Basic Keypad Programming; Full Keypad Programming - AES CellCOM Plus AB Installation & User Manual

Quick start guide
1) Enter programming mode (amber LED should be ON)
0 0 0 0
2) Enter a new user code...
1 0 2 0 0
3) Exit programming mode
* *
4) Enter the new user code to check the relay clicks.
Enter programming mode..
0 0 0 0
Exit programming mode..
* *
Enter a new ENGINEERS code...
Go into programming mode firstly then enter the following sequence...
0 1 ?
Location 4-8 digit code
Enter or delete new user codes
There are 3 groups of user codes. Group 10 for relay 1, group 20 for relay 2, and group 30 for
relay 3. The programming sequence is shown below...
1 0 2
10= relay 1 codes
2= add code
(1000 available)
5= delete code
20= relay 2 codes
(100 available)
30= relay 3 codes
(100 available)
P a g e | 13

Basic Keypad Programming

* *
0 ? ? ?

Full Keypad programming

The unit is now in programming mode. Amber LED on the
* *
keypad should remain permanently on. 0000 is the default
programming passcode.
The unit should exit programming mode and the amber LED
should start flashing again.
? ? ?
Validate
0 0 0
Memory locations
000-999 for relay 1
001-100 for relay 2
001-100 for relay 3
? #
#
Replace ???? with your new ENGINEERS
code. NOTE: Engineers code must be same
length as user codes.
? ? ? ?
Pin code 4-8 digits
Tip: The engineer code
must be the same length as
user codes. So if using a 6
digit engineers code, then
user codes must also be 6
digits long etc.
#
Validate
