Wiring and Connections
Note: Follow standard wiring practices.
The AdvisorOne panel has 16 screw terminals (see M, wiring diagram in Figure 4) and WAN, LAN, and PSTN connectors. The WAN
port is used to connect to IP Ethernet. The LAN port is used to learn or connect IP devices.
Wiring Requirements
The total system wire length allowed can vary depending on devices powered by the panel, the wire length between devices and the
panel, and the combined wire length of all devices. For maximum wire length allowed between compatible devices and the panel, see
Table1.
Table 1: Device Current Draw and Wiring Requirements
Device
Hardwired Interior Siren (13-949)
Piezo Dynamic Exterior Siren (13-950)
12 VDC 2A Power Supply
Telephone (RJ-31X)
Wired Input
Wired Output
Wiring External Contacts
The AdvisorOne panel has five inputs labeled IN1 - IN5 (see M, wiring diagram in Figure 4) that are used for connecting devices to the
panel. IN1 - IN3 are dedicated inputs. IN4/OUT1 and IN5/OUT2 can be configured as either inputs or outputs, depending on system
programming configuration. Advisor One does not supply power for sensors. Sensor Zones must be of the normally open or closed
contact type or wireless.
To add a device:
1. Connect one wire from the contact to the desired input terminal.
2. Connect the other wire to one of the two ground terminals.
3. Install the provided end-of-line (EOL) resistor at the last device.
Note: The value of the resistor used in the circuit must match the value selected in programming.
Connecting the Relay
The AdvisorOne panel provides two terminals to support a Form A (normally open) dry relay.
To add a connection to the relay:
1. Connect one wire from the N/O contact terminal to the positive voltage side of the device.
2. Connect the other wire from the COM terminal to the other side of the device.
Note: Relay may be used for inductive (.9pF or greater) and resistive loads.
Wiring an Optional Siren
The panel has two inputs labeled + and GND for interior/exterior siren operation (status and alarm sounds).
To add a siren:
1. Connect the positive wire from the siren to the Siren + terminal on the panel.
2. Connect the ground wire to the Siren GND (ground) terminal on the panel.
AdvisorOne Panel Quick Installation Guide
Device Current Draw
Standby 0 mA
Alarm 85 mA
Standby 0 mA
Alarm 150 mA
50 mA
Wire Requirements
22 AWG: 750 ft. maximum
18 AWG: 1,500 ft. maximum
22 AWG: 750 ft. maximum
18 AWG: 1,500 ft. maximum
22 AWG: 8 ft. maximum
18 AWG: 25 ft. maximum
4-conductor 26 AWG or larger
22 AWG: stranded: 200 ft. maximum
18 AWG: stranded: 500 ft. maximum
18 AWG: stranded
