CAMSHAFT

Removing the cylinder head cover
4
13 Nm (1.3 m kg, 9.4 ft
•
Order
Side cover (left/right)
Fuel tank
Coolant
Engine oil
1 Throttle cable
2 Throttle body
3 Clutch cable
4 Ignition coil coupler
5 Cylinder head cover breather hose
6 Ignition coil assembly
7 Spark plug
8 Cylinder head cover
9 Cylinder head cover gasket
6
5
7
Ib)
•
9
Job/Parts to remove
12 Nm (1.2 m kg, 8.7 ft
•
8
2
3
1
Q'ty
Refer to "GENERAL CHASSIS" on page
4-1.
Refer to "FUEL TANK" on page 7-1.
Drain.
Refer to "CHANGING THE COOLANT" on
page 3-18.
Drain.
Refer to "CHANGING THE ENGINE OIL" on
page 3-11.
2
1
1 Disconnect.
1 Disconnect.
1
1
1
1
1
For installation, reverse the removal proce-
dure.
