vehicle using a nonabrasive auto- Doing so could cause a fire or an electric shock.
  • Page 416 Vehicle care and maintenance After washing your vehicle, wipe off all waterdrops from the CAUTION rubber parts around the doors to prevent the doors from freez- Avoid automatic car washers that use rotating ing. brushes. These brushes may scratch the paint sur- NOTE face and make it dull.
  • Page 417 Vehicle care and maintenance Damaged paint CAUTION N00946200089 Do not put wax on the areas having black matte Small cracks and scratches in the paint coat should be touched coating because it can cause uneven discoloration, up as soon as possible with touch-up paint to prevent corrosion. patches, blurs, etc.

  • Page 418: Chrome Parts

    Vehicle care and maintenance Cleaning plastic parts Aluminum wheels (if so equipped) N00946300211 N00946500196 Use a sponge or chamois to clean these parts. 1. Remove dirt using a wet sponge. If a vehicle wax sticks to a gray or black rough surface of the 2.

  • Page 419: Under The Hood

    Vehicle care and maintenance Wiper blades N00946700097 Use a soft cloth and glass cleaner to remove grease, dead insects, etc., from the wiper blades. Replace the wiper blades when they no longer clean the windshield and rear window properly. Under the hood N00947000127 Never spray or splash water on the electrical components under the hood, as this may cause damage.

  • Page 420: Customer Assistance/ Reporting Safety Defects

    Customer assistance/Reporting Safety Defects Consumer information (For vehicles sold in U.S.A.) ....8- Reporting Safety Defects ....8- Important facts to know in case of an accident .

  • Page 421: Uniform Tire Quality Grading

    Customer assistance/Reporting Safety Defects Consumer information (For vehicles sold in WARNING U.S.A.) The traction grade assigned to this tire is based on N01047100171 straight-ahead braking traction tests, and does not This information is provided in compliance with the require- include acceleration, cornering, hydroplaning, or ments of the National Highway Traffic Safety Administration, peak traction characteristics.
  • Page 422 Tower C 1200 New Jersey Avenue, SE Ottawa, Ontario K1A 0N5 West Building To contact Mitsubishi Motor Sales of Canada, Inc. call 1- Washington, DC 20590 888-576-4878 or write to: You can also obtain other information about motor vehi- Mitsubishi Motor Sales of Canada, Inc.

  • Page 423: Specifications

    Key information to discuss with your insurance a choice. So, if you want genuine Mitsubishi Motors parts, you may have to specifically request them. Make certain your company insurance company understands imitations are not to be used in Understand your repair estimate before approving repairs.
  • Page 424 Specifications Vehicle labeling ......9- Vehicle dimensions ......9- Vehicle weights .

  • Page 425: Vehicle Labeling

    Specifications Vehicle labeling N01147400683 Keep a record of the chassis number and vehicle identification number. Such information will assist the police if your vehicle is stolen. 2 - Vehicle identification number plate The vehicle identification number is stamped in the location shown in the illustration.
  • Page 426 Specifications Chassis number The chassis number is stamped behind the lid on the right side of the luggage room. 4 - Vehicle information code plate The vehicle information code plate is located on the driver’s door sill.
  • Page 427 Specifications Electric motor number Tire and loading information placard The electric motor number is stamped on the cylinder block as N01148100599 The tire and loading information placard is located on the shown in the illustration. driver’s door sill. *- Front of the vehicle...

  • Page 428: Certification Label

    Specifications Certification label N01148200239 The certification label is located on the driver’s door sill.

  • Page 429: Vehicle Dimensions

    Specifications Vehicle dimensions Vehicle weights N01147500538 N01147600861 Overall length 144.8 in (3,675 mm) Gross vehicle weight rating 3,329 lb (1,510 kg) (GVWR) Overall width 62.4 in (1,585 mm) Front 1,488 lb (675 kg) Gross axle weight rating Overall height 63.6 in (1,615 mm) (GAWR) Rear 1,962 lb (890 kg)

  • Page 430: Charging System Specifications

    Specifications Charging system specifications N01148500014 Rated input voltage AC 240V (single phase) AC 120V (single phase) Rated input frequency 50 Hz/60 Hz Maximum rated current 15 A 8 A* Maximum power consumption 3.3 kW 1.0 kW* UL2594: Electric Vehicle Supply Equipment UL62: Flexible Cords and Cable UL2251: Plugs, Receptacles and Couplers for Electric Vehicle SAE J1772: (R) SAE Electric Vehicle and Plug in Hybrid Electric...

  • Page 431: Electric Motor Specifications

    Specifications Electric motor specifications 12V starter battery N01147300015 N01147800270 Electric motor model Y4F1 34B19L(S) Maximum output 49 kW Battery is a 12 volt type. Maximum torque 196 N•m...

  • Page 432: Tires And Wheels

    Specifications Tires and wheels N01147900734 Item Front Rear Tire 145/65R15 72H 175/60R15 81H Size 15x4J 15x5J Wheel 3.93 in (100 mm) Offset 1.37 in (35 mm) PCD: Pitch Circle Diameter (installation holes) NOTE Contact a certified i-MiEV dealer for details on the combination used on your vehicle. These tires satisfy vehicle loading conditions described in this owner’s manual.

  • Page 433: Refill Capacities

    Specifications Refill capacities N01148000989 Item Capacity Lubricants Windshield washer fluid 2.0 qt (1.9 L) — Brake As required Conforming to Brake fluid DOT 3 or DOT 4 Hot water heater fluid 2.0 qt (1.9 L) [Includes .42 qt (0.4 L) in reservoir] Dia Queen Super Long Life Coolant Premium or an equivalent* Coolant 5.4 qt (5.1 L)
  • Page 434 Alphabetical index Accessory (installation) 1-7 Back up lights Acoustic vehicle alerting system (AVAS) 3-38 Bulb capacity 7-36 Active stability control 3-46 Replacement 7-42 ASC indicator 3-48 Ball joint, steering linkage seals and drive shaft boots 7-27 ASC OFF indicator 3-48 Battery ASC OFF switch 3-47 Disconnection and connection 7-16...
  • Page 435 Alphabetical index California Perchlorate Materials Requirements 1-9 Dash lights brightness indicator 3-61 3-66 Capacities 9-10 Daytime running lights Card holder 3-123 3-129 Bulb capacity 7-36 Cargo loads 4-13 Replacement 7-40 Certification label 9-5 Defogger (rear window) 3-89 Charging Dimensions 9-6 Quick charging 1-33 Dimmer (high/low beam change) 3-81 Regular charging 1-20...
  • Page 436 Alphabetical index Specifications 9-8 Replacement 7-40 Electric motor switch 3-30 Fuses 7-29 Electric motor unit warning light 3-75 Fusible links 7-28 Electric power steering system (EPS) 3-44 Electric rear window defogger switch 3-89 Electronic immobilizer (Anti-theft starting system) 3-3 Gauges 3-58 Energy level gauge 3-69 General maintenance 7-27 Energy usage indicator 3-60...
  • Page 437 Alphabetical index Hood lock release mechanism and safety catch 7-27 Horn switch 3-90 Hot water heater fluid 7-7 9-10 Labeling 9-2 License plate lights Bulb capacity 7-36 If the vehicle breaks down 6-2 Replacement 7-47 i-MiEV 1-2 Liftgate 3-16 Cruising range 1-5 Link System 3-90 Main drive lithium-ion battery 1-4 Loading information 4-9...
  • Page 438 Alphabetical index Rear turn signal lights Bulb capacity 7-36 Replacement 7-42 Parking 4-8 Rear window defogger switch 3-89 Parking brake 3-25 Rear-view camera 3-55 Parking brake lever stroke 7-25 Rearview mirror Parking lights Inside 3-26 Bulb capacity 7-36 Outside 3-28 Polishing 7-54 Refill capacities 9-10 Power brakes 3-39...
  • Page 439 Alphabetical index Force limiter 2-23 Theft-alarm system 3-18 Front passenger seat belt warning light 2-18 Tire Maintenance and inspection 2-34 Quality grading 8-2 Pre-tensioner 2-21 Tire pressure monitoring system 3-49 Seat belt extender 2-20 Tire repair kit 6-7 Seat belt instructions 2-14 Tires 7-18 Seat belt use during pregnancy 2-21 Inflation pressure 7-21...
  • Page 440 Alphabetical index How to connect a USB memory device 3-117 Numerics How to connect an iPod 3-119 12V power outlet 3-123 12V starter battery 7-13 Vanity mirror 3-122 Specification 9-8 Vehicle care precautions 7-49 12V starter battery charging system warning light 3-74 Vehicle dimensions 9-6 Vehicle labeling 9-2 Vehicle preparation before driving 4-5...
