  • Page 1 IA260 Hardware User’s Manual First Edition, September 2008 www.moxa.com/product © 2008 Moxa Inc. All rights reserved. Reproduction without permission is prohibited.

  • Page 2: Copyright Notice

    IA260 Hardware User’s Manual Any software described in this manual is furnished under a license agreement and may be used only in accordance with the terms of that agreement. Copyright Notice Copyright © 2008 Moxa Inc. All rights reserved. Reproduction without permission is prohibited.

  • Page 3: Table Of Contents

    Table of Contents Chapter 1 Introduction ....................1-1 Overview..........................1-2 Model Descriptions and Package Checklist................1-2 Product Features ........................1-3 Product Hardware Specifications..................... 1-3 Hardware Block Diagram ......................1-5 Chapter 2 Hardware Introduction.................2-1 Appearance ..........................2-2 Dimensions ..........................2-3 LED Indicators......................... 2-4 Reset Button..........................

  • Page 4: Chapter 1 Introduction

    These features make the IA260 series ideal for your industrial embedded applications, such as SCADA, manufacturing automation, and other industrial applications. This manual introduces the IA260’s hardware. After a brief introduction of the hardware features, the manual focuses on installation and configuration.

  • Page 5: Overview

    Because of its VGA output capability, the IA260 can be used for protocol conversion or data acquisition for field site devices, and is also suitable for SCADA systems in industrial applications, such as manufacturing automation, production line process monitoring, and mining automation.

  • Page 6: Product Features

    IA260 Hardware User’s Manual Overview CBL-4PINDB9F-150: 150 cm, 4-pin header to DB9 female console port cable Universal Power Adaptor (includes terminal block to power jack converter) Product Warranty Statement NOTE: Notify your sales representative if any of the above items are missing or damaged.
  • Page 7 IA260 Hardware User’s Manual Overview Serial Signals RS-232: TxD, RxD, DTR, DSR, RTS, CTS, DCD, GND RS-422: TxD+, TxD-, RxD+, RxD-, GND RS-485-4w: TxD+, TxD-, RxD+, RxD-, GND RS-485-2w: Data+, Data-, GND Digital Input Input Channels 8, source type Input Voltage...

  • Page 8: Hardware Block Diagram

    IA260 Hardware User’s Manual Overview Regulatory Approvals CE (EN55022 Class A, EN61000-3-2 Class A, EN61000-3-3, EN55024), FCC (Part 15 Subpart B, CISPR 22 Class A), CCC (GB9254, GB 17625.1) Safety UL/cUL (UL60950-1, CSA C22.2 No. 60950-1-03), LVD (EN60950-1), CCC (GB4943)

  • Page 9: Chapter 2 Hardware Introduction

    The LED indicators allow users to monitor performance and identify trouble spots quickly, and the multiple ports can be used to connect a variety of devices. The IA260 comes with a reliable and stable hardware platform that lets you devote the bulk of your time to application development.

  • Page 10: Appearance

    IA260 Hardware User’s Manual Hardware Introduction Appearance Top View Power Input (12 to 48 VDC) DI x 8 DO x 8 Reset Front View LED Indicators Power, Ready, Storage LED Indicators LED Indicators Serial, Tx/Rx Serial, Tx/Rx 10/100 Mbps Ethernet x 2...

  • Page 11: Dimensions

    IA260 Hardware User’s Manual Hardware Introduction Rear View DIN-rail Kit Dimensions 132.5 34.8 57.55 33.43 21.6 45.85 11.1 11.1...

  • Page 12: Led Indicators

    Reset Button The IA260 has a reset button located on the top panel. The reset button can be used to do a simple Reset, which is equivalent to turning the power off and then back on again, or Reset to default, which returns the IA260 to its factory default parameter configuration.

  • Page 13: Real Time Clock

    DIN-Rail Mounting The aluminum DIN-Rail attachment plate is already attached to the product’s casing. To attach the plate to IA260, make sure that the stiff metal spring is facing the top of the IA260, as shown in the following figures.

  • Page 14: Wall Mounting (Optional)

    IA260 Hardware User’s Manual Hardware Introduction Wall Mounting (optional) For some applications, you will find it convenient to mount the IA260 on the wall, as depicted in the following illustrations. STEP 1: Attach the wallmount kit to the IA260’s rear panel with 2 screws.

  • Page 15: Hardware Connection Description

    Hardware Connection Description Chapter 3 This section describes how to connect the IA260 to a network and various devices for first time testing purposes. The following topics are covered in this chapter: Wiring Requirements Connecting the Power Grounding the Unit...

  • Page 16: Wiring Requirements

    Connecting the Power The IA260 has a 3-pin terminal block for a 12 to 48 VDC power input. The following figures show how the power input interface connects to external power sources. If the power is properly supplied, the Power LED will light up.

  • Page 17: Grounding The Unit

    Connecting to the Console Port The IA260’s console port is a 4-pin pin-header RS-232 port. It is designed for serial console terminals, which are useful for identifying the boot up message, or for debugging when the system cannot boot up.

  • Page 18: Connecting To A Display

    IA260. Connecting to the Network Connect one end of the Ethernet cable to one of the IA260’s 10/100M Ethernet ports (8-pin RJ45) and the other end of the cable to the Ethernet network. If the cable is properly connected, the...

  • Page 19: Connecting To A Serial Device

    Hardware Connection Description Connecting to a Serial Device Use properly wired serial cables to connect the IA260 to serial devices. The serial ports of the IA260 use male DB9 connectors. The ports can be configured by software for RS-232, RS-422, or 2-wire RS-485.

  • Page 20: Digital Input Wiring

    Digital Output Wiring Insert CompactFlash Card The IA260 has a built-in CompactFlash socket that allows users to add additional memory by inserting a CompactFlash memory card, without any risk to the computer. Follow the instructions below to insert a CompactFlash card: 1.
  • Page 21 IA260 Hardware User’s Manual Hardware Connection Description 3. Be sure to insert the CompactFlash card correctly into the protective cover, as shown in the figure below. 4. Insert the CompactFlash protective cover with the CompactFlash card into the socket, as shown in the figure.

  • Page 22: Usb Hosts

    IA260 Hardware User’s Manual Hardware Connection Description ATTENTION The IA260 does not support CompactFlash hot swap and PnP (Plug and Play) function. It is necessary to remove power source first before inserting or removing the CompactFlash card. USB Hosts The IA260 provides 2 USB 2.0 full speed hosts (OHCI), type A connectors, which support a...

  • Page 23: Appendix A Regulatory Approval Statements

    Regulatory Approval Statements Appendix A This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
