CHECKING THE BRAKE PEDAL
CK20
(1) Brake Pedal Lock
(A) Lock
(B) RELEASE
CK20H
196O711A
(1) Brake Pedal Lock
(A) Lock
BRAKE PEDAL (RIGHT AND LEFT)
To avoid personal injury:
Applying one rear wheel brake at
a time can cause the tractor to
swerve or roll over at high speeds.
1. Before operating the tractor on the
road or before applying the parking
brake, be sure to interlock the right
and left pedals as illustrated below.
196O712A
2. Use individual brakes to assist in mak-
ing sharp turns at slow speeds (Field
Operation Only).
(B) RELEASE
Disengage the brake pedal lock and
depress only one brake pedal.
3. Be sure brake pedals have equal ad-
justment when using locked together.
OPERATING THE TRACTOR 7-7
WARNING
