6
Hold the door shut to avoid opening.
The lock will carry out the
configuration process.
It take's 15-20 seconds to complete.
8
Press [Cfg]
The lock will carry out the
configuration process.
Troubleshooting #1
Lock configuration failed
1. Remove the mechanical key from the cylinder.
2. Check that the door was closed properly or if
lock operation was interfered.
14
Configuration OK
[Manual] indication illuminated.
[Cfg] indication blinks.
Note: If the configuration fails
refer to troubleshooting #1
Configuration OK
[OK] Indication blinks once.
2 short beeps emitted,
Illuminated buttons turn off.
7
Open the door using the handle.
Bring the latch as close as possible to
the door frame.
Note: Do not shut the door.
Latch
ENTR® User Manual
Door frame
Magnet
