Interlogix AdvisorOne Panel Quick Installation Manual page 4

Wiring an Optional Telephone Connection for Full-Line Seizure and RJ31X Jack
Note: Not all AdvisorOne panels have a PSTN module. Panels that contain a PSTN module can be identified by the PSTN cable (N in
Figure 4). Skip this section if the PSTN module is not present.
1. Run a 4-conductor cable from the premises Telco block to the RJ31X jack.
2. Connect the 4-conductor cable to the RJ31X.
3. Disconnect the green (tip) and red (ring) premises phone jack wires from the premises Telco block.
4. Splice the green (tip) wire to the black wire of the 4-conductor cable using a weatherproof wire connector.
5. Splice the red (ring) wire to the white or yellow wire of the 4-conductor cable using a weatherproof wire connector.
6. Connect the 4-conductor cable green wire to the Telco block TIP (+) post.
7. Connect the 4-conductor cable red wire to the Telco block RING (-) post.
8. Connect one end of the PSTN cable to the RJ31X and the other end to the PSTN connector (see M, wiring diagram in Figure 4).
Completing the Installation
1. Ensure that the power supply is not plugged in to the outlet.
2. Connect the spaded ends of the power supply wire to the terminals on the power supply.
Note: The dashed line/writing side of the wire indicates positive. Ensure consistency by wiring + to + and - to -. Unlike
previous panels, this is a DC power supply. Polarity must be observed or damage may occur.
3. Connect the other ends of the power supply wire to the 12V IN + and - terminals on the panel (Figure 4).
4. Secure the Terminal Cover (F in Figure 3) onto the panel. Make sure the tabs (E in Figure 3) are engaged.
Note: All three internal covers must be secured for proper operation.
5. Place the battery (L in Figure 3) in the battery compartment with the wires facing outward (J in Figure 3). Secure the battery in
position with the battery strap (K in Figure 3).
6. Supply power to the panel as noted in Table 2.
WARNING:
•
Use caution when installing or removing the power supply to an outlet with a metal cover.
•
Make sure the correct polarity is observed when connecting the wires from the panel to the power supply.
Table 2: Powering the Panel
Installation Action
US 1.
2.
Canada Plug the power supply into the outlet. Do not use securement tab and screw.
All Other Installations Follow regional requirements.
Note: To reduce the potential for a low battery indication, connect the battery within 15 seconds of providing AC power.
7. Connect the battery (L in Figure 3) to the battery connector on the panel (I in Figure 3).
Note that the cable connector locks into place.
8. Close the panel, making sure all tabs are engaged.
9. Install the screw securing the panel chassis (B in Figure 1).
10. Remove the film cover from the touch screen.
4 / 18
On the new power supply, knock out the screw hole in the securement tab.
Plug the power supply into the outlet and secure with the supplied screw.
AdvisorOne Panel Quick Installation Guide
