Gpstracker.net.in
PV2 GPS Vehicle Tracking System
............................................................................................................
............................................................................................................................
.............................................................................................................................
.................................................................................................................
........................................................................................................
.....................................................................................................
........................................................................................................
server:http://camera.gpstracker.net.in
User Manual
....................................................................................
.........................................................................................
Freedom is lost now...!
user name: with your username given,
2
2
2
4
5
7
7
9
10
11
12
Advertisement
Table of Contents
Related Manuals for GPS Tracker PV2
Summary of Contents for GPS Tracker PV2
-
Page 1: Table Of Contents
Gpstracker.net.in Freedom is lost now…! PV2 GPS Vehicle Tracking System User Manual ......................Chapter One: Product Introduction ..........................1. Product features ..........................2. Main Functions ......................... Chapter Two: State instructions ......................Chapter Three: Main unit installation ..................... Chapter Four: Terminal function setting ............................ -
Page 2: Chapter One: Product Introduction
Gpstracker.net.in Freedom is lost now…! Camera model: subjected to availability of the stock Chapter One: Product Introduction ZG007 satellite GPS positioning system is a new product which combined of location, tracking and anti-theft, listening to monitor, emergency for help, take photo, release advertisement, vehicle scheduling function. - Page 3 Gpstracker.net.in Freedom is lost now…! Two: Controlling (1) Intelligently stop Engine(Fuel) by force: Built-in oil&electricity cutting relay, The terminal will cut the oil intermittently after receiving the command. Several minutes later, the car will be stop and locked. (2) Remotely recover Engine(Fuel): The terminal will recover oil&electricity after receiving the commands of this.
-
Page 4: Chapter Two: State Instructions
Gpstracker.net.in Freedom is lost now…! management phone, at the same time, the LED display advertising SOS suggest (should install external LED screen already) (7) Illegally starting alarm: when vehicle is armed, and did not disarm, power on it directly, monitoring center will receive illegally starting alarm info. -
Page 5: Chapter Three: Main Unit Installation
Gpstracker.net.in Freedom is lost now…! LED light State description 0.5s Searching GPS networks 0.5s GPRS networks normal 0.5s 0.5s Transmitting GPRS data Normal OFF GSM module doesn't work Green 0.5s 0.5s GPS didn't gain location Green 0.5s GPS already gain location... - Page 6 Gpstracker.net.in Freedom is lost now…! 3. GPS/GSM Antenna installing The location of device is recommended to install in the following locations and require ensuring the right way, at the same time, please pay attention to the concealment. 1) In front bumper or near the headlight.
-
Page 7: Chapter Four: Terminal Function Setting
Gpstracker.net.in Freedom is lost now…! upper place, and avoid vehicle cables and speak or air condition where with strong magnetic,distance with 20CM 4) The back seat of the cab below the rear windshield. Note: GPS positioning device during the installation process as far as possible to ensure that plane up, and GPS 60 degrees above GPS is without metal shielding material. - Page 8 Gpstracker.net.in Freedom is lost now…! 1.0000DELTEL1 Delete Alarm 1.PasswordDELTELTel.No(1--3) 3.0000DELTEL2 Phone Number 2. PasswordDELTELALL 4.0000DELTEL3 4.0000DELTELALL ACCON:PasswordACCON 1.0000ACCON Relay Setting ACCOFF: PasswordACCOFF 2.0000ACCOFF Reboot Device PasswordREBOOT 0000REBOOT Voice Monitor PasswordMON 0000MON Modify User PasswordPWNew’Password( 4 digits) 0000PW1111 Password Back to Factory...
-
Page 9: Checking
Gpstracker.net.in Freedom is lost now…! Open/Close OPEN:PasswordD11 0000D11 CLOSE:PasswordD10 illegally ACC ON 0000D10 Alarm Default as CLOSED OPEN:PasswordE11 Open/Close 0000E11 CLOSE:PasswordE10 0000E10 Vibration Alarm Default as CLOSED OPEN:PasswordF11 Open/Close 0000F11 Geo-fence Alarm CLOSE:PasswordF10 0000F10 SMS Notify Default as CLOSED Checking... - Page 10 Gpstracker.net.in Freedom is lost now…! IMEI:359772032387509 0000DEVC Feedback: Drive Status: ARM(or DISARM) Checking Device ACC Status:ON (or OFF) Parameter PasswordDEVC GSM CSQ:29 Vibration Pickup:2 ON/OFF Parameter:00000000 S/N(ID):88888888 0000TELC Checking AXXXXXXXXXXX Alarm Phone PasswordTELC BXXXXXXXXXXX Number CXXXXXXXXXXX 0000VER Feedback: Checking Drive Hardware Version:V1.0...
-
Page 11: Chapter Five: Technical Parameters
Chapter Five: Technical parameters Working voltage 9V -- 33V DC Working current 30 mA --60 mA（DC） Backup battery 500 mAH Size 73×45×18.5mm Weight 0.19kg Working temperature -20℃ --80℃ Working humidity 5% -- 95%... -
Page 12: Chapter Six: Standard Package List And Accessories
Gpstracker.net.in Freedom is lost now…! GSM frequency range 850MHz / 900MHz / 1800 MHz / 1900 MHz Siemends 10 class GPS module AGPS GPS sensitivity -179Db GPS frequency 1575 MHz Positioning accuracy O TO 5METRES < 48s(Average value ） Cold start <... - Page 13 Note:1. to know additional features of server plz click on this link. http://www.gpstracker.net.in/cameraserversupport.html 2.for instructions file download from below link http://www.gpstracker.net.in/QuickSetup_Downloads/pv2manual.pdf 3..Download android pv2 settings configure application : http://gpstracker.net.in/download/Gps%20Settings.apk 4.Download desktop monitor application from http://www.gpstracker.net.in/camera_gps.zip 5.Download android monitor application from http://gpstracker.net.in/download/camera%20gps%20.apk...
