- Page 1 Installation Guide AL602ITI UL Listed ADA Fire Alarm Signaling Circuit Power Supply Rev. 091701...
- Page 2 2 outputs. The AL602ITI in non-alarm condition provides independent loop supervision for Class A and/or Class B FACP NAC circuits. In the event of a loop trouble the FACP will be notified via the AL602ITI’s steered input (input 1 or input 2).
-
Page 3: General Information
6.5 Amps/5 Minutes Installation Instructions: The AL602ITI should be installed in accordance with article 760 of The National Electrical Code or NFPA 72 as well as all applicable Local Codes. 1. Mount the AL602ITI in a desired location. It is recommended to first review the following tables for screw terminals, switch selection and LED status indications. - Page 4 Honeywell. Note: The AL602ITI will only synchronize horns, horn strobes and strobes that contain synchronization capability. Contact signal manufacturer for more detailed info. The same synchronization mode must be selected for all outputs.
- Page 5 LED Status Indication Table: BLINKING Out 1 Normal Alarm Condition Trouble Condition Out 2 Normal Alarm Condition Trouble Condition Out 3 Normal Alarm Condition Trouble Condition Out 4 Normal Alarm Condition Trouble Condition Input 1 Normal Alarm Condition Trouble Condition Input 2 Normal Alarm Condition...
- Page 6 (horns), and is active until a fire alarm is silenced. A trouble indi- cator output in the AL602ITI actives a relay output for AC power loss, low backup battery or trouble on any of the out- put circuits.
- Page 7 Fig. 1 - Advent FACP Hookup Diagram: AC TROUBLE DELAY OPTION BAT FAIL AC FAIL...
-
Page 8: Typical Application Diagrams
(pos +) to (pos +) and (neg -) to (neg -). Both device or another NAC1 AL602ITI of the corresponding output switches must be set to follow the (Zone1) same input. Install two (2) 2.2K ohm EOL resistors in parallel... - Page 9 EOL or next signaling outputs, bridge (pos +) to (pos +) and (neg -) to (neg -). Both 2.2K device or AL602ITI of the corresponding output switches must be set to follow the Optional paralleled same input. Install two (2) 2.2K ohm EOL resistors in parallel Class B output across the last notification appliance.
- Page 10 Optional Hookup Diagram: Fig. 6 Fire Alarm OPEN = 24V SW1 CLOSED = 12V XFMR Control Panel AL601ULB (FACP) POWER SUPPLY RLY1 PTC2 Black White Lead Lead ALTRONIX CORP. BAT --- 115 VAC 50/60 Hz, 1.45 amps N.O. Reset Switch 4-wire Smoke (Connect to seperate Detector...
-
Page 11: Maintenance
Typical Application Diagram for Connecting Horn/Strobes with Independent Control of Horns and Strobes: --- AUX + OUT1 OUT3 --- DC + INPUT SELECT TEMPORAL OUT1 OUT2 OUT3 OUT4 STROBE SYNC IN > OUT SYNC INP1 INP2 OUT2 OUT4 FAULT INPUT SELECT NO "REMOTE "... -
Page 12: Enclosure Dimensions
Enclosure Dimensions: 15.5”H x 12”W x 4.5”D 12" 2.25" 3.68" 4.56" 1.22" 4.5" 1.22" 1.22" .875" 1.3" 9.97" 1" 1" 2" 2" 8" 13.25" 13.53" 3.25" 2.2" 1.25" 1" 15.5" 1.22" 2.25" 3.68" 4.56" 2266 Second Street North North St. Paul, MN 55109 800-777-2624 www.interlogixinc.com IIAL602ITI - Rev.
