Continued
Input signal on DI2. Function:
(0=not used. 1=status on DI2. 2=door function with alarm
when open. 3=door alarm when open. 4=defrost start
(pulse-signal). 5=ext. main switch 6=night operation
7=thermostat band changeover (activate r21). 8=alarm
function when closed. 9=alarm function when open.
10=Appliance cleaning (pulse signal). 11=forced cooling at
hot gas defrost.). 12=night cover, 13=coordinated defrost).
15=case shut down
: 1=Light follows day /night
Configuration of light function
operation, 2=Light control via data communication
via 'o39' , 3=Light control with a DI-input, 4=As "2", but
light switch on and night cover will open if the network
cut out for more than 15 minutes.
Activation of light relay (only if o38=2)
Rail heat On time during day operations
Rail heat On time during night operations
Rail heat period time (On time + Off time)
Appliance cleaning. 0=no Appliance cleaning. 1=Fans only.
2=All output Off.
Selection of EL diagram. See overview page 12 and 13
Download a set of predetermined settings. See overview
page 27.
Access code 2 (partial access)
Replace the controllers factory settings with the present
settings
Input signal on DI3. Function: (high voltage input)
(0=not used. 1=status on DI2. 2=door function with alarm
when open. 3=door alarm when open. 4=defrost start
(pulse-signal). 5=ext. main switch 6=night operation,
7=
thermostat band changeover (activate r21)
used. 9=Not used.
10=Appliance cleaning (pulse signal).
11=forced cooling at hot gas defrost,
13=Not used. 14=Refrigeration stopped (forced
closing)). 15=case shut down
Rail heat control
0=not used, 1=pulse control with timer function (o41
and o42), 2=pulse control with dew point function
Dew point value where the rail heat is minimum
Dew point value where the rail heat is 100% on
Lowest permitted rail heat effect in %
Time delay from "open door" refrigeration is started
Fan operation at stopped cooling (forced closing):
0= Stopped (defrost allowed)
1= Running (defrost allowed)
2= Stopped (defrost not allowed)
3= Running (defrost not allowed)
1=defrost stop temperature, 2=S6 temperature,
3=S5_B temperature (application 9), 4=S3B (application
10)
Display of temperature
1= u56 Air temperature
2= u36 product temperature
Light and night blinds defined
0: Light is switch off and night blind is open when the
main switch is off
1: Light and night blind is independent of main switch
Configuration of alarm relay
The alarm relay will be activated upon an alarm signal
from the following groups:
1 - High temperature alarms
2 - Low temperature alarms
4 - Sensor error
8 - Digital input enabled for alarm
16 - Defrosting alarms
32 - Miscellaneous
64 - Injection alarms
The groups that are to activate the alarm relay must be
set by using a numerical value which is the sum of the
groups that must be activated.
(E.g.: a value of 5 will activate all high temperature
alarms and all sensor error and 0 will cancel the relay
function).
30
Code
o37
o38
On=light o39
o41
o42
o43
*** o46
* o61
* o62
*** o64
o67
o84
. 8=Not
12=night cover.
o85
o86
o87
o88
o89
o90
o92
o97
o98
P41
