FFT SPECTRUM ANALYSIS (RF, COMPOSITE, AUDIO)
Signal Sources
FFT length
Dynamic range
SCOPE ANALYSIS (RF, COMPOSITE, AUDIO)
Signal Sources
Record length
Dynamic range
METERING ACCURACY
RF Level
MPX Power
Total, Pos, Neg
Pilot, RDS
Audio
OUTPUTS
Composite
Audio (L, R)
AES3 (L, R)
SPDIF (L, R)
Optical (L, R)
Alarms
Headphone
COMMUNICATION INTERFACES
USB
Ethernet 10/100 Base-T
GSM Modem
MEASUREMENT STORAGE
Storage
Data format
POWER
Supply
Connector
SIZE AND WEIGHT
Dimensions (W;H;D)
Shipping Weight
65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
E-mail: office@devabroadcast.com ,Web: www.devabroadcast.com
RF (IF), MPX, Left, Right
2048 points
90 dB
RF (IF), MPX, Pilot, RDS, Main, Sub, Left, Right
4096 points
90 dB
±1 dB, 0 to 100 dBµV
±0.2 dBr, -12 to 12 dBr, 0.1 dBr resolution
±2 kHz, 10 to 100 kHz, 1 kHz resolution
±0.5 kHz, 1 to 12 kHz, 0.2 kHz resolution
±1 dB, +10.0 to -55.0 dB, 0.1 dB resolution
3.5 Vp-p @ 75kHz, 75Ω, unbalanced BNC Connector
+12 dBm, 600Ω balanced XLR Connector
5.0 Vp-p, 110Ω , balanced XLR Connector
3.0 Vp-p, 110Ω, unbalanced BNC Connector
Transmitter, TOSLINK
Programmable terminals on rear panel, optoisolated
6,3mm (1/4") Phone Jack
B-type Connector
RJ45 Connector
15 pin Male D-Sub Connector
2GB Build-in Memory Card
Text, CSV
100-240V / 50-60 Hz / 25W
IEC320
485 x 44 x 180 mm, 19" x 1.7" x 6.9"
540 x 115 x 300 mm / 2.7kg
- 10 -
