Vega VEGAPULS 62 Quick Setup Manual
Radar sensor for continuous level measurement of liquids
Hide thumbs
Also See for VEGAPULS 62:
- Operating instructions manual (104 pages) ,
- Quick setup manual (24 pages) ,
- Safety instruction (16 pages)
Subscribe to Our Youtube Channel
Related Manuals for Vega VEGAPULS 62
Summary of Contents for Vega VEGAPULS 62
- Page 1 Quick setup guide Radar sensor for continuous level measurement of liquids VEGAPULS 62 Modbus and Levelmaster protocol Document ID: 47114...
-
Page 2: Table Of Contents
Operating Instructions Manual as well as the Safety Manual that comes with instruments with SIL qualification. These manuals are available on our homepage. Operating instructions VEGAPULS 62 - Modbus and Levelmas- ter protocol: Document-ID 41362 Editing status of the quick setup guide: 2021-06-10 VEGAPULS 62 • Modbus and Levelmaster protocol... -
Page 3: For Your Safety
All operations described in this documentation must be carried out only by trained, qualified personnel authorised by the plant operator. During work on and with the device, the required personal protective equipment must always be worn. Appropriate use VEGAPULS 62 is a sensor for continuous level measurement. You can find detailed information about the area of application in chapter " Product description". Operational reliability is ensured only if the instrument is properly used according to the specifications in the operating instructions manual as well as possible supplementary instructions. -
Page 4: Eu Conformity
English language. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: • This device may not cause interference, and • This device must accept any interference, including interference that may cause undesired operation of the device VEGAPULS 62 • Modbus and Levelmaster protocol... -
Page 5: Environmental Instructions
That is why we have introduced an environment management system with the goal of continuously improving company environmental pro- tection. The environment management system is certified according to DIN EN ISO 14001. Please help us fulfil this obligation by observing the environmental instructions in this manual: • Chapter " Packaging, transport and storage" • Chapter " Disposal" VEGAPULS 62 • Modbus and Levelmaster protocol... -
Page 6: Product Description
• Test certificate (PDF) - optional Move to " www.vega.com" and enter in the search field the serial number of your instrument. Alternatively, you can access the data via your smartphone: • Download the VEGA Tools app from the " Apple App Store" or the " Google Play Store" • Scan the DataMatrix code on the type label of the instrument or • Enter the serial number manually in the app... -
Page 7: Mounting
Screw locking device Hexagon socket screws Antenna Caution: A secure hold of the antenna is only ensured with the untwist guard. The untwist guards inserted on site must hence be used again. Depending on temperature range and antenna material, these are VEGAPULS 62 • Modbus and Levelmaster protocol... - Page 8 10. Fasten counter nut (3) with a wrench (width across flats 36), max. torque see chapter " Technical data" Note: On the version with rinsing air connection, make sure that the holes in the antenna and in the process fitting coincide. This ensures a suf- ficient air flow (the air is led through the holes to the feed system. A rinsing of the whole parabolic antenna is not intended). Fig. 3: Dismounting, parabolic antenna Connection piece Compression nut Counter nut Parabolic antenna VEGAPULS 62 • Modbus and Levelmaster protocol...
-
Page 9: Mounting Preparations - Parabolic Antenna
10. Fasten counter nut (3) with a wrench (width across flats 36), max. torque see chapter " Technical data" Note: On the version with rinsing air connection, make sure that the holes in the antenna and in the process fitting coincide. This ensures a suf- ficient air flow (the air is led through the holes to the feed system. A rinsing of the whole parabolic antenna is not intended). Fig. 4: Dismounting, parabolic antenna Connection piece Compression nut Counter nut Parabolic antenna VEGAPULS 62 • Modbus and Levelmaster protocol... -
Page 10: Mounting Instructions
> 10 mm into the vessel > 200 mm (7.87") Fig. 5: Distance of the antenna to the vessel wall/vessel ceiling 2. Note min. socket diameter depending on the socket length For further information see chapter " Mounting". VEGAPULS 62 • Modbus and Levelmaster protocol... -
Page 11: Connecting To Power Supply And Bus System
4. Insert the cable into the sensor through the cable entry Fig. 6: Connection steps 5 and 6 5. Insert the wire ends into the terminals according to the wiring plan Information: Solid cores as well as flexible cores with wire end sleeves are insert- ed directly into the terminal openings. In case of flexible cores without end sleeves, press the terminal from above with a small screwdriver, the terminal opening is then free. When the screwdriver is released, the terminal closes again. VEGAPULS 62 • Modbus and Levelmaster protocol... -
Page 12: Wiring Plan
(sensor electronics) Connection compartment Electronics compartment Electronics compartment 4...20mA Fig. 8: Electronics compartment - double chamber housing Internal connection to the connection compartment For display and adjustment module or interface adapter VEGAPULS 62 • Modbus and Levelmaster protocol... - Page 13 Fig. 9: Connection compartment USB interface 2 Slide switch for integrated termination resistor (120 Ω) Modbus signal Voltage supply Terminal Function Polarity Voltage supply Voltage supply Modbus signal D0 Modbus signal D1 Function ground when installing ac- cording to CSA (Canadian Standards Association) VEGAPULS 62 • Modbus and Levelmaster protocol...
-
Page 14: Set Up The Sensor With The Display And Adjustment Module
Parameter adjustment Set parameters 1. Go to the menu " Setup" via the display and adjustment module. 2. In the menu item " Medium"you select the medium of your ap- plication, for example " Aqueous solution". VEGAPULS 62 • Modbus and Levelmaster protocol... - Page 15 Min. level = max. measuring distance Max. level = min. measuring distance Reference plane For this adjustment, the distance is entered when the vessel is full and nearly empty. If these values are not known, an adjustment with other distances, for example, 10 % and 90 % is also possible. Starting point for these distance specifications is always the seal surface of the thread or flange. The function " Echo curve memory" makes it possible to save the Diagnostics - Echo curve memory echo curve at the time of setup. This is generally recommended, and VEGAPULS 62 • Modbus and Levelmaster protocol...
- Page 16 3. All interfering signals in this range are detected by the sensor and stored after being confirmed with [OK]. Note: Check the distance to the medium surface, because if an incorrect (too large) value is entered, the existing level will be saved as a false signal. The level would then no longer be detectable in this area. VEGAPULS 62 • Modbus and Levelmaster protocol...
-
Page 17: Menu Overview
Current output Output character- 4 … 20 mA mode istics Failure mode ≤ 3.6 mA Current output - Min. current 3.8 mA Min./Max. Max. current 20.5 mA Lock adjustment Released Display Menu item Default setting Language Order-specific VEGAPULS 62 • Modbus and Levelmaster protocol... - Page 18 Linear Date/Time Actual date/Actual time Reset HART mode Address 0 Copy instrument settings - Info Menu item Parameter Device name VEGAPULS 6. Instrument version Hardware and software version Date of manufacture Date Instrument features Order-specific characteristics VEGAPULS 62 • Modbus and Levelmaster protocol...
-
Page 19: Set Up With Smartphone/Tablet, Pc/Notebook Via Bluetooth
The default setting of the sensor PIN is " 0000". First of all you have to change the sensor PIN in the adjustment menu of the sensor, e.g. to " 1111": 1. In the adjustment menu, go to " Additional adjustments", " PIN" Note: The menu item " PIN" is only displayed if in the menu " Setup", " Lock/ Unlock adjustment" the adjustment is released. 2. Change sensor PIN VEGAPULS 62 • Modbus and Levelmaster protocol... -
Page 20: Connecting
Start the adjustment app and select the function "Setup". The smart- phone/tablet searches automatically for Bluetooth-capable instru- ments in the area. PC/Notebook Start PACTware and the VEGA project assistant. Select the device search via Bluetooth and start the search function. The device auto- matically searches for Bluetooth-capable devices in the vicinity. Connecting The message "... - Page 21 6 Set up with smartphone/tablet, PC/notebook via Bluetooth App view Fig. 13: Example of an app view - Setup sensor adjustment VEGAPULS 62 • Modbus and Levelmaster protocol...
-
Page 22: Supplement
0.2 … 2.5 mm² (AWG 24 … 14) Ʋ Stranded wire with end sleeve 0.2 … 1.5 mm² (AWG 24 … 16) Voltage supply Operating voltage 8 … 30 V DC Max. power consumption 520 mW Reverse voltage protection Integrated VEGAPULS 62 • Modbus and Levelmaster protocol... - Page 23 Notes VEGAPULS 62 • Modbus and Levelmaster protocol...
- Page 24 Subject to change without prior notice © VEGA Grieshaber KG, Schiltach/Germany 2021 VEGA Grieshaber KG Am Hohenstein 113 Phone +49 7836 50-0 77761 Schiltach E-mail: info.de@vega.com...
