The support file page includes the following information:
System description
Dual image status and descriptions
Buffered log messages
Logging configuration details
SNTP configuration
Time zone configuration
Network details
Web parameters
Management access
SNMP
Port configuration details, summary, and statistics
Trunk statistics
Jumbo frames configuration details
Storm control, Auto DoS, and Flow control configuration
Web configuration
MAC address forwarding table and summary statistics
VLAN configuration and membership details
Trunk status
LLDP global mode details
Interface mode details
LLDP global and interface statistics, and local and remote device summaries
Port mirroring configuration
Loop protection status per interface
Spanning tree bridge and interface status and configuration, and port settings
To save the Support File data to a file, click Save As located at the top and bottom of the page.
You can print the text from your text editor. Alternatively, your browser may support printing only
the frame that contains the data (that is, it excludes the navigation pane and Web Applet) directly
from the Web page. Right-click the data area to see if your browser provides this option.

Locator

The Locator LED is a special LED that enables locating the device physically. When enabling the
Locate setting via the Web interface, the Locate LED on the switch blinks for 30 minutes and then
turns off.
To display the Locator page, click Diagnostics > Locator in the navigation pane.
Figure 45 Locator Page
Locator 57
