OPERATING MODES AND PAGES

Home Page

Immediately after power-up and boot process of DB4004, the Home page is shown on
the display. Transition to Home page can be made from any page where
Button is available. There is several Home page views available which can be altered through
Settings>Device>Home Screen menu.
On the default home screen the Header area is shown (see "Header Area" on page 25). Shown
are also the most important flags attributes of the decoded RDS signal (if present) and big indicator
of currently selected frequency. Pressing any of the Soft Buttons will set to the appropriate preset.

"Preset" explained

PRESET is a pre-saved set of parameters for instant automatic recall later on.

Creating a new Preset

Navigate to page of the DB4004 in which Soft Buttons are assigned to Preset. In such page
the labels of the soft buttons are FM Frequencies (e.g. Home page). Select desired frequency by
the Navigational Buttons and press hold Soft Button for about 2 seconds until two short beeps are
heard from DB4004. A new Preset was created with parameters corresponding to those at the time
of creation – FREQUENCY, ATT, ANTENNA PORT. The newly created Preset is assigned to the
Soft Button and Preset frequency is shown as button label.
