Endless Pools SwimCross Owner's Manual page 14

You have several possibilities for
the schedule (Mon-Fri, weekend,
every day, or single days). The
schedules will be repeated every
week. The time and duration are
set in 30 minute increments. Once
you have set the schedule, use
(top left) lit button to go back.
Ensure that you have selected the desired Water Care option in the main
Water Care menu.
MAINTENANCE
From the Settings page you can
access the Maintenance menu,
which gives you access to the
following options:
• Maintenance reminders
• Standby
• Error log
Use the or buttons to make a selection, and
button to select.
MAINTENANCE REMINDERS
The control panel will remind you
of maintenance required on your
SWIMCROSS Exercise System, like
rinsing or cleaning the filter. Each
task has its own duration, based on
normal use.
The Maintenance reminders menu
allows you to verify the time left
before maintenance is required, as well as to reset the time once a task
is completed.
Use the or buttons to move through the list.
To reset a task select it by pressing the
confirm by pressing the lit button next to confirm when prompted. Once
you have confirmed the task will be reset.
STANDBY
The Standby mode allows you to
service your System. Pumps will stop
for 30 minutes, and automatically
restart after this time. Press
(middle left) lit button to activate
Standby mode.
Once Standby mode has been
activated a screen will appear to
show that pumps are stopped. The normal page will return at the end of
maintenance.
Press on the button next to cancel to leave Standby mode and restart the
SWIMCROSS Exercise System.
ERROR LOG
In this section you can see errors
that have been archived by the
system. Use the or buttons
to move through the list. Errors are
archived chronologically, from
most recent to oldest (top to
bottom).
Operating Instructions
(middle left) lit
(middle left) lit button, then
Page 11
The Error log page shows the error code, the date of the error, and the
time. To see more details on an error select it with
button. A screen will appear with more information on the selected error.
For more information, see the Error messages section. To clear the Error
log page press (top right) lit button and confirm when prompted. The
page will be cleared.
DATE AND TIME
Here you can adjust the time format,
change the year, date, and time.
Use the or buttons to choose
the setting that you want to adjust,
and select it by pressing
(middle left) lit button.
Use the or buttons to change
the parameters, and (middle
left) lit button to move between
parameters. Press (top left) lit button to take you back to the main
Settings menu.
KEYPAD SETTINGS
In this section, you can change the
temperature unit, language, display
orientation, rim around the control
panel light color, and lock the control
panel.
Use the or buttons to
choose the setting that you want to
adjust. Select it by pressing the
(middle left) lit button then use the
setting.
When you change the display orientation, the contextual options and
or buttons adjust to the chosen orientation. The Audio and Setting
buttons remain unchanged, as well as the jets and lights buttons in the
home page.
Security settings allow you a Partial (Temperature) lock or Full (entire
control panel) lock. Select Security screen by pressing the
left) lit button then use the
Unlock. Press (top left) lit button to display an information screen
telling you to press and hold
To unlock Full, press and hold
ELECTRICAL CONFIGURATION
Please do not make changes in this section!
ABOUT
(middle left) lit
or buttons again to change the
or buttons to change to Full, Partial or
button for 5 seconds to lock.
button for 5 seconds.
This section shows information about
the control panel software number, and
the revision numbers of the different
components of your system.
(middle
