ECA16630
Electrical components are very sensitive to
and can be damaged by static electricity.
Therefore, never touch the terminals and be
sure to keep the contacts clean.
TIP
When resetting the ECU by turning the main
switch to "OFF", be sure to wait approximately
5 seconds before turning the main switch back
to "ON".

Checking the electrical system

TIP
Before checking the electrical system, make
sure that the battery voltage is at least 12 V.
BASIC SERVICE INFORMATION
ECA14371
Never insert the tester probes into the cou-
pler terminal slots. Always insert the
probes from the opposite end "a" of the
coupler, taking care not to loosen or dam-
age the leads.
ECA16640
For waterproof couplers, never insert the
tester probes directly into the coupler.
When performing any checks using a
waterproof coupler, use the specified test
harness or a suitable commercially avail-
able test harness.
1-30
a
