2.10 MAIN SWITCH
2.11 REMOTE PORT (COMPUTER INTERFACE)
Provide both RS-232 and relay signal to support NOVELL, UNIX, DOS, WINDOWS and
other operating systems.
2.12 TEL./MODEM port
Telecom transfer ports provide users to extend the applications.
● Caution: To reduce the risk of fire, use only No. 26AWG or larger telecommunication
line cord.
2.13 SITE WIRING FAULT INDICATORS (RED LED)
It comes on when the UPS is connected to an improperly wired AC power outlet.
Note: This device is available on 110 Vac model only.
2.14 BYPASS OUTPUT POWER RECEPTACLES
2.15 EXTERNAL BATTERY PACK CONNECTOR (optional)
Caution: Use only factory supplied or authorized connecting cable for external battery !
Caution:
Caution: Caution:
2.16 UPS OUTPUT RECEPTACLES
2.17 AC INPUT POWER RECEPTACLE
2.18 INPUT CIRCUIT BREAKER
It trips when the connected loads exceed the protected receptacle's capacity, The center
plungers of the circuit breakers extend when tripped.
