AC power failure report set to on
•
CPU low battery report set to on
•
Fail to communicate set to on
•
Entry delay plus the abort delay not to exceed 60 seconds
Automatic communication test (located in Advanced Programming tab)—Communication, Reporting, Destination, Edit—set to 7 days
for all reporting paths. Network addressing of devices shall not make use of public domain servers.
UL Canada Listed Installations
This section describes the requirements for cUL (UL Canada) listed installations. All cUL listed installations must follow the Canadian
Electrical Code and be installed per CAN/ULC-S540 Standard for the Installation of Residential Fire Warning Systems.
Canadian standards CSA certified accessories:
•
Standard Class 2, 12 VDC, 2A power supply (UTC Fire & Security P/N AV-PS12V).
•
Residential burglary alarm system unit (ORD-C1023-1974): Basic system as described for UL 1023 listed installations, plus Siren
timeout set to 5 minutes or more.
•
Residential fire warning system control unit (ULC-S545-M89): Basic system as described for UL 985 listed installations, plus Siren
timeout set to 5 minutes or more.
Compatible Receivers
Operation has been verified with industry standard SIA Contact ID format. It is the installer's responsibility to verify compatibility
between the panel and the UL listed receiver used during installation. The installer shall verify the compatibility of the receiver and the
system on a yearly basis.
UL has initially verified compatibility with the OH NetRec receiver.
Recent Closing
Enabled (2-minute window).
Sensor Tripping Instructions
Sensor
Door/window
Carbon monoxide alarm
Glass break
Motion sensor
Smoke
Key fob
Remote touchpad
SIA System Requirements
Verified to ANSI/SIA CP-01-2010 by UL, basic system, plus if multiple annunciations are required, use hardwired annunciator 13-046.
To add the secondary annunciator/siren:
1. Connect the positive wire from the siren to either the OUT1 terminal or OUT 2 terminal on the panel.
2. Connect the ground wire from the siren to a ground terminal on the panel.
To program the warning siren:
1. Press the Settings icon on the lower left of the main screen.
2. Press CONFIGURATION to enter programming.
16 / 18
Action
Open the secured door or window.
Press and hold the Test/Hush button (approximately 5 seconds) until the unit beeps two times,
and then release the button.
Test with an appropriate glass break sensor tester.
Avoid the motion sensor field of view for 5 minutes and then enter its view.
Press and hold the test button until the system sounds transmission beeps.
Press and hold the Lock and Unlock buttons simultaneously for 3 seconds.
Press and hold the two Emergency buttons simultaneously for 3 seconds.
