The icons located on the Bottom Bar are very important in completing the installation process. These icons are described in Table 4.
Table 4: Main Screen Bottom Bar Icons
Icon Description
System Status - Press this icon to access the System Status, Sensor Status, and Events Status screens.
System Status Attention - This indicates that a recent system status change has occurred or attention is required. Press the icon to
view the status.
Settings and Configuration - Press this icon to access the General settings, Display, Sound, Date & Time, Applications, and
Configuration screens.
Applications - Press this icon to gain quick access to the applications in the
Disarmed - Pressing this icon will begin the sequence of ARMING the system.
Note: When disarmed, only 24-hour sensors (smoke, carbon monoxide detectors, etc.) remain active.
System Programming and Configuration
The AdvisorOne panel provides the main processing unit for all system functions. The programming of system options and features is
menu-driven. Access is managed by codes. Interlogix recommends the following standard programming sequence: learn sensors, add
users, configure communications, configure system options, and configure applications. Table 5 below describes the programming and
access code options.
Notes:
•
Access and System Programming & Configuration options depend on what code is entered.
•
When prompted for an access code, the panel will automatically exit the Access Code screen after one minute of inactivity if no
access code has been entered.
•
After an access code has been entered to access the Configuration & Programming system options, the panel will automatically
return to the main screen after a period of inactivity. This period of inactivity is programmable. The default setting is ten minutes.
Table 5: Access Codes
The system supports 250 access codes.
Function Default Description
Dealer Code 4322 The default privilege level is the same as the installer code (see below). Use this code only if required when Dealer Lock has
been enabled and access to the dealer-protected programming options is required.
Installer Code 4321 Use this code to configure all programming features of the panel, except those that are dealer protected when Dealer Lock
has been enabled. These options can be accessed from the Configuration & Programming menu: Devices, Users,
Communications, System Options, Testing, Administration, etc. Dealer and installer codes should be changed.
Master Code 1234 Use the master code to arm/disarm the system and to enter user programming and bypass sensors.
User Codes Blank Use the user code to arm/disarm the system.
Duress Code Blank Use the duress code to arm/disarm the system. Use of the duress code will cause a silent alarm.
Entering the Settings and Configuration Screen
1. Press the Settings icon
2. Press CONFIGURATION to enter programming.
3. Enter the installer code or dealer code.
Configuring a Hardwired or Wireless Sensor
When configuring a hardwired or wireless sensor, refer to the specific sensors installation instructions for complete operation and
testing details.
1. From the Configuration & Programming screen, press DEVICES.
2. From the Devices screen, press EDIT next to Sensors.
3. From the Sensors screen, press TX ID or LEARN RF for wireless sensors or press Add HW for hardwired sensors.
6 / 18
on the lower left of the main screen.
system.
