Conventional transformer operations

Operating your locomotive in the conventional environment

1. Place your locomotive on Lionel or Lionel-compatible O-31 or larger
track.
2. Power your locomotive at 8-18 volts with your alternating current (AC)
transformer.
Power your locomotive with an alternating-current (AC) transformer only.
Caution!
Powering your locomotive with a direct-current (DC) transformer may result in
damage to sensitive electronic components.
3. Wait three to eight seconds as your locomotive determines whether it is in
a conventional environment or a TrainMaster Command Control environ-
ment.
When the locomotive has determined that a TrainMaster Command Base is not connected
to the track, the locomotive's headlight will illuminate and the RailSounds sound system
will start. You are ready for operation in the conventional environment.
4. Move 'em out!
Press the DIRECTION button on your transformer to sequence your locomotive through
the repeating pattern of operations: forward, neutral, reverse, neutral, and so on. You may
also briefly turn off track power to advance the locomotive to the next operating state.
Adjust the throttle until your locomotive moves at your desired speed.
When placing your locomotive on your layout for the first time, it will start out in
Note!
neutral. Thereafter, it will start in forward after every power interruption lasting five
seconds or longer.
Use the HORN and BELL buttons on your transformer to activate those features. Adjust
the volume using the volume control knob located inside the locomotive. Refer to Figure 6 on
page 14.
