Removing the air cut-off valve assembly
10 Nm (1.0 m kg, 7.2 ft
•
1
6
10 Nm (1.0 m kg, 7.2 ft Ib)
• •
Order
Seat
Side cover (left/right)
Air scoop (left/right)
Fuel tank
1 Air induction coupler
2 Air induction system pipe
3 Gasket
4 Pipe3
5 Air induction system hose
6 Air cut-off valve assembly
Ib)
•
4
2
5
Job/Parts to remove
AIR INDUCTION SYSTEM
3
Q'ty
Refer to"GENERAL CHASSIS" on page 4-1.
Refer to"FUEL TANK" on page 7-1.
1 Disconnect.
1
1
1
1
1
For installation, reverse the removal proce-
dure.
7-11
Remarks
