Configuration of alarm relay
The alarm relay will be activated upon an alarm signal from the following groups:
1 - High temperature alarms
2 - Low temperature alarms
4 - Sensor error
8 - Digital input enabled for alarm
16 - Defrosting alarms
32 - Miscellaneous
64 - Injection alarms
The groups that are to activate the alarm relay must be set by using a numerical value
which is the sum of the groups that must be activated.
(E.g.: a value of 5 will activate all high temperature alarms and all sensor error and 0
will cancel relay function

Service

Temperature measured with S5 sensor
Status on DI1 input. on/1=closed
Read the duration of the ongoing defrost or the duration of the last completed
defrost.
Temperature measured with S3 sensor
Status at the day-/night operation (night operation: on/off )
Temperature measured with S4 sensor
Thermostat temperature
Read the ongoing cutin time for the thermostat or the duration of the last com-
pleted cutin
Read the temperature at the S2 sensor
Read superheat
Read the control's actual superheat reference
Read the valve's actual opening degree
Read the evaporating pressure
Read the evaporating temperature
Read the temperature at the S6 sensor
Status on DI2 output. on/1=closed
Air temperature. Weighted S3 + S4
Measured temperature for alarm thermostat
* Status on relay for cooling
* Status on relay for fan
* Status on relay for defrost
* Status on relay for railheat
* Status on relay for alarm
* Status on relay for light
* Status on relay for valve in suction line
* Status on relay for compressor 2
* Temperature measured with S5B sensor
* Temperature measured with S3B sensor
* Status on relay for hot gas
* Status on relay for heating element in drip tray
* Status on relay for night blinds
* Status on relay for defrost B
* Status on relay for heat function
* Readout of the actual rail heat effect in %
Readout of which thermostat used for regulation: 1= Thermostat 1,
2= Thermostat 2
Status on input DI3 (on/1 = 230 V)
Readout of the actual cutin value for the thermostat
Readout of the actual cut out value for the thermostat
AK-CC 550A Manual RS8FS402 © Danfoss 2016-03
P41 Al.Rel. Conf.
Case shut down
Service
u09 S5 temp.
u10 DI1 status
u11 Defrost time
u12 S3 air temp
u13 Night Cond.
u16 S4 air temp
u17 Ther. air
u18 Ther runtime
u20 S2 temp.
u21 Superheat
u22 SH ref.
u23 AKV OD %
u25 Evap.press Pe
u26 Evap.temp Te
u36 S6 temp
u37 DI2 status
u56 Display air
u57 Alarm air
u58 Comp1/LLSV
u59 Fan relay
u60 Def. relay
u61 Railh. relay
u62 Alarm relay
u63 Light relay
u64 SuctionValve
u67 Comp2 relay
u75 S5 temp. B
u76 S3 temp. B
u80 Hotgas valve
u81 Drip tray
u82 Blinds relay
u83 Def. relay B
u84 Heat relay
u85 Rail DutyC %
u86 Ther. band
u87 DI3 status
u90 Cutin temp.
u91 Cutout temp.
