Continued
0 =Stop on time, 1=S5, 2=S4, 3=Sx
Defrost sensor:
(Application 1-8 and 10: both S5 and S6.
Application 9: S5 and S5B)
Pump down delay
Drain delay (used at hot gas defrost only)
Max. aggregate refrigeration time between two defrosts
Heat in drip tray. Time from defrosting stops to heating
in the drip tray is switched off
Adaptive defrost:
0=not active, 1=monitoring only, 2=skip allowed day,
3=skip allowed both day and night, 4=own assessment
+ all schedules
Time delay before opening of hot gas valve
Rail heat during defrost
0=off. 1=on. 2=Pulsating
Injection control function
Max. value of superheat reference
Min. value of superheat reference
MOP temperature. Off if MOP temp. = 15.0 °C
Period time of AKV pulsation
Only for trained personnel
Fan
Fan stop temperature (S5)
Pulse operation on fans: 0=No pulse operation, 1=At
thermostat cuts out only, 2= Only at thermostat cut
outs during night operation
Period time for fan pulsation (on-time + off-time)
On-time in % of period time
Real time clock
Six start times for defrost.
Setting of hours.
0=OFF
Six start times for defrost.
Setting of minutes.
0=OFF
Clock - Setting of hours
Clock - Setting of minute
Clock - Setting of date
Clock - Setting of month
Clock - Setting of year
Miscellaneous
Delay of output signals after start-up
Input signal on DI1. Function:
0=not used. 1=status on DI1. 2=door function with alarm
when open. 3=door alarm when open. 4=defrost start
(pulse-signal). 5=ext.main switch. 6=night operation
7=thermostat band changeover (activate r21). 8=alarm
function when closed. 9=alarm function when open.
10=Appliance cleaning (pulse signal). 11=forced cooling at
12=night cover. 15=case shut down
hot gas defrost,
Network address
On/Off switch (Service Pin message)
IMPORTANT! o61 must be set prior to o04
(used at LON 485 and DANBUSS only)
Access code 1 (all settings)
: 0=Pt1000, 1=Ptc1000,
Used sensor type
Readout of software version
Max hold time after coordinated defrost
Select signal for display view. S4% (100%=S4, 0%=S3)
Pressure transmitter working range – min. value
Pressure transmitter working range – max. value
Refrigerant setting:
1=R12. 2=R22. 3=R134a. 4=R502. 5=R717. 6=R13.
7=R13b1. 8=R23. 9=R500. 10=R503. 11=R114.
12=R142b. 13= 14=R32. 15=R227.
User defined.
16=R401A. 17=R507. 18=R402A. 19=R404A. 20=R407C.
21=R407A. 22=R407B. 23=R410A. 24=R170. 25=R290.
26=R600. 27=R600a. 28=R744. 29=R1270. 30=R417A.
31=R422A. 32=R413A. 33=R422D. 34=R427A. 35=R438A.
36=R513A. 37=R407F. 38=R1234ze. 39=R1234yf.
AK-CC 550A
Code 1
d10 1
d16 1
d17
d18 1
d20
d21 1
d23
d27
n09 1
n10 1
n11 1
n13 1
F04 1
F05 1
F06 1
F07 1
t01 - 1
t06
t11 - 1
t16
t07 1
t08 1
t45 1
t46 1
t47 1
o01 1
o02 1
o03 1
o04 1
o05 1
o06 1
o08 1
o16 1
o17 1
o20 1
o21 1
o30 1
Manual RS8FS402 © Danfoss 2016-03
2 3 4 5 6 7 8 9
1 1 1 1 1 1 1 1
1 1 1 1 1 1 1 1
1
1 1 1 1 1 1 1 1
1
1 1 1 1 1 1 1 1
1
1 1 1 1 1 1
1 1 1 1 1 1 1 1
1 1 1 1 1 1 1 1
1 1 1 1 1 1 1 1
1 1 1 1 1 1 1 1
1 1 1 1 1 1 1 1
1 1 1 1 1 1 1 1
1 1 1 1 1 1 1 1
1 1 1 1 1 1 1 1
1 1 1 1 1 1 1 1
1 1 1 1 1 1 1 1
1 1 1 1 1 1 1 1
1 1 1 1 1 1 1 1
1 1 1 1 1 1 1 1
1 1 1 1 1 1 1 1
1 1 1 1 1 1 1 1
1 1 1 1 1 1 1 1
1 1 1 1 1 1 1 1
1 1 1 1 1 1 1 1
1 1 1 1 1 1 1 1
1 1 1 1 1 1 1 1
1 1 1 1 1 1 1 1
1 1 1 1 1 1 1 1
1 1 1 1 1 1 1 1
1 1 1 1 1 1 1
1 1 1 1 1 1 1 1
1 1 1 1 1 1 1 1
1 1 1 1 1 1 1 1
10 Min. Max. Fac.
1 0 3 0
1 0 min. 60 min. 0
0 min. 60 min. 0
1 0 hrs 48 hrs 0/OFF
0 min. 240 min. 30
1 0 4 0
0 min 60 min 0
1 0 2 2
1 2°C 20°C 12
1 2°C 20°C 3
1 -50°C 15°C 15
1 3 sec 6 sec 6
1 -50°C 50°C 50
1 0 2 0
1 1 min. 30 min. 5
1 0 % 100 % 100
1 0 hrs 23 hrs 0
1 0 min. 59 min. 0
1 0 hrs 23 hrs 0
1 0 min. 59 min. 0
1 1 day 31 day 1
1 1 mon. 12 mon. 1
1 0 year 99 year 0
1 0 sec 600 sec 5
1 0 15 0
1 0 240 0
1 0/Off 1/On 0/Off
1 0 100 0
1 0/Pt 1/Ptc 0/Pt
1
1 0 min. 360 min. 20
0 % 100 % 100
1 -1 bar 5 bar -1
1 6 bar 200 bar 12
1 0 39 0
