1000Base-T Ports
SFP Transceiver
Slots

Description of Hardware

The switch contains 8/10 1000BASE-T RJ-45 ports. All RJ-45 ports support
automatic MDI/MDI-X operation, auto-negotiation, and IEEE 802.3x auto-
negotiation of flow control, so the optimum data rate, and transmission can be
selected automatically.
Vi3010 supports the Small Form Factor Pluggable (SFP) transceiver slots. The SFP
transceiver slots are shared with RJ-45 port 9 to 10. In the default configuration, if
a SFP transceiver (purchased separately) is installed in a slot and has a valid link on
the port, the associated RJ-45 port is disabled.
The following table shows a list of transceiver types which have been tested with
the switch. For an updated list of vendors supplying these transceivers, contact
your local dealer. For information on the recommended standards for fiber optic
cabling, see "1000 Mbps Gigabit Ethernet Collision Domain" on page 27.
Media Fiber
Standard Diameter
(microns)
1000BASE-SX 50/125
62.5/125
1000BASE-LX/ 9/125
LHX/ XD/ZX
9/125
9/125
1000BASE-LX N/A
Single Fiber
1000BASE-T N/A
100-FX 50/125
62.5/125
Table 1: Supported SFP Transceivers
NOTE:
vendors.
Wavelength (nm) Maximum Distance*
850 550 m
850 275 m
1310 10 km
1550 30.50 km
1300 10 km
TX-1310/RX-1550 20 km
Tx-1550/RX-1310 20 km
N/A 100 m
850 2 km
1550 15km
*Maximum distance may vary for different SFP
