2. INSTALLATION & CONNECTION
2.1 Install the camera
1. Find the bracket and its accessories supplied with the camera.
2. Attached the base of the bracket (the round one) to where you want to install this camera, and fasten it with the
supplied screws.
3. Assemble the bracket as illustrated below, and adjust the angle of the camera.
2.2 Connect to power
Connect the supplied power adapter to the camera's power jack (DC 5V) on the rear panel and
the power outlet.
2. INSTALLATION & CONNECTION
2.1 Install the camera
4. Find the bracket and its accessories supplied with the camera.
5. Attached the base of the bracket (the round one) to where you want to install this camera, and fasten it with the
supplied screws.
6. Assemble the bracket as illustrated below, and adjust the angle of the camera.
2.2 Connect to power
Connect the supplied power adapter to the camera's power jack (DC 5V) on the rear panel and
the power outlet.
3
3
