REMOTE CONTROL VALVE LEVER
(1) Remote Control Valve Lever
(A) A Port
(C) Push
(B) B Port
(D) Pull
Lever (1)
Push
A
In
Port
B
Out
Port A, B
196O908A
Move the lever up or down and hold. This
Pressure
will raise or lower the implement. Lever
Returning
will return to neutral when released.
Pull
Out
Do not hold the lever in the "pull"
In
or "push" position once the re-
mote cylinder has reached the
Coupler Size
end of the stroke, as this will
cause oil to flow through the re-
PT 1/2´´
lief valve. Forcing oil through the
relief valve for extended periods
will overheat the oil.
When using the tractor hydraulic
system to power front loader, do
not operate boom and bucket cyl-
inders simultaneously.
HYDRAULIC UNIT 9-7
IMPORTANT
