Quick setup guide
Radar sensor for continuous level
measurement of liquids
VEGAPULS 62
HART and accumulator pack
Document ID: 47110

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VEGAPULS 62 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Vega VEGAPULS 62

  • Page 1 Quick setup guide Radar sensor for continuous level measurement of liquids VEGAPULS 62 HART and accumulator pack Document ID: 47110...
  • Page 2: Table Of Contents

    Operating Instructions Manual as well as the Safety Manual that comes with instruments with SIL qualification. These manuals are available in the download area of "www.vega.com". Operating instructions VEGAPULS 62 - HART and power pack: Document-ID 40793 Editing status of the quick setup guide: 2018-07-05 VEGAPULS 62 • HART and accumulator pack...
  • Page 3: For Your Safety

    During work on and with the device the required personal protective equipment must always be worn. Appropriate use The VEGAPULS 62 is a sensor for continuous level measurement. Due to the integrated accumulator the instrument is particularly suitable as a portable measuring system or test sensor for special applications.
  • Page 4: Eu Conformity

    For operation inside of closed vessels, points a to f in annex E of EN 302372 must be fulfilled. Radio license for USA This approval is only valid for USA. Hence the following text is only available in the English language. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: • This device may not cause interference, and VEGAPULS 62 • HART and accumulator pack...
  • Page 5: Environmental Instructions

    That is why we have introduced an environment management system with the goal of continuously improving company environmental pro- tection. The environment management system is certified according to DIN EN ISO 14001. Please help us fulfil this obligation by observing the environmental instructions in this manual: • Chapter "Packaging, transport and storage" • Chapter "Disposal" VEGAPULS 62 • HART and accumulator pack...
  • Page 6: Product Description

    • Test certificate (PDF) - optional Go to "www.vega.com", "Instrument search (serial number)". Enter the serial number. Alternatively, you can access the data via your smartphone: • Download the VEGA Tools app from the "Apple App Store" or the "Google Play Store" • Scan the Data Matrix code on the type label of the instrument or • Enter the serial number manually in the app...
  • Page 7 2 Product description Scope of this operating This operating instructions manual applies to the following instrument instructions manual versions: • Hardware from 2.1.0 • Software from 4.5.1 VEGAPULS 62 • HART and accumulator pack...
  • Page 8: Mounting

    Screw locking device Hexagon socket screws Antenna Caution: A secure hold of the antenna is only ensured with the untwist guard. The untwist guards inserted on site must hence be used again. Depending on temperature range and antenna material, these are VEGAPULS 62 • HART and accumulator pack...
  • Page 9 10. Fasten counter nut (3) with a wrench (width across flats 36), max. torque see chapter "Technical data" Note: On the version with rinsing air connection, make sure that the holes in the antenna and in the process fitting coincide. This ensures a suf- ficient air flow (the air is led through the holes to the feed system. A rinsing of the whole parabolic antenna is not intended). Fig. 3: Dismounting, parabolic antenna Connection piece Compression nut Counter nut Parabolic antenna VEGAPULS 62 • HART and accumulator pack...
  • Page 10: Mounting Preparations - Parabolic Antenna

    10. Fasten counter nut (3) with a wrench (width across flats 36), max. torque see chapter "Technical data" Note: On the version with rinsing air connection, make sure that the holes in the antenna and in the process fitting coincide. This ensures a suf- ficient air flow (the air is led through the holes to the feed system. A rinsing of the whole parabolic antenna is not intended). Fig. 4: Dismounting, parabolic antenna Connection piece Compression nut Counter nut Parabolic antenna VEGAPULS 62 • HART and accumulator pack...
  • Page 11: Mounting Instructions

    > 10 mm into the vessel > 200 mm (7.87") Fig. 5: Distance of the antenna to the vessel wall/vessel ceiling 2. Note min. socket diameter depending on the socket length For further information see chapter "Mounting". VEGAPULS 62 • HART and accumulator pack...
  • Page 12: Connecting To Power Supply

    9 = sensor is switched on every 24 hours for 3 minutes The green LED characterizes the charging process: • LED flashes = Accumulator is charging • LED lights = accumulator is full, battery charger should be unplugged (accumulator life time) After pressing the key or changing the mode the yellow LED shows the accumulator status for approximately 10 s as follows: • LED lights = accumulator is full • LED flashes = accumulator should be charged VEGAPULS 62 • HART and accumulator pack...
  • Page 13 4 Connecting to power supply • LED off = accumulator is empty VEGAPULS 62 • HART and accumulator pack...
  • Page 14: Set Up With The Display And Adjustment Module

    3. Screw housing lid with inspection window tightly back on Disassembly is carried out in reverse order. The display and adjustment module is powered by the sensor, an ad- ditional connection is not necessary. Fig. 7: Installing the display and adjustment module in the electronics compart- ment of the single chamber housing VEGAPULS 62 • HART and accumulator pack...
  • Page 15: Parameter Adjustment

    2. In the menu item "Medium"you select the medium of your applica- tion, for example "Aqueous solution". 3. Select in the menu item "Application" the vessel, the application and the vessel form, for example, storage tank. 4. Carry out the adjustment in the menu items "Min. adjustment" and "Max. adjustment". VEGAPULS 62 • HART and accumulator pack...
  • Page 16 The function "Echo curve memory" makes it possible to save the memory echo curve at the time of setup. This is generally recommended, and it is absolutely necessary if you want to use the Asset Management functions. If possible, the curve should be saved with a low level in the vessel. With the adjustment software PACTware and a PC, a high resolution echo curve can be displayed and used to recognize signal changes during operation. In addition, the echo curve of setup can be dis- played in the echo curve window and compared with the current echo curve. VEGAPULS 62 • HART and accumulator pack...
  • Page 17 This is useful if the saved false signal suppression no longer matches the metrological conditions in the vessel. Extend: is used to extend an already created false signal suppres- sion. This is useful if a false signal suppression was carried out with VEGAPULS 62 • HART and accumulator pack...
  • Page 18: Menu Overview

    Lock adjustment Released Display Menu item Default setting Language Order-specific Displayed value Filling height in % Backlight Switched on Diagnostics Menu item Parameter Default setting Sensor status Peak value Distance Electronics tem- Temperature perature Measurement re- liability VEGAPULS 62 • HART and accumulator pack...
  • Page 19 Actual date/Actual time Reset HART mode Address 0 Copy instrument set- tings Info Menu item Parameter VEGAPULS 6. Device name Instrument version Hardware and software version Date of manufacture Date Instrument features Order-specific characteristics VEGAPULS 62 • HART and accumulator pack...
  • Page 20: Supplement

    0 … +45° C (+32 … +167 °F) Ʋ Accumulator operation -20 … +60° C (-4 … +140 °F) Temperature derating accumulator capacity Ʋ +25° C (+77 °F) 100 % Ʋ -10° C (+14 °F) 50 % VEGAPULS 62 • HART and accumulator pack...
  • Page 21 Notes VEGAPULS 62 • HART and accumulator pack...
  • Page 22 Notes VEGAPULS 62 • HART and accumulator pack...
  • Page 23 Notes VEGAPULS 62 • HART and accumulator pack...
  • Page 24: Information

    Subject to change without prior notice © VEGA Grieshaber KG, Schiltach/Germany 2018 VEGA Grieshaber KG Phone +49 7836 50-0 Am Hohenstein 113...
