AES CellCOM Plus AB Installation & User Manual page 9

Step 2: Programming dial out numbers for single call button models
Programing text messages must start with a pass code string, followed by a command, followed
by data, and each command is separated in the SMS by #.
To begin, program the unit to dial numbers when the call button is pressed. This module will dial
up to 4 telephone numbers in sequence, for each push button.
9999#111telephonenumber#
Pass code
Function code
(add number)
Button number
(1-10)
TIP...
111 = Telephone number 1.
112 = Telephone number 2.
113 = Telephone number 3.
The phone image shows an example of a number being
stored and the reply sent by the unit to confirm OK.
Up to 4 numbers can be sent in a single SMS. The pass
code only needs entered at the beginning of each message,
and then each new command string is separated by #.
E.g. 9999#111telephonenumber1#112telephonenumber2#113telephonenumber3#
Step2: Programming dial out numbers for multi button versions
6
5
7
4
8 3
9
2
10
1
Please note the position of the buttons on the above panel options. For example, if you have a 2
button panel, you will be programming dial out numbers for buttons 3 and 8. For a 4 button panel,
the corresponding button locations are 2,3,8 and 9.
To program various button locations, change the button number digit to the button number as
shown.
P a g e | 9
Data
Telephone number
position 1-4
7
4
8 3
9
2
10 1
7 4
8
8 3
9 9
2
9999#1110
987654321
#
11098765
4321 OK
8
3
2
3
