Item Symbol
1
2
3
4
5
6
7
8
9
10
11
099-005425-EW501
14.07.2016
Machine description – quick overview
Description 0
Slide latch, lock for the protective cap
Securing elements for shielding gas cylinder (strap/chain)
Protective cap
Cover for the wire feed mechanism and other operating elements.
Depending on the machine series, additional stickers with information on the
replacement parts and JOB lists will be located on the inside.
Wire spool inspection window
Check wire supply
Cooling air outlet
Bracket for shielding gas cylinder
Wheels, fixed castors
D-sub connection socket, 9-pole
With this machine series for maintenance purposes only (specialist staff)
Connecting nipple G¼, shielding gas connection
Key button, Automatic cutout
Wire feed motor supply voltage fuse
(press to reset a triggered fuse)
Mains connection cable > see 5.1.8 chapter
Rear view
