Select Group Overview - eXact Micro 20 Instruction Manual

Select group overview

Below is a list of Menu and selection choices with abbreviations.
1 Water Quality
CL1 — Free & Total Chlorine
PH2 — pH
FE3 — Iron
AL4 — Total Alkalinity
TU5 — Total Hardness
CU6 — Copper
MN7 — Manganese
F8 — Fluoride
5 Oxidizers
CL1 — Free & Total Chlorine
bR2 — Bromine
O3 — Ozone
Cd4 — Chlorine Dioxide
PA5 — Peracetic Acid Low
HP6 — Hydrogen Peroxide
PM7 — Permanganate
QA8 — Quaternary Ammonia
Compound QAC
CLH — Chlorine High Range
eXact Micro 20 meter messages
®
The following are some of the common messages that may display on your photometer, including error
messages. If an error message other than those listed below is displayed, please contact technical
support in the USA at (803) 329–0162 (ext. 0).
LCD Message Description
HI In READ mode: test sample concentration is above the
measurement range (test specific).
LO In READ mode: test sample concentration is below the
measurement range (test specific).
LO In ZERO mode: sample absorbency (due to a cloudy
or colored sample or a dirty cell) is too high to zero, the
meter will read "LO" or low battery
ER Excessive stray light detected. Normally this does not
occur, even when testing in sunlight.
Low battery indication during testing
(meter may not zero)
Flashing result Lost connection to eXact iDip
on LCD
12
2 Miscellaneous
CN1 — Cyanide
FE2 — Iron (II) & Total Iron
NH3 — Ammonia
PO4 — Phosphate
S5 — Sulfide
PHA — Acid pH
PHb — Alkali pH
6 Specialty
F1 — Fluoride
MN2 — Manganese
AI3 — Aluminum
SO4 — Sulfate
QA5 — Quaternary Ammonia
CR6 — Chromium
Mo7 — Molybdate
THH — Total Hardness
High Range
THL — Total Hardness
Low Range
app
®
3 Pool & Spa
AL1 — Total Alkalinity
PH2 — pH
CL3 — Free & Total Chlorine
PO4 — Phosphate
CA5 — Calcium Hardness
bR6 — Bromine
Cy7 — Cyanuric Acid
bG8 — Biguanide
CHH — Chloride High Range
7 Transmission
TR1 — Transmission (525nm)
TR2 — Transmission (638nm)
Corrective Action
Dilute and retest. Dilution kit available
(Part No. 487200)
Sample value is below
measurement range.
Dilute sample, filter sample or clean
cell. One of these options should
remedy the problem. You may need
to replace batteries if low battery
indication.
Place the light blocking CAP over the
CELL for zeroing and for reading result.
Moving to a shaded can also fix
this problem.
Replace batteries immediately. Otherwise
meter may read LO while testing.
Press ON/ZERO to stop flashing. Remove
and replace the battery cover if flashing
continues for future tests.
4 Environmental
AL1 — Total Alkalinity
NO2 — Nitrite
NO3 — Nitrate
NH4 — Ammonia
CH5 — Chloride
CL6 — Free & Total Chlorine
PH7 — pH
PO8 — Phosphate
CU9 — Copper
