Related Manuals for GPS Tracker mp2
Summary of Contents for GPS Tracker mp2
- Page 1 Gpstracker.net.in Freedom is lost now…! Model no: mp2 Personal GPS Tracker USERS MANUAL...
-
Page 2: Product Overview
Gpstracker.net.in Freedom is lost now…! 1 Product Overview This tracker shows you with your mobile phone or PC the location of your targets via SMS or GPRS TRACKER has the following features Tracking via SMS or GPRS ... - Page 3 Gpstracker.net.in Freedom is lost now…! 3 Track Parameters& Panel Description Item Specification Charging Voltage DC 5V/500mA (Micro USB port) Internal Battery Rechargeable and removable 830 mAh battery (3.7V) Operating temperature -20° to 55° C Humidity 5% to 95% Non-condensing GSM module GSM 900/1800/1900Mhz GPS Chipset sirmens (AGPS)
-
Page 4: Getting Started
Gpstracker.net.in Freedom is lost now…! Panel Description 4 Getting Started 4.1 Hardware and Accessories USB Power Cable User Manual Other document or software if required 4.2 Light and Button Functionality++++++ ... - Page 5 Gpstracker.net.in Freedom is lost now…! Red LED -- Indicating power status Power off / charging complete / working / GPS optional Flashing (on for 0.05s and off for 4.95 s) Low power Flashing (on for 1s and off for 4 s) GPS on Charging Green LED -- Indicating GPS status...
- Page 6 Gpstracker.net.in Freedom is lost now…! 4.3 First Use Ensure that Tracker has a working SIM installed Check that the SIM has not run out of credit Check that the SIM Lock code is turned off ...
- Page 7 Gpstracker.net.in Freedom is lost now…! Step 2. Step:3...
-
Page 8: Power Off
Gpstracker.net.in Freedom is lost now…! Note: When it is power on, but not finding SIM card or showing errors on SIM card, the three LEDs will be on and off one by one as a circle repeatedly. Power Off: When it is on, press the power button for 3 seconds to switch off the power; Power/GPS/GSM LED will shut off right now. - Page 9 Gpstracker.net.in Freedom is lost now…! 5.1 Basic SMS Commands 5.1.1 Return the location of the tracker Description: To know the location of your Track, send an SMS to Track and it will report its location by SMS. Command: W<password>, <000> Notes: The default password is 000000.
- Page 10 Gpstracker.net.in Freedom is lost now…! SMS sent: W000000,003,3,1,123456789 SMS received: W01,003,Set phone number OK Meaning: When the SOS button is pressed, Track will send an SMS to telephone number “123456789” and also make a phone call to it. When a call is coming in, the blue light is on. Press ACCEPT button to receive the incoming call and then talk with the caller.
- Page 11 Gpstracker.net.in Freedom is lost now…! 5.3.2 Setting You can send message “SF” with your cell phone to your reset phone numbers in Tracker to set it. After that, if your vehicle is illegal moved or abnormal vibrated; it will inform you about it via SMS right now.
- Page 12 Gpstracker.net.in Freedom is lost now…! Geo-fence SMS to the SOS =02, 50m preset number. =03, 100m =04, 200m =05, 300m =06, 500m =07, 1000m =08, 2000m Extend Settings W000000,008,ABCDEFG A=0, turn off the function of sending an SMS location report to the authorized phone number when it makes a call to tracker.
- Page 13 Gpstracker.net.in Freedom is lost now…! Position by sms GOOGLE MAP LINK URL : W000000,100 Set phone number for W000000,030,T T is the telephone number for Voice surveillance wiretapping and max. 16 digits Set time zone difference W000000,032,T T=0, to turn off this function T=[-720, 720] to set time difference in minute to GMT.
- Page 14 Gpstracker.net.in Freedom is lost now…!
