A 100 Mbps network communication system based on Ethernet and
Fast Ethernet
the CSMA/ CD access method.
Full Duplex Transmission method that allows two network devices to transmit
and receive concurrently, effectively doubling the bandwidth of that
link.
Gigabit A 1000 Mbps network communication system based on Ethernet
Ethernet
and the CSMA/ CD access method.
IEEE Institute of Electrical and Electronic Engineers.
IEEE 802.3 Defines carrier sense multiple access with collision detection
(CSMA/CD) access method and physical layer specifications.
IEEE 802.3AB Defines CSMA/CD access method and physical layer specifications
for 1000BASE-T Gigabit Ethernet (now incorporated in IEEE 802.3-
2005).
Defines CSMA/CD access method and physical layer specifications
IEEE 802.3U
for 100BASE- TX Fast Ethernet (now incorporated in IEEE 802.3-
2005).
IEEE 802.3X Defines Ethernet frame start/stop requests and timers used for flow
control on full-duplex links (now incorporated in IEEE 802.3-2005).
IEEE 802.3Z Defines CSMA/CD access method and physical layer specifications for
1000BASE Gigabit Ethernet (now incorporated in IEEE 802.3-2005).
Defines Power Over Ethernet is used to transmit electrical power,
IEEE
802.3at/af PoE IEEE 802.3af (Class 4 PDs limited to 15.4W), PoE++ IEEE 802.3at
(Class 4 PDs limited to 30W).
Lan Segment Separate LAN or collision domain.
LED Light emitting diode used for monitoring a device or network
condition.
Local Area A group of interconnected computer and support devices.
Network
(LAN)
Media Access A portion of the networking protocol that governs access to the
Control (MAC) transmission medium, facilitating the exchange of data between
network nodes.
MIB An acronym for Management Information Base. It is a set of
database objects that contains information about the device.
Modal Bandwidth for multimode fiber is referred to as modal bandwidth
Bandwidth because it varies with the modal field (or core diameter) of the fiber.
Modal bandwidth is specified in units of MHz per km, which
indicates the amount of bandwidth supported by the fiber for a one
km distance.
Wire distance between two end stations in the same collision
Network
Diameter domain.
RJ-45 A connector for twisted-pair wiring.
Connector
Ports that are on separate collision domains or LAN segments.
Switched
Ports
