Vega VEGAPULS 62 Quick Setup Manual
Radar sensor for continuous level measurement of liquids
Hide thumbs
Also See for VEGAPULS 62:
- Operating instructions manual (104 pages) ,
- Quick setup manual (24 pages) ,
- Safety instruction (16 pages)
Subscribe to Our Youtube Channel
Related Manuals for Vega VEGAPULS 62
Summary of Contents for Vega VEGAPULS 62
-
Page 1: Quick Setup Guide
Quick setup guide Radar sensor for continuous level measurement of liquids VEGAPULS 62 4 … 20 mA/HART - four-wire Approval according to LPR radio standard Document ID: 47121... -
Page 2: Table Of Contents
You can find supplementary information in the corresponding, more detailed Operating Instructions Manual as well as the Safety Manual that comes with instruments with SIL qualification. These manuals are available on the supplied DVD or in the download area of "www.vega. com". Operating instructions VEGAPULS 62 - 4 … 20 mA/HART - four- wire - Approval according to LPR radio standard; Document-ID... -
Page 3: For Your Safety
During work on and with the device the required personal protective equipment must always be worn. Appropriate use VEGAPULS 62 is a sensor for continuous level measurement. You can find detailed information about the area of application in chapter "Product description". Operational reliability is ensured only if the instrument is properly used according to the specifications in the operating instructions manual as well as possible supplementary instructions. -
Page 4: Ce Conformity
Hungary implementing this radio standard at a later date. For operation outside of closed vessels, the following conditions must be fulfilled: • The installation must be carried out by trained qualified personnel • The instrument must be stationary mounted and the antenna directed vertically downward VEGAPULS 62 • 4 … 20 mA/HART - four-wire... -
Page 5: Radio License For Usa/Canada
That is why we have introduced an environment management system with the goal of continuously improving company environmental pro- tection. The environment management system is certified according to DIN EN ISO 14001. Please help us fulfill this obligation by observing the environmental instructions in this manual: • Chapter "Packaging, transport and storage" • Chapter "Disposal" VEGAPULS 62 • 4 … 20 mA/HART - four-wire... -
Page 6: Product Description
Go to www.vega.com "VEGA Tools" and "Instrument search". Enter the serial number. Alternatively, you can access the data via your smartphone: • Download the smartphone app "VEGA Tools" from the "Apple App Store" or the "Google Play Store" • Scan the Data Matrix code on the type label of the instrument or •... -
Page 7: Mounting
A secure hold of the antenna is only ensured with the untwist guard. The untwist guards inserted on site must hence be used again. Depending on temperature range and antenna material, these are VEGAPULS 62 • 4 … 20 mA/HART - four-wire... - Page 8 On the version with rinsing air connection, make sure that the holes in the antenna and in the process fitting coincide. This ensures a suf- ficient air flow (the air is led through the holes to the feed system. A rinsing of the whole parabolic antenna is not intended). Fig. 3: Dismounting, parabolic antenna Connection piece Compression nut Counter nut Parabolic antenna VEGAPULS 62 • 4 … 20 mA/HART - four-wire...
-
Page 9: Mounting Instructions
> 200 mm (7.87") Fig. 4: Distance of the antenna to the vessel wall/vessel ceiling 2. Note min. socket diameter depending on the socket length For further information see chapter "Mounting". VEGAPULS 62 • 4 … 20 mA/HART - four-wire... -
Page 10: Connecting To Power Supply
5. Insert the wire ends into the terminals according to the wiring plan Information: Solid cores as well as flexible cores with wire end sleeves are insert- ed directly into the terminal openings. In case of flexible cores without end sleeves, press the terminal from above with a small screwdriver, the terminal opening is then free. When the screwdriver is released, the terminal closes again. VEGAPULS 62 • 4 … 20 mA/HART - four-wire... -
Page 11: Wiring Plan, Double Chamber Housing
Voltage supply Voltage supply 4 … 20 mA output (active) 4 … 20 mA output (passive) Mass - output Function ground when in- stalling according to CSA (Canadian Standards Asso- ciation) VEGAPULS 62 • 4 … 20 mA/HART - four-wire... - Page 12 Voltage supply Voltage supply 4 … 20 mA output (active) 4 … 20 mA output (passive) Mass - output Function ground when in- stalling according to CSA (Canadian Standards Asso- ciation) VEGAPULS 62 • 4 … 20 mA/HART - four-wire...
-
Page 13: Set Up With The Display And Adjustment Module
Parameter adjustment Set parameters 1. Go to the menu "Setup" via the display and adjustment module. 2. In the menu item "Medium"you select the medium of your applica- tion, for example "Aqueous solution". VEGAPULS 62 • 4 … 20 mA/HART - four-wire... - Page 14 Diagnostics - Echo curve The function "Echo curve memory" makes it possible to save the echo memory curve at the time of setup. This is generally recommended, and it is VEGAPULS 62 • 4 … 20 mA/HART - four-wire...
- Page 15 Proceed as follows: 1. Select with [->] the menu item "False signal suppression" and confirm with [OK]. 2. Confirm again with [OK]. 3. Confirm again with [OK]. 4. Confirm again with [OK] and enter the actual distance from the sensor to the product surface. VEGAPULS 62 • 4 … 20 mA/HART - four-wire...
- Page 16 Vessel form Vessel top Dished form Vessel bottom Dished form Vessel height/ 35 m Measuring range Max. adjustment 0,000 m(d) 100.00 % Min. adjustment 35 m 0.00 % Damping Integration time 0.0 s VEGAPULS 62 • 4 … 20 mA/HART - four-wire...
- Page 17 Menu item Default setting Instrument units Distance in m Temperature in °C False signal suppres- sion Linearization Linear Date/Time Actual date/Actual time Reset HART mode Address 0 Copy instrument set- tings VEGAPULS 62 • 4 … 20 mA/HART - four-wire...
- Page 18 5 Set up with the display and adjustment module Menu - Info Menu item Parameter VEGAPULS 6. Device name Instrument version Hardware and software version Date of manufacture Date Instrument features Order-specific characteristics VEGAPULS 62 • 4 … 20 mA/HART - four-wire...
-
Page 19: Supplement
0.2 … 1.5 mm² (AWG 24 … 16) Voltage supply Operating voltage Ʋ Version for low voltage 9.6 … 48 V DC, 20 … 42 V AC, 50/60 Hz Ʋ Version for mains voltage 90 … 253 V AC, 50/60 Hz Reverse voltage protection Integrated Max. power consumption 4 VA; 2.1 W VEGAPULS 62 • 4 … 20 mA/HART - four-wire... - Page 20 Subject to change without prior notice © VEGA Grieshaber KG, Schiltach/Germany 2016 VEGA Grieshaber KG Phone +49 7836 50-0 Am Hohenstein 113...
